olympia electronics GRL-37/90/WP/WL User manual

Aluminium, ABS/PC, PC
<24h
IP65
o
5 to 40 C
Up to 95%
3 years (1 year for the battery)
180 mins
220-240V AC/50-60Hz
12V/7Ah
6450gr.
3200lm
GRL-37/90/WP/WL
Page 1 from 5923037018_09_001
4260gr
90 mins
2x12V/7Ah
GRL-37/180/WP/WL
307 x 100 x 333 mm
13.3W/14VA
Basic Insulation
13.7V/25mA
63 mA AC
230/710mA
14.7V
1.7A/2.3A
18V
8A/250V FB, 5x20mm
Prated = 21.6W, Irated = 1.2A
10.8V
23,5V DC
o
tc = 75 C at R11
TECHNICAL CHARACTERISTICS (for LED MODULE Specifications see page 4)
OPERATION VOLTAGE
OPERATION TEMPERATURE RANGE
RELATIVE HUMIDITY
INSULATION BETWEEN SUPPLY & BATTERY CIRCUIT
EXTERNAL DIMENSIONS
CONSTRUCTION MATERIALS
TYPICAL WEIGHT
GUARANTEE
CONTROL GEAR WITH AUTOMATIC
TEST FUNCTION
MAXIMUM POWER CONSUMPTION
SUPPLY CURRENT
U-OUT
OPEN CIRCUIT VOLTAGE
BATTERIES (Pb)
CHARGING TIME
INDICATIONS - CONTROLS
BATTERY PROTECTION
MINIMUM AUTONOMOUS DURATION
DEGREES OF COVER PROTECTION
PRODUCED IN ACCORDANCE WITH
EMERGENCY ILLUMINATION
LIGHT SOURCE
POWER-CHARGE indicator, LAMP FAULT–BATT. FAULT indicator, TEST button
From overcharge and deep discharge
White power LEDs
CONTROL GEAR CHARACTERISTICS
CONTROL GEAR FUSE
CONTROL GEAR MAX. TEMPERATURE
CUTOFF VOLTAGE
MIN./MAX. DISCHARGE CURRENT
TRICKLE CHARGE VOLTAGE/CURRENT
CHARGING VOLTAGE
MIN./MAX. CHARGE CURRENT
Do NOT stare at operating light source.The luminaire should be positioned so that
prolonged staring into the luminaire at a distance closer than 1.2m is not expected.
E = 904.8 lux.
thr
o
These luminaires are used indoors (ta 40 C)
where emergency light is needed. Each luminaire
must be connected permanently to the mains
power supply.
GENERAL
The WL luminaire models have the ability to
communicate over the air with Olympia’s control
panels for wireless emergency luminaires. The
luminaires can also communicate with a PC/laptop
through a gateway (Ethernet, Wi-Fi, USB). For
more information, please refer to Wireless
Emergency Lighting guides, available on the
company’s website.
WIRELESS COMMUNICATION
Thank you for your trust in our products
Olympia Electronics - European manufacturer
TX POWER
TX/RX FREQUENCY RANGE
11dBm
868.150-868.450MHz
EN 60598-1, EN 60598-2-22, EN 55015, EN 61547, EN 61000-3-2,
EN 61000-3-3, EN 62311, ETSI EN 303 446-1 V1.1.0, ETSI EN 300 220-2 V3.1.1
SELF-TESTING NON MAINTAINED EMERGENCY LUMINAIRE WITH WIRELESS COMMUNICATION

Page 2 from 5923037018_09_001
The unit automatically tests the emergency circuit
every 15 days (if the battery and mains power are
OPERATION DESCRIPTION
When the unit is connected to the main power
supply (after connecting the battery) the indicator
LAMP FAULT – BATT. FAULT remains OFF
whereas the indicator POWER CHARGE blinks to
indicate that the batteries are charging. When the
batteries are fully charged this indicator will light
permanently. If this indicator does not light then
probably the battery has not been connected. If the
batteries are connected and the indicator does not
light then contact a qualified service technician for
assistance. The charging procedure is monitored
by a microprocessor and is based on a 3 stage
cycle thus ensuring a fast and full charge of the
battery. The charge current is supplied by a high
efficiency switch mode power supply which
ensures perfect charging even during the
fluctuations of the mains power supply.
BATTERY CUTOFF
The unit enters this state during the power supply
failure and when the battery has been fully
discharged. In this state the luminaire draws the
least power from the battery in order to prevent
deep discharge.
Is accomplished by briefly (<1 sec.) pressing the
TEST button. This permits the user to test the good
operation of the luminaire’s emergency circuit. The
unit simulates a power failure and the lamps are lit
using the batteries. This manual test does not
affect the automatic test.
DIMMING OPTION
Whe n the v oltag e is interr u pted, wi th
corresponding pressings of the button, we can
choose the illumination of 100%, 50%, 33% or
turned off, either to increase the autonomy time or
not to consume the battery power unnecessarily.
This option is canceled when the power network is
restored.
LAMP TESTING
The luminaire tests the good condition of the lamps
in emergency mode and warns the user for
probable malfunction. If a lamp is found faulty then
the LAMP FAULT indicator starts to blink. To verify
which lamp is faulty use the TEST button. If the
faulty lamp is replaced then the error is
automatically restored and the indicator is turned
OFF.
B AT T E RY C H A R G E FA I L U R E D U E T O
SHORTCUT
The recharging device will recharge the battery
normally after the short circuit is removed and the
batterie(s) are reinstalled.
MANUAL TESTING
AUTOMATIC EMERGENCY CIRCUIT TEST
1. Every test, installation or maintenance procedure
must be done only by qualified personnel.
type, by the manufacturer or by a competent
connected). During this test the lamps are turned
ON for 3 seconds using the batteries. In some
cases this function might not be acceptable (i.e in
cinema theaters) so the installer must take this into
account during the installation.
AUTOMATIC DURATION TEST
This test is conducted every 6 months by
simulating a power failure, if the battery and mains
power supply are connected. The unit lights the
lamps using the charged battery and counts the
time until the stated duration. If the lamps are ON
during the end of the test then the unit is restored to
its normal operation (lamps OFF and battery
charging). If the lamps go OFF before the end of the
test then the unit is restored to its normal operation
but the LAMP FAULT / BATT. FAULT indicator is lit
to show that there is a problem with the battery and
that the battery must be replaced. Let it be noted
that this duration test is also done during every long
power failure. If the power failure lasts for a long
time and the luminaire has entered the BATTERY
CUTOFF mode and the duration measured is not
correct then the fault indicator will light when the
power is restored.
ERASING ERRORS
Erasing errors is accomplished with a prolonged
pressing of the TEST button (>5 sec) when the unit
is connected to the mains power supply. The fault
indicated with the indicator LAMP FAULT / BATT.
FAULT will be erased. If the cause of the fault has
not been restored (i.e burned lamp) then the
indicator will light again. If the fault was caused by a
low emergency duration and you erase the error
then this will be indicated again during the next
duration test after 6 months. In this case (for
duration errors) it is vital to replace the battery
before erasing the error (the error is automatically
erased if the mains power and the battery are
disconnected).
WARNING !!!
2. The unit must be connected to the mains power
supply using a line fuse rated accordingly.
3. The replacement of the battery and the light
source must be done using parts of the same
person.
4. If the luminaire must be isolated from the mains
power supply for more than 2 months then the
batteries must be disconnected by removing the
battery connectors.
5. I s not allowed to discard batteries in to t i
common trash bins, the y m u s t b e
discarded only in battery recycling points.
Do not incinerate.

The on-board button has the two following
functions:
Button functionality:
1. Short press (<2"): a status message will
be sent to the Gateway device of the
wireless network.
2. Long press (>2"): Loads factory default
settings to the module.
Button
LD3
LD2
LD1
Antenna
Default settings:
• SID: 00000001
• RF Channel: 13 ( 869.525MHz )
This LED may blink according to the
following patterns:
3. Fast flash [2 times/s]: The device has
2. Rapid flash [5 times/s]: The device has
established direct connection to a single
Gateway device.
1. Very fast blink [5 times/s]: the module is
not initialized correctly. In this case you
have to press for more than 2 seconds the
push button, in order to reset the module
(loads default settings).
3. Moderate flash [1 second ON / 1 second
OFF]: received signal strength is acceptable
for reliable communication.
The middle LED (LD2-green) indicates the
received signal strength (RSSI) of the router
module.
The top LED (LD3-green) indicates the
network connection status.
This LED may blink according to the
following patterns:
Wireless Communication LED
indications (interior)
1. Steady ON: The device has established
direct connection to a Gateway device, and
at least one more Gateway device is
available for alternate routing
(false condition).
established connection to a Router device
and at least one more Router device is
available on the same hop level, as an
alternate route (redundant connection).
4. Moderate flash [1 second ON / 1 second
OFF]: The device has established
connection to a single Router device, and
no alternatives exist on the same hop level.
5. No light: The device is disconnected.
This LED may blink according to the
following patterns:
1. Very fast flash [5 times/s]: received signal
strength is excellent.
2. Fast flash [2 times/s]: received signal
strength is good.
4. Very slow [2 seconds ON / 2 seconds
OFF]: received signal strength is not
acceptable for reliable communication, or
no signal.
The bottom LED (LD1-red) indicates
operation status.
2. Moderate flash [2 times/s]: The module
is properly operating.
Page 3 from 5 923037018_09_001

Page 4 from 5923037018_09_001
INSTALLATION PROCEDURE (For wall mounting only)
ATTENTION!! After installing the luminaire, you are advised to briefly press (<5sec) the test button
in order to conduct a lamp test. If there is no fault indicator permanently turned on, it means that the
luminaire is working properly in emergency mode. After 24 hours of the installation, you are advised
to conduct a battery capacity test, by disconnecting the mains power supply from the luminaire. The
luminaire should operate in emergency mode, for at least the nominal duration time. The result of
the test will be available in the fault indication LEDs, after reconnecting the luminaire to the mains
power supply. If there is no error indicated, it means that the luminaire will meet its nominal duration
in case of an emergency. In case of any error, please contact the installer or the representative
seller of this product.
to the 4 sealing o-rings.
WARNING!! After the installation has finished, charge the batteries for at least 24 hours so as
to obtain the rated autonomous duration.
and tighten it all the way.
neutral.
6. Reinstall the front cover and fasten the retaining screws. (Tightening torque 1Nm). Pay attention
5. Connect the cables to the respective positions in the terminal block L for phase and N for
to ensure the tightness isolation IP65). Install the cable gland, pass the round cable through
1. Use the supplied mounting accessories to mount the device (Fig1).
2. Remove the four cover retaining screws (Fig 1).
3. Instal the battery cable connectors to the batteries taking care of the polarity, black cable (-) and
red cable (+).
4. Always use in any case round mains cable, with external diameter of 6-9mm (H05RN-F
ATTENTION!! The cable must not be deformed in any way (This requirement is important
type 2x1mm² or any other type, at least equal to it’s mechanical and electrical properties).
N
L
4
3
TEST
button
Fig. 1
POWER
CHARGE
indicator
Mounting holes
LAMP FAULT
BATT. FAULT
indicator
Cover
retaining
screws
INDICATION LED STATUS (with the mains power supply connected)
POWER / CHARGE LAMP FAULT / BATT. FAULT
Disconnected battery / not charging Normal operation mode
Charged battery Low emergency duration (replace battery)
Battery under charge Lamp fault (Check lamps and replace if needed)
Indicator ON Indicator BlinkingIndicator OFF

Page 5 from 5923037018_09_001
The light source contained in this luminaire shall only be replaced by the manufacturer, or his
agent, or a similar qualified person.
NOTE! The light source is non-user replaceable.
in the position of the old one.
and power the device.
battery.
3. Connect the new battery with the same type
(step 3 of the installation procedure) and place it
4. Follow the step 6 of the installation procedure
2. Disconnect the cables and remove the old
LABELING EXPLANATION:
X: Self contained
NOTE: LED= Light Emitting Diode
A: Including test device
B: Including remote test mode
C: Including inhibiting mode
F: Automatic test gear complying with IEC 61347-2-7 denoted EL-T
*90: 1.5 hour duration
180: 3 hour duration
(*)Non Maintained operation: The luminaire lights its illumination source, only in power supply’s failure.
0: Non Maintained (*)
Battery replacement
It can be done only by a competent person and after the mains interruption
1. Follow the step 2 of the installation procedure.
Olympia Electronics S.A.
68 °C max.
17.5-20.5V
14W
1005183
Manufacturer
Model Number
Voltage Range
Temperature (tc)
Nominal Power
Supply Current 600 mA on each lamp
Max Working Voltage for Proper Insulation 700 V
LV Supply - Control Conductors Insulation Type Basic Insulation
Connections Cable connection between main pcb and led module
LED Module Type
LED MODULE CHARACTERISTICS
Built-in
WARRANTY
Olympia Electronics guarantees the quality, condition and operation of the goods. The period of
warranty is specified in the official catalogue of Olympia Electronics and also in the technical leaflet,
which accompanies each product. This warranty ceases to exist if the buyer does not follow the
technical instructions included in official documents given by Olympia Electronics or if the buyer
modifies the goods provided or has any repairs or re-setting done by a third party, unless Olympia
Electronics has fully agreed to them in writing. Products that have been damaged can be returned to
the premises of our company for repair or replacement, as long as the warranty period is valid.
www.olympia-electronics.com
Olympia Electronics reserves the right to repair or to replace the returned goods and to or not charge
the buyer depending on the reason of defection. Olympia Electronics reserves the right to charge or
not the buyer the transportation cost.
HEAD OFFICE
72nd km. O.N.R. Thessaloniki-Katerini
P.C. 60300 P.O. Box 06 Εginio Pierias Greece
[email protected]
AΒC F
0
X90
