olympia electronics GR-415/4P User manual

GENERAL
o
These luminaires are used indoors (ta 40 C)
where emergency light is needed. Each luminaire
must be permanently connected to mains power
supply. In normal operation (L1 connected to L)
the led strip lights and the battery is charging. In
case of a mains power supply failure the
luminaire will light the led strip automatically in
emergency mode (powered by its battery). When
the mains power supply is restored the device
turns to normal operation.
INSTALLATION
To install the luminaire follow the installation
instructions on page 2.
OPERATION
Battery Charging
The battery charging is completely controlled. In
this case, the best possible battery maintenance
is achieved, as well as the elongation of its
duration. When the battery has completely
charged, it charges with a maintenance current.
Battery Cut-off
The luminaire enters in this operation when the
mains power supply fails and battery has lost its
energy. During this operation the luminaire enters
the idle state and
battery consumption is negligible, in order to be
protected from deep discharge.
Manual Test
The manual test can be conducted only if the main
power supply and the battery is connected. By
pressing the test button briefly an operation test is
initiated. During this test period all indication LEDs
are OFF.
Automatic Operational Test
This test includes all the operations that provide
the manual test and is conducted automatically
every 15 days. In order to be performed, the main
power supply and the battery should be
connected.
Automatic Autonomous Test
The Automatic Autonomous Test is conducted and
measures the luminaire`s back up operation. This
test is conducted automatically every six months.
In order to be performed, the main power supply
and the battery should be connected (the battery
should be charged). If the battery is not charged,
the test is postponed until the battery is
completely charged. If during the Automatic
Autonomous Test the luminaire’s duration is lower
than the nominal, then the battery must be
replaced.
Back Up Operation
The autonomous duration of battery during
emergency mode is at least the one that is stated
in the technical characteristics. During emergency
mode, a LED strip test is also performed.
Resetting Errors
Push the Test button for 10 seconds, to delete all
the indicated LED errors. Then the luminaire
enters regular operation mode.
Page 1 from 3923416001_09_008
Thank you for your trust in our products
Olympia Electronics - European manufacturer
3D LIGHT SELF TESTING MAINTAINED EMERGENCY LUMINAIRES
220-240V AC/50-60Hz
OPERATION TEMPERATURE RANGE
RELATIVE HUMIDITY
EXTERNAL DIMENSIONS
CONSTRUCTION MATERIALS
TYPICAL WEIGHT
GUARANTEE
OPERATION VOLTAGE
MAXIMUM POWER CONSUMPTION
BATTERIES (Ni-Cd)
CHARGING TIME
INDICATIONS
BATTERY PROTECTION
MINIMUM AUTONOMOUS DURATION
DEGREES OF COVER PROTECTION
PRODUCED IN ACCORDANCE WITH
ILLUMINATION SOURCE
90min
24h
Charge, Lamp Fault, Battery Fault indication LED, TEST Button
From overcharge and deep discharge
IP40
EN 60598-1, EN 60598-2-22, ΕΝ 55015, ΕΝ 61547, ΕΝ 61000-3-2, ΕΝ 61000-3-3, EN 1838
5 to 40 C
o
Up to 95%
3 years (1 year for the battery)
180min
4.8V/3Ah4.8V/1.5Ah
460lm / 460lm
4 power LEDs
320 x 310 x 310 mm
ABS/PC, PC
2900gr.2820gr.
11VA
GR-416/4PGR-415/4P
14VA
ILLUMINATION (230V AC / emergency)
TECHNICAL CHARACTERISTICS (for LED MODULE Specs. s ee page 3)
- CONTROLS

Page 2 from 3
Indication LED status (with connected mains
power supply).
Charge
On: Good charge current.
Οff: No battery (No charging current
or disconnected battery).
Lamp Fault with L1 connected to L
Οn (with LED strip off): Faulty LED strip (must be
replaced).
Οn (with LED strip on): Problem in the back up
circuit of the LED strip (must be checked by an
authorized personnel).
Off: Good LED strip.
Battery Fault
Οff: Battery OK.
Blink (With Charge LED ON): Autonomy or low
battery problem (the battery must be replaced).
Blink (With Charge LED Off):
No charging current or disconnected battery.
ΑΤΤΕΝΤΙΟΝ!!!
1. Operations for installation, maintainance or
testing must be done by authorized personnel
only.
2. The device must be connected to the mains
power supply through a fuse dependent by the
total amount of the line’s power load.
In case of battery or lamp replacement, these
must be replaced by parts of the same type, by the
manufacturer or by a competent person.
t i
in battery recycling
points. Do not incinerate.
3.
4. In case of inactive use for a period greater than 2
months, disconnect the battery by pulling out the
battery’s connector.
5. I s not allowed to discard batteries in to
common trash bins, they must be
discarded only
923416001_09_008
In order for the luminaire to become operational,
you have to:
1. Remove the mounting base by removing the 4
retaining screws (figure 1).
2. Place the mounting base to the ceiling by using the
mounting accessories (included).
3. Connect the wires to the terminal block according to
figure 2.
4. Connect the battery`s connector to the appropriate
connector (figure 3).
5. Refit the luminaire`s body by placing the removed
screws in step 1.
6. Power on the luminaire.
Also the luminaire can be used in hanging installation by
using the rings on the mounting base.
NOTE!! After finishing the installation you must
power the luminaire at least for 24 hours for battery
charging to perform the nominal autonomy.
BATTERY REPLACEMENT
It can be done only by a competent person and after
the mains interruption.
1. Detach the labeling frame from its base (step 1 of the
installation procedure).
2. Disconnect the connector and remove the old battery.
3. Connect the new battery with the same type and place
it in the position of the old one.
4. Replace the removed part (step 1).
INSTALLATION INSTRUCTIONS
Figure 1
220-240V AC / 50-60 Hz
L
N
Figure 2
Figure 3
N 1 2 NLL1
L1
(*) Maintained operation: The luminaire lights its
illumination source, when it is powered by the mains
power supply or not.
Non Maintained operation: The luminaire lights its
illumination source, only in power supply’s failure.
NOTE: LED= Light Emitting Diode
LABELING EXPLANATION:
X: Self contained
1: Maintained (*)
A: Including test device
G: Internally illuminated safety sign
*90: 1.5 hour duration
180: 3 hours duration
Remove the
retaining screws
Mounting
Base

Page 3 from 3923416001_09_008
WARRANTY
Olympia Electronics guarantees the quality, condition and operation of the goods. The period of
warranty is specified in the official catalogue of Olympia Electronics and also in the technical leaflet,
which accompanies each product. This warranty ceases to exist if the buyer does not follow the
technical instructions included in official documents given by Olympia Electronics or if the buyer
modifies the goods provided or has any repairs or re-setting done by a third party, unless Olympia
Electronics has fully agreed to them in writing. Products that have been damaged can be returned to
the premises of our company for repair or replacement, as long as the warranty period is valid.
Olympia Electronics reserves the right to repair or to replace the returned goods and to
the buyer depending on the reason of defection. Olympia Electronics reserves the right to charge or
not the buyer the transportation cost.
HEAD OFFICE
72nd km. O.N.R. Thessaloniki-Katerini
P.C. 60300 P.O. Box 06 Εginio Pierias Greece
or not charge
www.olympia-electronics.gr
[email protected]
The light source contained in this luminaire shall only be replaced by the manufacturer, or his
agent, or a similar qualified person.
NOTE! The light source is non-user replaceable.
LED MODULE CHARACTERISTICS
Fixed connection between main pcb and led module
12-13.6V DC
4W
1806103
GR-416/4P GR-415/4P
60 °C max. across the board
Olympia Electronics S.A
Manufacturer
Model Number
Voltage Range
Connections
Nominal Power
Temperature (tc)
