olympia electronics GRL-37/90/WL User manual

Page 1 from 5923037016_09_001
SELF-TESTING NON MAINTAINED EMERGENCY LUMINAIRE WITH WIRELESS COMMUNICATION
TECHNICAL CHARACTERISTICS (for LED MODULE Specifications see page 5)
220-240V AC/50-60Hz
90 min.
<24 h
POWER-CHARGE indicator, LAMP FAULT–BATT. FAULT indicator, TEST button
From overcharge and deep discharge
IP42
2x12V/7Ah
White Power LEDs
13.3W/14VA
o
5 to 40 C
Up to 95%
Aluminum, ABS/PC, PC
3 years (1 year for the battery)
3200lm
302 x 94 x 350 mm.
6310gr.
Thank you for your trust in our products
Olympia Electronics - European manufacturer
GRL-37/180/WL
OPERATION TEMPERATURE RANGE
RELATIVE HUMIDITY
EXTERNAL DIMENSIONS
CONSTRUCTION MATERIALS
TYPICAL WEIGHT
GUARANTEE
OPERATION VOLTAGE
MAXIMUM POWER CONSUMPTION
BATTERIES (Pb)
CHARGING TIME
INDICATIONS - CONTROLS
BATTERY PROTECTION
MINIMUM AUTONOMOUS DURATION
DEGREES OF COVER PROTECTION
PRODUCED IN ACCORDANCE WITH
EMERGENCY ILLUMINATION
LIGHT SOURCE
12V/7Ah
180 min.
4120gr.
GRL-37/90/WL
o
These luminaires are used (ta 40 C) where
emergency light is needed. Each luminaire must
be connected permanently to the mains power
supply.
OPERATION DESCRIPTION
GENERAL
When the unit is connected to the mains power
supply (after connecting the battery) the indicator
LAMP FAULT – BATT. FAULT remains OFF
whereas the indicator POWER CHARGE blinks to
indicate that the batteries are charging. When the
batteries are fully charged this indicator will light
permanently. If this indicator does not light then
probably the battery has not been connected. If
the batteries are connected and the indicator does
not light then contact a qualified service technician
for assistance. The charging procedure is
monitored by a microprocessor and is based on a
3 stage cycle thus ensuring a fast and full charge
of the battery. The charge current is supplied by a
high efficiency switch mode power supply which
ensures perfect charging even during the
fluctuations of the mains power supply.
BATTERY CUTOFF
The unit enters this state during the power supply
failure and when the battery has been fully
discharged. In this state the luminaire draws the
least power from the battery in order to prevent
deep discharge.
Is accomplished by briefly (<1 sec.) pressing the
TEST button. This permits the user to test the good
operation of the luminaire’s emergency circuit. The
unit simulates a power failure and the lamps are lit
using the batteries. This manual test does not affect
the automatic test.
When the luminaire is in emergency mode, with
corresponding pressings of the button, we can
choose the illumination of 100%, 50%, 33% or
turned off, either to increase the autonomy time or
not to consume the battery power unnecessarily.
This option is canceled when the network is
restored.
MANUAL TESTING
DIMMING OPTION
TX POWER
TX/RX FREQUENCY RANGE
11dBm
868.150-868.450MHz
EN 60598-1, EN 60598-2-22, EN 55015, EN 61547, EN 61000-3-2,
EN 61000-3-3, EN 62311, ETSI EN 303 446-1 V1.1.0, ETSI EN 300 220-2 V3.1.1

Page 2 from 5923037016_09_001
LAMP TESTING
AUTOMATIC DURATION TEST
Erasing errors is accomplished with a prolonged
pressing of the TEST button (>5 sec) when the unit
is connected to the mains power supply. The fault
indicated with the indicator LAMP FAULT / BATT.
FAULT will be erased. If the cause of the fault has
not been restored (i.e burned lamp) then the
indicator will light again. If the fault was caused by
a low emergency duration and you erase the error
then this will be indicated again during the next
duration test after 6 months. In this case (for
duration errors) it is vital to replace the battery
before erasing the error (the error is automatically
erased if the mains power and the battery are
disconnected).
AUTOMATIC EMERGENCY CIRCUIT TEST
The unit automatically tests the emergency circuit
every 15 days (if the battery and mains power are
connected) . During this test the lamps are turned
ON for 3 seconds using the batteries. In some
cases this function might not be acceptable (i.e in
cases this function might not be acceptable (i.e in
cinema theaters) so the installer must take this
into account during the installation.
This test is conducted every 6 months by
simulating a power failure, if the battery and mains
power supply are connected. The unit lights the
lamps using the charged battery and counts the
time until the stated duration. If the lamps are ON
during the end of the test then the unit is restored
to its normal operation (lamps OFF and battery
charging). If the lamps go OFF before the end of
the test then the unit is restored to its normal
operation but the LAMP FAULT / BATT. FAULT
indicator is lit to show that there is a problem with
the battery and that the battery must be replaced.
Let it be noted that this duration test is also done
during every long power failure. If the power
failure lasts for a long time and the luminaire has
entered the BATTERY CUTOFF mode and the
duration measured is not correct then the fault
indicator will light when the power is restored.
ERASING ERRORS
The luminaire tests the good condition of the
lamps in emergency mode and warns the user for
probable malfunction. If a lamp is found faulty then
the LAMP FAULT indicator starts to blink. To verify
which lamp is faulty use the TEST button. If the
faulty lamp is replaced then the error is
automatically restored and the indicator is turned
OFF.
The WL luminaire models have the ability to
communicate over the air with Olympia’s control
panels for wireless emergency luminaires. The
luminaires can also communicate with a
PC/laptop through a gateway (Ethernet, Wi-Fi,
USB). For more information, please refer to
Wireless Emergency Lighting guides, available
on the company’s website.
procedure must be done only by qualified
Wireless communication
WARNING !!!
1. Every test, installation or maintenance
personnel.
3. The replacement of the battery and the
light source must be done using parts of
2. The unit must be connected to the mains
accordingly.
the same type, by the manufacturer or by
a competent person.
4. If the luminaire must be isolated from the
mains power supply for more than 2
months then the batteries must be
disconnected by removing the battery
power supply using a line fuse rated
connectors.
5. I s not allowed to discard batteries in to t i
common trash bins, they must be
discarded only in battery recycling
points. Do not incinerate.
Battery replacement
It can be done only by a competent person
and after the mains interruption.
1. Follow the step 2 of the installation
procedure.
2. Disconnect the cables and remove the
old battery.
3. Connect the new battery with the same
type (step 3 of the installation procedure)
and place it in the position of the old one.
4. Follow the step 6 of the installation
procedure and power the device.

2. Long press (>2"): Loads factory default
settings to the module.
Button functionality:
The on-board button has the two following
functions:
1. Short press (<2"): a status message will
be sent to the Gateway device of the
wireless network.
Button
LD3
LD2
LD1
Antenna
• SID: 00000001
Default settings:
• RF Channel: 13 ( 869.525MHz )
1. Very fast flash [5 times/s]: received signal
strength is excellent.
3. Moderate flash [1 second ON / 1 second
OFF]: received signal strength is acceptable
for reliable communication.
3. Fast flash [2 times/s]: The device has
5. No light: The device is disconnected.
1. Very fast blink [5 times/s]: the module is
not initialized correctly. In this case you
have to press for more than 2 seconds the
push button, in order to reset the module
(loads default settings).
established connection to a Router device
and at least one more Router device is
available on the same hop level, as an
alternate route (redundant connection).
The bottom LED (LD1-red) indicates
operation status.
(false condition).
This LED may blink according to the
following patterns:
The middle LED (LD2-green) indicates the
received signal strength (RSSI) of the router
module.
2. Rapid flash [5 times/s]: The device has
established direct connection to a single
Gateway device.
1. Steady ON: The device has established
direct connection to a Gateway device, and
at least one more Gateway device is
available for alternate routing
Wireless Communication LED
indications (interior)
The top LED (LD3-green) indicates the
network connection status.
This LED may blink according to the
following patterns:
4. Moderate flash [1 second ON / 1 second
OFF]: The device has established
connection to a single Router device, and
no alternatives exist on the same hop level.
This LED may blink according to the
following patterns:
2. Fast flash [2 times/s]: received signal
strength is good.
4. Very slow [2 seconds ON / 2 seconds
OFF]: received signal strength is not
acceptable for reliable communication, or
no signal.
2. Moderate flash [2 times/s]: The module
is properly operating.
Page 3 from 5 923037016_09_001

Page 4 from 5923037016_09_001
neutral (Fig. 2).
and red cable to (+) pole (Fig. 2).
4. Install the included cable gland or the rubber o-ring. Pass through the mains cable and stabilize it
1. Install the included mounting accessories to hook the device from the mounting holes (Fig.1).
2. Unfasten the 4 mounting screws to remove the front plastic cover (Fig.1).
3. Make sure that the battery’s cables are connected to the respective poles. Black cable to (-) pole
by fastening the cable gland. Connect the wires to the terminal blocks L for live wire and Ν for
1N*m).
5. Refit with care the front plastic cover, by fastening the 4 mounting screws (tightening torque
After the installation has finished, charge the batteries for at least 24 hours so as to obtain the
rated autonomy duration.
WARNING!!
INSTALLATION PROCEDURE (For wall mounting only)
INDICATION LED STATUS (with the mains power supply connected)
Indicator ON Indicator Blinking Indicator OFF
POWER / CHARGE LAMP FAULT / BATT. FAULT
Disconnected battery / not charging Normal operation mode
Charged battery Low emergency duration (replace battery)
Battery under charge Lamp fault (Check lamps and replace if needed)
TEST
button
Fig. 1
POWER
CHARGE
indicator
Mounting holes
LAMP FAULT
BATT. FAULT
indicator
Cover
retaining
screws
4
N
L
3
Fig.2

Page 5 from 5923037016_09_001
Olympia Electronics guarantees the quality, condition and operation of the goods. The period of
warranty is specified in the official catalogue of Olympia Electronics and also in the technical leaflet,
which accompanies each product. This warranty ceases to exist if the buyer does not follow the
technical instructions included in official documents given by Olympia Electronics or if the buyer
modifies the goods provided or has any repairs or re-setting done by a third party, unless Olympia
Electronics has fully agreed to them in writing. Products that have been damaged can be returned to
the premises of our company for repair or replacement, as long as the warranty period is valid.
www.olympia-electronics.com
72nd km. O.N.R. Thessaloniki-Katerini
WARRANTY
P.C. 60300 P.O. Box 06 Εginio Pierias Greece
HEAD OFFICE
[email protected]
Olympia Electronics reserves the right to repair or to replace the returned goods and to or not charge
the buyer depending on the reason of defection. Olympia Electronics reserves the right to charge or
not the buyer the transportation cost.
NOTE! The light source is non-user replaceable.
The light source contained in this luminaire shall only be replaced by the manufacturer, or his
agent, or a similar qualified person.
LED MODULE CHARACTERISTICS
Olympia Electronics S.A.
68 °C max. across the board
Cable connection between main pcb and led module
17.5-20.5V
14W
1005183
Manufacturer
Manufacturer
Voltage Range
Connections
Nominal Power
Temperature (tc)
GRL-37/90/WL GRL-37/180/WL
180: 3 hour duration
90: 1.5 hour duration
C: Including inhibiting mode
LABELING EXPLANATION:
B: Including remote test mode
X: Self contained
A: Including test device
F: Automatic test gear complying with IEC 61347-2-7 denoted EL-T
0: Non maintained (*)
(*) Non Maintained operation: The luminaire turns on illumination source, only in case of power
supply failure.
NOTE: LED= Light Emitting Diode
A B C F
0
X90
