olympia electronics BS-536 User manual

921536000_09_011921536000_09_011Page 1 from 2 Page 2 from 2
TO THE ZONE
OF THE PANEL
TERMINAL
RESISTOR
BS-536 BS-536
OUT IN DETE CTOR ’S
BASE
-R
O
U
T
-
-
L
N
I
T
+
U
R
O
N
+
L
I
1,4μ
BS-536 manual call point
KOLINDROS
PIERIAS
60061 HELLAS
EN-54-11: 2001 + A1: 2005
Plastic key input
Α
1 1
ΑΒ
Β
Figure 3
Figure 4
Figure 2
Figure 1
INSTALLATION INSTRUCTIONS
Insert the supplied plastic key into the input (Figure 1) rotate by 90 ° and pull
it until the call point will be reset to it`s original position.
Recovery Procedure 90°
OUT IN
MANUAL CALL POINT
TECHNICAL CHARACTERISTICS
OPERATION TEMPERATURE RANGE
RELATIVE HUMIDITY
EXTERNAL DIMENSIONS
CONSTRUCTION MATERIALS
TYPICAL WEIGHT
GUARANTEE
OPERATION VOLTAGE
ALARM CURRENT
ALARM RESISTOR
TYPE
USE
DEGREES OF COVER PROTECTION
PRODUCED IN ACCORDANCE WITH
Type A
Indoor
10-30V DC
470ohms
8-30mA
ABS/PC
IP 20
EN 54-11
o
-10 to 70 C
Up to 95%
2 years
98 x 94 x 58 mm
180gr.
BS-536
This is an emergency fire alarm button. Use
this call point to manually activate the alarm
system at the sight of fire. It is essential for it
to exist in cooperation with other detectors.
It is used as a signal to evacuate the building
in case of fire.
GENERAL
Using it is very simple. All you have to do is
push the see-through plastic cover and the
call point automatically activates the alarm
system.
In this case the see-through plastic cover
does not brake but it can be reset to it`s
original position with the special plastic key
which is included.
This way you can test a specific call point
and maintenance the fire detection panel as
well.
In every fire detection system it is essential
that you place one call point besides the
control panel and the rest mainly in corridors
and exits of the building.
1. First, unfasten the retailing screws and
remove the plastic cover.
2. Remove carefully the interior parts of the
device and use the supplied mounting parts to
the A-A or B - B positions (Figure 2).
should be placed at a height of about 1.4 m
from the floor.(Figure 1).
3. During their installation must be attention
taken that the distance between two buttons
does not exceed 30 m and all buttons
Installation and Connection
4. Inside the call point there are four
special terminal blocks with indications
IN and OUT used to fasten the cables.
The connection is made direct to the zone
of the control panel regardless of polarity.
If in a zone there are more than one then
they are connected in parallel. If in the
same zone there are detectors then the
call point is connected in parallel with the
detectors of this specific zone.
If the last device installed on a zone is
a call point then you must place on it the
resistor which was removed from that
zone. The Figure 4 below shows the
connections between two call points
and a detector to a zone of a fire detection
panel It also shows the connection of the
resistor to the last button of that zone.
5. Reinstall the parts which have been
removed during the previous steps and
the device is ready to operate.
Thank you for your trust in our products
Olympia Electronics - European manufacturer
HEAD OFFICE
[email protected]
72nd km. O.N.R. Thessaloniki-Katerini
www.olympia-electronics.com
P.C. 60300 P.O. Box 06 Εginio Pierias Greece
WARRANTY
Olympia Electronics guarantees the quality, condition and operation of the goods. The period of warranty
is specified in the official catalogue of Olympia Electronics and also in the technical leaflet, which
accompanies each product. This warranty ceases to exist if the buyer does not follow the technical
instructions included in official documents given by Olympia Electronics or if the buyer modifies the goods
provided or has any repairs or re-setting done by a third party, unless Olympia Electronics has fully
agreed to them in writing. Products that have been damaged can be returned to the premises of our
company for repair or replacement, as long as the warranty period is valid.
Olympia Electronics reserves the right to repair or to replace the returned goods and to or not charge the
buyer depending on the reason of defection. Olympia Electronics reserves the right to charge or not the
buyer the transportation cost.
