Omron E2F-X1R5Y1 User manual

D-29E2F
E2F
Cylindrical Proximity Sensor in Plastic Housing
E2F
• High quality full body plastic housing for high water
proof requirements
• Polyarylate housing for light chemical resistance
Applications
Ordering Information
Sensors
*1. A different frequency type is available. (E2F-X@@5; e.g.E2F-X5E15)
*2. A short-circuit protection type is available. (E2F-X@Y@-53; e.g. E2F-X5Y1-53) Power supply voltage: 100 to 120 VAC
Accessories (Order Separately)
Detection of bottle caps
Warm water
cleaning
High humidity environment
Model Sensing distance Output specifications
Model
Operating status
NO NC
M8 DC 3-wire NPN E2F-X1R5E1 E2F-X1R5E2
AC 2-wire Models E2F-X1R5Y1 E2F-X1R5Y2
M12 DC 3-wire NPN E2F-X2E1 E2F-X2E2
AC 2-wire Models E2F-X2Y1 E2F-X2Y2
M18 DC 3-wire NPN E2F-X5E1 E2F-X5E2
AC 2-wire Models E2F-X5Y1 E2F-X5Y2
M30 DC 3-wire NPN E2F-X10E1 E2F-X10E2
AC 2-wire Models E2F-X10Y1 E2F-X10Y2
Shielded
1.5mm
2mm
*1 *1
*1 *1
5mm
*1 *1
*1
*2 *1
*2
10mm
*1 *1
*1
*2 *1
*2
F502-EN2-04.book Seite 29 Dienstag, 26. Juli 2005 5:48 17

D-30 Inductive Sensors
Rating/performance
Model E2F-X1R5E@
E2F-X1R5Y@
E2F-X2E@
E2F-X2Y@
E2F-X5E@
E2F-X5Y@
E2F-X10E@
E2F-X10Y@
Item
Sensing distance 1.5 mm ±10% 2 mm ±10% 5 mm ±10% 10 mm ±10%
Setting distance 0 to 1.2 mm 0 to 1.6 mm 0 to 4 mm 0 to 8 mm
Differential distance 10% max.
Sensing object Ferrous metal (Sensitivity lowers with non-ferrous metals)
Standard sensing
object Iron, 8 ×8 ×1 mm Iron, 12 ×12 ×1 mm Iron, 18 ×18 ×1 mm Iron, 30 ×30 ×1 mm
Response frequen-
cy*1
*1. The response frequencies are average values measured on condition that the distance between each sensing object is twice as large as the size of the sensing
object and the sensing distance set is half of the maximum sensing distance.
E models: 2 kHz, Y mod-
els: 25 Hz
E models: 1.5 kHz, Y mod-
els: 25 Hz
E models: 600 Hz, Y mod-
els: 25 Hz
E models: 400 Hz, Y mod-
els: 25 Hz
Power supply(Oper-
ating voltage range)
E models: 12 to 24 VDC (10 to 30 VDC), ripple (p-p): 10% max.
Y models: 24 to 240 VAC (20 to 264 VAC)
Current consumption E models: 17 mA max.
Leakage current Y models: 1.7 mA at 200 VAC
Control
output
Switch-
ing ca-
pacity
E models: 200 mA max. Y models: 5 to 100 mA E models: 200 mA max. Y models: 5 to 300 mA
Residual
voltage
E models: 2 V max. (load current: 200 mA with cable length: 2 m)
Y models: Refer to the Specifications
Indicator lamp E models: Detection indicator (red LED) Y models: Operation indicator (red LED)
Operating status
(with sensing object
approaching)
E1, Y1 models: ON
E2, Y2 models: NC
Protective circuits E models: Reverse connection protection, load short-circuit protection, surge absorber Y models: None
Ambient temperature Operating/Storage: -25°C to 70°C (with no icing or condensation)
Ambient humidity Operating/Storage: 35% to 95%RH
Temperature influ-
ence A maximum fluctuation of ±10% max. of sensing distance at 23°C in temperature range of -25°C and 70°C
Voltage influence E models: ±2.5% max. of sensing distance within a range of ±15% of rated power supply voltage Y models: ±1%
max. of sensing distance within a range of ±10% of rated power supply voltage
Insulation resistance 50 MΩmin. (at 500 VDC) between current carry parts and case
Dielectric strength E models: 1,000 VAC, 50/60 Hz for 1 min between current carry parts and case
Vibration resistance 10 to 55 Hz, 1.5-mm double amplitude for 2 hours each in X, Y, and Z directions
Shock resistance Destruction: 1,000 m/s2for 10 times each in X, Y, and Z directions
Protective structure IEC IP67
Connection method Pre-wired models (standard length: 2 m)
Weight (Packed
state) Approx.40g Approx. 50 g Approx. 130 g Approx. 170 g
Material
Case
Polyarylate
Sensing
surface
Clamp-
ing nut Polyallylate resin
Accessories Instruction manual
F502-EN2-04.book Seite 30 Dienstag, 26. Juli 2005 5:48 17

D-31E2F
E2F
Characteristic data (typical)
Sensing Distance vs. Sensing Object
Output Circuit Diagram
E2F-X1R5@@ E2F-X2@@
E2F-X5@@ E2F-X10@@
Output Operating
status Model Timing chart Output circuit
DC 3-
wire
NO
E2F-X1R5E1
E2F-X2E1
E2F-X5E1
E2F-X10E1
NC
E2F-X1R5E2
E2F-X2E2
E2F-X5E2
E2F-X10E2
AC 2-
wire
Models
NO
E2F-X1R5Y1
E2F-X2Y1
E2F-X5Y1
E2F-X10Y1
NC
E2F-X1R5Y2
E2F-X2Y2
E2F-X5Y2
E2F-X10Y2
0 5 10 15
Side length of sensi
n
Sensing distance X (mm)
2.5
2.0
1.5
1.0
0.5
Stain
l
(SUS
Alum
Mild
s
Bras
s
#
d
t=1
mm
X
0 5 10 15
2.4
2.2
2
1.8
1.6
1.4
1.2
1
0.8
0.6
0.4
0.2
Sensing distance X (mm)
Side length of sensin
t=1
mm
X
#d
0 5 10 15 20 25 30
3
Side length of sensi
Sensing distance X (mm)
7
6
5
4
3
2
1
t=1
mm
X
#
d
0 102030405060
12
11
10
9
8
7
6
5
4
3
2
1
Side length of sensing object d (mm)
Stainless steel
(SUS304)
Aluminum
Mild steel
Brass
Sensing distance X (mm)
t=1
mm
X
#
d
Yes
No
Operates
Reset
H
L
ON
OFF
Load (between brown
and black leads)
Sensing object
Detection indicator
Output voltage
(between black and
blue leads) Load
Brown
Black
*1
Tr
*1. 200 mA max. (source current)
*2. When connecting to the transistor circuit.
Output
*2
Blue
100W
2.2W
Main
circuit
+V
0V
4.7kW
Yes
No
Operates
Reset
H
L
ON
OFF
Load (between brown
and black leads)
Sensing object
Detection indicator
Output voltage
(between black and
blue leads)
Yes
No
Operates
Reset
ON
OFF
Load
Sensing object
Detection indicator
Load
Brown
Blue
Main
circuit
Yes
No
Operates
Reset
ON
OFF
Load
Sensing object
Detection indicator
F502-EN2-04.book Seite 31 Dienstag, 26. Juli 2005 5:48 17

D-32 Inductive Sensors
Precautions
Design
Effects of Surrounding Metal
Provide a minimum distance as shown in the table below be-
tween the Sensor and the surrounding metal.
Effects of Surrounding Metal(Unit: mm)
Mutual Interference
When installing two or more Sensors face-to-face or side-by-
side, ensure that the minimum distances given in the following
table are maintained.
Mutual Interference (Unit: mm)
Note: Figures in parentheses are for an E2F used in combination with an E2F
(i.e., E2F-X@@@5) that is operating at a different frequency.
Mounting
Do not apply excessive torque when tightening any nuts.
●Maintenance and Inspection
Do not use the AC 2-wire models (sensing surface is broken),
where directly exposed to water. There is fear of an electric
shock.
Correct Use
Model Item l d D m n
E2F-X1R5@@
0
8
0
4.5 12
E2F-X2@@ 12 8 18
E2F-X5@@ 18 20 27
E2F-X10@@ 30 40 45
Model Item A B
E2F-X1R5@@ 20 15
E2F-X2@@ 30 (20) 20(12)
E2F-X5@@ 50 (30) 35 (18)
E2F-X10@@ 100(50) 70(35)
l
m
n
l
m
D
d dia.
AB
Model Tensile strength (torque)
E2F-X1R5@@ 0.78 N•m
E2F-X2@@
E2F-X5@@ 2 N•m
E2F-X10@@
F502-EN2-04.book Seite 32 Dienstag, 26. Juli 2005 5:48 17

D-33E2F
E2F
Dimensions (Unit: mm)
DC 3-wire Models AC 2-wire Models
E2F-X1R5E@
15 dia.
13 20
22
30
M8 x 1 4
Indicator
Two, clamping nuts
Two, washers
(see note)
Note:
Vinyl-insulated round cord, 3.5 dia.,
3 cores (0.12 dia. x 13); Standard length: 2m
E2F-X1R5Y@
15 dia.
13 29
32
40
M8 x 1 4
Indicator
Two, clamping nuts
Two, washers
(see note)
Note:
Vinyl-insulated round cord, 3.5 dia.,
3 cores (0.12 dia. x 13); Standard length: 2m
E2F-X2E@
17 24
27
38
M12 x 1
4
Indicator
Two, clamping nuts
(see note)
Note:
Oil-and vibration-resistant,
vinyl-insulated round cord, 6 dia.,
0.5 dia. x 3 cores; Standard length: 2m
The cord can be extended up to 200 m
in an independent metal conduit.
E2F-X2Y@
17 29
32
43
M12 x 1 4
Indicator
Two, clamping nuts
(see note)
Note:
Oil-and vibration-resistant,
vinyl-insulated round cord, 6 dia.,
0.5 dia. x 2 cores; Standard length: 2m
The cord can be extended up to 200 m
in an independent metal conduit.
E2F-X5E@
24 29
32
40
47
M30 x 1.5
4
Indicator
Two, clamping nuts
(see note)
Note:
Oil-and vibration-resistant,
vinyl-insulated round cord, 6 dia.,
0.5 dia. x 2 cores; Standard length: 2m
The cord can be extended up to 200 m
in an independent metal conduit.
24 29
32
40
47
M18 x 1
4
Indicator
Two, clamping nuts
(see note)
Note:
Oil-and vibration-resistant,
vinyl-insulated round cord, 6 dia.,
0.5 dia. x 2 cores; Standard length: 2m
The cord can be extended up to 200 m
in an independent metal conduit.
E2F-X5Y@
F502-EN2-04.book Seite 33 Dienstag, 26. Juli 2005 5:48 17

D-34 Inductive Sensors
Mounting Hole Dimension
E2F-X10E@
36 38
41
50
57
M30 x 1.5
5
Indicator
Two, clamping nuts
(see note)
Note:
Oil-and vibration-resistant,
vinyl-insulated round cord, 6 dia.,
0.5 dia. x 3 cores; Standard length: 2m
The cord can be extended up to 200 m
in an independent metal conduit.
E2F-X10Y@
36 38
41
50
57
M30 x 1.5
5
Indicator
Two, clamping nuts
(see note)
Note:
Oil-and vibration-resistant,
vinyl-insulated round cord, 6 dia.,
0.5 dia. x 2 cores; Standard length: 2m
The cord can be extended up to 200 m
in an independent metal conduit.
Model E2F-X1R5@@ E2F-X2@@ E2F-X5@@ E2F-X10@@
F (mm) 8.5-mm dia. 12.5-mm dia. 18.5-mm dia. 30.5-mm dia.
+0 +0 +0 +0
F
In the interest of product improvement, specifications are subject to change without notice.
ALL DIMENSIONS SHOWN ARE IN MILLIMETERS.
To convert millimeters into inches, multiply by 0.03937. To convert grams into ounces, multiply by 0.03527.
Cat. No. D07E-EN-01
