Omron V680-HAM91 User manual

Man. No.: Z279-E1-04A
ID Flag Sensors
V680-HAM91
V680-HAM81
V680-series ID Flag Sensors
User’s Manual
Antennas
V680-HS51
V680-HS52
V680-HS63
V680-HS65
RF Tags
V680-D1KP52MT
V680-D1KP66T/-D1KP66MT
V680-D1KP58HTN
V680-D2KF52M
V680-D8KF67/-D8KF67M
V680-D8KF68/-D32KF68
V680-D1KP52M-BT01/D1KP52M-BT11
V680-D2KF67/-D2KF67M
V680-D1KP53M
V680-D2KF52M-BT01/D2KF52M-BT11
V680-D1KP66T-SP

Introduction
Thank you for purchasing a V680-series ID System. This manual describes the functions, performance, and
application methods needed for optimum use of the V680-series RFID System.
Please observe the following items when using the ID System.
• Allow the ID System to be installed and operated only by qualified specialist with a sufficient knowledge of
electrical systems.
•Read and understand this manual before attempting to use the ID System and use the ID System correctly.
•Keep this manual in a safe and accessible location so that it is available for reference when required.

Introduction Section 1 Section 2 Section 3 Section 4 Section 5 Section 6 Section 7
Introduc-
tion
Section 1
Section 2
Section 3
Section 4
Section 5
Section 6
Section 7
READ AND UNDERSTAND THIS DOCUMENT
Product Overview
Names and Functions of Components
Functions
Installation, Connections, and Wiring
Control I/O Interface
Troubleshooting
Appendices
RFID System
V680-HAM91 ID Flag Sensor
V680-HAM81 ID Flag Sensor
V680-HS51 Antenna
V680-HS52 Antenna
V680-HS63 Antenna
V680-HS65 Antenna
V680-1KP52MT RF Tag
V680-1KP52MT-BT01/-D1KP52M-BT11 RF Tag
V680-1KP53M RF Tag
V680-1KP66T/-D1KP66MT RF Tag
V680-1KP66T-SP RF Tag
V680-1KP58HTN RF Tag
V680-2KF52M RF Tag
V680-2KF52MT-BT01/-D2KF52M-BT11 RF Tag
V680-2KF67/-D2KF67M RF Tag
V680-8KF67/-D8KF67M RF Tag
V680-D8KF68/-D32KF68 RF Tag
User's Manual

2
Introduction
RFID System
User's Manual
Introduction
READ AND UNDERSTAND THIS DOCUMENT
Please read and understand this document before using the products. Please consult your OMRON representative if you have any questions or comments.
WARRANTY
OMRON’s exclusive warranty is that the products are free from defects in materials and workmanship for a period of one year (or other period if specified)
from date of sale by OMRON.
OMRON MAKES NO WARRANTY OR REPRESENTATION, EXPRESS OR IMPLIED, REGARDING NON-INFRINGEMENT, MERCHANTABILITY, OR FIT-
NESS FOR PARTICULAR PURPOSE OF THE PRODUCTS. ANY BUYER OR USER ACKNOWLEDGES THAT THE BUYER OR USER ALONE HAS
DETERMINED THAT THE PRODUCTS WILL SUITABLY MEET THE REQUIREMENTS OF THEIR INTENDED USE. OMRON DISCLAIMS ALL OTHER
WARRANTIES, EXPRESS OR IMPLIED.
LIMITATIONS OF LIABILITY
OMRON SHALL NOT BE RESPONSIBLE FOR SPECIAL, INDIRECT, OR CONSEQUENTIAL DAMAGES, LOSS OF PROFITS OR COMMERCIAL LOSS IN
ANY WAY CONNECTED WITH THE PRODUCTS, WHETHER SUCH CLAIM IS BASED ON CONTRACT, WARRANTY, NEGLIGENCE, OR STRICT LIABIL-
ITY.
In no event shall responsibility of OMRON for any act exceed the individual price of the product on which liability is asserted.
IN NO EVENT SHALL OMRON BE RESPONSIBLE FOR WARRANTY, REPAIR, OR OTHER CLAIMS REGARDING THE PRODUCTS UNLESS OMRON’S
ANALYSIS CONFIRMS THAT THE PRODUCTS WERE PROPERLY HANDLED, STORED, INSTALLED, AND MAINTAINED AND NOT SUBJECT TO CON-
TAMINATION, ABUSE, MISUSE, OR INAPPROPRIATE MODIFICATION OR REPAIR.
SUITABILITY FOR USE
THE PRODUCTS CONTAINED IN THIS DOCUMENT ARE NOT SAFETY RATED. THEY ARE NOT DESIGNED OR RATED FOR ENSURING SAFETY OF
PERSONS, AND SHOULD NOT BE RELIED UPON AS A SAFETY COMPONENT OR PROTECTIVE DEVICE FOR SUCH PURPOSES. Please refer to sep-
arate catalogs for OMRON's safety rated products.
OMRON shall not be responsible for conformity with any standards, codes, or regulations that apply to the combination of products in the customer’s applica-
tion or use of the product.
At the customer’s request, OMRON will provide applicable third party certification documents identifying ratings and limitations of use that apply to the prod-
ucts. This information by itself is not sufficient for a complete determination of the suitability of the products in combination with the end product, machine,
system, or other application or use.
The following are some examples of applications for which particular attention must be given. This is not intended to be an exhaustive list of all possible uses
of the products, nor is it intended to imply that the uses listed may be suitable for the products:
•Outdoor use, uses involving potential chemical contamination or electrical interference, or conditions or uses not described in this document.
•Nuclear energy control systems, combustion systems, railroad systems, aviation systems, medical equipment, amusement machines, vehicles, safety
equipment, and installations subject to separate industry or government regulations.
•Systems, machines, and equipment that could present a risk to life or property.
Please know and observe all prohibitions of use applicable to the products.
NEVER USE THE PRODUCTS FOR AN APPLICATION INVOLVING SERIOUS RISK TO LIFE OR PROPERTY WITHOUT ENSURING THAT THE SYSTEM
AS A WHOLE HAS BEEN DESIGNED TO ADDRESS THE RISKS, AND THAT THE OMRON PRODUCT IS PROPERLY RATED AND INSTALLED FOR THE
INTENDED USE WITHIN THE OVERALL EQUIPMENT OR SYSTEM.
PERFORMANCE DATA
Performance data given in this document is provided as a guide for the user in determining suitability and does not constitute a warranty. It may represent the
result of OMRON’s test conditions, and the users must correlate it to actual application requirements. Actual performance is subject to the OMRON Warranty
and Limitations of Liability.
CHANGE IN SPECIFICATIONS
Product specifications and accessories may be changed at any time based on improvements and other reasons.
It is our practice to change model numbers when published ratings or features are changed, or when significant construction changes are made. However,
some specifications of the product may be changed without any notice. When in doubt, special model numbers may be assigned to fix or establish key spec-
ifications for your application on your request. Please consult with your OMRON representative at any time to confirm actual specifications of purchased prod-
ucts.
DIMENSIONS AND WEIGHTS
Dimensions and weights are nominal and are not to be used for manufacturing purposes, even when tolerances are shown.
ERRORS AND OMISSIONS
The information in this document has been carefully checked and is believed to be accurate; however, no responsibility is assumed for clerical, typographical,
or proofreading errors, or omissions.
PROGRAMMABLE PRODUCTS
OMRON shall not be responsible for the user’s programming of a programmable product, or any consequence thereof.
COPYRIGHT AND COPY PERMISSION
This document shall not be copied for sales or promotions without permission. This document is protected by copyright and is intended solely for use in con-
junction with the product. Please notify us before copying or reproducing this document in any manner, for any other purpose. If copying or transmitting this
document to another, please copy or transmit it in its entirety.

3
RFID System
User's Manual
Introduction
Introduction
zAlert Symbols for Safe Use
The following symbols are used in this manual to indicate precautions that must be observed to ensure safe
use of V680-HAM91, V680-HAM81, V680-series Antennas, and V680-series RF Tags.
The precautions provided here contain important safety information. Be sure to observe these precautions.
The following signal words are used in this manual.
zMeanings of Alert Symbols
zWarning
Safety Precautions
Indicates a potentially hazardous situation which, if not avoided, will result in minor or mod-
erate injury, or may result in serious injury or death. Additionally, there may be significant
property damage.
Indicates general prohibitions for which there is no specific symbol.
These Products are not designed to be used either directly or indirectly in applications that detect human
presence for the purpose of maintaining safety. Do not use these Products as a sensing means for protecting
human lives.
WARNING
WARNING

4
Introduction
RFID System
User's Manual
Introduction
Be sure to observe the following precautions to ensure safe use of the Products.
1. Do not use the Products in environments with flammable, explosive, or corrosive gasses.
2. Do not attempt to disassemble, repair, or modify any Product.
3. Because a cable has a locking mechanism, make sure that it has been locked before using the cable.
4. Make sure the power supplied by the DC power supply unit is within the rated power supply voltage (24
VDC +10%/−15%) before using the Product.
5. Do not connect the power supply in reverse.
6. Do not allow water or pieces of wire to enter from openings in the case. Doing so may cause fire or electric
shock.
7. Provide sufficient ventilation space.
8. Do not install the Products near any equipment that generates a large amount of heat (such as heaters,
transformers, and large-capacity resistors).
9. Turn OFF the Controller power supply before mounting or removing an Antenna.
10. If an error is detected in any Product, immediately stop operation and turn OFF the power supply. Consult
with an OMRON representative.
11. Dispose of the Products as industrial waste.
12. Do not clean the Products with paint thinner, benzene, acetone, or kerosene.
13. If multiple Antennas are mounted near each other, communications performance may decrease due to
mutual interference. Refer to Mutual Interference between Antennas (Reference) on page 149 and check
to make sure there is no mutual interference between the Antennas.
14. To remove the Unit, catch a tool on the hook and gently remove the Unit.
15. Do not perform wiring incorrectly or short-circuit the load. Doing so may result in rupture or damage from
burning.
16. Do not use the product in environments subject to oil.
17. Do not never use the AC power supply.
Precautions for Safe Use

5
RFID System
User's Manual
Introduction
Introduction
Always observe the following precautions to prevent operation failures, malfunctions, and adverse effects on
performance and equipment.
1. Installation and Storage Environment
Do not use or store the Product in the following locations.
• Locations subject to corrosive gases, dust, dirt, metal powder, or salt.
• Locations where the specified ambient temperature and ambient humidity range is exceeded.
• Locations subject to extreme temperature changes that may result in condensation.
• Locations where the product would be directly subjected to vibration or shock exceeding specifica-
tions.
• Locations subject to contact with water, oil, or chemicals
2. Installation
• The Products communicate with RF Tags using the 13.56-MHz frequency band. Some motors,
inverters, and switching power supplies generate noise that can affect communications with the RF
Tags and cause errors. If such devices are located near the RF Tags, always test operation in
advance to confirm whether the system will be affected.
• Observe the following precautions to minimize the effects of normal noise.
(1) Ground all metal objects in the vicinity of the Products to 100 Ωor less.
(2) Do not use the Products near high-voltage or high-current lines.
• Do not pull on the cables with excessive strength.
• The Product is not waterproof. Do not use it in an environment where mist is present.
• Do not expose the Products to chemicals that adversely affect the Product materials.
• The dust cover is attached at the CN2 connector. When neither writing in the RF Tags nor address
shift function/noise check function is used, the connection to this connector is unnecessary. In this
case, please keep the duct cover attached.
3. About control at the initial state
There is a possibility that the state of Input/Output becomes unstable while starting this product.
Please control Input/Output after one second or more passes after turning on the power supply to this
product.
4. Use at high temperatures (V680-D1KP58HTN)
• Data stored in memory in the RF Tag may be lost due to the characteristics of EEPROM, if the accu-
mulated usage time of the RF Tag at a high temperature over 125°C exceeds 10 hours after writing
data to the RF Tag.
• Do not communicate between the Antenna and the RF Tag in an environment where the ambient
operating temperature is 85°C or higher.
An error in communications between the Antenna and the RF Tag may occur.
• Do not use the commands using UID (unique identification number for each RF Tag) when the RF tag
is used at a high temperature over 125°C. The UID may be lost due to the characteristics of
EEPROM.
For Use at high temperatures, refer to Product Specifications - Use at high temperatures (V680-D1KP58HTN) in Sec-
tion 7 Appendices.
p.93
Precautions for Correct Use

6
Introduction Meanings of Symbols
RFID System
User's Manual
Introduction
Meanings of Symbols
Indicates particularly important points related to a function, including precautions and application advice.
Indicates page numbers containing relevant information.
Indicates reference to helpful information and explanations for difficult terminology.

7
RFID System
User's Manual
Introcuction
Introduction
Table of Contents
Introduction
Safety Precautions 3
Precautions for Safe Use 4
Precautions for Correct Use 5
Meanings of Symbols 6
Table of Contents 7
Section 1 Product Overview 9
Features 10
System Configuration 11
Section 2 Names and Functions of Components 13
ID Flag Sensor 14
Antennas 21
RF Tags 22
Section 3 Functions 25
Communications Mode 26
Optional Functions 28
Wire-saving Mode 30
Parity Check 31
Address Shift 32
Noise Measurement 33
Write Protection 34
Section 4 Installation, Connections, and Wiring 37
ID Flag Sensor 38
Installing Antennas 43
Installing RF Tags 46

8RFID System
User's Manual
Introduction
Introduction
Section 5 Control I/O Interface 53
I/O Interface Control 54
I/O Control Flow 55
Timing Charts 56
Sample Programming 65
Section 6 Troubleshooting 69
Handling Errors 70
Errors and Countermeasures 71
Maintenance and Inspection 72
Section 7 Appendices 73
Product Specifications 74
Characteristics 104
Reference Data: Antenna and RF Tags Installation 133
RF Tag Memory Capacities and Memory Types 165
RF Tag Memory Map 166
Chemical Resistance of the Antennas and RF Tags 167
V600-Compatible Mode 173
Degree of Protection 188
Revision History 190

Section 1 Product Overview
9
RFID System
User’s Manual
Section 1
Product Overview
Features 10
System Configuration 11

10
Section 1 Features
RFID System
User's Manual
Section 1
Product Overview
Features
The V680-series ID System uses electromagnetic induction in the 13.56-MHz bandwidth, which conforms to
the international standards in ISO/IEC 18000-3 (ISO/IEC 15693). A V680-series ID System enables reading
and writing RF Tag data without contact by connecting a V680-HAM91/V680-HAM81 ID Flag Sensor to a
V680-series Antenna. With control performed in connection with the Basic I/O Units of a Programmable
Controller, ID Flag Sensors provide data management for applications such as quality and process control at
production sites.
Simple Operation with I/O Control as Simple as Using a Regular Sensor
The V680-HAM91 and V680-HAM81 can be used right away to create an RFID System with operation
as easy as with regular Sensors. Start operation simply by setting the mode switch on the ID Flag
Sensor to output the read results to the I/O interface.
Advanced Line Management
In accessing RF Tag data, up to 64,000 IDs are possible with 16-bit data. And, using the address shift
function enables accessing up to 128 bits, making it possible to build advanced lines.
Conforms to International Standards of ISO/IEC 18000-3 (ISO/IEC 15693)
Compliance with international standards enables the V680 to be exported to and used in the world's
main countries.
RF Tags Available with EEPROM or FRAM
Two types of RF Tag memory are available: EEPROM, with a maximum heat resistance of 180°C
(30 min./200 cycles) and a capacity of 1,000 bytes, and FRAM, with a capacity of 2, 8, or 32 kilobytes,
and long memory life of 10 billion accesses. Chose the ideal type for various worksite applications.
Smooth Replacement of Previous RFID Systems
All functions of the previous V600 Series are supported, so assets on existing lines can still be used.

11
RFID System
User's Manual
Section 1 System Configuration
Section 1
Product Overview
System Configuration
The ID Flag Sensor is connected to a Programmable Controller or wire-reduction device using I/O Interface.
The ID Flag Sensor can be connected with a connector by using a optional interface cable. All of the various
V680-series Antennas and RF Tags can be used.
When embedding the V680-D1KP52MT, V680-D1KP53M, and V680-D2KF52M in a metal surface, please use the
V680-HS51 or -HS52 Antenna. It can not communicate with the V680-HS63 Antenna.
V680-A60 2 m
5 m
10 m
Host
Interface Cable Terminal block wiring
Connector connection
ID Flag Sensor
Antenna V680-HS52-R
V680-HS52-W V680-HS63-R
V680-HS63-W V680-HS65-R
V680-HS65-W
Connector connection
V680-D1KP52MT
V680-D2KF52M V680-D1KP66T
V680-D1KP66MT
V680-D1KP66T-SP
V680-D2KF67
V680-D2KF67M
V680-D8KF67
V680-D8KF67M
Wireless Communications
V680-D8KF68
V680-D32KF68
RF Tags
Programmable Controllers,
Link Terminal (B7A),
I/O Relay Terminal etc.
V680-HS51
V680-HAM81
V680-HAM91
Sensor Controller
V680-D1KP53M
V680-D1KP52M-BT01
V680-D1KP52M-BT11
V680-D2KF52M-BT01
V680-D2KF52M-BT11
V680-D1KP58HTN

12
Section 1 System Configuration
RFID System
User's Manual
Section 1
Product Overview
MEMO

Section 2 Names and Functions of Components
13
RFID System
User's Manual
Section 2
Names and Functions of Components
ID Flag Sensor 14
Antennas 21
RF Tags 22

14
Section 2 ID Flag Sensor
RFID System
User's Manual
Section 2
Names and Functions of Components
ID Flag Sensor
Interface Connector : CN2
Connect to Inputs.
Note. Please use the optional Interface Cable(Optional).
Mode Switches
IF Flag Sensor Operation Mode setting switches.
Interface Connector : CN1
Connect to 24VDC power, INHIBIT/TRIG Input and Outputs.
Recommended Power Supply : S8VS-03024(OMRON)
Note. Please use the Interface Cable(Optional).
State Indicator LED
RUN : ID Flag Sensor Status(Green)
T/R : RF Tag communications status(Yellow)
NORMAL/ERROR : IF Flag Sensor operation result(Green/Red)
READ/WRITE : READ or WRITE operation status(Green/Yellow)
VERIFY OK/NG : Verify Read operation result(Green/Red)
Data Display LED
Date Display(Green)
Error Code Display(Red)
Noise Level Display (Green)
•Access Mode Setting Switch : Set the access mode to the RF Tags.
•Output Mode Setting Switch : Set the output mode and output time.
•Read Mode Setting Switch : Set the read operation mode.
•Write Mode Setting Switch : Set the write operation mode.
Antenna Connector
Connects to V680-series Antennas.
Access Address Setting
Set the access address to the RF Tag in hexadecimal notation (0000 hex to
FFFF hex)

15
RFID System
User's Manual
Section 2 ID Flag Sensor
Section 2
Names and Functions of Components
Status Indicator LED
RUN
The ID Flag Sensor status is displayed.
T/R
The communication status with the RF Tags is displayed.
NORMAL ERROR
The ID Flag Sensor operation result is displayed.
READ/WRITE
The Read or Write operation mode is displayed.
VERIFY OK/NG
The Verify Read operation result is displayed.
Data Display LED
The Data Display LED show the 16 bits of data that was read or
written when communication complete normally, and show the
Error Code when error was occurred. It also show the Noise Level
when measured the noise level.
Status Definition
Lit green Normal
Not lit No power supply or Fatal error.
Status Definition
Lit yellow Communicating with RF Tag , Measuring Noise level.
Not lit Standby
Status Definition
Lit green Normal Completion
Lit red Error occurred
Not lit Standby
Status Definition
Lit green Read operation
Lit yellow Write operation
Not lit Standby or Noise check operation
Status Definition
Lit green Verification result is matched.
Lit red Verification result is mismatched.
Not lit Standby
Status Definition
Lit green Data ( Read, Write, Noise Level )
Flashing
red/Lit red Error Code
Not lit Standby

16
Section 2 ID Flag Sensor
RFID System
User's Manual
Section 2
Names and Functions of Components
I/O Connector CN1
CN1 connects to 24 VDC, INHIBIT/TRIG input and all other Outputs.
Note1: Wire colors are for the V680-A60 Interface Cable (sold separately).
2: ERR Output is OFF active. It turns ON after Powered-up correctly. It can use as checking
output for powering up the product.
Pin Name Wire colors
(See Note1.) Description I/O
1 FG FG line FG ground terminal FG
2 Not used. --- --- ---
3 Not used. --- --- ---
4 NOISE_OUT Gray/Red ON when checking noise Output
5 0 V Blue 24-VDC power supply GND line Power supply
6 24 VDC Brown 24-VDC power supply input line Power supply
7 PARITY Gray/White Parity check output (Even: OFF, Odd: ON) Output
8 INHIBIT/TRIG Red Inhibit input for auto modes 1, 2, and 3
Trigger input for trigger modes 1, 2, and 3 Input
9 NORMAL/STRB Light green Normal read completion output in Read Mode
Output for verification results in Verify Mode
Normal write completion output for Write Mode
Strobe output when Read Mode is set to Wire-saving Mode
Output
10 ERR Purple Error output (OFF: active) (See Note2.) Output
11 OD9 White/Red Read data output bit 10 Output
12 OD8 White/Black Read data output bit 9 Output
13 OD11 White/Yellow Read data output bit 12 Outpu
14 OD10 White/Green Read data output bit 11 Output
15 OD13 White/Blue Read data output bit 14 Output
16 OD12 White/Brown Read data output bit 13 Output
17 OD15 Gray/Black Read data output bit 16 Output
18 OD14 White/Orange Read data output bit 15 Output
19 OD1 Yellow Read data output bit 2 Output
20 OD0 Green Read data output bit 1
Match output in Verify Mode Output
21 OD3 Black Read data output bit 4 Output
22 OD2 White Read data output bit 3 Output
23 OD5 Orange Read data output bit 6 Output
24 OD4 Gray Read data output bit 5 Output
25 OD7 Pink Read data output bit 8
Mismatch output in Verify Mode Output
26 OD6 Light blue Read data output bit 7 Output
I/O connector : CN1
Triangle mark
ID Flag Sensor connectors viewed from mating side
MIL-compliant Connector (MIL-C-83503)
(Applicable Connector: OMRON XG4A-2639-A)
2
1
26
25

17
RFID System
User's Manual
Section 2 ID Flag Sensor
Section 2
Names and Functions of Components
I/O Connector CN2
CN2 connects to Input signals except for INHIBIT/TRIG.
Note: Wire colors are for the V680-A60 Interface Cable (sold separately).
This connector is not required if data will not be written to RF Tags or the address shift function and noise check function
will not be used.
Pin No.. Name Wire colors
(See Note.) Description I/O
1 FG FG line FG ground terminal FG
2 Not used. --- --- ---
3 Not used --- --- ---
4 Not used Gray/Red --- ---
5R
/W Blue Read/write mode switching input (Read: OFF, Write: ON) Input
6 NOISE_IN/WRITE
PROTECT Brown Noise check mode setting input (Noise check : ON in Read mode)
Write protect enable/disable input (Enabled : OFF, Disabled : ON in Write mode)
Input
7 ADR2 Gray/White Address shift input bit 2 Input
8 Not used Red --- Input
9 ADR0 Light green Address shift input bit 0 Input
10 ADR1 Purple Address shift input bit 1 Input
11 ID9 White/Red Write data input bit 10 in Write Mode.
Verify data input bit 10 in Verify Mode Input
12 ID8 White/Black Write data input bit 9 in Write Mode
Verify data input bit 9 in Verify Mode Input
13 ID11 White/Yellow Write data input bit 12 in Write Mode
Verify data input bit 12 in Verify Mode Input
14 ID10 White/Green Write data input bit 11 in Write Mode
Verify data input bit 11 in Verify Mode Input
15 ID13 White/Blue Write data input bit 14 in Write Mode
Verify data input bit 14 in Verify Mode Input
16 ID12 White/Brown Write data input bit 13 in Write Mode
Verify data input bit 13 in Verify Mode Input
17 ID15 Gray/Black Write data input bit 16 in Write Mode
Verify data input bit 16 in Verify Mode Input
18 ID14 White/Orange Write data input bit 15 in Write Mode
Verify data input bit 15 in Verify Mode Input
19 ID1 Yellow Write data input bit 2 in Write Mode
Verify data input bit 2 in Verify Mode Input
20 ID0 Green Write data input bit 1 in Write Mode
Verify data input bit 1 in Verify Mode Input
21 ID3 Black Write data input bit 4 in Write Mode
Verify data input bit 4 in Verify Mode Input
22 ID2 White Write data input bit 3 in Write Mode
Verify data input bit 3 in Verify Mode Input
23 ID5 Orange Write data input bit 6 in Write Mode
Verify data input bit 6 in Verify Mode Input
24 ID4 Gray Write data input bit 5 in Write Mode
Verify data input bit 5 in Verify Mode Input
25 ID7 Pink Write data input bit 8 in Write Mode
Verify data input bit 8 in Verify Mode Input
26 ID6 Light blue Write data input bit 7 in Write Mode
Verify data input bit 7 in Verify Mode Input
I/O connector : CN2
Triangle mark
ID Flag Sensor connectors viewed from mating side
MIL-compliant Connector (MIL-C-83503)
(Applicable Connector: OMRON XG4A-2639-A)
2
1
26
25

18
Section 2 ID Flag Sensor
RFID System
User's Manual
Section 2
Names and Functions of Components
Mode Setting Switches
Access Mode Setting Switch
Use this switch to set the communications mode for communications with RF Tags.
Output Mode Setting Switch
Use this switch to set the output mode and output time width.
Note. TRIGGER MODE 1 is not influenced the OUTPUT MODE settings. Set the OUTPUT mode switch either from "0" to "9".
The setting of the mode setting switch is read only when the power supply is turned ON. Therefore, settings cannot be
changed while the power is being supplied. Turn OFF the power supply before changing the settings.
No. Name Remarks
0 SYNC1 TRIGGER MODE 1 : The ID Flag Sensor starts to communicate with RF Tags when the trigger signal inputs. p.56
1AUTO1
AUTO MODE 1 : The ID Flag Sensor starts to communicate with RF Tags automatically when the RF Tag comes
in the communication area.
p.60
2 SYNC2
TRIGGER MODE 2 : Functional compatible mode with V600 series (V600-HAM91/-HAM81/-HAR91/-HAR81) p.175
3AUTO2
AUTO MODE 2 : Functional compatible mode with V600 series (V600-HAM91/-HAM81/-HAR91/-HAR81) p.178
4 SYNC3
TRIGGER MODE 3 : Functional compatible mode of V600 series (V600-HAR92) p.181
5AUTO3
AUTO MODE 3 : Functional compatible mode of V600 series (V600-HAR92) p.183
6NOISE
CHECK
NOISE MEASURING MODE : The maintenance mode to measure the environmental noise level. p.63
7 ---
Setting Prohibit
(The ID Flag Sensor indicates Settings Error.)
8
9
No. Setting Setting Combination with the access mode
0 10 ms OFF DELAY 10 ms OFF delay Auto Mode 1, Auto Mode 3, or Trigger Mode 3
Note: A mode setting error will occur if one of the above
access modes is not set.
1 50 ms OFF DELAY 50 ms OFF delay
2 500 ms OFF DELAY 500 ms OFF delay
3 10 ms 10 ms output Auto Mode 2 or Trigger Mode 3
Note: A mode setting error will occur if one of the above
access modes is not set.
4 50 ms 50 ms output
5 CONTINUOUS Continuous output
6 --- Setting prohibited : except for Trigger Mode1(See Note.)
(The ID Flag Sensor indicates Settings Error.)
7
8
9
Refer to the following figure for a set position of the Setting Switch.
Cutting edge
Example) When it sets "1".
Refer to the following figure for a set position of the Setting Switch.
Cutting edge
Example) When it sets "1".
