E3X-DA-N
A-419E3X-DA-N
Digital Fiber Amplifier
E3X-DA-N
Truly ultimate fiber amplifier
in pursuit of "user friendliness"
and "high performance"
UL991*
Features
Reducing power line wiring meaning
space is saved. New design for easier
maintenance.
The connector type that uses the wire-saving connector sup-
plies power to the single-conductor slave connectors via the
three-conductor master connector. Hence, the following three
has been made possible.
1. Wiring is much simpler.
2. Relay connectors are not required meaning that space is used
more efficiently and costs are reduced.
3. Simple inventory control because of no differentiation between
master and slave in the amplifier section.
Super digital display by use of the Auto
Power Control (APC) circuit
The incident level of LEDs used in sensors is prone to deteriorate
with time and as a result, detection becomes unstable.
Using the APC (auto power control) circuit for the first time as the
fiber sensor, the E3X-DA-N series has no digital value variations,
realizing severe detection.
This makes the E3X-DA-N ideal for applications where a high de-
gree of sensitivity is required, such as detecting crystal glass.
Industry First Patent pending
Master Connector
New Connector Design
Power supply pin
Slave Connector
Up to 16 Amplifiers
can be connected together.
Optical
commu-
nications
Industry First
Incident level
Time
Threshold
3000
Detection becomes unstable
Incident level
Time
Threshold
3000
Stable detection
Conventional
Digital Fiber
Amplifiers
E3X-DA-N Series
* UL-listed including UL991 tests/evaluations Applicable standard: UL3121-1 Standards for additional tests/evaluations
for applications: UL991, SEMI S2-0200

A-420 Advanced Photoelectric Sensors
Power consumption reduced by 70%.
Power consumption has been
reduced up to about 70%
from 1800 mW to 600 mW. (If
the digital display is off)
The digital display can be changed to full-
OFF or Dark-ON during RUN.
Power consumption can be reduced by setting the display to Full-
OFF/Dark-ON in applications where the digital display is rarely
looked at during RUN.
(Can be set at the Mobile Console only)
Beeper-sized, new-generation Mobile Console
unleashing the power of the ultimate fiber amplifier
Remote setting/adjustment function
Incident level and threshold can be displayed simultaneously.
Simultaneous turning possible using group teaching.
Differences in incident light avoided by group zero-reset.
Sensor head flashing during Amplifier operation
Alternatively, the amplifier channel can be displayed.
Previous models E3X-DA-N
(Digital display not lit)
600mW
1800mW
This ECO label is indicated on
products that meet the environmental
standards established by OMRON.
Eco mode
Setting/teaching/fine adjustment can
be made at the fiber front-end.
The Mobile Console has enabled
setting and teaching at the fiber
front-end, which could only be
made at the amplifier. You can
perform major adjustments while
looking at the work position, etc.
Head
Function indicator
Incident level monitor
Channel settings
Threshold display
Operation keys
Battery monitor
Optical
communications
1ch
2ch
3ch
4ch
5ch
New
Concept
Patent
pending
While teaching had to be
performed for each Amplifier
separately, it can now be
performed for several Ampli-
fiers at once using the Mo-
bile Console.
The incident levels of sever-
al amplifiers can be batch-
reset to zero by the group
zero-reset. This feature is
useful for reducing differenc-
es between the amplifiers.
Group teaching
If the amplifier being operat-
ed is away from the sensor
head, the sensor head can be
flashed or the amplifier chan-
nel can be displayed.

A-421E3X-DA-N
E3X-DA-N
Ordering Information
Amplifier units
Prewired
Connector type
Item Shape Control output Model
NPN output PNP output
Standard models ON/OFF output E3X-DA11-N E3X-DA41-N
Monitor-output models ·ON/OFF output
·Monitor output E3X-DA21-N E3X-DA51-N
Mark-detecting models (Blue LED)
ON/OFF output
E3X-DAB11-N E3X-DAB41-N
Mark-detecting models (Green LED) E3X-DAG11-N E3X-DAG41-N
Infrared models E3X-DAH11-N E3X-DAH41-N
Differential output type E3X-DA11D ---
Water-resistant models E3X-DA11V E3X-DA41V
Twin-output models E3X-DA11TW E3X-DA41TW
Item Shape Applicable Connector
(order separately) Control output Model
NPN output PNP output
Standard models Master E3X-CN11 ON/OFF output E3X-DA6 E3X-DA8
Slave E3X-CN12
Monitor-output models Master E3X-CN21 ·ON/OFF output
·Monitor-output E3X-DA7 E3X-DA9
Slave E3X-CN22
Mark-detecting models
(Blue LED)
Master E3X-CN11
ON/OFF output
E3X-DAB6 E3X-DAB8
Slave E3X-CN12
Mark-detecting models
(Green LED)
Master E3X-CN11 E3X-DAG6 E3X-DAG8
Slave E3X-CN12
Infrared models Master E3X-CN11 E3X-DAH6 E3X-DAH8
Slave E3X-CN12
Differential output type Master E3X-CN11
E3X-DA6D ---
Slave E3X-CN12
Water-resistant models
(M8 Connector)
XS3F-M421-40#-A
XS3F-M422-40#-A E3X-DA14V E3X-DA44V
Twin-output models
Master E3X-CN21
E3X-DA6TW E3X-DA8TW
Slave E3X-CN22

A-422 Advanced Photoelectric Sensors
Amplifier units Connectors (Order Separately) Note: Stickers for Connectors are included as accessories.
Sensor I/O Connectors (Order separately)
Mobile Console (Order Separately)
Item Shape Cable length No. of conductors Model
Master
connector
2 m
3E3X-CN11
4E3X-CN21
Slave con-
nector
1E3X-CN12
2E3X-CN22
Size Cable type Shape Cable length Model
M8 Standard cable
2 m
4 conductors
XS3F-M421-402-A
5 m XS3F-M421-405-A
2 m XS3F-M422-402-A
5 m XS3F-M422-405-A
Shape Model Remarks
(Set form)
E3X-MC11
Mobile Console with head, cable,
and AC adapter provided as ac-
cessories. Power supply provid-
ed by chargeable battery
E3X-MC11-C1 Mobile Console
E3X-MC11-H1 Head
E39-Z12-1 Cable (1.5 m)
Straight
connector
L-shaped
connector
In general, amplifier units and connectors are sold separately.
Refer to the following tables for order placement.
When using 5 sets
amplifier units Applicable Connector
(order separately)
Type NPN PNP Master
connector
Slave
connector
Standard models E3X-DA6 E3X-DA8
+
E3X-CN11 E3X-CN12
Mark-detecting models
E3X-DAB6 E3X-DAB8
E3X-DAG6 E3X-DAG8
Infrared models E3X-DAH6 E3X-DAH8
Differential
output E3X-DA6D ---
Monitor-output models E3X-DA7 E3X-DA9 E3X-CN21 E3X-CN22
Twin-output models E3X-DA6TW E3X-DA8TW
amplifier units (5 Units) +1 Master Connector + 4 Slave
Connectors

A-423E3X-DA-N
E3X-DA-N
Rating/Performance
Amplifier units
Prewired
Type Standard
models
Monitor-out-
put models Mark-detecting models Infrared models
Water-resis-
tant models
Twin-output
models
Model NPN
output E3X-DA11-N E3X-DA21-N E3X-DAB11-N
E3X-DAG11-N E3X-DAH11-N E3X-DA11V E3X-DA11TW
Item
PNP
output E3X-DA41-N E3X-DA51-N E3X-DAB41-N
E3X-DAG41-N E3X-DAH41-N E3X-DA41V E3X-DA41TW
Light source
(wave length) Red LED (660 nm) Blue LED (470 nm)
Green LED
(525 nm)
Infrared LED
(870 nm) Red LED (660 nm)
Power supply voltage 12 to 24 VDC ±10%, ripple (p-p) : 10% max.
Power consumption
Normal: Power consumption 960 mW max. (power consumption 40 mA max. at supply voltage 24 V) Eco
mode: Power consumption 720 mW max. (power consumption 30 mA max. at supply voltage 24 V) Digital
display OFF: Power consumption 600 mW max. (power consumption 25 mA max. at supply voltage 24 V)
Con-
trol
output
ON/OFF output Load current 50 mA (residual voltage NPN/PNP: 1 V max. each) Open collector output type (depends on the
NPN/PNP output format) Light-ON/Dark-ON, switch selectable
Monitor output ---
1 to 5 VDC,
load 10 k
min.
---
Protective circuits Reverse polarity protection, output short-circuit protection, mutual interference prevention (possible for up to
10 amplifiers)
Re-
spons
e time
Super-high-
speed mode: 0.25 ms for operation and reset respectively
0.5 ms for
operation
and reset
respectively
Standard mode: Operation/reset: 1 ms each
2 ms for
operation
and reset
respectively
Super-long-dis-
tance mode: 4 ms for operation and reset respectively
7 ms for
operation
and reset
respectively
Sensitivity setting Teaching or manual method
Func-
tions
Timer functions OFF delay 0 to 200 ms (1 to 20: 1 ms increments, 20 to 200 ms: 5 ms increments), when the Mobile Control
is used, select either OFF delay, ON delay or one shot.
Automatic pow-
er control (APC)
Fiber-optic current digital con-
trol --- Fiber-optic current digital control
Zero reset Yes (negative indication possible)
Initial reset Yes (setting conditions initialized)
Monitor focus ---
Upper and
lower limit val-
ues of output
range can be
set per digital
value of 100
---
Indicator lamp
Operation indicator (orange), 7-segment digital incident level display (red), 7-segment digital incident level
percent display (red), incident level & threshold value double-bar display (green, red), 7-segment digital
threshold value display (red)
Display timing Normal/peak hold/bottom hold selectable
Display direction Normal/reverse selectable
Optical axis adjustment
function Yes (hyper flashing emission function)
Ambient lighting Incandescent lamp: 10,000 lux max. Sunlight 20,000 lux max.
Ambient temperature Operating: Groups of 1 to 3 amplifiers: -25 to +55°C, Groups of 4 to 11 amplifiers: -25 to +50°C, Groups of
12 to 16 amplifiers: -25 to +45°C Storage: -30 to +70°C (with no icing and condensation)
Ambient humidity Operating/Storage: 35% to 85% RH (with no condensation)

A-424 Advanced Photoelectric Sensors
Connector type
Specifications that differ from those of the prewired type
* For waterproof type only, voltage resistance is 500 VAC 50/60 Hz 1 min
Insulation resistance 20 M min. at 500 VDC
Dielectric strength 1,000 VAC at 50/60 Hz for 1 minute
Vibration resistance 10 to 55 Hz, 1.5 mm double amplitude for 2 hours each in X, Y, and Z directions
Shock resistance Destruction: 500 m/s2 for 3 times each in X, Y, and Z directions
Degree of protection IEC 60529 IP50 (with Protective Cover attached)
lEC 60529
IP66 (with
protective
cover at-
tached)
IEC 60529
IP50 (with
protective
cover
attached)
Connection method Prewired models (standard length: 2 m)
Weight (Packed state) Approx. 100 g Approx. 110 g Approx. 100 g
Mate-
rial
Case PBT (polybutylene terephthalate)
Cover Polycarbonate Polyethersul-
fone
Accessories Instruction manual
Type Standard
models
Monitor-out-
put models Mark-detecting models Infrared models
Water-resis-
tant models
(See note.)
Twin-out-
put models
Model NPN
output E3X-DA6 E3X-DA7 E3X-DAB6 E3X-DAG6 E3X-DAH6
E3X-DA14V E3X-DA6TW
Item PNP
output E3X-DA8 E3X-DA9 E3X-DAB8 E3X-DAG8 E3X-DAH8
E3X-DA44V E3X-DA8TW
Connection method Connector type M8 connector Connector
Weight (Packed state) Approx. 55 g 65 g Approx. 55 g
Type Standard
models
Monitor-out-
put models Mark-detecting models Infrared models
Water-resis-
tant models
Twin-output
models
Model NPN
output E3X-DA11-N E3X-DA21-N E3X-DAB11-N
E3X-DAG11-N E3X-DAH11-N E3X-DA11V E3X-DA11TW
Item
PNP
output E3X-DA41-N E3X-DA51-N E3X-DAB41-N
E3X-DAG41-N E3X-DAH41-N E3X-DA41V E3X-DA41TW
Amplifier unit Connectors
Item Model E3X-CN11/21/22 E3X-CN12
Rated current 2.5 A
Rated voltage 50 V
Contact resistance
20 m max. (20 mVDC max., 100 mA max.) [By connection with
amplifier unit and connection with adjacent connector
(except conductor resistance of cable)]
No. of insertions 50 times (By connection with amplifier unit and connection with ad-
jacent connector)
Material Housing PBT (polybutylene terephthalate)
Contacts Phosphor bronze/gold-plated nickel
Weight
(Packed state) Approx. 55 g Approx. 25 g
Mobile Console
Item Model E3X-MC11
Supply volt-
age Charged with AC adapter
Connection
method Connected via adapter
Weight
(packed state)
Approx. 580 g (Console
only: 120 g)
For details of the Mobile Console, refer
to the instruction manual attached to the
product.

A-425E3X-DA-N
E3X-DA-N
Digital Fiber Amplifier
* Differential output digital fiber amplifier (E3X-DA11D/E3X-DA6D)
Applicable fiber unit characteristic
(Through-beam model)
Note: Refer to E3X-DA-N for the note of the fiber unit.
Sensing distance (mm) (Values in parentheses: When using the E39-F1 lens unit)
Standard object (mm) *1
Minimum sensing object
*2 (Opaque object) de-
fault
*1. The sensing object is operating.
*2. Value applied when the response time is set to 3-11. The value can be detected if the temperature varies within the operating ambient temperature. (Value when
the sensing object is operating)
Sensitivity
switching HIGH LOW
11 steps can be
set 1 2 3-11 1 2
3-11
Fiber type
Re-
sponse
time
270 or
570 s
0.5 or 1 ms
1 to 200 ms or 2
to 400 ms
270 or
570 s
0.5 or 1 ms
1 to 200 ms or 2
to 400 ms
E32-ET11R 240 (1680) 280 (1960) 370 (2590) 140(980) 180(1260) 240 (1680) 1 mm dia. (0.01
mm dia.)
E32-ET21R 50 60 80 30 40 50
E32-T16WR 580 690 910 350 450 580 (0.3 mm dia.)*3
*3. The digital value is 1000 and the value can be detected in each detection area.
Refer to the E3X-DA-N for the note of the fiber unit.
(Reflective model)
E32-T16PR 380 450 600 230 290 380 (0.2 mm dia.)
Sensing distance (mm)*1
*1. Sensing distance indicates values for white paper.
Standard object (mm) *2
Minimum sensing object
*3 (Opaque object) de-
fault
*2. The sensing object is operating.
*3. Value applied when the response time is set to 3-11. The value can be detected if the temperature varies within the operating ambient temperature. (Value when
the sensing object is operating)
Sensitivity
switching HIGH LOW
11 steps can be
set 1 2 3-11 1 2
3-11
Fiber type
Re-
sponse
time
270 or
570 s
0.5 or 1 ms
1 to 200 ms or 2
to 400 ms
270 or
570 s
0.5 or 1 ms
1 to 200 ms or 2
to 400 ms
E32-ED11R 80 90 120 45 60 80
150 x 150 (0.01
mm dia.)
E32-ED21R 13 15 20 7 10 13 25 x 25 (0.01 mm
dia.)

A-426 Advanced Photoelectric Sensors
Differences from E3X-DA-N amplifier unit
Differential output type (edge detection type)
Item Prewiring type amplifier units with Connectors
Item NPN output E3X-DA11D E3X-DA6D
Power consumption Power consumption 960 mW max. (at power supply voltage 24 V, power consumption 40 mA max.)
Con-
trol
out-
put
ON/OFF output Load current 50 mA (residual voltage NPN/PNP: 1 V max. each) Open collector output type L.ON (ON at edge
detection)/D.ON (OFF at edge detection) switch selectable
Detection mode One-side edge detection mode/both-side edge detection mode
Response time One-side edge detection mode: 270/500 s/1/2/4/10/20/30/50/100/200 ms selectable Both-side edge detection
mode: 570 s/1/2/4/10/20/30/50/100/200/400 ms selectable
Func
tions
Timer function OFF delay timer for L.ON ON delay timer for D.ON 0 to 5 s (1 to 20 ms: 1 ms increments, 20 to 20 ms: 5 ms
increments, 200 ms to 1 s: 100 ms, 1 to 5 s: 1 s increments)
APC Yes
Zero reset Yes (negative indication)
Initial reset Yes (setting conditions initialized)
Sensitivity
switching Yes (HIGH/LOW)
Teaching level One-point teaching level 1 to 50% variable (1% increments)
Indicator lamp Operation indicator (orange), 7-segment incident level display (red), 7-segment digital edge detection level dis-
play (red)
For the outline drawings and other details, refer to the instruction manuals attached to the products.

A-427E3X-DA-N
E3X-DA-N
Output Circuit Diagram
NPN output
Note: With E3X-DA#TW models, only channel 1 is output when set for area sensing operation.
L ON The range between the CH1 and CH2 thresholds turns ON
D ON The range between the CH1 and CH2 thresholds turns OFF (CH2 is always OFF)
Model Output transistor
Status Timing chart Mode selection switch Output circuit
E3X-DA11-N
E3X-DAB11-N
E3X-DAG11-N
E3X-DAH11-N
E3X-DA11V
E3X-DA6
E3X-DAB6
E3X-DAG6
E3X-DAH6
E3X-DA14V
Light ON LON
(LIGHT ON)
Dark ON DON
(DARK ON)
E3X-DA21-N
E3X-DA7
Light ON LON
(LIGHT ON)
Dark ON DON
(DARK ON)
E3X-DA11TW
E3X-DA6TW
Light ON LON
(LIGHT ON)
Dark ON DON
(DARK ON)
Incident light
No incident light
ON
OFF
ON
OFF
Operate
Release
Operation
Indicator
(orange)
(Between brown and black)
Output
transistor
Load
(relay)
T
Main
circuit
Load
Operation Indicator
(orange) Brown
1
3
4Black
Blue
Control output 12 to 24
VDC
Display
Connector Pin Arrangement
Note: Pin 2 is not used.
1
24
3
T
Incident light
No incident light
ON
OFF
ON
OFF
Operate
Release
Operation
Indicator
(orange)
(Between brown and black)
Output
transistor
Load
(relay)
Incident light
No incident light
ON
OFF
ON
OFF
Operate
Release
Operation
Indicator
(orange)
(Between brown and black)
Output
transistor
Load
(relay)
T
Main
circuit
Load
Load
Operation Indicator
(orange) Brown
Black
Control output
Orange
Blue
Monitor output
1 to 5V
12 to 24
VDC
(see
note)
Note: Load resistance: 10Wmin.
47W
Display
Incident light
No incident light
ON
OFF
ON
OFF
Operate
Release
Operation
Indicator
(orange)
(Between brown and black)
Output
transistor
Load
(relay)
T
Incident light
No incident light
ON
OFF
ON
OFF
Operate
Release
Operation
Indicator
(orange)
(Between brown and black)
Output
transistor
Load
(relay)
T
CH1/
CH2
Main
circuit
Load
Load
Operation Indicator
(orange) Brown
Black
Control output 1
Control output 2
Orange
Blue
12 to 24
VDC
Operation
Indicator
(orange)
Display
T
Incident light
No incident light
ON
OFF
ON
OFF
Operate
Release
Operation
Indicator
(orange)
(Between brown and black)
Output
transistor
Load
(relay)
CH1/
CH2

A-428 Advanced Photoelectric Sensors
PNP output
Note: With E3X-DA#TW models, only channel 1 is output when set for area sensing operation.
L ON The range between the CH1 and CH2 thresholds turns ON
D ON The range between the CH1 and CH2 thresholds turns OFF (CH2 is always OFF)
Connectors (Sensor I/O Connectors)
Model Output transis-
tor Status Timing chart Mode selection switch Output circuit
E3X-DA41-N
E3X-DAB41-N
E3X-DAG41-N
E3X-DAH41-N
E3X-DA41V
E3X-DA8
E3X-DAB8
E3X-DAG8
E3X-DAH8
E3X-DA44V
Light ON LON
(LIGHT ON)
Dark ON DON
(DARK ON)
E3X-DA51-N
E3X-DA9
Light ON LON
(LIGHT ON)
Dark ON DON
(DARK ON)
E3X-DA41TW
E3X-DA8TW
Light ON LON
(LIGHT ON)
Dark ON DON
(DARK ON)
T
Incident light
No incident light
ON
OFF
ON
OFF
Operate
Release
Operation
Indicator
(orange)
(Between blue and black)
Output
transistor
Load
(relay)
Main
circuit
Load
Operation Indicator (orange) Brown
1
4
3
Control output
Black
Blue
12 to 24
VDC
Display
Connector Pin Arrangement
Note: Pin 2 is not used.
1
24
3
T
Incident light
No incident light
ON
OFF
ON
OFF
Operate
Release
Operation
Indicator
(orange)
(Between blue and black)
Output
transistor
Load
(relay)
T
Incident light
No incident light
ON
OFF
ON
OFF
Operate
Release
Operation
Indicator
(orange)
(Between blue and black)
Output
transistor
Load
(relay) Main
circuit Load
Load
Monitor output
1 to 5 V
Operation Indicator (orange) Brown
Control output
Black
Blue
Orange
12 to 24
VDC
47W
Note: Load resistance: 10kWmin.
Display
(see note)
T
Incident light
No incident light
ON
OFF
ON
OFF
Operate
Release
Operation
Indicator
(orange)
(Between blue and black)
Output
transistor
Load
(relay)
T
Incident light
No incident light
ON
OFF
ON
OFF
Operate
Release
Operation
Indicator
(orange)
(Between blue and black)
Output
transistor
Load
(relay)
CH1/
CH2
Main
circuit
Load
Load
Operation Indicator (orange)
Control
output 2
Control
output 1
Brown
Black
Orange
Blue
12 to 24
VDC
Operation
Indicator
(orange)
Display
T
ncident light
No incident light
ON
OFF
ON
OFF
Operate
Release
Operation
Indicator
(orange)
(Between blue and black)
Output
transistor
Load
(relay)
CH1/
CH2
Brown
White
Blue
Black
Color of cable
conductors
XS3F-M421-402A
XS3F-M421-405A
XS3F-M422-402A
XS3F-M422-405A
2
4
1
3
1
2
3
4
Note: Pin 2 is open.
Class Wire, outer
jacket color Connector pin No. Application
For DC
Brown APower sup-
ply (+V)
White B-
Blue CPower sup-
ply (0 V)
Black DOutput

A-429E3X-DA-N
E3X-DA-N
Characteristic data (default)
Connection
Connection with linear sensor controller K3NX-VD2#
Nomenclature:
amplifier units
Standard, monitor-output, mark-detecting, infrared, and
water-resistant models
Twin-output models
Hysteresis vs. sensing distance Repeated accuracy vs. sensing distance
Reflective model Reflective model
E32-D11L E32-DC200
Monitor output vs. distance
(In standard mode)
Through-beam Reflective model
E32-TC200 E32-DC200
30
25
20
15
10
5
0100 200 400300 500
Distance (mm)
Hysteresis (mm)
Super-
long-distance
Super-
high-speed
Standard
Sensing object: White paper
Distance Hysteresis
OFFON
100
90
80
70
60
50
40
30
20
10
020 40 8060 100
Distance (mm)
Repeat accuracy (mm)
Super-
long-distance
Standard
Sensing object: White paper
X
ON
Super-
high-
speed
6
5
4
3
2
1
050 100 150 250200 300
Distance (mm)
Monitor output (V)
6
5
4
3
2
1
010 3020 5040 60 9070 80 100
Distance (mm)
Monitor output (V)
0 V Blue
+V Brown
Monitor output Orange
E3X-DA-N 12 to 24
VDC
12 VDC, 80 mA *
K3NX-VD2#
123456789
10 11 12 13 14 15 16 17
*Use this service power supply for the Sensor with reference to
the power consumption of each Sensor.
Note: 1. Various I/O Units are available for the K3NX. Select an
appropriate output type depending on the application.
2. For details about the K3NX, refer to the K3NX Datasheet
(N084) or the K3NX Operation Manual (N90).
3. This wiring is for the K3NX, with DC power supply
specifications and the Monitor (Analog) Sensor with DC
power supply specifications. Check respective power
supply specifications before wiring them.
Level DisplayLock Button
Setting Buttons
TEACH
MODE
Operation Indicator (orange)
ON when output is ON.
OFF when output is OFF.
Operation Mode Selector
Use to switch between
Light ON and Dark ON modes.
Mode Selector
Use to select SET,
ADJ, or RUN mode.
Level DisplayLock Button
Setting Buttons
TEACH
MODE
Mode Selector
Use to select SET,
ADJ, or RUN mode.
Channel-selection Swit
c
Use to switch between
channel 1 and 2.
Operation Indicator (orange)
ON when output is ON.

A-430 Advanced Photoelectric Sensors
Operation
General
Digital incident level (4000 max.)
To reset to zero again:
Note: There is no limit on the number of times zero-reset can be used.
To return the initial digital incident level:
Hold down
both for 3 s.
*
Sensitivity increment
with threshold decrement
Sensitivity decrement
with threshold increment
Fine sensitivity adjustment
RUN mode
Digital incident level
Digital percent
Analog value
ADJ mode
Digital threshold
Digital Percent
Analog value
Select the channel to be
adjusted using the channel
selection switch.
Twin-output Models
Changing the Display (RUN Mode)
@ Manual Tuning (Fine Sensitivity Adjustment) in ADJ Mode
Perform fine sensitivity adjustment after teaching and manual tuning
(without using the teaching function) in the way shown below:
1Zero-reset (RUN Mode)
Set the mode selector
to .
RUN
2
Initial Reset (SET Mode)
Set the mode selector
to .
SET
3
The items displayed in ADJ mode vary with the display
setting in RUN mode.
1s
1s
2s
2s
2s
TEACH MODE
TEACH
TEACH MODE
TEACH
TEACH
RUN
RUN
ADJ
TEACH MODE
MODE
MODE
MODE
SET
CH1 CH2
MODE MODE
Set the mode selector
to .
(Factory-set to RUN)
RUN
Digital incident level (4000 max.)
Digital Percent
Analog incident level and threshold
Set the mode selector
to .
ADJ
Cancel Execute initial reset
Hold down
both for 5 s.

A-431E3X-DA-N
E3X-DA-N
TEACH
Sensing function Displayed as "F".
Standard
(factory-set)
Super-high speed
Super-long distance
OFF
(factory-set)
Peak
Bottom
Timer function Displayed as "t".
0
(Factory-set)
Adjustable in 1-ms units for
0 to 20 ms and in 5-ms units
for higher.
200
Flashing setting Displayed as "L".
OFF
(factory-set)
ON
Hold setting Displayed as "H".
Display orientation
setting
Reversing display
Standard
(factory-set)
Reverse
Digital incident level display
Setting upper
limit for monitoring
Alternates between
"A-UP" and setting value.
(Factory setting)
Note: It is not possible to set an upper limit
that is lower than the lower limit.
Setting lower
limit for monitoring
Alternates between
"A-LO" and setting value.
(Factory setting)
Note: It is not possible to set an lower limit
that is lower than the upper limit.
Available with: E3X-DA21-N
E3X-DA51-N
E3X-DA7
E3X-DA9
Monitor Focus
(A)(B)
(A)(B)
Setting Functions in SET Mode4
2s
2s
MODE
TEACH
TEACH
MODE
SET
TEACH
TEACH
2s
2s
TEACH
MODE
MODE
TEACH
TEACH
2s
TEACH
TEACH
TEACH
TEACH
MODE
TEACH
2s
TEACH
TEACH
MODE
Alternates
Alternates
In units of 100 from 4,000
TEACH
MODE
TEACH
TEACH
TEACH
TEACH
Alternates
Alternates
Alternates
In units of 100 from 0
Alternates
Alternates
TEACH
Alternates
Set the mode selector
to .
SET There are four different sensitivity settings. Refer to page AB- for
details.

A-432 Advanced Photoelectric Sensors
Twin-output models
TEACH
Setting the
operating mode Changing the operating mode
L ON
D ON
Sensing function Displayed as "F".
Standard (factory-set)
Area
Super-long distance
Super-high speed
Digital incident level display
OFF (Factory-set)
Peak
Bottom
Timer function Displayed as "t".
0(Factory-set)
Adjustable in 1-ms units for 0
to 20 ms and in 5-ms units
for higher.
200
Flashing setting Displayed as "L".
OFF (Factory-set)
ON
Hold setting Displayed as "H".
Reversing display
Standard (Factory-set)
Reverse
(Factory setting)
L ON
D ON
(Factory setting)
Setting Functions in SET Mode4
The operating mode for the channel set
with the channel-selection switch can be
changed.
SET
CH1 CH2
Changed using the channel-selection switch
Channel 1 Channel 2
2s
MODE
TEACH
TEACH
TEACH
TEACH
TEACHTEACH
@Area Sensing
Area sensing is possible using the threshold values
for channels 1 and 2.
· If channel 1 is set to L/ON, output turns ON when
the incident level is between the thresholds.
· If channel 1 is set to D/ON, output turns OFF
when the incident level is between the thresholds.
The result is output to control output 1.
(Control output 2 is always OFF.)
2s
2s
2s
TEACH
TEACH
TEACH
MODE
MODE
MODE
TEACH
TEACH
TEACH
TEACH
2s
TEACH
TEACH
MODE
Set the mode selector
to .
SET
(A)(B)
(A)(B)
Display orientation
setting
There are four different sensitivity settings. Refer to page AB- for
details.

A-433E3X-DA-N
E3X-DA-N
General
• The four types of teaching given below are available.
• Once setting is made, operation is performed in the preset status thereafter. When a teaching error occurs, the level indicators
flash in red. Restart setting from the beginning.
Maximum Sensitivity Setting
One-point without-object teaching
Note: If one-point teaching is not available because the difference in level is too
fine, try two-point teaching.
Operation Mode Selector
There is no operation mode selector for twin-output models.
Two-point With/Without-object Teaching
Note: With and without work may be in any order.
Pin-point teaching (for positioning)
When teaching is performed (SET mode)
SET
CH1 CH2
Twin-output models only Select the channel to be adjusted using the channel selection switch.
Set the mode selector to .
SET
Proce-
dure
Operation
1 Set the mode selector to SET.
2Press the TEACH button for 3
seconds min.
3
Setting is completed when the
red-lit level indicators turn to
green. Then they return to the
digital incident level display.
4 Set to RUN mode.
Proce-
dure
Operation
1 Set the mode selector to SET.
2Press the SET button once
(about 1 s).
3
Setting is completed when the
red level indicators are turned
ON. They then return to the digi-
tal incident level display.
4 Set to RUN mode.
5The threshold is automatically
set with the object.
Operating mode Operation
Light ON L ON
Dark ON D ON
SET
3s
TEACH
(red)
(green)
RUN
SET
1s
TEACH
(red)
RUN
Object
ON
Output
(Factory-set)
L
D
Proce-
dure
Operation
1Set the mode selector to SET.
2With the work present, press the
SET button once (about 1 s).
3The level indicators are lit red.
4If no work is pending, press the
SET button once (about 1 s).
5
Setting is completed when the
green indicators are turned ON.
Then they return to the digital in-
cident level display.
6Set to RUN mode.
Proce-
dure
Operation
1Set the mode selector to SET.
2If no work is pending, press the
SET button once (about 1 s).
3The level indicators are lit red.
4
Place the object in the desired
position, and press the TEACH
button for 3 seconds min.
5
Setting is completed when the
green indicators are turned ON.
Then they return to the digital in-
cident level display. (Red indica-
tors start flashing if setting is not
OK.)
6 Set to RUN mode.
SET
Object
1s
TEACH
(red)
1s
TEACH
(green)
RUN
SET
1s
TEACH
(red)
Object
3s
TEACH
(green)
RUN

A-434 Advanced Photoelectric Sensors
Precautions
Amplifier units
Design
Power ON
The sensor is ready to sense an object within 200 ms after turn-
ing the power ON. If the load and sensor are connected to differ-
ent power supplies, always turn on the sensor power first.
Mounting
Connection/removing of amplifier units
(Connection)
1. Install the units one by one to the DIN rail.
2. Slide one unit toward the other, match the clips at the front
ends, and then bring them together until they "click".
(Removing)
Slide one unit away from the other and remove them one by
one. (Do not remove the connected units together from the
DIN rail.)
Fitting of Mobile Console head
When fitting the Mobile Console head, a 20 mm or more clear-
ance is needed on the left side.
Use of Mobile Console
For the twin output type (E3X-DA##TW), up to 16 channels
(eight E3X-DA##TW units) can be set from the Mobile Con-
sole E3X-MC11. (Note that the operation mode and area de-
tection cannot be set.)
Adjustment
Mutual interference prevention function
The digital display value may vary due to the light from the
other sensor. In that case, low the sensitivity (raise the thresh-
old) to stabilize detection.
EEPROM Write Error
If a write error occurs (operation indicator starts flashing) due
to power-off, static electricity or other noise in the teaching
mode, perform teaching again.
Optical communication
When connecting the amplifier units, assemble them in close
contact. During operation, do not slide or dismantle the ampli-
fier units.
Hysteresis adjustment
The Mobile Console allows hysteresis adjustment, but note
that the unit may not operate properly if the hysteresis setting
is lower than the factory value.
Correct Use
Note:1 .When the amplifier units are connected to each other, the
operable ambient temperature changes depending on the
number of connected amplifier units. Check "Ratings/Per-
formance".
2 .Before connecting or removing the units, always switch
power off.
Click into
place
Clip
20mm

A-435E3X-DA-N
E3X-DA-N
Amplifier Unit Connectors
Installation
Connector installation
1. Insert the Master or Slave Connector into the amplifier unit
until it clicks into place.
2. Link amplifier units to each other after the master and slave
Connectors have been inserted.
3. Apply the supplied seal to the non-connecting surface of the
master/slave connector.
Note: Apply seal to the grooved side.
Removing Connectors
1. Slide the slave amplifier unit (s) on which the connector
must be removed from the rest of the group.
2. After the amplifier unit (s) has been separated, press down
the lever on the connector and remove it. (Do not attempt
to remove connectors without separating them from other
amplifier units first.)
Mounting End Plate (PFP-M)
Depending on the installation, an amplifier unit may move dur-
ing operation. In this case, use an end plate.
Before installing an end plate, remove the clip from the master
amplifier unit using a nipper or similar tool.
The sensor bottom is also equipped with a clip removing
mechanism.
1. Insert the clip to be removed into the slit underneath the clip
on another amplifier unit.
2. Remove the clip by rotating the amplifier unit.
When fitting the Mobile Console, set the end plate in the guide
as shown in the following figure.
Tensile stress for connectors (including cables)
E3X-CN11, E3X-CN21, E3X-CN22: 30 N max.
E3X-CN12: 12N max.
Insert
Sticker
Sticker
Remove
Lever
Press down
Clip
Rotate
End Plate

A-436 Advanced Photoelectric Sensors
Dimensions (Unit: mm)
Amplifier Units
8
10.7
Two,
2.4 dia. 10
17.15 44.9 x3 = 14.7
13.05
364.3
38.6
31.5
9.9
5.3
* 1. The Mounting Bracket can also be
used on side A.
* 2. E3X-DA11-N/DA41-N/DAB11-N:
A 4-dia., 3-conductor, vinyl-insulated
round cable (conductor cross-sectional area:
0.45 mm²; insulation diameter: 1.1 mm) is used.
E3X-DA21-N/DA51-N: A 4-dia., 4-conductor,
vinyl-insulated round cable (conductor cross-
sectional area: 0.2 mm²; insulation diameter:
1.1 mm is used.
Hole for
optical
communi-
cations
3.4
22.4 16
4.4
4.1
13 34.8
2.4
22.4 16
4
Two, 3.2 dia. holes Mounting Bracket (E39-L143)SUS304
stainless steel, sold separately
10.75
(A) * 1
16
2-M3
* 2
Operation Indicator
Incident level display
Threshold level display
With Mounting Blanket Attached
Mounting Holes
prewired
E3X-DA11-N E3X-DAG11-N E3X-DA21-N
E3X-DAH11-N E3X-DAB11-N E3X-DAB41-N
E3X-DA41-N E3X-DAG41-N E3X-DA51-N
E3X-DAH41-N E3X-DA11D
6.9
81.5
4.9 x 3=14.7
Operation indicator
Incident level display
Threshold level display
30.05
25.95
a*1
12
8
10.7
Two, 2.4 dia.
4.3
9.9
3.43.9
33
Hole for optical
communications
23.9
14.4
11.5 67.2
37
16
16
23.9
6.6
11.2
2.8
* 2
40
5.4
5.4
3.4
3.4
16
With Mounting Blacket Attached
2-M3
* 1. The mounting Bracket can also be used on side A.
* 2. 4-dia., 3-conductor, vinyl-insulated round cable
(conductor cross-sectional area: 0.2 mm²; insulation
diameter: 1.1 mm is used.
Mounting Bracket (E39-L148)
SUS304 stainless steel, sold separately
Mounting Holes
Amplifier units with Cables, Water-resistant Models
E3X-DA11V
E3X-DA41V

A-437E3X-DA-N
E3X-DA-N
8
10.7
Two, 2.4 dia.
10
17.15 4.9 x 3 = 14.7
13.05
364.3
38.6
31.5
9.9
5.3
Hole for
optical
communi-
cations
3.4
22.4 16
4.4
3.4
13 34.8
2.4
22.4 16
4
Two, 3.2 dia. holes Mounting Bracket (E39-L143)SUS304
stainless steel, sold separately
10.75
(A) * 1
* 1. The Mounting Bracket can also be used on side A.
* 2. A 4-dia., 4-conductor, vinyl-insulated round cable
(conductor cross-sectional area: 0.2 mm²; insulation
diameter: 1.1 mm) is used.
16
2-M3
* 2
Operation Indicator
Incident level display
Threshold level display
With Mounting Blanket Attached
Mounting Holes
Amplifier units with Cables, Twin-output Models
E3X-DA11TW
E3X-DA41TW
10 64.33
8
Two, 2.4 dia.
10.7
9.9
3.4
38.6
13
3.95.1
1.7
4.2
6.2 1.7
36.7
14
31.5
5.5
Hole for optical communications
1.8
13.05
Operation Indicator
Incident level display
Threshold level display
17.15 4.9 x 3 = 14.7
1.8
Connector type
E3X-DA6E3X-DAG6
E3X-DA7E3X-DAH6
E3X-DA8E3X-DAB8
E3X-DA9E3X-DAG8
E3X-DAB6E3X-DAH8
E3X-DA6D
1.5
31.5
1.8 5.1 3.9
12.95
4
10
64.3
67.5
71
E3X-CN11:
4.0 dia.
E3X-CN21:
4.0 dia.
64.3
67.5
71
1.5
31.5
1.8 5.1 3.9 34.8
12.95
E3X-CN12: 2.6 dia.
E3X-CN22: 4.0 dia.
11.55
17.45
4
10
Dimensions with Master Connector Connected Dimensions with Slave Connector Connected

A-438 Advanced Photoelectric Sensors
4.9 x 3 = 14.7
Operation Indicator
Incident level display
Threshold level display
30.05
25.95
* The Mounting Bracket can
also be on side A.
(A) * 1
12
8
10.7
Two,
2.4 dia.
4.3
9.9
3.43.9
33
Hole for
optical
communi-
cations
23.9
14.4
11.5 67.2
37
16
16
23.9
11
2.8 M8
40
5.4
5.4
3.4
3.4
16
With Mounting Bracket Attached
Two, M3
11.2
Mounting Bracket (E39-L148), Sold separately
SUS304 stainless steel
6.9
81.5
Amplifier Units M8 Connectors,
Water-resistant Models
E3X-DA14V
E3X-DA44V
10 64.33
8
Two, 2.4 dia.
10.7
9.9
3.4
38.6
13
3.95.1
1.7
4.2
6.2 1.7
36.7
14
31.5
5.5
Hole for optical
communications
1.8
13.05
Incident level display
Threshold level display
Operation Indicator
17.15 4.9 x 3 = 14.7
1.8
Amplifier units with Standard Connectors,
Twin-output Models
E3X-DA6TW
E3X-DA8TW
1.5
31.5
1.8 5.1 3.9
12.95
4
10
64.3
67.5
71
E3X-CN21:
4.0 dia.
64.3
67.5
71
1.5
31.5
1.8 5.1 3.9 34.8
12.95
E3X-CN22: 4.0 dia.
11.55
17.45
4
10
Dimensions with Master Connector Connected Dimensions with Slave Connector Connected
