Omron HEM-637 User manual

Instruction Manual
Wrist Blood Pressure Monitor
with Advanced Positioning
Sensor (APS)
Model HEM-637
Thank you for purchasing the
Omron Wrist Blood Pressure Monitor with APS.

2
Contents
Introduction ……………………………………………………………………… 3
Know Your Unit ……………………………………………………………… 4, 5
Suggestions Before Measuring Blood Pressure ………………………………… 6
Initial Set-Up
Battery Installation / Replacement ……………………………………… 7, 8
Automatic Memory Setting ………………………………………………… 9
Advanced Positioning Sensor (APS) Setting ……………………………… 10
Wrist Selection Setting …………………………………………………… 11
Alarm Setting ………………………………………………………… 12, 13
Date and Time Setting ………………………………………………… 14, 15
How to Reset this Monitor ………………………………………………… 16
Correct Usage
How to Apply the Wrist Cuff …………………………………………… 17
How to Wrap the Wrist Cuff ……………………………………………… 18
How to Measure Blood Pressure ……………………………………… 19-21
How to Use the Memory Function ………………………………………… 22
Memory Reset Function …………………………………………………… 23
How to Use the Graph Function ……………………………………… 24, 25
Troubleshooting ……………………………………………………………… 26
Care and Maintenance ………………………………………………………… 27
Caution ………………………………………………………………………… 28
Specifications…………………………………………………………………… 29
Warranty ……………………………………………………………………… 30
Notes …………………………………………………………………………… 31

3
Introduction
Thank you for purchasing the Omron HEM-637 Wrist Blood Pressure Monitor
with Advanced Positioning Sensor (APS). This remarkable instrument is ideal
for people who frequently monitor their own blood pressure because it’s so
compact and easy to use. There is no tricky arm cuff, just a small, pre-formed
wrist cuff that is easy to apply. With the push of a button the Omron Wrist
Monitor measures your blood pressure and pulse and displays the reading
on a clear digital panel. Perfect for quick, easy readings at home, at work,
and while traveling.
The Omron Wrist Monitor uses the oscillometric method of blood pressure
measurement. This means the monitor detects your blood’s movement through
the artery in your wrist and converts the movements into a digital reading.
An oscillometric monitor does not need a stethoscope so the monitor is simple
to use and measurements are easy to obtain.
Clinical research has proven a direct relationship between blood pressure
in the wrist and blood pressure in the arm. Changes in wrist blood pressure
reflect changes in arm blood pressure because the arteries in the wrist
and the arm connect. Frequently measuring the blood pressure in your
wrist will provide you and your doctor with an accurate indication
of changes in your true blood pressure.
Please read this instruction manual thoroughly before
operating the Omron Wrist Blood Pressure Monitor with
Advanced Positioning Sensor (APS) to assure proper use.
For specific information on your own blood pressure,
CONTACT YOUR PHYSICIAN.

4
Know Your Unit
Battery Cover
Insert the batteries.
Wrist Cuff
Wrap the wrist cuff
over your wrist snugly.
Main unit
Two AAA Alkaline
batteries (LR03)
Carrying Case
Blood pressure changes throughout the day. IntelliSense technology was developed
by Omron which enables your blood pressure monitor to inflate and deflate at the
optimum level for each individual. This helps ensure accurate measurement,
and is particularly useful for people with certain arrythmia or heart disorders.
Correct cuff positioning is critical when monitoring blood pressure. The Omron
Wrist (APS) Blood Pressure Monitor has a unique positioning sensor that
confirms the cuff is level with the user’s heart. This helps ensure that each
reading is accurate and reliable.
IntelliSense™ Technology Is An Assurance of Accuracy
Advanced Positioning Sensor (APS) Ensures a Reliable Measurement

5
Know Your Unit
Systolic Blood
Pressure Display
Diastolic Blood
Pressure Display
Date/Time
Display
button
Push to move the displayed
item forward. Push to move
the displayed item backward.
In the Selection Screen, push
either button for selection.
Mark
Displayed when the
stored measurement
values are called out.
SET button
Push this button
to set various items
on the monitor such
as time setting.
GRAPH button
Push this button to see
the graph.
MEMORY button
Push this button to see
the measured values
stored in the monitor.
START/STOP button
Push this button to measure
blood pressure. You can also
push this button to stop
measurement or turn off the
power. Push this button in
the Setting Screen to lock
the setting.
Pulse Display

6
Suggestions Before Measuring
Blood Pressure
1. Avoid eating, smoking and exercising for at least
30 minutes before taking measurement. Also rest
for at least 10 to 15 minutes before taking a reading.
2. Stress raises blood pressure. Avoid taking
measurements during stressful times.
3. The cuff can be applied to your left
or right wrist.
4. Measurements should be taken in a quiet place
and you should be in a relaxed, seated position.
5. Remain still and do not talk during
the measurements.
6. Keep a record of you blood pressure and pulse for you doctor.
Remember, a single measurement does not provide an accurate indication
of your true blood pressure. You need to take and record several readings
over a period of time. Try to measure your blood pressure at the same
time each day for consistency.
7. Wait 2-3 minutes between measurements. Waiting allows the engorged blood
vessels to return to normal. You may require more rest time between readings
depending on your individual physiological characteristics.

7
Battery Installation
Use this monitor after inserting batteries in the main unit.
1. Place the main unit with the Battery
Cover facing upward.
2. Remove the Battery Cover.
Push down the indent portion of Battery Cover
and slide it into the direction of the arrow.
3. Insert two AAA Batteries with the polarities
in the correct direction.
4.Close the Battery Cover.
Close the Battery Cover by sliding it as shown
in the Figure until it clicks.

8
Battery Replacement
• High performance alkaline dry cell batteries (2 “AAA”) should be good
for approximately 300 readings.
• Battery life varies with ambient temperature. Battery life is shorter under
cold conditions such as during the winter.
• If the battery replacement symbol blinks while measuring or if pressure
is not applied when the START / STOP button is pressed, replace both
batteries (use the same brand).
• Holding the START / STOP button down may shorten battery life. To avoid
pressure on the button when transporting or storing, use the case provided.
• If the batteries have been replaced or removed, resetting of the date and
time is required.
• If you are not going to use this monitor for a long period of time (approximately
three months or more), remove the batteries.
• Do not use batteries not specified for this unit, worn and new batteries
together, or different brands of batteries together.

9
Automatic Memory Setting
Automatic Memory Screen
Automatic Memory OFF Screen
1. Push the SET button while the power
is turned off.
Automatic Memory Screen is displayed.
2. Select ON or OFF.
• The monitor is set to ON (to store) at time
of your purchase.
To set it to OFF, push the button.
• If you want to set to ON after setting it
to OFF, push the button.
3. Lock the setting.
If you are going to change other settings, push the SET button
to lock the setting.
• When you push the SET button, the display changes to the
Position Sensor Screen.
If you want to finish operation after locking the setting, push
the START/STOP button to turn off the power.
The monitor stores the measured values and the date and time of measurement,
which is helpful for the continuous blood pressure management.
However, if more than one person is expected to use this monitor, the measured
values of more than one person will be stored. In that case, setting the Automatic
Memory to OFF is recommended.

10
Advanced Positioning Sensor (APS) Setting
Position Sensor Screen
Position Sensor OFF Screen
Position Sensor ON
and SIGNAL ON Screen
Position Sensor ON and
SIGNAL OFF Screen
1. Push the SET button while the power
is turned off.
Keep pressing the SET button until the
Position Sensor Screen is displayed.
2. Select ON or OFF.
• The Position Sensor is set to ON and the
SIGNAL is set to ON (to beep) at the time
of your purchase of the monitor.
Set the (APS) function to ON or OFF and set SIGNAL of the position sensor
to ON (beeps) or OFF (does not beep).
For setting the Position Sensor to OFF
Push the button to set the Position
Sensor to OFF.
• To set it to ON after setting it OFF,
push the button.
• There is no SIGNAL setting when
the Position Sensor is set to OFF.
How to set the SIGNAL to OFF when
the Position Sensor is set to ON
Push the SET button to make
SIGNAL ON flash.
To set the monitor to SIGNAL OFF, push
the button.
3. Lock the setting.
If you are also going to change other settings, push the SET button
to lock the setting.
• When you push the SET button, the display changes
to Measurement Screen.
If you want to finish after locking the setting, push the START/STOP
button to turn off the power.

11
Wrist Selection Setting
1. Push the SET button while the power
is turned off.
Keep pressing the button until the
Measurement Screen is displayed. Measuring (Wrist) Screen
Measuring (Wrist) Right Wrist Screen
2. Select Left Wrist or Right Wrist.
• The initial setting is LEFT at the time
of your purchase.
To change the setting to RIGHT, push
the button.
• If you want to change the setting to
LEFT after having set to RIGHT, push
the button.
3. Lock the setting.
If you are also going to change other settings, push the SET
button to lock the setting.
• When you push the SET button, the display changes
to an Alarm Screen.
If you want to finish after locking the setting, push the
START/STOP button to turn off the power.
Measurement can be made on the left wrist or on the right wrist.

12
You can set the alarm to go off twice a day at a specified time in the
morning and evening.
• You can stop the alarm by pushing any of the buttons of this blood pressure
monitor.
• Alarm will stop automatically after sounding for 2 minutes.
• Alarm will not sound when this monitor is in use, such as for measurement,
the Memory Call Screen, and the Graph Call Screen.
1. Push the SET button while the power
is turned off.
Keep pressing the button until the Alarm
Screen is displayed.
2. Set the Alarm.
• The initial setting is (not to go off) at the
time of your purchase.
Alarm Screen
Example of Alarm setting (If you want to set the
alarm to go off at 6:30 A.M. and 8 P.M.)
Push the button to set the Hour to AM 6.
Push the SET button to lock the Hour.
• Minute will flash.
Push the button to set the Minute to 30.
Push the SET button to lock the Minute.
• Each time you push the button, the display
changes in the regressive order, such as 59
and 58.
• If you keep pressing the button, Minute will
change fast forward.
• The mark flashes.
Push either or to change from (not to go
off) to (to go off), then push the SET button
to lock the setting.
Alarm Setting

13
Alarm Setting Continued
• Once the first alarm time is locked, the second
alarm time of Hour and PM 8 flashes.
In the same manner, set the hour for the second
time and (to go off).
3. Lock the setting.
If you are also going to change other settings,
push the SET button to lock the setting.
• When you push the SET button, the display
changes to the Time Screen.
If you want to finish by locking the setting, push
the START/STOP button to turn off the power.
Screen of setting the alarm to
go off at 6:30 A.M. and 8 P.M.
Screen of indicating that
the alarm is sounding

14
Date and Time Setting
Time Screen
1. Push the SET button while the power
is turn off.
Keep pressing the button until the Time Screen
is displayed.
• The year in Gregorian calendar is shown in
flash display as the Time Screen appears.
2. Push the button to set the year to the
current year in Gregorian calendar.
3. Push the SET button.
4. Push the button to set the Month to the
current month.
5. Push the SET button.
6. Push the button to set the Day to the
current day.
Setting the date and time is recommended before use of the monitor for continuous
blood pressure management
This blood pressure monitor automatically stores 90 measurement values. If you use
the monitor without setting the date and time correctly, the measured values will
be stored with the wrong date and time.
In the following cases, it is necessary to set the date and time:
• When you use the monitor for the first time
• After replacing the batteries
• After reset settings

15
Date and Time Setting Continued
7. Push the SET button.
8. Set the Hour and Minute.
The hour can be set between 12 A.M. and 11 A.M.,
and 12 P.M. and 11 P.M..
Flashing Screen
of Hour AM 12
Example of setting the time at the time tone for 8 A.M.
1. Set the hour to AM 8 in advance.
2. Set the minute display to flashing 59, and push
the button on the instant when the time tone
is heard.
• At the moment you push the arrow button,
the time is set to 00 seconds and matches
with the time tone.
3. Minute is indicated by flashing display of 00.
9. Lock the setting.
• Push the SET button.
Flashing Screen
of Hour AM 8
Flashing Screen
of Minute 59
Screen of 8 A.M.
on January 25, 2002

16
How to Reset This Monitor
Reset Settings
Any change made in the Setting Mode is cancelled to restore the state at the
time of your purchase of the monitor.
• After initialization, be sure to set the date and time.
• The stored measurement values are not deleted. If you want to delete
them, execute All Memory Erasure.
1. Push the SET button while the power
is turned off.
Keep pressing the button until the Reset
Settings Screen is displayed.
2. Select YES or NO.
• The initial setting of the monitor is NO
at any time.
For selecting YES
Push the button and select YES.
If you push the SET button, a screen asking
Are You Sure is displayed for reconfirmation.
To set to YES, push the button again.
• To cancel, push the button.
If you select YES and push the SET button, all
settings are resumed to the state at the time of
your purchase and the display changes to the
Automatic Memory Screen.
• If you select NO and push the SET button,
the display changes to Automatic Memory
Screen under the present setting.
If you want to finish setting here, push the
START/STOP button to turn off the power.
Reset Settings Screen
Reset Settings YES Screen
Are You Sure YES Screen
Automatic Memory ON Screen

17
How to Apply the Wrist Cuff
How to wrap the wrist cuff is one of the most important points for
correct measurement. Wrap the cuff snugly on your wrist.
• This monitor is preset to measure on your left hand when you
purchased it. If you desire to measure on your right hand, change
the mode to Right Hand measurement in setting.
• Wrap the wrist cuff over your skin.
• Please be careful not to catch the cuff of your shirt.
1. Place the wrist cuff over your left wrist with
your left thumb facing upward.
• Cover the wrist cuff by leaving clearance
of 1/2 inch (the clearance almost equal to the
width of an index finger) between the edge
of the wrist cuff and the bottom of the palm
as shown in the Figure to the right.
Check if the wrist cuff completely covers your
wrist as shown in the Figure to the right.
How to wrap the wrist cuff correctly (on left wrist)

18
How to Wrap the Wrist Cuff
2. Pull the wrist cuff upward holding the edge of the wrist
cuff so that it can be wrapped snugly.
• If the wrist cuff is not wrapped snugly, correct
measurement may not be possible.
Lightly press the velcro part with your finger so that
it is fastened tightly.
• If the velcro part is not tightly fastened, the wrist cuff will
become loose during measurement and the measurement may
be impossible.
• Those having a slender wrist (wrist circumference of less
than 5 3/4inches) may feel the wrist cuff move if the velcro
is not wrapped snugly. In that case, do not wrap the wrist
cuff any tighter, it will not affect the measurement.
• Fold and fasten the extra portion of wrist cuff as shown
to the right. Even if the extra portion of wrist cuff
is not fastened, it will not affect the measurement.
You can also measure your blood pressure on your right wrist.
Wrap the wrist cuff as shown in the Figure to the right.
• Change the Measurement to Right Hand in the Setting Mode.
1
2

19
How to Measure Blood Pressure
(This measurement example describes the situation
where the Position Sensor is set to ON and the
SIGNAL is set to ON.)
• If the date and time
is not set, the Time
Screen is displayed.
Be sure to set the date
and time before using
this monitor
Time Screen
1. Push the START/STOP
button.
The Position Sensor Screen
is displayed.
Hold your elbow firmly to avoid body movement.
Remain still and do not talk during measurement.
2. Adjust the height of your wrist by using your
elbow as the axis so that the mark can
be aligned with the mark.
The wrist movement is indicated with the mark.
Slowly move your wrist up and down so that the
wrist comes to the level of your heart ( mark).
Please be careful not to raise your wrist too high.
If your wrist is raised higher than the level of your heart, the monitor will let
it know with the display of a mark.
Slowly lower your wrist so that the mark aligns with the level
of your heart ( mark) using your elbow as the axis.
When the wrist reaches the proper position, the monitor beeps
and automatically starts inflation and measurement.

20
How to Measure Blood Pressure Continued
When the wrist reaches the level of your heart, the monitor beeps and the mark
changes to the mark instantly. Hold your wrist at that position and do not
make any movements until the measurement results are displayed.
• Be careful not to raise your wrist too high.
When your wrist reaches the
proper position, the monitor beeps
and automatically starts inflation
and measurement.
Inflation Start Screen
Inflation in
Progress Screen
Mark
Indicating
Inflation in
Progress
Pulse
Rate
Mark
Deflation Start Screen
Measurement Results
Display Screen
3. When the measurement finishes, the deflation
mark flashes and the wrist cuff deflates.
The measurement results (blood pressure
values, pulse rate, date and time) are displayed.
• If the velcro opens during measurement,
wrap the wrist cuff snugly again, fasten the
velcro securely, and start measurement again.
• If you want to stop measurement, push the
START/STOP button.
After the monitor stops inflation and deflates,
the power turns off automatically.
Deflation
Mark
