Omron Sysmac NY532-1500 User manual

Industrial PC Platform
NY-series
IPC Machine Controller
Industrial Panel PC / Industrial Box PC
Industrial Panel PC
Industrial Box PC
Setup
User’s Manual
W568-E1-01
NY532-1500
NY532-1400
NY532-1300
NY512-1500
NY512-1400
NY512-1300

All rights reserved. No part of this publication may be reproduced, stored in a retrieval system, or transmitted, in
any form, or by any means, mechanical, electronic, photocopying, recording, or otherwise, without the prior
written permission of OMRON.
No patent liability is assumed with respect to the use of the information contained herein. Moreover, because
OMRON is constantly striving to improve its high-quality products, the information contained in this manual is
subject to change without notice. Every precaution has been taken in the preparation of this manual. Neverthe-
less, OMRON assumes no responsibility for errors or omissions. Neither is any liability assumed for damages
resulting from the use of the information contained in this publication.
• Sysmac and SYSMAC are trademarks or registered trademarks of OMRON Corporation in Japan and other
countries for OMRON factory automation products.
• Microsoft, Windows, Excel, and Visual Basic are either registered trademarks or trademarks of Microsoft Corpora-
tion in the United States and other countries.
• EtherCAT®is registered trademark and patented technology, licensed by Beckhoff Automation GmbH, Germany.
• ODVA, CIP, CompoNet, DeviceNet, and EtherNet/IP are trademarks of ODVA.
• The SD and SDHC logos are trademarks of SD-3C, LLC.
• Intel and Intel Core are trademarks of Intel Corporation in the U.S. and / or other countries.
Other company names and product names in this document are the trademarks or registered trademarks of their
respective companies.
Trademarks
Copyrights
NOTE
Microsoft product screen shots reprinted with permission from Microsoft Corporation.

Introduction
Thank you for purchasing an NY-series IPC Machine Controller Industrial Panel PC / Industrial Box
PC.
This manual provides a collective term of Industrial Panel PC and Industrial Box PC which are applica-
ble products as the NY-series Industrial PC. This manual also provides the range of devices that are
directly controlled by the Machine Automation Control Software embedded in the NY-series Industrial
PC as the Controller.
This manual contains information that is necessary to use the NY-series Controller. Please read this
manual and make sure you understand the functionality and performance of the NY-series Controller
before you attempt to use it in a control system.
Keep this manual in a safe place where it will be available for reference during operation.
Intended Audience
This manual is intended for the following personnel, who must also have knowledge of electrical sys-
tems (an electrical engineer or the equivalent).
• Personnel in charge of introducing FA systems.
• Personnel in charge of designing FA systems.
• Personnel in charge of installing and maintaining FA systems.
• Personnel in charge of managing FA systems and facilities.
For programming, this manual is intended for personnel who understand the programming language
specifications in international standard IEC 61131-3 or Japanese standard JIS B 3503.
Applicable Products
This manual covers the following products.
• NY-series IPC Machine Controller Industrial Panel PC
•NY532-15££
•NY532-14££
•NY532-13££
• NY-series IPC Machine Controller Industrial Box PC
•NY512-15££
•NY512-14££
•NY512-13££
Part of the specifications and restrictions for the Industrial PC are given in other manuals.
Refer to Relevant Manuals on page 2 and Related Manuals on page 19.
Introduction
1
NY-series Industrial Panel PC / Industrial Box PC Setup User’s Manual (W568)

Relevant Manuals
The following table provides the relevant manuals for the NY-series Controller. Read all of the manuals
that are relevant to your system configuration and application before you use the NY-series Controller.
Most operations are performed from the Sysmac Studio Automation Software. Refer to the Sysmac
Studio Version 1 Operation Manual (Cat. No. W504) for information on the Sysmac Studio.
Manual
Basic information
Purpose of use
NY-series IPC Machine Controller Industrial Panel PC Hardware User’s Manual NY-series IPC Machine Controller Industrial Box PC Hardware User’s Manual
NY-series IPC Machine Controller Industrial Panel PC / Industrial Box PC Setup User’s Manual NY-series IPC Machine Controller Industrial Panel PC / Industrial Box PC Software User’s Manual NY-series Instructions Reference Manual NY-series IPC Machine Controller Industrial Panel PC / Industrial Box PC Motion Control User’s Manual NY-series Motion Control Instructions Reference Manual NY-series IPC Machine Controller Industrial Panel PC / Industrial Box PC Built-in EtherCAT Port User’s Manual NY-series IPC Machine Controller Industrial Panel PC / Industrial Box PC Built-in EtherNet/IP Port User’s Manual NY-series Troubleshooting Manual
Introduction to NY-series Panel PCs ¡
Introduction to NY-series Box PCs ¡
Setting devices and hardware
¡ ¡
Using motion control ¡
Using EtherCAT ¡
Using EtherNet/IP ¡
Making setup*1
¡
Making initial settings
Preparing to use Controllers
Software settings
¡
Using motion control ¡
Using EtherCAT ¡
Using EtherNet/IP ¡
Writing the user program
¡ ¡
Using motion control ¡ ¡
Using EtherCAT ¡
Using EtherNet/IP ¡
Programming error processing ¡
Testing operation and debugging
¡
Using motion control ¡
Using EtherCAT ¡
Using EtherNet/IP ¡
Learning about error management and
corrections*2 ¡
Relevant Manuals
2NY-series Industrial Panel PC / Industrial Box PC Setup User’s Manual (W568)

Manual
Basic information
Purpose of use
NY-series IPC Machine Controller Industrial Panel PC Hardware User’s Manual NY-series IPC Machine Controller Industrial Box PC Hardware User’s Manual NY-series IPC Machine Controller Industrial Panel PC / Industrial Box PC Setup User’s Manual NY-series IPC Machine Controller Industrial Panel PC / Industrial Box PC Software User’s Manual NY-series Instructions Reference Manual NY-series IPC Machine Controller Industrial Panel PC / Industrial Box PC Motion Control User’s Manual NY-series Motion Control Instructions Reference Manual NY-series IPC Machine Controller Industrial Panel PC / Industrial Box PC Built-in EtherCAT Port User’s Manual NY-series IPC Machine Controller Industrial Panel PC / Industrial Box PC Built-in EtherNet/IP Port User’s Manual NY-series Troubleshooting Manual
Maintenance
¡ ¡
Using motion control ¡
Using EtherCAT ¡
Using EtherNet/IP ¡
*1. Refer to the NY-series Industrial Panel PC / Industrial Box PC Setup User’s Manual (Cat. No. W568) for how to set up and how to use
the utilities on Windows.
*2. Refer to the NY-series Troubleshooting Manual (Cat. No. W564) for the error management concepts and the error items.
Relevant Manuals
3
NY-series Industrial Panel PC / Industrial Box PC Setup User’s Manual (W568)

Manual Structure
Some of the descriptions of functions in this manual are common to NJ/NX-series.
Therefore, note the following conditions.
• The same function names are used for the common functions of the NJ/NX/NY-series. If the term
“CPU Unit” is included in the function names, such as the CPU Unit names, CPU Unit write protec-
tion, and other functions, it indicates the “Controller” in the NY-series.
• The “CPU Unit” that is described in a list of function specifications in this manual also indicates the
“Controller” in the NY-series.
Page Structure
The following page structure is used in this manual.
4-9
4 Installation and Wiring
NJ-series CPU Unit Hardware User’s Manual (W500)
stinUgnitnuoM3-4
4
stnenopmoCrellortnoCgnitcennoC1-3-4
4-3 Mounting Units
The Units that make up an NJ-series Controller can be connected simply by pressing the Units together
and locking the sliders by moving them toward the back of the Units. The End Cover is connected in the
same way to the Unit on the far right side of the Controller.
1Join the Units so that the connectors fit exactly.
2The yellow sliders at the top and bottom of each Unit lock the Units together. Move the sliders
toward the back of the Units as shown below until they click into place.
Precautions for Correct UsePrecautions for Correct Use
4-3-1 Connecting Controller Components
Connector
Hook Hook holes
Slider
Lock
Release
Move the sliders toward the back
until they lock into place.
Level 1 heading
Level 2 heading
Level 3 heading
Level 2 heading
A step in a procedure
Manual name
Special information
Level 3 heading
Page tab
Gives the current
headings.
Indicates a procedure.
Icons indicate
precautions, additional
information, or reference
information.
Gives the number
of the main section.
This illustration is provided only as a sample. It may not literally appear in this manual.
The sliders on the tops and bottoms of the Power Supply Unit, CPU Unit, I/O Units, Special I/O
Units, and CPU Bus Units must be completely locked (until they click into place) after connecting
the adjacent Unit connectors.
Manual Structure
4NY-series Industrial Panel PC / Industrial Box PC Setup User’s Manual (W568)

Special Information
Special information in this manual is classified as follows:
Precautions for Safe Use
Precautions on what to do and what not to do to ensure safe usage of the product.
Precautions for Correct Use
Precautions on what to do and what not to do to ensure proper operation and performance.
Additional Information
Additional information to read as required.
This information is provided to increase understanding or make operation easier.
Version Information
Information on differences in specifications and functionality for Controller with different unit versions
and for different versions of the Sysmac Studio is given.
Precaution on Terminology
In this manual, “download” refers to transferring data from the Sysmac Studio to the physical Control-
ler and “upload” refers to transferring data from the physical Controller to the Sysmac Studio.
For the Sysmac Studio, synchronization is used to both upload and download data. Here, “synchron-
ize” means to automatically compare the data for the Sysmac Studio on the computer with the data in
the physical Controller and transfer the data in the direction that is specified by the user.
Manual Structure
5
NY-series Industrial Panel PC / Industrial Box PC Setup User’s Manual (W568)

CONTENTS
Introduction .............................................................................................................. 1
Intended Audience.......................................................................................................................................1
Applicable Products .....................................................................................................................................1
Relevant Manuals..................................................................................................... 2
Manual Structure...................................................................................................... 4
Page Structure.............................................................................................................................................4
Special Information ......................................................................................................................................5
Precaution on Terminology ..........................................................................................................................5
Terms and Conditions Agreement........................................................................ 11
Warranty, Limitations of Liability ................................................................................................................ 11
Application Considerations ........................................................................................................................ 11
Disclaimers ................................................................................................................................................12
Safety Precautions................................................................................................. 13
Precautions for Safe Use ...................................................................................... 14
Precautions for Correct Use ................................................................................. 15
Regulations and Standards .................................................................................. 16
Conformance to EU Directives ..................................................................................................................16
Software Licenses and Copyrights ............................................................................................................16
Versions .................................................................................................................. 17
Checking Versions .....................................................................................................................................17
Related Manuals..................................................................................................... 19
Revision History..................................................................................................... 21
Sections in this Manual ......................................................................................... 23
Section 1 Introduction to the Industrial PC
1-1 Features .................................................................................................................................1 - 2
1-2 Operation of the Operating System ....................................................................................1 - 3
1-2-1 Overview of Operating System Operation..................................................................................1 - 3
1-2-2 Data Exchange between Operating Systems.............................................................................1 - 3
1-2-3 External Interface for Each Operating System ...........................................................................1 - 5
1-3 Product Model Numbers ......................................................................................................1 - 6
1-4 Application Procedures........................................................................................................1 - 7
1-4-1 Overall Procedure ......................................................................................................................1 - 7
1-5 Monitoring Function .............................................................................................................1 - 9
1-5-1 Monitoring System Information...................................................................................................1 - 9
1-5-2 Monitoring Controller Status.....................................................................................................1 - 10
CONTENTS
6NY-series Industrial Panel PC / Industrial Box PC Setup User’s Manual (W568)

Section 2 Initial Settings
2-1 Initial Settings for Windows.................................................................................................2 - 2
2-1-1 Windows Settings.......................................................................................................................2 - 2
2-1-2 Creating Recovery Image of Initial State....................................................................................2 - 3
2-1-3 Installing Software ......................................................................................................................2 - 3
2-1-4 User Account Settings................................................................................................................2 - 4
2-1-5 Customize Windows...................................................................................................................2 - 4
2-2 Starting and Exiting ..............................................................................................................2 - 5
2-2-1 Starting .......................................................................................................................................2 - 5
2-2-2 Exiting.........................................................................................................................................2 - 6
2-2-3 Restarting ...................................................................................................................................2 - 6
2-3 UPS Settings .........................................................................................................................2 - 8
2-4 Industrial Monitor Settings ..................................................................................................2 - 9
2-4-1 Industrial Monitor Utility ..............................................................................................................2 - 9
2-4-2 Industrial Monitor Brightness Utility ..........................................................................................2 - 11
Section 3 Controller Preparation
3-1 Internal Port Settings............................................................................................................3 - 2
3-2 Shared Folder Settings.........................................................................................................3 - 3
3-2-1 Windows Settings.......................................................................................................................3 - 3
3-2-2 Controller Setup .........................................................................................................................3 - 7
Section 4 Industrial PC Support Utility
4-1 Outline of Industrial PC Support Utility ..............................................................................4 - 2
4-2 Starting the Industrial PC Support Utility ...........................................................................4 - 3
4-2-1 Starting the Industrial PC Support Utility ....................................................................................4 - 3
4-2-2 Screen of Industrial PC Support Utility .......................................................................................4 - 4
4-3 Displaying Production Information .....................................................................................4 - 5
4-4 System Monitor .....................................................................................................................4 - 6
4-5 Controller Monitor.................................................................................................................4 - 7
4-6 Controller Operation.............................................................................................................4 - 9
4-6-1 Mode Change.............................................................................................................................4 - 9
4-6-2 Resetting the Controller............................................................................................................4 - 10
4-6-3 Controller Backup..................................................................................................................... 4 - 11
4-7 Network Settings for Controller.........................................................................................4 - 16
4-8 Virtual SD Memory Card Settings......................................................................................4 - 18
4-9 Operation Authority Verification........................................................................................4 - 20
4-10 Report Log...........................................................................................................................4 - 22
Section 5 NYCompolet
5-1 Outline of NYCompolet.........................................................................................................5 - 2
5-2 How to Use the NYCompolet ...............................................................................................5 - 3
5-3 Communications Setup........................................................................................................5 - 4
5-3-1 Communications Setup Procedure.............................................................................................5 - 4
5-3-2 Additional Functions to Communications Setup.........................................................................5 - 4
5-4 NYCompolet Interface ..........................................................................................................5 - 6
CONTENTS
7
NY-series Industrial Panel PC / Industrial Box PC Setup User’s Manual (W568)

5-4-1 Interface Members .....................................................................................................................5 - 6
5-4-2 Usage Method ............................................................................................................................5 - 7
Section 6 Industrial PC API
6-1 Outline of Industrial PC API .................................................................................................6 - 2
6-2 How to Use the Industrial PC API........................................................................................6 - 3
6-3 Industrial PC System API .....................................................................................................6 - 4
6-3-1 Members of the Industrial PC System API .................................................................................6 - 4
6-3-2 Usage Method ............................................................................................................................6 - 4
6-4 Industrial PC Controller API ................................................................................................6 - 5
6-4-1 IPCController Class....................................................................................................................6 - 5
6-4-2 ControllerAccessException Class ..............................................................................................6 - 6
6-4-3 ControllerInternalExecuteException class..................................................................................6 - 6
6-4-4 Usage Method ............................................................................................................................6 - 6
Section 7 Backup and Recovery
7-1 Backing up and Recovering the Industrial PC System .....................................................7 - 2
7-1-1 Outline of Rescue Disk Utility .....................................................................................................7 - 2
7-1-2 Applicable Range of Backup Functions with the Rescue Disk Utility .........................................7 - 2
7-1-3 Preparing the Rescue Disk Utility...............................................................................................7 - 2
7-1-4 Backup with the Rescue Disk Utility ...........................................................................................7 - 3
7-1-5 Recovery with the Rescue Disk Utility........................................................................................7 - 5
7-2 Backing Up, Restoring, and Comparing Controller Data ..................................................7 - 7
Section 8 Troubleshooting during Setup
8-1 Starting in Safe Mode ...........................................................................................................8 - 2
Appendices
A-1 Updating ............................................................................................................................... A - 2
A-1-1 Updating Windows Software ..................................................................................................... A - 2
A-2 Changing the Internal Port Settings................................................................................... A - 3
A-3 Changing Windows File Sharing Setting........................................................................... A - 4
A-3-1 Procedure to Change ................................................................................................................ A - 4
A-3-2 Cautions When Using Virtual SD Memory Card........................................................................ A - 4
A-4 Windows of Industrial PC.................................................................................................... A - 5
A-4-1 Windows Operating System ...................................................................................................... A - 5
A-4-2 Supported Languages ............................................................................................................... A - 5
A-5 Industrial PC Tray Utility ..................................................................................................... A - 6
A-5-1 Outline of Industrial PC Tray Utility............................................................................................ A - 6
A-5-2 Starting the Industrial PC Tray Utility......................................................................................... A - 6
A-5-3 Status Display on Icon............................................................................................................... A - 6
A-5-4 Industrial PC Tray Utility Menu .................................................................................................. A - 6
A-5-5 Notification Message Display .................................................................................................... A - 7
A-6 Customize Windows ............................................................................................................ A - 8
A-6-1 Enhanced Write Filter................................................................................................................ A - 8
A-6-2 File-Based Write Filter............................................................................................................... A - 9
CONTENTS
8NY-series Industrial Panel PC / Industrial Box PC Setup User’s Manual (W568)

Index
CONTENTS
9
NY-series Industrial Panel PC / Industrial Box PC Setup User’s Manual (W568)

CONTENTS
10 NY-series Industrial Panel PC / Industrial Box PC Setup User’s Manual (W568)

Terms and Conditions Agreement
Warranty, Limitations of Liability
Warranties
• Exclusive Warranty
Omron’s exclusive warranty is that the Products will be free from defects in materials and workman-
ship for a period of twelve months from the date of sale by Omron (or such other period expressed
in writing by Omron). Omron disclaims all other warranties, express or implied.
• Limitations
OMRON MAKES NO WARRANTY OR REPRESENTATION, EXPRESS OR IMPLIED, ABOUT
NON-INFRINGEMENT, MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE OF
THE PRODUCTS. BUYER ACKNOWLEDGES THAT IT ALONE HAS DETERMINED THAT THE
PRODUCTS WILL SUITABLY MEET THE REQUIREMENTS OF THEIR INTENDED USE.
Omron further disclaims all warranties and responsibility of any type for claims or expenses based
on infringement by the Products or otherwise of any intellectual property right.
• Buyer Remedy
Omron’s sole obligation hereunder shall be, at Omron’s election, to (i) replace (in the form originally
shipped with Buyer responsible for labor charges for removal or replacement thereof) the non-com-
plying Product, (ii) repair the non-complying Product, or (iii) repay or credit Buyer an amount equal
to the purchase price of the non-complying Product; provided that in no event shall Omron be re-
sponsible for warranty, repair, indemnity or any other claims or expenses regarding the Products un-
less Omron’s analysis confirms that the Products were properly handled, stored, installed and main-
tained and not subject to contamination, abuse, misuse or inappropriate modification. Return of any
Products by Buyer must be approved in writing by Omron before shipment. Omron Companies shall
not be liable for the suitability or unsuitability or the results from the use of Products in combination
with any electrical or electronic components, circuits, system assemblies or any other materials or
substances or environments. Any advice, recommendations or information given orally or in writing,
are not to be construed as an amendment or addition to the above warranty.
See http://www.omron.com/global/ or contact your Omron representative for published information.
Limitation on Liability; Etc
OMRON COMPANIES SHALL NOT BE LIABLE FOR SPECIAL, INDIRECT, INCIDENTAL, OR CON-
SEQUENTIAL DAMAGES, LOSS OF PROFITS OR PRODUCTION OR COMMERCIAL LOSS IN ANY
WAY CONNECTED WITH THE PRODUCTS, WHETHER SUCH CLAIM IS BASED IN CONTRACT,
WARRANTY, NEGLIGENCE OR STRICT LIABILITY.
Further, in no event shall liability of Omron Companies exceed the individual price of the Product on
which liability is asserted.
Application Considerations
Terms and Conditions Agreement
11
NY-series Industrial Panel PC / Industrial Box PC Setup User’s Manual (W568)

Suitability of Use
Omron Companies shall not be responsible for conformity with any standards, codes or regulations
which apply to the combination of the Product in the Buyer’s application or use of the Product. At Buy-
er’s request, Omron will provide applicable third party certification documents identifying ratings and
limitations of use which apply to the Product. This information by itself is not sufficient for a complete
determination of the suitability of the Product in combination with the end product, machine, system, or
other application or use. Buyer shall be solely responsible for determining appropriateness of the par-
ticular Product with respect to Buyer’s application, product or system. Buyer shall take application re-
sponsibility in all cases.
NEVER USE THE PRODUCT FOR AN APPLICATION INVOLVING SERIOUS RISK TO LIFE OR
PROPERTY WITHOUT ENSURING THAT THE SYSTEM AS A WHOLE HAS BEEN DESIGNED TO
ADDRESS THE RISKS, AND THAT THE OMRON PRODUCT(S) IS PROPERLY RATED AND IN-
STALLED FOR THE INTENDED USE WITHIN THE OVERALL EQUIPMENT OR SYSTEM.
Programmable Products
Omron Companies shall not be responsible for the user’s programming of a programmable Product, or
any consequence thereof.
Disclaimers
Performance Data
Data presented in Omron Company websites, catalogs and other materials is provided as a guide for
the user in determining suitability and does not constitute a warranty. It may represent the result of
Omron’s test conditions, and the user must correlate it to actual application requirements. Actual per-
formance is subject to the Omron’s Warranty and Limitations of Liability.
Change in Specifications
Product specifications and accessories may be changed at any time based on improvements and oth-
er reasons. It is our practice to change part numbers when published ratings or features are changed,
or when significant construction changes are made. However, some specifications of the Product may
be changed without any notice. When in doubt, special part numbers may be assigned to fix or estab-
lish key specifications for your application. Please consult with your Omron’s representative at any
time to confirm actual specifications of purchased Product.
Errors and Omissions
Information presented by Omron Companies has been checked and is believed to be accurate; how-
ever, no responsibility is assumed for clerical, typographical or proofreading errors or omissions.
Terms and Conditions Agreement
12 NY-series Industrial Panel PC / Industrial Box PC Setup User’s Manual (W568)

Safety Precautions
Refer to the following manuals for safety precautions.
•NY-series Industrial Box PC Hardware User’s Manual (Cat. No. W556)
•NY-series Industrial Panel PC Hardware User’s Manual (Cat. No. W557)
•NY-series Industrial Panel PC / Industrial Box PC Software User’s Manual (Cat. No. W558)
Safety Precautions
13
NY-series Industrial Panel PC / Industrial Box PC Setup User’s Manual (W568)

Precautions for Safe Use
Refer to the following manuals for precautions for safe use.
•NY-series Industrial Box PC Hardware User’s Manual (Cat. No. W556)
•NY-series Industrial Panel PC Hardware User’s Manual (Cat. No. W557)
•NY-series Industrial Panel PC / Industrial Box PC Software User’s Manual (Cat. No. W558)
Precautions for Safe Use
14 NY-series Industrial Panel PC / Industrial Box PC Setup User’s Manual (W568)

Precautions for Correct Use
Refer to the following manuals for precautions for correct use.
•NY-series Industrial Box PC Hardware User’s Manual (Cat. No. W556)
•NY-series Industrial Panel PC Hardware User’s Manual (Cat. No. W557)
•NY-series Industrial Panel PC / Industrial Box PC Software User’s Manual (Cat. No. W558)
Precautions for Correct Use
15
NY-series Industrial Panel PC / Industrial Box PC Setup User’s Manual (W568)

Regulations and Standards
Conformance to EU Directives
Applicable Directives
• EMC Directive
Concepts
EMC Directive
OMRON devices that comply with EU Directives also conform to the related EMC standards so that
they can be more easily built into other devices or the overall machine. The actual products have
been checked for conformity to EMC standards.*
Whether the products conform to the standards in the system used by the customer, however, must
be checked by the customer. EMC-related performance of the OMRON devices that comply with
EU Directives will vary depending on the configuration, wiring, and other conditions of the equip-
ment or control panel on which the OMRON devices are installed. The customer must, therefore,
perform the final check to confirm that devices and the overall machine conform to EMC standards.
*1. Applicable EMC (Electromagnetic Compatibility) standards are as follows:
EMS (Electromagnetic Susceptibility): EN 61131-2
EMI (Electromagnetic Interference): EN 61131-2
(Radiated emission: 10-m regulations)
Conformance to EU Directives
The NY-series Controllers comply with EU Directives. To ensure that the machine or device in
which the NY-series Controller is used complies with EU Directives, the Controller must be installed
as follows:
• The NY-series Controller must be installed within a control panel.
• You must use the power supply in SELV specifications for the DC power supplies connected to
DC Power Supply Units and I/O Units.
• NY-series Controllers that comply with EU Directives also conform to the Common Emission
Standard (EN 61000-6-4). Radiated emission characteristics (10-m regulations) may vary de-
pending on the configuration of the control panel used, other devices connected to the control
panel, wiring, and other conditions.
You must therefore confirm that the overall machine or equipment complies with EC Directives.
Software Licenses and Copyrights
This product incorporates certain third party software. The license and copyright information associ-
ated with this software is available at http://www.fa.omron.co.jp/nj_info_e/.
Regulations and Standards
16 NY-series Industrial Panel PC / Industrial Box PC Setup User’s Manual (W568)

Versions
Hardware revisions and unit versions are used to manage the hardware and software in NY-series
Controllers and EtherCAT slaves. The hardware revision or unit version is updated each time there is
a change in hardware or software specifications.
Even when two Units or EtherCAT slaves have the same model number, they will have functional or
performance differences if they have different hardware revisions or unit versions.
Checking Versions
You can check versions on the ID information indications or with the Sysmac Studio.
Checking Unit Versions on ID Information Indications
The unit version is given on the ID information indication on the back side of the product.
The ID information on an NY-series NY5£2-1£££ Controller is shown below.
ID information indication
Unit version
Ver.1.
Checking Unit Versions with the Sysmac Studio
You can use the Sysmac Studio to check unit versions. The procedure is different for Units and for
EtherCAT slaves.
Checking the Unit Version of an NY-series Controller
You can use the Production Information while the Sysmac Studio is online to check the unit version
of a Unit. You can only do this for the Controller.
1Right-click CPU Rack under Configurations and Setup - CPU/Expansion Racks in the Multi-
view Explorer and select Production Information.
The Production Information Dialog Box is displayed.
Changing Information Displayed in Production Information Dialog Box
1Click the Show Detail or Show Outline Button at the lower right of the Production Information
Dialog Box.
The view will change between the production information details and outline.
Versions
17
NY-series Industrial Panel PC / Industrial Box PC Setup User’s Manual (W568)

Outline View Detail View
The information that is displayed is different for the Outline View and Detail View. The Detail
View displays the unit version, hardware revision, and other versions. The Outline View dis-
plays only the unit version.
Checking the Unit Version of an EtherCAT Slave
You can use the Production Information while the Sysmac Studio is online to check the unit version
of an EtherCAT slave.
Use the following procedure to check the unit version.
1Double-click EtherCAT under Configurations and Setup in the Multiview Explorer. Or, right-
click EtherCAT under Configurations and Setup and select Edit from the menu.
The EtherCAT Tab Page is displayed.
2Right-click the master on the EtherCAT Tab Page and select Display Production Information.
The Production Information Dialog Box is displayed.
The unit version is displayed after “Rev.”
Changing Information Displayed in Production Information Dialog Box
1Click the Show Detail or Show Outline Button at the lower right of the Production Information
Dialog Box.
The view will change between the production information details and outline.
Outline View Detail View
Versions
18 NY-series Industrial Panel PC / Industrial Box PC Setup User’s Manual (W568)
