Omron Sysmac NYB-0 Series Instructions for use

Industrial PC Platform
NY-series
Industrial Box PC
Hardware User's Manual
NYB££-££0
NYB££-££1
NYB££-££2
NYB££-££3
NYB££-££4
Industrial Box PC
W553-E2-09

NOTE
All rights reserved. No part of this publication may be reproduced, stored in a retrieval system, or
transmitted, in any form, or by any means, mechanical, electronic, photocopying, recording, or other-
wise, without the prior written permission of OMRON.
No patent liability is assumed with respect to the use of the information contained herein. Moreover,
because OMRON is constantly striving to improve its high-quality products, the information contained
in this manual is subject to change without notice. Every precaution has been taken in the preparation
of this manual. Nevertheless, OMRON assumes no responsibility for errors or omissions. Neither is
any liability assumed for damages resulting from the use of the information contained in this publica-
tion.
Trademarks
•Sysmac and SYSMAC are trademarks or registered trademarks of OMRON Corporation in Japan
and other countries for OMRON factory automation products.
•Windows is a registered trademark of Microsoft Corporation in the USA and other countries.
•The SD and SDHC logos are trademarks of SD-3C, LLC.
•CFAST is a registered trademark of CompactFlash Association.
•Intel, the Intel Logo, Celeron and Intel Core are trademarks of Intel Corporation in the U.S. and/or
other countries.
Other company names and product names in this document are the trademarks or registered trade-
marks of their respective companies.
Copyrights
Microsoft product screen shots reprinted with permission from Microsoft Corporation.

Introduction
Thank you for purchasing the Industrial Box PC.
This manual contains information that is necessary to use the Industrial Box PC (hereafter also named
as Box PC). Please read this manual and make sure you understand the functionality and perform-
ance of the Box PC before attempting to use it.
Keep this manual in a safe place where it will be available for reference during operation.
Intended Audience
This manual is intended for the following personnel, who must also have knowledge of electrical sys-
tems (an electrical engineer or the equivalent).
• Personnel in charge of introducing Factory Automation systems.
• Personnel in charge of designing Factory Automation systems.
• Personnel in charge of installing and maintaining Factory Automation systems.
• Personnel in charge of managing Factory Automation systems and facilities.
Applicable Products
This manual covers following Industrial Box PC products:
Product Model
Industrial Box PC •NYB££-££0
•NYB££-££1
•NYB££-££2
•NYB££-££3
•NYB££-££4
Additional Information
Refer to 1-4 Product Configuration Box PC on page 1-5 for configuration details.
Introduction
1
NY-series Industrial Box PC Hardware User's Manual (W553)

Introduction
2NY-series Industrial Box PC Hardware User's Manual (W553)

Sections in this Manual
Operating Procedures
Specifications
Installation
Hardware
System Configurations
Overview
1
2
3
4
5
6
1
2
3
4
6
5
1
7
7
Appendices
Maintenance
A
A
Sections in this Manual
3
NY-series Industrial Box PC Hardware User's Manual (W553)

CONTENTS
Introduction .............................................................................................................. 1
Intended Audience...........................................................................................................................................1
Applicable Products .........................................................................................................................................1
Sections in this Manual ........................................................................................... 3
Manual Information.................................................................................................. 9
Page Structure.................................................................................................................................................9
Special Information ........................................................................................................................................10
Terms and Conditions Agreement........................................................................ 11
Warranty, Limitations of Liability .................................................................................................................... 11
Application Considerations ............................................................................................................................12
Disclaimers ....................................................................................................................................................13
Safety Precautions................................................................................................. 14
Definition of Precautionary Information..........................................................................................................14
Symbols .........................................................................................................................................................14
Warnings........................................................................................................................................................15
Cautions.........................................................................................................................................................17
Precautions for Safe Use ...................................................................................... 18
Disassembly, Dropping, Mounting, Installation and Storage .........................................................................18
Wiring.............................................................................................................................................................18
Power Supply Design and Turning ON/OFF the Power Supply.....................................................................19
Actual Operation ............................................................................................................................................19
Operation .......................................................................................................................................................19
General Communications ..............................................................................................................................20
Battery Replacement .....................................................................................................................................20
Cleaning, Maintenance and Disposal ............................................................................................................20
Precautions for Correct Use ................................................................................. 21
Storage, Installation and Mounting ................................................................................................................21
Wiring.............................................................................................................................................................21
Actual Operation and Operation ....................................................................................................................22
Battery Replacement .....................................................................................................................................22
SD Memory Cards .........................................................................................................................................22
Regulations and Standards .................................................................................. 23
Conformance to EU Directives ......................................................................................................................23
Conformance to KC Certification ...................................................................................................................24
Conformance to UL and CSA Standards.......................................................................................................24
Software Licenses and Copyrights ................................................................................................................24
Related Manuals..................................................................................................... 25
Related Box PC Manual ................................................................................................................................25
Related Products Manuals.............................................................................................................................25
Industrial Monitor Manual ..............................................................................................................................26
Terminology and Abbreviations ........................................................................... 27
Industrial PC Platform ...................................................................................................................................27
Hardware ......................................................................................................................................................27
Software.........................................................................................................................................................28
Revision History..................................................................................................... 29
CONTENTS
4NY-series Industrial Box PC Hardware User's Manual (W553)

Section 1 Overview
1-1 Intended Use .........................................................................................................................1-2
1-2 Hardware Features.................................................................................................................1-3
1-3 ID Information Label ..............................................................................................................1-4
1-4 Product Configuration Box PC .............................................................................................1-5
1-5 Industrial PC Platform Overview ..........................................................................................1-7
1-5-1 Industrial Monitor ........................................................................................................................1-7
1-5-2 Industrial Box PC .......................................................................................................................1-8
1-5-3 Industrial Panel PC ....................................................................................................................1-8
Section 2 System Configurations
2-1 Configuration for NYB and NYP ...........................................................................................2-2
Section 3 Hardware
3-1 Layers and Components .......................................................................................................3-3
3-1-1 Cooling Layer ..............................................................................................................................3-4
3-1-2 Base Layer ..................................................................................................................................3-5
3-1-3 Expansion Layer (Optional).........................................................................................................3-6
3-2 LED Indicators........................................................................................................................3-7
3-2-1 PWR LED Indicator .....................................................................................................................3-7
3-2-2 ERR LED Indicator......................................................................................................................3-8
3-2-3 HDD LED Indicator......................................................................................................................3-8
3-2-4 RUN LED Indicator......................................................................................................................3-8
3-3 Power Button..........................................................................................................................3-9
3-4 Connectors ...........................................................................................................................3-10
3-4-1 Power Connector ......................................................................................................................3-10
3-4-2 I/O Connector............................................................................................................................3-10
3-4-3 USB Connectors .......................................................................................................................3-11
3-4-4 Ethernet Connectors .................................................................................................................3-12
3-4-5 DVI Connector...........................................................................................................................3-12
3-4-6 RS-232C Connector (Optional) .................................................................................................3-13
3-4-7 DVI-D Connector (Optional) ......................................................................................................3-13
3-4-8 NY Monitor Link Connector (Optional) ......................................................................................3-14
3-4-9 Ethernet Connector (Optional) ..................................................................................................3-15
3-5 SD Memory Card Slot ..........................................................................................................3-16
3-6 CFast Card Slot (Optional) ..................................................................................................3-17
3-7 Drive Bays ............................................................................................................................3-18
3-8 PCIe Card Slot ......................................................................................................................3-19
3-9 Spare Parts ...........................................................................................................................3-20
3-9-1 Battery.......................................................................................................................................3-20
3-9-2 Fan Unit.....................................................................................................................................3-20
3-9-3 Accessory Kit ............................................................................................................................3-21
3-10 Optional Hardware ...............................................................................................................3-22
3-10-1 Mounting Brackets ....................................................................................................................3-22
3-10-2 SD Memory Cards.....................................................................................................................3-23
3-10-3 USB Flash Drives......................................................................................................................3-23
3-10-4 CFast Cards ..............................................................................................................................3-24
3-10-5 HDD and SSD Storage Devices................................................................................................3-25
3-10-6 DVI Cables ................................................................................................................................3-26
3-10-7 USB Type-A to USB Type-B Cables .........................................................................................3-26
CONTENTS
5
NY-series Industrial Box PC Hardware User's Manual (W553)

3-10-8 NY Monitor Link Cables ............................................................................................................3-27
3-10-9 Industrial Monitor ......................................................................................................................3-30
3-10-10 Power Supply ............................................................................................................................3-30
3-10-11 UPS...........................................................................................................................................3-31
3-10-12 UPS Communication Cable ......................................................................................................3-31
Section 4 Specifications
4-1 General Specifications .........................................................................................................4-2
4-1-1 Dimensions and Weight ..............................................................................................................4-2
4-1-2 General Electrical Specifications.................................................................................................4-3
4-1-3 Power Consumption Specifications.............................................................................................4-4
4-1-4 Power Supply Specifications.......................................................................................................4-5
4-1-5 CPU Specifications .....................................................................................................................4-6
4-1-6 Memory Specifications ................................................................................................................4-9
4-1-7 Storage Device Specifications ..................................................................................................4-11
4-1-8 PCIe Card Specifications ..........................................................................................................4-14
4-1-9 Bracket Specifications...............................................................................................................4-17
4-2 Connector Specifications ...................................................................................................4-18
4-2-1 Power Connector Specifications ...............................................................................................4-18
4-2-2 I/O Connector Specifications.....................................................................................................4-19
4-2-3 USB Connector Specifications ..................................................................................................4-23
4-2-4 Ethernet Connector Specifications............................................................................................4-24
4-2-5 DVI Connector Specifications ...................................................................................................4-26
4-2-6 DVI-D Connector Specifications................................................................................................4-27
4-2-7 RS-232C Connector Specifications...........................................................................................4-28
4-2-8 NY Monitor Link Connector Specifications................................................................................4-28
4-3 Software Specifications .....................................................................................................4-30
4-4 Environmental Specifications.............................................................................................4-31
4-4-1 Operation Environment Specifications ......................................................................................4-31
4-4-2 Temperature and Humidity Specifications.................................................................................4-32
4-4-3 Recycling Specifications ...........................................................................................................4-39
Section 5 Installation
5-1 Unpack ....................................................................................................................................5-2
5-1-1 Unpack Procedure ......................................................................................................................5-2
5-1-2 Items Supplied ............................................................................................................................5-2
5-2 Install Options ........................................................................................................................5-5
5-2-1 Install a Drive ..............................................................................................................................5-5
5-2-2 Install the PCIe Card ...................................................................................................................5-9
5-3 Mount ....................................................................................................................................5-14
5-3-1 Installation Method in Control Panels........................................................................................5-14
5-3-2 Product Orientation ...................................................................................................................5-15
5-3-3 Temperature ..............................................................................................................................5-15
5-3-4 Humidity ....................................................................................................................................5-18
5-3-5 Vibration and Shock ..................................................................................................................5-18
5-3-6 Atmosphere...............................................................................................................................5-19
5-3-7 Electrical Environment ..............................................................................................................5-19
5-3-8 Book Mount Procedure .............................................................................................................5-24
5-3-9 Wall Mount Procedure...............................................................................................................5-25
5-4 Wire .......................................................................................................................................5-26
5-4-1 Wiring Warnings and Cautions..................................................................................................5-26
5-4-2 Ground ......................................................................................................................................5-26
5-4-3 Wire the Power Connector ........................................................................................................5-33
5-4-4 Wire the I/O Connector .............................................................................................................5-36
5-5 Connect.................................................................................................................................5-39
CONTENTS
6NY-series Industrial Box PC Hardware User's Manual (W553)

5-5-1 Connector Identification ............................................................................................................5-39
5-5-2 Connection Procedure ..............................................................................................................5-40
5-6 Initial Power ON ...................................................................................................................5-42
5-6-1 Initial Power ON Procedure.......................................................................................................5-42
5-6-2 Windows Startup First Time ......................................................................................................5-44
5-7 Install Software ....................................................................................................................5-46
5-8 Connect UPS ........................................................................................................................5-47
5-8-1 Connect UPS Using the USB Connector ..................................................................................5-48
5-8-2 Connect UPS Using the I/O Connector.....................................................................................5-50
5-9 Create Backup and Repair Data .........................................................................................5-53
Section 6 Operating Procedures
6-1 Power ON................................................................................................................................6-2
6-1-1 Power ON Using the Power Button.............................................................................................6-2
6-1-2 Power ON Using the Power ON/OFF Input.................................................................................6-2
6-1-3 Auto Power ON ...........................................................................................................................6-2
6-2 Power OFF ..............................................................................................................................6-3
6-2-1 Power OFF Using the Power Button ...........................................................................................6-3
6-2-2 Power OFF Using Windows Shut Down .....................................................................................6-3
6-2-3 Power OFF Using the Power ON/OFF Input...............................................................................6-4
6-2-4 Forced Power OFF Using the Power Button...............................................................................6-4
6-3 React to Product Messages ..................................................................................................6-5
6-4 React to Windows Messages................................................................................................6-6
Section 7 Maintenance
7-1 Preventive Maintenance ........................................................................................................7-2
7-1-1 Preventive Maintenance Schedule..............................................................................................7-2
7-1-2 Clean the Box PC........................................................................................................................7-3
7-2 Corrective Maintenance ........................................................................................................7-4
7-2-1 Warning and Error Messages......................................................................................................7-4
7-2-2 Remove the Cover ......................................................................................................................7-6
7-2-3 Replace the Fan Unit ..................................................................................................................7-7
7-2-4 Replace the Battery.....................................................................................................................7-9
7-2-5 Replace a Drive.........................................................................................................................7-11
7-2-6 Replace the PCIe Card .............................................................................................................7-16
7-2-7 Replace the CFast Card............................................................................................................7-21
Appendices
A-1 BIOS ....................................................................................................................................... A-2
A-1-1 BIOS Overview........................................................................................................................... A-2
A-1-2 BIOS for 4th generation CPUs.................................................................................................... A-4
A-1-3 BIOS for 6th generation CPUs.................................................................................................. A-12
A-1-4 BIOS for 7th generation CPUs.................................................................................................. A-30
A-1-5 BIOS for Atom CPUs................................................................................................................ A-46
A-2 DVI Connector Pin Details.................................................................................................. A-52
A-2-1 DVI-I Connector Pin Details ..................................................................................................... A-52
A-2-2 DVI-D Connector Pin Details.................................................................................................... A-53
A-3 RS-232C Connector Pin Details......................................................................................... A-55
CONTENTS
7
NY-series Industrial Box PC Hardware User's Manual (W553)

Index
CONTENTS
8NY-series Industrial Box PC Hardware User's Manual (W553)

Manual Information
This section provides information about this manual.
Page Structure
The following page structure is used in this manual.
A
B
C
C D
E
F
B
C
H
5 Installation
5 - 3
NY-series User's Manual (W555)
5-1 Unpack
5
5-1-1 Unpack Procedure
G
5-1 Unpack
This section provides details on how to unpack the Industrial Panel PC.
5-1-1 Unpack Procedure
1Check the package for damage.
If there is any visible damage:
• Take photos of the package and save them.
• Inform your supplier immediately.
2Open the package.
Ensure not to damage the contents.
3Ensure that all items are present.
Additional Information
Refer to 5-1-2 Items Supplied with the Product for the items supplied.
Note: This illustration is provided as a sample. It will not literally appear in this manual.
Item Explanation Item Explanation
A Level 1 heading E Special Information
B Level 2 heading F Manual name
C Level 3 heading G Page tab with the number of the main section
D Step in a procedure H Page number
Manual Information
9
NY-series Industrial Box PC Hardware User's Manual (W553)

Special Information
Special information in this manual is classified as follows:
Precautions for Safe Use
Precautions on what to do and what not to do to ensure safe usage of the product.
Precautions for Correct Use
Precautions on what to do and what not to do to ensure proper operation and performance.
Additional Information
Additional information to read as required.
This information is provided to increase understanding or make operation easier.
Version Information
Information on differences in specifications and functionality between different versions.
Manual Information
10 NY-series Industrial Box PC Hardware User's Manual (W553)

Terms and Conditions Agreement
Warranty, Limitations of Liability
Warranties
Exclusive Warranty
Omron’s exclusive warranty is that the Products will be free from defects in materials and
workmanship for a period of twelve months from the date of sale by Omron (or such other period
expressed in writing by Omron). Omron disclaims all other warranties, express or implied.
Limitations
OMRON MAKES NO WARRANTY OR REPRESENTATION, EXPRESS OR IMPLIED, ABOUT
NON-INFRINGEMENT, MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE OF
THE PRODUCTS. BUYER ACKNOWLEDGES THAT IT ALONE HAS DETERMINED THAT THE
PRODUCTS WILL SUITABLY MEET THE REQUIREMENTS OF THEIR INTENDED USE.
Omron further disclaims all warranties and responsibility of any type for claims or expenses based
on infringement by the Products or otherwise of any intellectual property right.
Buyer Remedy
Omron’s sole obligation hereunder shall be, at Omron’s election, to (i) replace (in the form originally
shipped with Buyer responsible for labor charges for removal or replacement thereof) the non-
complying Product, (ii) repair the non-complying Product, or (iii) repay or credit Buyer an amount
equal to the purchase price of the non-complying Product; provided that in no event shall Omron be
responsible for warranty, repair, indemnity or any other claims or expenses regarding the Products
unless Omron’s analysis confirms that the Products were properly handled, stored, installed and
maintained and not subject to contamination, abuse, misuse or inappropriate modification. Return
of any Products by Buyer must be approved in writing by Omron before shipment. Omron
Companies shall not be liable for the suitability or unsuitability or the results from the use of
Products in combination with any electrical or electronic components, circuits, system assemblies
or any other materials or substances or environments. Any advice, recommendations or
information given orally or in writing, are not to be construed as an amendment or addition to the
above warranty.
See http://www.omron.com/global/ or contact your Omron representative for published information.
Terms and Conditions Agreement
11
NY-series Industrial Box PC Hardware User's Manual (W553)

Limitation on Liability; Etc
OMRON COMPANIES SHALL NOT BE LIABLE FOR SPECIAL, INDIRECT, INCIDENTAL, OR
CONSEQUENTIAL DAMAGES, LOSS OF PROFITS OR PRODUCTION OR COMMERCIAL LOSS IN
ANY WAY CONNECTED WITH THE PRODUCTS, WHETHER SUCH CLAIM IS BASED IN
CONTRACT, WARRANTY, NEGLIGENCE OR STRICT LIABILITY.
Further, in no event shall liability of Omron Companies exceed the individual price of the Product on
which liability is asserted.
Application Considerations
Suitability of Use
Omron Companies shall not be responsible for conformity with any standards, codes or regulations
which apply to the combination of the Product in the Buyer’s application or use of the Product. At
Buyer’s request, Omron will provide applicable third party certification documents identifying ratings
and limitations of use which apply to the Product. This information by itself is not sufficient for a
complete determination of the suitability of the Product in combination with the end product, machine,
system, or other application or use. Buyer shall be solely responsible for determining appropriateness
of the particular Product with respect to Buyer’s application, product or system. Buyer shall take
application responsibility in all cases.
NEVER USE THE PRODUCT FOR AN APPLICATION INVOLVING SERIOUS RISK TO LIFE OR
PROPERTY OR IN LARGE QUANTITIES WITHOUT ENSURING THAT THE SYSTEM AS A WHOLE
HAS BEEN DESIGNED TO ADDRESS THE RISKS, AND THAT THE OMRON PRODUCT(S) IS
PROPERLY RATED AND INSTALLED FOR THE INTENDED USE WITHIN THE OVERALL
EQUIPMENT OR SYSTEM.
Programmable Products
• Omron Companies shall not be responsible for the user’s programming of a programmable Product,
or any consequence thereof.
•Omron Companies shall not be responsible for the operation of the user accessible operating sys-
tem (e.g. Windows, Linux), or any consequence thereof.
Terms and Conditions Agreement
12 NY-series Industrial Box PC Hardware User's Manual (W553)

Disclaimers
Performance Data
Data presented in Omron Company websites, catalogs and other materials is provided as a guide for
the user in determining suitability and does not constitute a warranty. It may represent the result of
Omron’s test conditions, and the user must correlate it to actual application requirements. Actual
performance is subject to the Omron’s Warranty and Limitations of Liability.
Change in Specifications
Product specifications and accessories may be changed at any time based on improvements and
other reasons. It is our practice to change part numbers when published ratings or features are
changed, or when significant construction changes are made. However, some specifications of the
Product may be changed without any notice. When in doubt, special part numbers may be assigned to
fix or establish key specifications for your application. Please consult with your Omron’s representative
at any time to confirm actual specifications of purchased Product.
Errors and Omissions
Information presented by Omron Companies has been checked and is believed to be accurate;
however, no responsibility is assumed for clerical, typographical or proofreading errors or omissions.
Terms and Conditions Agreement
13
NY-series Industrial Box PC Hardware User's Manual (W553)

Safety Precautions
Definition of Precautionary Information
The following notation is used in this manual to provide precautions required to ensure safe usage of
the Industrial Box PC. The safety precautions that are provided are extremely important to safety.
Always read and heed the information provided in all safety precautions.
The following notation is used.
WARNING
Indicates a potentially hazardous situation which, if not avoid-
ed, could result in death or serious injury. Additionally, there
may be severe property damage.
Caution
Indicates a potentially hazardous situation which, if not avoid-
ed, may result in minor or moderate injury, or property damage.
Symbols
The circle and slash symbol indicates operations that you must not do. The
specific operation is shown in the circle and explained in text.
This example indicates prohibiting disassembly.
The triangle symbol indicates precautions (including warnings). The specific
operation is shown in the triangle and explained in text.
This example indicates a precaution for electric shock.
The triangle symbol indicates precautions (including warnings). The specific
operation is shown in the triangle and explained in text.
This example indicates a general precaution.
The filled circle symbol indicates operations that you must do. The specific
operation is shown in the circle and explained in text.
This example shows a general precaution for something that you must do.
Safety Precautions
14 NY-series Industrial Box PC Hardware User's Manual (W553)

Warnings
WARNING
Disassembly and Dropping
Do not attempt to disassemble, repair, or modify the product in any way. Doing so may
result in malfunction or fire.
Installation
Always connect to a ground of 100 Ω or less when installing the product.
Ensure that installation and post-installation checks of the product are performed by per-
sonnel in charge who possess a thorough understanding of the machinery to be instal-
led.
Fail-safe Measures
Provide safety measures in external circuits to ensure safety in the system if an abnor-
mality occurs due to malfunction of the product or due to other external factors affecting
operation. Not doing so may result in serious accidents due to incorrect operation.
Emergency stop circuits, interlock circuit, limit circuits, and similar safety measures must
be provided in external control circuits.
Unintended behavior may occur when an error occurs in internal memory of the product.
As a countermeasure for such problems, external safety measures must be provided to
ensure safe operation of the system.
The use of an uninterruptible power supply (UPS) allows normal operation to continue
even if a momentary power failure occurs, possibly resulting in the reception of an erro-
neous signal from an external device affected by the momentary power failure. Take ex-
ternal fail-safe measures. Where necessary, monitor the power supply voltage on the
system for external devices and use it as an interlock condition.
Safety Precautions
15
NY-series Industrial Box PC Hardware User's Manual (W553)

Actual Operation
Security setting adjustments should only be performed by the engineer in charge that
possesses a thorough understanding of the security settings. Selecting non-recommend-
ed security settings can put your system at risk.
Changing BIOS information is only allowed for the engineer in charge that possesses a
thorough understanding of the BIOS settings because it can change the behavior of the
product.
Safety Precautions
16 NY-series Industrial Box PC Hardware User's Manual (W553)

Cautions
Caution
Installation
When installing or removing a PCIe card, ensure to grip the Card Clip on the sides to
prevent contact with the sharp edges of the sheet metal frame tab. Injury may result.
Wiring
The product has an internal non-isolated DC power supply. Circuit ground (0 VDC) and
frame ground are connected together. When connecting a non-isolated device or a non-
isolated interface to the product, take appropriate actions to avoid communication fail-
ures or damage to the mentioned ports.
Industrial PC Platform Product Non-isolated
Device
Non-isolated
Interface
24 VDC
0 VDC
Never ground the 24 VDC side of the power supply. This may cause a short circuit.
Safety Precautions
17
NY-series Industrial Box PC Hardware User's Manual (W553)

Precautions for Safe Use
Disassembly, Dropping, Mounting, Installation and Storage
• Do not drop the product or subject it to abnormal vibration or shock. Doing so may result in product
malfunction or burning.
• When unpacking, check carefully for any external scratches or other damages. Also, shake the
product gently and check for any abnormal sound.
• Always use the devices specified in the relevant manual.
• The product must be installed in a control panel.
• Always install equipment that is included in the product specifications. Not doing so may result in
failure or malfunction.
• If the storage period exceeds 6 months, check the performance of the Fan Unit before production
starts.
• Install the product in the correct orientation and temperature according to the specifications in the
manual to prevent overheating. Not doing so may result in malfunction.
• When connecting peripheral devices to the product, ensure sufficient countermeasures against
noise and static electricity during installation of the peripheral devices.
• Always use the CFast Card slot cover to fully insert the CFast Card. Attempting to fully insert the
CFast Card using your finger can result in injury of your finger due to sharp edges around the CFast
Card bay.
• When closing the PCIe drawer ensure the power cable is not stressed or damaged.
Wiring
• Follow the instructions in the manual to correctly perform connector wiring and insertion. Double-
check all wiring and connector insertion before turning ON the power supply.
• Always ensure connectors, cables, PCIe Cards and Storage devices are completely locked in place
to prevent accidental disconnection.
• Before you connect a computer to the product, disconnect the power supply plug of the computer
from the AC outlet. Also, if the computer has an FG terminal, make the connections so that the FG
terminal has the same electrical potential as the product. A difference in electrical potential between
the computer and the product may cause failure or malfunction.
• Do not bend or pull the cables beyond normal limit. Do not place heavy objects on top of the cables
or other wiring lines. Doing so may break the cables.
• Always use power supply wires with sufficient wire diameters to prevent voltage drop and burning.
Make sure that the current capacity of the wire is sufficient. Otherwise, excessive heat may be gen-
erated. When cross-wiring terminals, the total current for all the terminals will flow in the wire. When
wiring cross-overs, make sure that the current capacity of each of the wires is not exceeded.
• Be sure that all mounting bracket screws and cable connector screws are tightened to the torque
specified in the relevant manuals. The loose screws may result in fire or malfunction.
• Use crimp terminals for wiring.
• For an NY Monitor Link connection, always follow the cable type and connection method specifica-
tions in the manual. Otherwise, communications may be faulty.
Precautions for Safe Use
18 NY-series Industrial Box PC Hardware User's Manual (W553)
