Emergency Stop Switch
A165E
Mounting Aperture of
16 mm
• Modular construction, easy installation
• Direct opening mechanism with mini-
mum contact separation of 3 mm in ac-
cordance with EN60947-5-1, . (only
for NC contacts)
• Conforms to EN418, EN60947-5-1.
• Includes a safety lock to prevent mis-
use.
• Features separate construction that al-
lows the Switch to be separated for
easier wiring and one-piece-like con-
struction that allows easier handling.
• High reliability, IP65
• Short mounting depth, less than 28.5
mm below panel
• Quick and easy assembly, snap-in
Switch.
• A165E is identifiable, clearly visible
and will stop a dangerous process,
without creating additional hazards.
Æ
Model Number Structure
Model Number Legend
1. Lighted/Non-lighted
None: Non-lighted
L: Lighted
2. Head Size
S: 30 mm dia.
M: 40 mm dia.
3. Illumination (Operation Voltage/Rated Voltage)
None: Non-lighted
24D: LED (24 VDC)
4. Contacts
01: SPST (NC)
02: DPST (NC)
03U: TPST (NC)
One-body, non-lighted models only
1 2 3 4
A165E-##-#-#
F502-EN2-04.book Seite 283 Dienstag, 26. Juli 2005 5:48 17

G-284 Safety Sensors / Components
Ordering Information
List of Models
Note: The above models have a surface indication of “RESET.” Models with “STOP” indication are also available. For further information, contact
your OMRON representative.
Accessories (Order Separately)
Specifications
Approved Standards
Note: UL: UL508, cUL: CSA C22 No. 14
Approved Standard Ratings
UL, cUL
Illumination Rated voltage Pushbutton color Pushbutton size Terminal Contact
Standard load
(125 VAC at 5 A,
250 VAC at 3 A,
30 VDC at 3 A)
LED 24 VDC
Red
30 dia.
Solder terminal
SPST-NC A165E-LS-24D-01
DPST-NC A165E-LS-24D-02
None ---
SPST-NC A165E-S-01
DPST-NC A165E-S-02
TPST-NC A165E-S-03U
LED 24 VDC
40 dia.
SPST-NC A165E-LM-24D-01
DPST-NC A165E-LM-24D-02
None ---
SPST-NC A165E-M-01
DPST-NC A165E-M-02
TPST-NC A165E-M-03U
Item Appearance Type Model Precautions
Yellow Plate Yellow, 45 dia. A16Z-5070 Use this as an emergency stop
nameplate.
Panel Plug
Rectangular A16ZJ-3003 Used for covering the panel cutouts
for future panel expansion.
Square A16ZA-3003
Round A16ZT-3003
Tightening Tool --- A16Z-3004 Useful for repetitive mounting. Be
careful not to tighten excessively.
Extractor --- A16Z-5080 Convenient for extracting the Switch
and Lamp.
Recognized Organization Standards File No.
UL, cUL (see note) UL508 E41515
AZCO EN60947-5-1 C9805501
Rated voltage Rated current
A165E series A165E-U series
125 VAC
250 VAC
30 VDC
5 A (General use)
3 A (General use)
3 A (Resistive)
1 A (General use)
0.5 A (General use)
1 A (Resistive)
F502-EN2-04.book Seite 284 Dienstag, 26. Juli 2005 5:48 17

G-285A165E
A165E
Ratings
Switch Ratings
Characteristics
Note: LED not mounted. Test them with the LED removed.
Operating Characteristics
Rated voltage Resistive load
A165E series A165E#-U series
125 VAC
250 VAC
30 VDC
5 A
3 A
3 A
1 A
0.5 A
1 A
Minimum applicable
load 150 mA at 5 VDC 1 mA at 5 VDC
Item Emergency Stop Switch
Allowable operating
frequency
Mechanical 20 operations/minute max.
Electrical 10 operations/minute max.
Insulation resistance 100 MΩmin. (at 500 VDC)
Dielectric strength
1,000 VAC, 50/60 Hz for 1 min between terminals of same polarity
2,000 VAC, 50/60 Hz for 1 min between terminals of different polarity and also between each
terminal and ground
1,000 VAC, 50/60 Hz for 1 min between lamp terminals (see note)
Vibration resistance Malfunction 10 to 55 Hz, 1.5-mm double amplitude (malfunction within 1 ms)
Shock resistance
Destruction 500 m/s2
Malfunction 300 m/s2max. (malfunction within 1 ms),
150 m/s2max. In case of A165E#U series
Durability Mechanical 100,000 operations min.
Electrical 100,000 operations min.
Ambient temperature Operating:-10°C to 55°C (with no icing or condensation)
Storage:-25°C to 65°C (with no icing or condensation)
Ambient humidity Operating:35% to 85%
Electric shock protection class Class II
PTI (tracking characteristic) 175
Degree of contamination 3
Weight Approx. 16 g (in case of DPDT Switches)
Features Characteristics
Operating force (OF) max. 14.7 N
Releasing force (RF) min. 0.1 N·m
Pretravel (PT) 3.5±0.5 mm (3±0.5 mm In case of A165E#U series)
F502-EN2-04.book Seite 285 Dienstag, 26. Juli 2005 5:48 17

G-286 Safety Sensors / Components
Nomenclature
\
Push-lock, Turn-reset System Prevents Misuse Safety Lock Prevents Misuse
Even if an object or person touches the pushbutton by mistake, the
contact will not be released unless the pushbutton reaches the lock
position.
Illumination Colors
∑LED Illumination
Red
∑Non-lighted
Red
Protective Structure and Terminal Type
∑Protective Structure
Oil-resistant IP65
∑Terminal Type
Switch Specifications
∑Standard Loads
Illumination Method
∑LED
Lamp
∑LED lamp
Solder terminals
(tab terminals #110)
Note: A165E Emergency Stop Switch must be ordered as a set.
No LED is installed for the non-lighted model.
5 A at 125 VAC
3 A at 250 VAC
3 A at 30 VDC
Contact open
Contact closed
Lock position
F502-EN2-04.book Seite 286 Dienstag, 26. Juli 2005 5:48 17

A165E
G-287A165E
Dimensions
Note: All units are in millimeters unless otherwise indicated.
22.1±0.8
22.1±0.8
22.7
16+0.2 dia.
0
3+0.1 dia.
0
Lock ring
Lock
Packing (T0.5)
Mounting ring
30 dia.
A165E
A165E
Mounting ring
Lock ring
Lock
Packing (T0.5)
16+0.2 dia.
0
3+0.1 dia.
0
30 dia.
A165E#U
Mounting ring
Packing (T0.5)
Lock ring
Mounting ring
16+0.2 dia.
03+0.1 dia.
0
30 dia.
Non-lighted models
30 mm diameter
7.8+0.3 dia.
0
Panel cutout
dimensions
Note: 1. When applying a coating such as
paint to the panel, dimensions
after the coating must satisfy the
specified dimensions.
2. Recommended panel thickness:
0.5 to 3.2 mm.
Lighted models
30 mm diameter
0
7.8+0.3 dia.
Panel cutout
dimensions
Note: 1. When applying a coating such as
paint to the panel, dimensions
after the coating must satisfy the
specified dimensions.
2. Recommended panel thickness:
0.5 to 3.2 mm.
One-body models
30 mm diameter
7.8+0.3 dia.
0
Panel cutout
dimensions
Note: 1. When applying a coating such as
paint to the panel, dimensions
after the coating must satisfy the
specified dimensions.
2. Recommended panel thickness:
0.5 to 3.2 mm.
F502-EN2-04.book Seite 287 Dienstag, 26. Juli 2005 5:48 17

G-288 Safety Sensors / Components
M16¥1
10.8±0.5
21.1±0.8
28.5±0.8
20±0.8
M16¥1
1.42.6
M16¥1
21.5±0.5
SR82
1
0.5
12.3
15.8
2.8
12.1
18
0.5
12.3
15.8
2.8
6.05
18
A165E
A165E
A165E#U
Mounting ring
Lock ring
Lock
Packing (T0.5)
40 dia.
16+0.2 dia.
0
3+0.1 dia.
0
Mounting ring
Lock ring
Lock
Packing (T0.5)
40 dia.
16+0.2 dia.
0
3+0.1 dia.
0
Mounting ring
Lock ring
40 dia.
3+0.1 dia.
0
16+0.2 dia.
0
Operation part
SR82
Lock
Packing (T0.5)
Switch
Switch
Non-lighted models
40 mm diameter
7.8+0.3 dia.
0
Panel cutout
dimensions
Note: 1. When applying a coating such as
paint to the panel, dimensions
after the coating must satisfy the
specified dimensions.
2. Recommended panel thickness:
0.5 to 3.2 mm.
Lighted models
40 mm diameter
7.8+0.3 dia.
0
Panel cutout
dimensions
Note: 1. When applying a coating such as
paint to the panel, dimensions
after the coating must satisfy the
specified dimensions.
2. Recommended panel thickness:
0.5 to 3.2 mm.
Non-lighted,
one-body models
40 mm diameter
7.8+0.3 dia.
0
Panel cutout
dimensions
Note: 1. When applying a coating such as
paint to the panel, dimensions
after the coating must satisfy the
specified dimensions.
2. Recommended panel thickness:
0.5 to 3.2 mm.
F502-EN2-04.book Seite 288 Dienstag, 26. Juli 2005 5:48 17

G-289A165E
A165E
Accessories
Yellow Plate (Vinyl Chloride)
Lock Ring
Panel Plugs
Select an appropriate Panel Plug according to the panel design and
mount from the front side of the panel. Panel cutout dimensions are
the same as those for the Switch.
Screw Fitting
Terminal Arrangement
t=1
A16Z-5070
15.6 dia.
45 dia.
12 ¥12
15.8 ±0.1 dia.
Rough surface
15 dia. 0
-0.1
Rough
surface
Rectangular Square Round
A16Z-3004
18 dia.
NC3
NC1
NC2
SPST Switches
Note: The L+ and L-terminals are not available with the non-lighted models.
DPST Switches TPST Switches
Stopper
F502-EN2-04.book Seite 289 Dienstag, 26. Juli 2005 5:48 17

G-290 Safety Sensors / Components
In the interest of product improvement, specifications are subject to change without notice.
