Onespace 50-CS01 User manual

7
CRAFT STATION IN SILVER WITH BLUE GLASS
ASSEMBLY INSTRUCTIONS
MODEL 50-CS01
SUPPLIER CODE: HMOF
For fastest service on claims, requests for replacement parts,
www.comfortproducts.net/support
e-mail: [e-mail]
Keep your sales receipt as documentation of your ownership.
CUSTOMER SERVICE
or questions, please visit our website at:
OneSpace is a Trademark of Comfort Products, Inc.
™

Desktop maximum
weight capacity
=
130 lbs
r maximumewarD
weight capacity
=
sbl10
ASSEMBLY OVERVIEW (50-CS01)
2 of 10
THE DRAWING BELOW SHOWS THE BACK OF THE DESK.

PARTSLIST1OF2 (50-CS01) # DESCRIPTION SIDE 1 SIDE 2 STOCK # QTY.
#
DESCRIPTION
STOCK #
QTY.
1 Right Leg 51-CS01LEGR 1
2Left Leg 51-CS01LEGL 1
3Support Frame 51-CS01SF 1
4Non-locking
Caster 51-CS01CA 2
5
6
Locking Caster 51-CS01CAL 2
Glide 51-CS01GD 4
7 Lift 51-CS01LFT 1
1
3 of 10
8Desktop Frame 51-CS01DF
THE PART NUMBER CAN BE FOUND ON THE SIDE OF THE PART, EITHER STAMPED OR ON A STICKER.
ITEMS ARE NOT SHOWN TO SCALE.

ITEMS ARE NOT SHOWN TO SCALE.
PARTSLIST2OF2 (50-CS01) # DESCRIPTION SIDE 1 SIDE 2 STOCK # QTY.
#
DESCRIPTION
STOCK #
QTY.
Right Drawer
Frame 51-CS01DFR 1
10 Left Drawer
Frame 51-CS01DFL 1
11 Crossbar 51-CS01CR 4
12 Drawer with
Bottom Piece 51-CS01DWR 2
13
14
9
Tray Frame 51-CS01TRF 2
Multi-slot Tray 51-CS01TRM 2
15 Single Slot Tray 51-CS01TRS 2
1
4 of 10
16 Glass Desktop 51-CS01DT
1
17 Metal Lip 51-CS01LIP
2
18 Desktop Stopper 51-CS01STP

5 of 10
EXTRA HARDWARE INCLUDED FOR YOUR CONVENIENCE. ITEMS ARE NOT SHOWN TO SCALE.
HARDWARE LIST (50-CS01)
PART DESCRIPTION QT Y.
A
M4 X 14MM 2
C 10
- READ THE INSTRUCTION MANUAL BEFORE ASSEMBLING.
- REMOVE ALL PIECES BEFORE BEGINNING INSTALLATION.
- OPEN THE HARDWARE AS NEEDED .
- ASSEMBLE IN AN AREA WITH PLENTY OF SPACE.
- READ EACH STEP BEFORE BEGINNING CONSTRUCTION.
- HAVE A SCREWDRIVER BEFORE YOU BEGIN ASSEMBLING
(NOT INCLUDED).
- NEVER FORCE THE SCREWS OR FITTINGS.
- KEEP THIS MANUAL FOR FUTURE REFERENCE.
- TIGHTEN ALL THE SCREWS EVERY 6 MONTHS.
CLEANING AND CARE
- CLEAN SURFACES WITH A DRY OR DAMP CLOTH.
- DO NOT USE ABRASIVE CLEANERS.
- DO NOT USE A POWER DRILL.
HARDWARE KIT
STOCK # 51-CS01HA
D
F
M6 x 15MM
M6 x 12MM
Allen Wrench
2
B
M6 x 25MM 12
E
M6 x 45MM 6
1
Extra Hardware (A - E) 1 set
IF YOU ARE MISSING ANY OF THESE PARTS, OR IF YOU HAVE A DAMAGED PART, PLEASE VISIT WWW.COMFORTPRODUCTS.NET/SUPPORT
REFERENCE THE MODEL # ON THE FRONT OF THIS MANUAL. SIMPLY COMPLETE THE INFORMATION, INCLUDING THE PART YOU NEED. THE
PART WILL NORMALLY BE SHIPPED WITHIN 48 HOURS.

ASSEMBLY INSTRUCTIONS (50-CS01)
6 of 10
STEP 1
Screw in the two Non-locking Casters (4) at the back of the Right (1) and Left (2) Legs
and screw in the Locking Casters (5) at the front of the Legs. You may alternately screw
in the four Glides (6) in place of the Casters.
Attach the Legs to the Support Frame (3) with four Screws (A),
tightening with the Allen wrench (F).
STEP 2
Using two Screws (B) attach the Desktop Stoppers (18) to the top back of the Legs as shown.
Attach the Lift (7) to the Support Frame (3) with two Screws (C),
tightening with the Allen wrench (F).
C x 2
A x 4
B x 2
F
F
NOTE: THE DRAWINGS BELOW SHOW THE BACK OF THE DESK.
2 (Left)
1 (Right)
5 (Locking)
4 (Non-locking)
6 x 4 (optional)
18
7
A
B
3
C

ASSEMBLY INSTRUCTIONS (50-CS01)
7 of 10
STEP 3
Attach the Desktop Frame (8) to the Legs using two Screws (D).
Attach the Lift (7) to the Desktop Frame using two Screws (C).
STEP 4
Use six Screws (E) to attach the Right Drawer Frame (9) and the Left Drawer Frame (10) to the four Crossbars (11). The top
holes of the Right Drawer Frame will be used later to attach the entire frame to the desk.
E x 6
F
F
C x 2
D x 2
C
8
7
10
11 9
E
D

ASSEMBLY INSTRUCTIONS (50-CS01)
8 of 10
STEP 5
Attach the Tray Frames (13) to the Desktop Frame (8) using four Screws (C).
Attach the Right Drawer Frame (9) and the two top Crossbars (11) to the
Right Leg (1) using two Screws (A).
Place the Bottom Pieces in the Drawers (12)
and insert the Drawers into the frame.
STEP 6
Insert the Multi-slot (14) and Single Slot (15) Trays into the Tray Frames (13).
F
C x 4
A x 2
13
A
C
8
9
1
11
12
14
15
NOTE: THE DRAWINGS BELOW NOW SHOW THE FRONT OF THE DESK.

ASSEMBLY INSTRUCTIONS (50-CS01)
9 of 10
STEP 7
Attach the Glass Desktop (16) to the Desktop Frame (8) using six Screws (E).
Attach the Lip (17) to the Desktop Frame (8) using two Screws (C).
F
C x 2
E x 6
16
17
C
E

•
•
•
10 OF 10
DO NOT stand on the desk. Do not use the desk as a stepladder.
ed.
Every 6 months, check all bolts and screws to ensure they are tight.
Comfort Products, Inc.
P.O. Box 999
Memphis, TN 38101
Comfort Products warrants this product to be free from defects in material and workmanship for one (1) year. This warranty is made by
Comfort Products only to the original end-user customer acquiring the product directly from Comfort Products’ authorized dealers
as shown by the original sales receipt. The end-user customer remedy pursuant to this warranty is limited to repair or replacement of
parts at Comfort Products’ option within a reasonable amount of time. Comfort Products reserves the right to require damaged parts
to be returned to Comfort Products upon request. Consent from Comfort Products must be obtained before any warranty work is
performed. This warranty applies under conditions of normal use and is not subject to defects caused by improper assembly or
disassembly; defects occurring after purchase due to product mo sure
to the elements; labor or assembly cost. This warranty does not cover the cost of transportation or labor. In no event shall Comfort
Products be liable in either tort or contract for any loss or direct, special, incidental, consequential or exemplary damages. This Limited
Warranty is NOT applicable to end-user customers who use Comfort Products for rental purposes. This warranty applies only to end-user
customers in the United States. All warranties are limited to the original purchaser for normal use. The weight capacity of the desktop is
130 pounds and the weight capacity of the drawers is 10 pounds. For claims or questions concerning this warranty, please visit:
www.comfortproducts.net or email us at: [email protected]
PLEASE VISIT WWW.COMFORTPRODUCTS.NET FOR WARRANTY INFORMATION
www.comfortproducts.net
[email protected]
OneSpace is a Trademark of Comfort Products, Inc.
™
MODEL: 50-CS01
