Onespace 50-JN01 User manual

MOBILE LAPTOP COMPUTER DESK, DUAL SURFACE
ASSEMBLY INSTRUCTIONS
MODEL # 50-JN01
SUPPLIER CODE: JNFF
OneSpace is a Trademark of Comfort Products, Inc.
™

2 OF 7
mumixamelbatpotpaL
weight capacity
=
15lbs
mumixamelbatdapesuoM
weight capacity
=
10lbs
A
B
M
JK
FF
E
D
I
N
N
CH
HG
G
G

HARDWARE KIT
STOCK # 51-JN01HA
PART DESCRIPTION QTY
STOCK NO
REPLACEMENT PARTS
IF YOU ARE MISSING ANY OF THE PARTS ABOVE, OR IF YOU HAVE A DAMAGED PART, PLEASE VISIT WWW.COMFORTPRODUCTS.NET/SUPPORT
REFERENCE THE MODEL # ON THE FRONT OF THIS MANUAL. SIMPLY COMPLETE THE INFORMATION, INCLUDING THE PART YOU NEED.
THE PART WILL NORMALLY BE SHIPPED WITHIN 48 HOURS.
- READ THE INSTRUCTION MANUAL BEFORE ASSEMBLING.
- REMOVE ALL PIECES BEFORE BEGINNING INSTALLATION.
- OPEN THE HARDWARE AS NEEDED.
- ASSEMBLE IN AN AREA WITH PLENTY OF SPACE.
- READ EACH STEP BEFORE BEGINNING CONSTRUCTION.
- HAVE THE TOOLS BELOW BEFORE YOU BEGIN ASSEMBLING.
- NEVER FORCE THE SCREWS OR FITTINGS.
- KEEP THIS MANUAL FOR FUTURE REFERENCE.
- TIGHTEN ALL THE SCREWS EVERY 6 MONTHS.
- DO NOT SHIFT OR DRAG THE PRODUCT AFTER ASSEMBLY.
CLEANING AND CARE
- CLEAN SURFACES WITH A DRY OR DAMP CLOTH.
- DO NOT USE ABRASIVE CLEANERS.
- DO NOT USE FURNITURE WAX OR POLISH AS THE UNIT
IS FINISHED WITH A PROTECTIVE CLEAR LACQUER.
1
- THE FOLLOWING TOOLS ARE NOT INCLUDED.
51-JN01LB
Laptop Board
A
1
51-JN01MB
Mouse Pad Board
B
1
51-JN01BS
Base
C
1
51-JN01BSP
Center Bar
D
1
51-JN01TSP
Top Support
E
2
51-JN01BR
Support Bar
F
PART DESCRIPTION QTY
STOCK NO
51-JN01CV
Base Cover
I
51-JN01PA
Pivot Anchor
J
1
K
M
PART DESCRIPTION QTY
PARTS AND HARDWARE LIST (50-JN01)
EXTRA HARDWARE INCLUDED FOR YOUR CONVENIENCE. ITEMS ARE NOT SHOWN TO SCALE.
51-JN01TK
Tilt Knob
2
51-JN01SK
Support Knob
N
3
51-JN01CA
Caster
G
2
51-JN01CAL
Locking Caster
H
51-JN01UB 1
U Bracket
Washer
Wrench
Allen Key
Extra Hardware Pack
(1-5)
M6 Nut
1
1
3 OF 7
M6X35MM
M6X23MM
M6X12MM
1
2
3
4
5
6
6
4
4
2
6
7
1
1
1

ASSEMBLY INSTRUCTION (50-JN01)
DO NOT TIGHTEN SCREWS UNTIL COMPLETELY ASSEMBLED
STEP 2
STEP 1
Screw the Locking Casters (H) into the middle legs of the Base (C). Screw the Non-locking Casters (G) into the outer legs of the Base.
Attach the Center Bar (D) to the Base using four Screws (1). NOTE: The holes at
the top of the Center Bar should be facing the shorter end of the Base.
Slide the Base Cover (I) over the Center Bar.
1X4
5X4
1
5
4 OF 7
4X2
J
X2
5
1
4
5
1
M
F
E
4 PCS
4 PCS
Attach the Pivot Anchor (J) to the Top Support (E) using the Tilt Knob (M) and two Washers (4).
Attach the Support Bars (F) to the Top Support (E) using
two Screws (1) and two M6 Nuts (5).
2 PCS
2 PCS
2 PCS
X2
D
I
C
G
G
G
H
H
The holes should face this
direction.

ASSEMBLY INSTRUCTION (50-JN01)
DO NOT TIGHTEN SCREWS UNTIL COMPLETELY ASSEMBLED
STEP 3
STEP 4
3X4
AK
J
3
5 OF 7
Attach the Pivot Anchor (J) to the Laptop Board (A) using two Screws (3).
Attach the Top Support (E) to the Laptop Board (A) using the U Bracket (K) and two Screws (3).
2X4
B
F
2
Attach the Support Bars (F) to the Mouse Pad Board (B) using four Screws (2).
4 pcs
4 pcs

ASSEMBLY INSTRUCTION (50-JN01)
DO NOT TIGHTEN SCREWS UNTIL COMPLETELY ASSEMBLED
STEP 5
6 OF 7
Insert the Top Support (E) into the Center Bar (D). Secure it at the desired height using the Support Knobs (N) .
N

• DO NOT stand on the desk. Do not use the desk as a stepladder.
•
• Every 6 months, check all bolts and screws to ensure they are tight.
• This products is California 93120 Compliant for Formaldehyde.
PLEASE VISIT WWW.COMFORTPRODUCTS.NET FOR W ARRANTY INFORMATION
MODE L : # 50-JN01
Comfort Products, Inc.
P.O. Box 999
Memphis, TN 38101
www.comfortproducts.net
[e-mail]
OneSpace is a Trademark of Comfort Products, Inc.
™
7 OF 7
