1 - System Overview
1.1 - Accessories

If you purchased additional items such as mounting brackets, power supplies or antennas, they will be
located in the system box or within the outer shipping carton.
All drivers and product guides can be found on the corresponding product page. For more information
on accessories and additional features, visit the ML510G-50 page at:
US: https://www.onlogic.com/ml510g-50/
EU: https://www.onlogic.com/eu-en/ml510g-50/




1.2 - Product Specifications
ML510G-50
Processor
Up to Intel Core i7
Memory Type
2 DDR4 SO-DIMM (non-ECC)
Memory Capacity
32 GB
Chipset
Intel H310
Integrated Graphics
Intel UHD Graphics 610/630
Front I/O
2 USB 2.0 ports
4 COM ports (1 RS232/422/485, 3 RS232) (optional)
1 Power button
Back I/O
2 DisplayPort connectors (max resolution: 4096x2304 @ 60 Hz)
2 Gb LAN ports (+2 optional Gb LAN)
4 USB 3.1 ports
2 Audio jacks (line-out; mic-in)
4 Antenna punchouts
Expansion & Storage
1 M.2 2230 E-key (PCIe x1, USB 2.0)
1 M.2 2260 M-key (PCIe x1)
1 M.2 2280 M-key (SATA)
System Monitoring
TPM (optional)
Watchdog Timer
Operating Systems
Windows 10, Ubuntu 18.04
LAN Controllers
Intel I219-V
Realtek RTL8111H
Voltage Input
19 VDC
Dimensions
197 x 86.2 x 202 mm (7.76 x 3.41 x 7.95 in)
Mounting
Wall, DIN, VESA
Temperature
Operating Temperature: 0°C ~ 40°C or 0°C ~ 50°C with some power
adapter configurations
Regulatory Information
2011/65/EU (RoHS 2 Directive)
CE
EN 55022
EN 55024
EN 55032
EN 60950-1
FCC 47 CFR Part 15


1.3 - Exterior Features and Dimensions
1.3.1 - Front I/O
1.3.2 - Back I/O


1.3.3 - ML510G-50 Dimensions



2 - I/O Definitions
2.1 - Serial Ports


Pin
RS-232
RS-422
RS-485
1
DCD
TX-
TX-/RX-
2
RX
RX+
NC
3
TX
TX+
TX+/RX+
4
DTR
RX-
NC
5
GND
GND
GND
6
DSR
NC
NC
7
RTS
NC
NC
8
CTS
NC
NC
9
Power
Power
Power

NC = Not Connected


2.2 - LAN
LED
Color
State
Condition
Link
-
Off
LAN link is not
established
Green
On
LAN link is established
Blinki
ng
LAN activity occurring
Speed
-
Off
10 Mb/s data rate
Yello
w
On
100 Mb/s data rate
Green
On
1000 Mb/s data rate
 


3 - Mounting Instructions
3.1 - Wall and DIN Mounts

Step 1: Attach wall mounting brackets to the chassis using screw M3x0.5 Flat Head screws.
The three 4.6 mm holes are for DIN mounting. For DIN, use M3 or 4-40 screws
Step 2: Mark and prepare holes on the surface for mounting.
Step 3: Fasten system to surface.
 



Note: both the rubber feet and mounting brackets provide the same height of 3.7 mm.












