Opitec Easy-Line Wind Generator User manual

116.655
Easy-Line Wind Generator
Stocklist Quantity Size (mm) Description Part-Nr.
Plywood 1 80 x 70 x 10 Baseplate 1
Acrylic Glass 1 115 x 80 x 2 Motor Holder 2
LED, yellow 2 ø 10 Lamp 3
Motor 1 2-polig Generator 4
Windmill 1 ø 60 Windmill 5
Screw 2 2,9 x 13 Attachment 6
Drawing Pin 2 Attachment 7
Tools required:
Hammer
Philips
Screwdriver
Please note:
The OPITEC handicraft packs are not toys in a typical off-the-shelf
sense, but rather additional teaching and learning material for edu-
cational purposes. This craft pack may only be constructed by child-
ren and adolescents under the guidance and supervision of experi-
enced adults. Not suitable for children under 36 months. Choking
hazard!
1

2
12
343
4
5
3
7
2
6
1
Construction Manual 116.655
Easy-Line Wind Generator
1 Fix the prefabricated acrylic plate (2) to the broad sides of the ply-
wood baseplate (1) by using the two screws (6).
2 Mount the motor (4) from behind into the opening of the acrylic
plate
as depicted.
3 Attach the fan (5) from the front side to the motor shaft.
How it works:
Propel the fan by blowing, wind or another fan. The LED lights up as soon as the generator (motor) provides sucient electricity.
If the LED is o:
- Check wiring (Possibly reverse the polarity!)
- Rotational speed of the fan might be to low
4 Connect the red wire of the motor to the cathode (= short leg) of the
LED (3). Next, connect the black wire of the motor to the anode of the
LED. Finally fix the LED onto the baseplate using the drawing pins (7).
Done!
cathode (=
short leg)
cathode
