Opus VS 2000CA User manual

User’s guide VS 2000 CA User’s guide VS 2000 CA
Technical data:
Shredder type: cross-cut
Feed opening: 230 mm
Performance: 20 / 1 CD / 1 credit card
Cutting with: 4x35 mm
Volume for shreds: 41
Supply: 230 V
Input current : 2,4A
Dimensions H / W / D: 660x416x310 mm
Net weight: 13,4 kg
Gross weight: 14,3 kg
* paper 80g/m²
16.06.2010
dystrybutor: OPUS Sp. z o.o. ●ul. Toruńska 8 ●44 – 122 Gliwice ●www.opus.pl
7
User’s guide
VS 2000CA

User’s guide VS 2000 CA User’s guide VS 2000 CA
Safety precautions:
•Before putting the machine into operation please read the safety
precautions, manufacturer recommendation and the operation manual.
The operation manual should be easily available at any time for the
operator.
•The machine should be installed on a sturdy and level surface near the
230V socket
•The machine should be protected against moisture and dust
•Do not place the machine near the heating units or ventilation units
•The machine should not be used in vicinity of inflammable liquids or
gases
•The supplying cable should be protected against any damage, must not
be used to pull the machine or to remove plug from a socket
•During a long standstill or before replacing the machine, unplug the
machine from the socket
•The machine is turned off completely after removing the plug from
a socket
•The machine should be kept away from children’s reach
•Danger! Machine contains rotary elements. Be careful with long hair,
loose jewellery, ties and other loose pieces of clothing – they can
become entangled in cutting head.
•Be careful when reaching the feeding slot
•Use the machine only according to its destination!
•It is necessary to check and supervise if the machine operates
correctly. In case of any malfunctions it is required to contact service
point.
•The machine must not be located outside, should be operated in room
temperature higher than +8°C
•Before removing any cover from the machine, unplug the machine from
the socket
•Using inappropriate lubricants causes fire hazard!
•The machine should be operated according to general safety rules.
•Any repairs can be conducted only by authorised staff.
1 6
Declaration of Conformity
Deklaracja Zgodności
OPUS Sp.z o.o. hereby declares that the machine specified below is in accordance with the
following directives and standards:
Opus Sp.z o.o. deklaruje z pełnąodpowiedzialnością, że urządzenie, którego dotyczy niniejsza
deklaracja jest zgodne z postanowieniami następujących dyrektyw UE oraz powiązanymi z nimi
normami zharmonizowanymi:
73/23/EWG , 89/336/EWG , 99/5/WE
PN-EN 60950:2000 ; PN- EN 55014-1:2001; PN –CISPR 16-1: 1997; PN –CISPR 16-2: 1999
Name/ Nazwa : OPUS Sp. z o. o.
Address/ Adres : ul. Toruńska 8 44-122 Gliwice
Type of the machine / typ : Niszczarka / Shredder
Model No / model : VS 1500 CA
POLAND / Polska …………………………………
(Place / Kraj) (Signature / podpis)
05.04.2005 Aleksander Macha
(Date / Data) (Full Name/ Imięi Nazwisko)

User’s guide VS 2000 CA User’s guide VS 2000 CA
Possible malfunctions:
When the machine does not function or functions incorrectly, please check
the following:
•If the machine is plugged in?
•If the main switch is on “ON” position?
•If there is no paper stuck inside the shredding mechanism?
•If the cutting head is installed correctly? (the safety switch located
under the cutting head works only if the cutting head and waste bin
are correctly installed)
In case of further malfunctions contact authorized service team.
Cleaning of the volume for shreds:
Cleaning the volume for shreds is necessary, when the shreds can be seen
in the bin window. To empty the bin:
•Pull the shred bin out of the shredder.
•Empty the bin.
•Push the bin into the shredder.
Some paper scraps may remain inside the shredding mechanism after
emptying the shred bin, it can cause increasing sound level temporarily.
Maintenance:
To prevent reduction of efficiency and increase of sound level as well as to
prolong machine lifespan, it is necessary to oil cutting shafts regularly. After
filling the waste bin for several times, the blades should be greased with
special oil (provided by OPUS). Put the oil on few pieces of paper and
shred them so that the oil was spread on the whole cutting mechanism.
5
Recommendations:
•The machine is designed to shred paper, plastic cards and
CD/DVDs.
•Clean up the waste bin frequently
•The shredder can be operated only with paper bin included.
•To ensure long and faultless utilisation of the machine do not shred
more than 20 sheets of 70g/m². Do not shred computer printout,
PVC foil, coated paper or cardboard – it can cause damage of
cutting mechanism.
•Do not shred more than one CD at one time. Before shredding put
the CD into the envelope or between two sheets of paper.
•NOTE! Desk-side shredders are not designed for continuous
operation.
•It is recommended to make 30 minutes break after every 15
minutes of shredding. The shredder is protected against
overheating. When the max temperature of engine is exceeded the
machine turns off automatically.
•Do not set REV mode, if it is not necessary
NOTE! Not complying with the recommendations above can result
with warranty void.

User’s guide VS 2000 CA User’s guide VS 2000 CA
2
Machine construction:
Installation:
•Pull out the volume for shreds. Push four castors into the wholes at the
bottom of the bin and secure it by the gum covers.
•Wsuńz powrotem pojemnik na ścinki
•Place the cutting head on the waste basket
•Plug in the 230V wall socket
•Press the main switch to the position „AUTO/ON”, green LED
illuminates The shredder is ready to operation
3
LCD Display Functions
If these warning icons
flash, please follow
step 2
If this icon flashes, please follow step 1
1.
The machine works properly when this icon
flashes, the dots show the increasing power
2
OVERHEAT – cool down the motor for 30
minutes
OVERLOAD – max 20 sheets can be shredded
DOOR OPEN – please make sure the basket is
in the right place
Operation:
The main switch is located at the top of the shredder. It can be set in three
positions:
•ON/OFF – after choosing this option the machine is ready to operation.
Starts automatically when the paper is inserted and stops automatically
when no further paper is inserted.
•FWD – this option is recommended for cleaning scraps of paper on the
cutters. This button works only during ON-mode
•REV –this position helps to remove paper if it gets stuck inside the
cutting shafts. It can also be used for cleaning shredding mechanism.
When the waste bin is full the machine does not work →removing shreds
from the bin is necessary.

User’s guide VS 2000 CA User’s guide VS 2000 CA
4
