Oregon Scientific RRM902 User manual

Rainbow Clock with 8 Soothing Sounds and FM Radio
Model: RRM902 / RRM902U / RRM902A
USER MANUAL

EN
2
OVERVIEW
FRONT VIEW
1
2
3
4
5
6
8
7
9
10
11
12
1. SNOOZE · SOUND: activate snooze alarm; turn
soothing sound on / off; select soothing sound
2. :clock signal reception indicator
3. ZONE: time zone offset
4. : external audio device successfully connected
5. : radio is on
6. : soothing sound is on
7. : radio station selected (user can set up to 8
stations); soothing sound selected for alarm option
8. Name of soothing sound selected is displayed
9. OFF Zz: sleep function enabled (ZZ) / disabled (OFF ZZ)
10. : remote sensor reception indicator
11. : daily alarm is on
12. VOL: volume level is displayed
BACK VIEW
1
2
3
4
5
6
7
8
9
10
11
12
13
14
1. : activate / deactivate alarm function; set alarm;
view alarm status (when radio is on)
2. : toggle station number (when radio is on); save
radio frequency
3. : turn radio on / off
4. TUNE +/-: auto search / adjust radio frequency
5. °C / °F: user selectable temperature units

EN
3
6. DIMMER: select display brightness
7. COLOUR (OFF·PROGRAM·LOOP): activate /
deactivate color-changing light show; select pre-
programmed (sound specific) light show or rainbow
loop effect
8. : set clock
9. ZZ: activate sleep timer; adjust timer settings (120, 90,
60, 30, 15, 0)
10. VOL+ / VOL-: increase / decrease value
of the setting; increase / decrease volume
11. RESET: reset unit to default settings
12. SEARCH: initiate sensor search
13. PAUSE: select a specific color lighting; restart color-
changing effect
14. Socket for audio line-in
BOTTOM VIEW
1
2
1. Adapter socket
2. Battery compartment
REMOTE SENSOR
1
2
34
5
1. LED status indicator
2. Wall mount hole
3. Battery compartment
4. RESET hole: reset unit to default settings
5. CHANNEL switch: select Channel 1
GETTING STARTED
POWER SUPPLY
Adapter
The adapter powers the unit. Plug adapter into socket,
making sure the adapter is not obstructed and is easily
accessible to the unit.
To completely disconnect from power, the adapter should be
disconnected from the main unit.

EN
4
NOTE The main unit and adapter should not be exposed to
wet conditions. No objects filled with liquid, such as vases,
should be placed on the main unit and adapter.
1 x CR2032 battery for memory back-up
To insert batteries:
1. Remove the battery compartment cover.
2. Insert the battery, matching the polarities.
3. Press RESET after each battery change.
LOCATION MEANING
Clock area Main unit batteries low
Outdoor temperature
area Sensor batteries low
REMOTE SENSOR
To set up the remote sensor:
1. Slide open the battery compartment.
2. Slide channel switch to select channel 1.
3. Insert the battery, matching the polarities.
4. Press RESET after each battery change.
5. Close the battery compartment.
6. Press and hold SEARCH on main unit to initiate search
and start receiving time and temperature data from the
sensor.
7. Place the sensor within 30 m (98 ft) of the main unit
using the table stand or wall mount.
TIP The transmission range may vary depending on many
factors. You may need to experiment with various locations
to get the best results.
NOTE Use alkaline batteries for longer usage and consumer
grade lithium batteries in temperatures below freezing.
SENSOR DATA TRANSMISSION
Outdoor sensor:
The sensor reception icon in the remote sensor area shows
the status:
ICON DESCRIPTION
Main unit is searching
for sensor(s)
A channel has been
found
The sensor cannot be
found

EN
5
NOTE If the sensor is not found, check the batteries,
obstructions and remote unit location. Press and hold
SEARCH to force another sensor search.
For best results:
• Place the sensor out of direct sunlight and moisture.
• Position the sensor so that it faces the main unit,
minimizing obstructions such as doors, walls and
furniture.
• Place the sensor in a location with a clear view to the
sky, away from metallic / electronic objects.
• Position the sensor close to the main unit during cold
winter months as below-freezing temperatures may
affect battery performance and signal transmission.
TIP Ideal placements for the sensor would be in any
location on the exterior of the home at a height of not more
than 1.5m (5 ft) and which can shield it from direct sunlight
or wet conditions for an accurate reading.
CLOCK
CLOCK RECEPTION
This product is designed to synchronize its clock
automatically with a clock signal.
RRM902: EU: DCF-77 signal: within 1500km (932 miles) of
Frankfurt, Germany.
RRM902U: UK: MSF-60 signal: within 1500km (932 miles)
of Anthorn, England.
RRM902A: US: WWVB-60 signal: within 3200km (2000
miles) of Fort Collins, Colorado.
To enable / disable signal reception:
Press and hold VOL+ to enable, or VOL- to
disable signal reception.
NOTE Reception takes 2-10 minutes. If the signal is weak,
it can take up to 24 hours to get a valid signal.
If signal reception is unsuccessful, place your unit next to
a window, press and hold VOL+ to force another
signal search.
Clock signal reception indicator:
STRONG SIGNAL WEAK / NO SIGNAL
MANUALLY SET CLOCK
To set the clock manually, disable the clock signal reception
first.

EN
6
1. Press and hold .
2. Press VOL+ or VOL- to change the
settings.
3. Press to confirm.
The setting order is: time zone offset, 12/24-hour format,
hour, minute.
RMR902 / RMR902U: Time zone offset sets the clock +/-
23 hours from the received clock signal time. If you have
deactivated the clock signal reception, do not set a value
for time zone.
NOTE If you enter +1 in the time offset setting, this will
give you your local time plus one hour. If you are in the US
(RRM902A) set the clock to:
0 for Pacific time +1 for Mountain time
+2 for Central time +3 for Eastern time
AUDIO OPTIONS
SOOTHING SOUNDS
To activate / deactivate soothing sounds:
• Place finger on SNOOZE·SOUND for 2 seconds.
To toggle soothing sounds:
• Touch SNOOZE · SOUND repeatedly to select desired
sound (1-8).
The selected sound name and will be displayed.
NOTE This will automatically turn off the radio.
RADIO
To activate / deactivate radio:
• Press to turn radio ON / OFF.
The radio station selected with corresponding
frequency and will be displayed when radio is on.
NOTE This will automatically turn off the soothing sound.
To set radio station:
1. Press to turn radio on.
2. Press repeatedly to navigate to desired station
storage location (1-8).
3. Press and hold TUNE+ / TUNE- to auto search or press
TUNE+ / TUNE- to manually select frequency. Station
number will disappear

EN
7
4. Once desired frequency has been found, press and hold
to save. Station number (e.g., ) indicates
where it has been stored.
5. Repeat steps 2 – 4 for all storage locations.
For your convenience, the volume and radio frequency will
be stored in memory for the next time radio is turned on.
To view alarm display (when radio is on):
• Press .
MUSIC FROM EXTERNAL AUDIO DEVICE
Using a cable, plug one end to your music storage device
and one end to audio line-in socket ( ) located at the
back of unit.
When cable has been successfully connected, will
be displayed on the LCD screen and sound will emit from
speakers.
NOTE
• To play music from external audio device, ensure
soothing sound and radio is turned off.
• Connecting / disconnecting of external audio device will
turn the alarm off.
VOLUME CONTROL
• Press VOL+ or VOL-.
ALARM
To set the alarm:
1. Press and hold .
2. Press VOL+ or VOL- to change the
settings.
3. Press to confirm.
The setting order is: Hour, minute, alarm option (
soothing sound / beep or Radio), sound type (1-8:
soothing sound, 9: beep) or radio station, volume (cannot
be adjusted for beep alarm).
To toggle alarms ON / OFF:
1. Press to display alarm time.
2. Press again to turn alarm ON / OFF.
indicates alarm is on.
To silence the alarm:
• Touch SNOOZE · SOUND to silence it for 8 minutes
OR
• Press any other key (except DIMMER) to turn the alarm
off and activate it again after 24 hours.

EN
8
COLOR PLAY
To activate light show (looped):
• Slide COLOR switch to LOOP.
To stop light show at a particular color:
• Press PAUSE when it reaches desired color.
Press PAUSE again to restart loop.
Each soothing sound is programmed with a unique color-
changing light show which complements the music, improves
the ambience and adds a decorative touch to any room.
To start programmed light show:
• Slide COLOR switch to PROGRAM.
To deactivate light show:
• Slide COLOR switch to OFF.
SLEEP TIMER
To activate audio sleep timer:
• Press SLEEP to activate sleep timer.
Zz indicates sleep timer is on.
NOTE
• If neither soothing sound nor radio is activated when
SLEEP is pressed, the unit will automatically activate
the last audio type played.
• If either soothing sound or radio is playing when SLEEP
is pressed, the unit will start counting down sleep timer
and continue playing audio type.
To select duration:
• Press SLEEP repeatedly.
To view time remaining:
• Press SLEEP.
NOTE If external audio device is plugged in while sleep
timer is on (and radio / soothing sound is not playing),
OFFZZ will be displayed briefly to indicate sleep function has
been temporarily disabled.
TEMPERATURE
To toggle temperature unit:
• Press °C / °F.
BACKLIGHT
To adjust brightness:
• Press DIMMER.
RESET
Press RESET to return to the default settings.

EN
9
SPECIFICATIONS
TYPE DESCRIPTION
Main unit
L x W x H 155 x 43 x 145 mm
(6.1 x 1.7 x 5.7 in)
Weight 526 g (18.6 oz) without battery
FM 87.5 to 108 MHz
Power 4.5V adapter and 1x CR2032 for
memory back-up
Remote Sensor (THN132N)
L x W x H 92 x 60 x 20 mm
(3.6 x 2.4 x 0.8 in)
Weight 62g (2.22 oz)
Transmission
range 30m (98 ft) unobstructed
Frequency 433 MHz
Temperature
range
-30°C to 60°C
(-22°F to 140°F)
Power 1 x UM-3 (AA) 1.5V battery
PRECAUTIONS
• Do not subject the unit to excessive force, shock, dust,
temperature or humidity.
• Do not cover the ventilation holes with any items such
as newspapers, curtains etc.
• Do not immerse the unit in water. If you spill liquid over
it, dry it immediately with a soft, lint-free cloth.
• Do not clean the unit with abrasive or corrosive
materials.
• Do not tamper with the unit’s internal components. This
invalidates the warranty.
• Only use fresh batteries. Do not mix new and old
batteries.
• Images shown in this manual may differ from the actual
display.
• When disposing of this product, ensure it is collected
separately for special treatment and not as normal
household waste.
• Placement of this product on certain types of wood
may result in damage to its finish for which Oregon
Scientific will not be responsible. Consult the furniture
manufacturer's care instructions for information.
• The contents of this manual may not be reproduced
without the permission of the manufacturer.
• Do not dispose old batteries as unsorted municipal
waste. Collection of such waste separately for special
treatment is necessary.
• Please note that some units are equipped with a
battery safety strip. Remove the strip from the battery
compartment before first use.
NOTE The technical specifications for this product and the
contents of the user manual are subject to change without
notice.
NOTE Features and accessories will not be available in all
countries. For more information, please contact your local
retailer.

EN
10
ABOUT OREGON SCIENTIFIC
Visit our website (www.oregonscientific.com) to learn more
about Oregon Scientific products.
If you're in the US and would like to contact our Customer
Care department directly, please visit: www2.oregonscientific.
com/service/support.asp
For international inquiries, please visit:
www2.oregonscientific.com/about/international.asp
EU DECLARATION OF CONFORMITY
Hereby, Oregon Scientific, declares that this Rainbow Clock
with 8 Soothing Sounds and FM Radio (Model: RRM902 /
RRM902U / RRM902A) is in compliance with the essential
requirements and other relevant provisions of Directive
1999/5/EC. A copy of the signed and dated Declaration of
Conformity is available on request via our Oregon Scientific
Customer Service.
COUNTRIES RTTE APPROVAL COMPLIED
All EU countries,Switzerland CH
and Norway N
FCC STATEMENT
This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions: (1) This
device may not cause harmful interference, and (2) This
device must accept any interference received, including
interference that may cause undesired operation.
WARNING Changes or modifications not expressly
approved by the party responsible for compliance could void
the user's authority to operate the equipment.
NOTE This equipment has been tested and found to
comply with the limits for a Class B digital device, pursuant
to Part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference
in a residential installation.
This equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in accordance
with the instructions, may cause harmful interference to
radio communications. However, there is no guarantee
that interference will not occur in a particular installation.
If this equipment does cause harmful interference to radio
or television reception, which can be determined by turning
the equipment off and on, the user is encouraged to try
to correct the interference by one or more of the following
measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and
receiver.

EN
11
• Connect the equipment into an outlet on a circuit
different from that to which the receiver is connected.
• Consult the dealer or an experienced radio / TV
technician for help.
DECLARATION OF CONFORMITY
The following information is not to be used as contact
for support or sales. Please visit our website at www2.
oregonscientific.com/service for all enquiries.
We
Name: Oregon Scientific, Inc.
Address: 19861 SW 95th Ave.,Tualatin,
Oregon 97062 USA
Telephone No.: 1-800-853-8883
declare that the product
Product No.: RRM902 / RRM902U / RRM902A
Product Name: Rainbow Clock with 8 Soothing
Sounds and FM Radio
Manufacturer: IDT Technology Limited
Address: Block C, 9/F, Kaiser Estate,
Phase 1, 41 Man Yue St.,
Hung Hom, Kowloon,
Hong Kong
is in conformity with Part 15 of the FCC Rules. Operation is
subject to the following two conditions: 1) This device may
not cause harmful interference. 2) This device must accept
any interference received, including interference that may
cause undesired operation.
