Oricom T1000-1 User manual

Australia New Zealand
Oricom International Pty Ltd Atlas Gentech (NZ) Limited
Locked Bag 658 Private Bag 14927
South Windsor, NSW 2756 Panmure, Auckland
Customer Support Customer Support
Email: [email protected] Email: [email protected]
Web: www.oricom.com.au Web: www.atlasgentech.co.nz
Phone: [phone] Phone: [phone] (Toll Call)
Fax: [phone] Fax: [phone]
Touch Digital
Cordless Phone
Touch T1000 Series
User
Guide

touch
PACK CONTENTS
Depending on the model you have purchased the pack should contain the following items:
T1000-1 T1000-2 T1000-3
Base units 1 1 1
Cordless handsets 1 2 3
Charging cradles 0 1 2
Power adaptors 1 2 3
Phone line cords 1 1 1
Modular Australian adaptor plug 1 1 1
Handset rechargeable AAA
Ni-MH Batteries (1.2V 750mAh) 3 6 9
This user guide 1 1 1
Warranty card 1 1 1
If any of these items are missing, please contact the retailer where you purchased the product from. You may expand your
Oricom Touch T1000 by adding more handsets (T1050). These may be purchased separately from the retailer where you
purchased the product from or direct from Oricom (Australia only). The T1000 can accommodate a total of 4 cordless handsets.
•Avoid exposure of this telephone to moisture or liquid.
•To prevent electric shock, do not open the handset or
base cabinet.
•Avoid metallic contact (e.g. metal clips, keys) between
the battery contacts and charging conductors.
•Do not use the handset in an explosive hazard area such
as where there is gas leaking.
•Do not use your telephone during an electrical
storm/thunderstorm as it is possible to get an electric
shock. Refer to information contained in the White
pages directory.
•As there is a slight chance that the telephone could
be damaged by an electrical storm, it is recommended
that you unplug the phone from the mains supply and
telephone socket during an electrical storm.
•Follow the local regulations regarding the disposal of your
packing materials, exhausted batteries and used phone.
Wherever possible, recycle these materials.
•We advise that this phone should not be used near intensive
care medical equipment or by persons with pacemakers.
•Clean with a dry, soft, lint-free cloth. Never use cleaning
agents, particularly aggressive solvents.
•Because the phone works by sending radio signals
between base station and handset, wearers of hearing
aids may experience interference in the form of a
humming noise.
•Your phone can interfere with electrical equipment
such as answering machines, TV and radio sets, clock
radios and computers if placed too close. It is recommended
that you position the base unit at least one metre from
such appliances.
•This telephone complies with applicable safety
requirements for exposure to radio waves (EMR). The mean
power of this telephone does not exceed 20mW limit
at which point testing is required.
•The earpiece of the handset may attract small metal
objects such as staples and pins. Care should be taken
when placing the handset near these items.
•This telephone is not designed for making emergency
telephone calls when the mains power fails. Always have a
corded phone available to be able to make and receive
calls to emergency services if the mains power fails.
•Privacy of communications may not be ensured when
using this telephone.
ENVIRONMENT AND SAFETY

me
Make sure your base is:
•Located within reach of a mains power socket and
telephone socket.
•At least 1 metre away from other electrical appliances, to
avoid interference.
•Not located in humid or damp conditions, e.g. in a
bathroom.
1Connect the base power lead and the telephone line cord
to the back of the base. Plug the power adaptor into the
mains wall socket.
2For multi-handset packs only: Plug the charger power
adaptor into the mains power socket.
3On each handset: Slide the battery cover off and insert
the batteries supplied following the markings shown inside
the battery compartment, then slide the cover back on until
it clicks into place.
4Place the handsets in the base/charger handset cradle
and charge for 15 hours before use.
5Plug the telephone line cord into the wall socket.
Attaching the belt clip
With the back of the handset facing you, align the belt clip
with the two slots on the side of the handset and push
securely into place.
Your Oricom Touch phone is now ready for use
ATTENTION
Congratulations on your purchase of the Oricom Touch
Phone with its high tech touch sensitive keypad. The touch
panel is much more sensitive than a normal phone keypad
and provides very fast and responsive keying - however
like most new technology it takes a little getting used to.
To get the best use out of your Touch Phone
•Pick it up from the rear and cradle it in your hand.
•During use, avoid touching the keypad area unnecessarily
to prevent accidental triggering of the keypad.
•The keypad will automatically disable when you hold
the receiver to your ear. The idea being, to reduce the risk
of accidental keypad presses while the phone is held
against the side of your face.
QUICK SET UP
Telephone socket
In-line filter
(not supplied)
DO YOU HAVE BROADBAND?
If you do you must connect a in-line filter (not supplied)
between the telephone socket and your Touch phone base
to ensure that your broadband and Touch phone work
properly. See below.
IMPORTANT NOTE: Ensure all phone sockets in use have
their own in-line filter. Touch Phone

only
YOUR HANDSET DISPLAY
USING YOUR TOUCH PHONE AND BASE
Earpiece/Receiver
Display
Display with icons and blue backlight.
Up/Down
Press during a call to increase/decrease
earpiece volume. During standby use to
scroll Up or Down through the menu
options and through phonebook and
Calls log entries. Talk
Press to make and receive calls.
Redial/Pause
Use to redial any of the last 20 numbers
called. Press to enter a pause in a number.
Alphanumeric keypad
Use to enter digits and characters.
When entering text, press repeatedly to
enter punctuation.
Recall/Cancel
For use with certain network services,
including Call Waiting. Press to delete an
incorrect character/digit. Press to return
to previous menu.
End
Press to end calls. Press to exit the menu
and return to standby mode.
Phonebook
Use to access the phonebook.
#/Conf
When entering text use to toggle between
lower and upper case. Press to start a
conference call.
Menu/Mute
Press to access the menu or confirm a
menu setting. During a call, press to mute
the microphone.
INT
Use to call another registered handset.
Find Handset (page)
Press to page/locate a misplaced handset.
(Located on the base behind the handset).
In Use/Message
LED indicator
Illuminates when
the line is in use.
Flashes when you
are connected to a
switcboard and you
have new voice
messages.
*
Headset jack (2.5mm) Explanation
Remains steady - the handset is in range with the base.
Disappears and OUT OF RANGE is displayed when the handset is out of range of
the base.
Keypad is locked. You cannot make calls, only receive them.
Automatic keypad lock - which is activated when the handset is placed against the side
of the face.
Displayed when the handset ringer is set to OFF.
Alarm is set.
Small letter entry activated.
An envelope indicates you have voice messages from your Network provider’s voicemail service.
(You will need to subscribe to your Network provider’s service.)
Always displayed, shows the battery status.
Battery is fully charged.
Battery is low and needs charging. LOW BATTERY will also be displayed.
Battery charging.
Symbol
Scrolling bars

touch
1
USING YOUR PHONE
CONTENTS
Touch Activated Keypad
Unlike other phones your Touch phone has a ‘touch
activated keypad’. The touch activated keypad will
automatically disable when you hold the handset receiver
to your ear. The idea being, to reduce the risk of accidental
keypad presses while the phone is held against the
side of your face. Likewise, the keypad also disables
automatically 5 seconds after the last key is pressed. To
‘wake’ the keypad enabling you to dial further digits, e.g. if
you are using telephone banking or want to access the
menu, just touch any of the numbers to reactivate the
keypad. When the keypad illuminates dial normally. It
is very easy to tell when the keypad is disabled, as
the keypad backlight will not be on. Additionally if you
want to manually disable the keypad when carrying
the handset to prevent accidental key operations, just
press followed by the key. The manual keylock
feature cannot be activated during a call. A key icon will
appear in the top left of the display to show the keys are
locked, pressing followed by the will unlock the
keys again for use.
To return to standby mode at any time, press
Make a call
Press , wait for the dial tone and dial the number.
Preparatory dialling
Enter the number first, then press to dial or to
cancel.
Press to delete digits.
Switch to handsfree/speakerphone during a call
Press . SPKR will be displayed. Press again to go
back to the handset.
Adjust the call volume
During a call, press or to increase/decrease
the volume.
End a call
Press or place the handset on the base/charger.
Receive a call
When the phone rings, lift the handset from the
base/charger and press .
USING YOUR PHONE 1
Touch Activated Keypad 1
To return to standby
mode at any time 1
Make a call 1
Preparatory dialling 1
Switch to handsfree/
speakerphone during a call 1
Adjust the call volume 1
End a call 1
Receive a call 1
Headset connection port 2
Redial a number 2
Mute ON/OFF 2
Call waiting 2
Page a handset 2
Phonebook 3
Store a phonebook entry 3
Dial a phonebook entry 3
Edit a phonebook entry 3
Delete a phonebook entry 3
Delete all phonebook entries 4
MENUS AND SETTINGS 5
Navigating the menus 5
Display settings 5
Display language 5
Display contrast 5
Backlight time 5
Handset settings 5
Handset ringtone 5
Handset ringer volume 5
Key tones 6
Recall time 6
Smart key lock On/Off 6
Manual key lock On/Off 7
Auto Answer On/Off 7
Handset Name 7
Reset to Default settings 7
Clock settings 8
Set the time 8
Setting caller ID display format 8
Set the alarm 8
NETWORK SERVICES 9
Caller ID 9
Call log 9
View/dial/edit from the call log 9
Store a number to the
phonebook 9
Delete an entry/all entries 10
Voice Message/Message
Waiting 10
To clear the icon manually 10
MULTI-HANDSET USE 11
Register a new handset 11
Select a base to use 11
De-register a handset 11
Make internal call 11
Transfer an external call 12
3-Way conference call 12
SIMPLE SOLUTIONS 12
How does the ‘Touch
Activated Keypad’ work? 12
Troubleshooting 12
GENERAL INFORMATION 14
Safety 14
Batteries 14
Cleaning your product 15
NOTES FOR OPERATION IN
NEW ZEALAND 16
REN (RN for New Zealand) 16
Caller ID 16
WARRANTY 17
Customer support 18

me
23
If auto-answer is on and the handset is in the base:
Lift the handset to answer the call. You do not need to
press .
Headset connection port
The headset has a connection port suitable for 2.5mm
stereo jack, on the right-hand side with which to connect a
headset (headset not supplied). There is no guarantee the
headset will function properly.
Redial a number
Press , then . Or
Press , then press or to scroll to any of
the last 20 dialled numbers and press to dial.
Mute ON/OFF
Mute your voice so the caller cannot hear you. During a call:
Press to switch mute ON/OFF. MUTE will be shown
on the display.
Call waiting
(Australia only)
To use Call Waiting you must subscribe to the relevant
service from your network provider.
During a call, you will hear two loud beeps periodically to notify
you of another incoming call. If you wish to answer this call:
1When the handset receives a second call, the number of
the caller appears on the display. It will display for 60
seconds or until you press a key on the phone. Press
listen for dial tone then Press to put the current
call on hold and talk with the second caller.
2To toggle between calls press listen to dial tone then
press .
Callerinformationofthissecondcallwillbestoredinthecalllog.
If you have subscribed to your telephone network operators
Call Waiting Caller ID service (Australia only), your phone
will display the number of the second incoming call for
around 60 seconds while you are talking on the phone.
(New Zealand only)
1To put your current call on hold and talk to the second
caller press the key.
2To toggle between calls press the key.
Page a handset
Press on the base. Handset(s) will ring.
To stop the paging ring, press again or press any
key on the handset.
Phonebook
Store up to 60 phonebook entries. Names up to 16
characters, numbers up to 24 digits.
Store a phonebook entry
1Press then twice.
2 Enter a name using the keypad and press .
3Enter a number using the keypad and press to
confirm.
To enter characters, press the key showing the required
letter repeatedly until the letter you want is displayed. Wait
for the cursor to move to the right if the next letter is on the
same key and press the key to confirm.
Press repeatedly to display * # ? ! $ & % / \ | ~
Press repeatedly to display 0 ‘ “ [ ] < > { }
Press to delete characters/digits.
Press to switch from lower to upper case, will be
shown if a smaller letter is entered.
Press repeatedly to display SPACE 1 _ + = . , ; :
To enter a pause in a number, press .
Dial a phonebook entry
1Press .
2Scroll or to display the entry you want. Or,
search alphabetically, by pressing the alphanumeric button
showing the first letter of the name you want the relevant
number of times.
3Press to dial.
Edit a phonebook entry
1Press .
2Scroll or to display the entry you want. Or,
search alphabetically.
3Press , then or , or press to display
EDIT RECORD and press .
4Edit the name using the keypad and press to
confirm.
5Edit the number using the keypad and press to
confirm.
Press to delete incorrect characters/digits.
Delete a phonebook entry
1Press .
2Scroll or to display the entry you want. Or,
search alphabetically.
>

only
45
3Press , then or , or press to display
DELETE RECORD and press .
4Press again to confirm.
Delete all phonebook entries
1Press then .
2Scroll or , or press to display DELETE ALL
and press .
3Press again to confirm.
Navigating the menus
You can use the menus to change the settings on your
Touch phone.
• To open the main menu, press .
• Press or to scroll through the menus.
• To return to standby mode at any time, press .
• To return to the previous screen, press .
• To confirm a menu selection, press and you will
hear a confirmation beep.
Display Settings
Display language
1 Press , then scroll or , or press to
select LANGUAGE and press .
2Scroll or to select from ENGLISH, FRENCH,
SPANISH, PORTUGUESE, DUTCH, GERMAN, ITALIAN,
SWEDISH, FINNISH, DANISH or NORWEGIAN and
press to confirm.
Display contrast
1Press , then scroll or , or press to
select PHONE SETUP and press .
2Scroll or , or press to select SET CONTRAST
and press to confirm.
Backlight time
1Press , then scroll or , or press to select
PHONE SETUP and press .
2Scroll or , or press to select BACKLIGHT TIME
and press .
3Scroll or to select the time you want the
backlight to stay on after the last button press, then
press to confirm.
Handset settings
Handset ringtone
1Press , then scroll or , or press to RING
SETTING and press .
2Scroll or , or press to select RINGER TONE
and press .
3Scroll or to select EXTERNAL CALL or
INTERNAL CALL ringtone volume then press .
4Scroll or to select from 10 polyphonic ringtones
and 4 standard ringtones, then press to confirm.
Handset ringer volume
1Press , then scroll or , or press to select
RING SETTING and press .
MENUS AND SETTINGS

touch
67
2Scroll or to select RINGER VOLUME and
press .
3Scroll or to select EXTERNAL CALL or
INTERNAL CALL ringtone volume then press .
4Scroll or to select the required volume and
press to confirm.
Key tones
1Press , then scroll or , or press to
select PHONE SETUP and press .
2Scroll or , or press to select KEY TONE
and press .
3Scroll or to select from 4 key tones to silent
key tone and press to confirm.
Recall time
Only change this setting if your call waiting function does
not work. Select 100ms for use in Australia and 600ms for
use in New Zealand.
1Press , then scroll or , or press to
select PHONE SETUP and press .
2Scroll or , or press to select RECALL TIME
and press .
3Scroll or to select the recall time you require
and press to confirm.
Smart key lock On/Off
Smart key lock prevents accidental activation of keys
during a call. When set to ON, when you have dialled the
number and you hold the receiver to your ear the keypad
automatically locks. When you move your ear away from
the keypad the keylock deactivates again. We recommend
that smart keylock is left switched on to prevent accidental
dialling when using the handset.
1 Press , then scroll or , or press to
select PHONE SETUP and press .
2 Scroll or , or press to select SMART KEY
LOCK and press .
3Scroll or to select ON or OFF and press to
confirm.
Manual key lock On/Off
Use the manual key lock to lock the keypad and prevent
accidental dialling at any time.
1In standby mode, press then immediately press .
The symbol is displayed while the key lock is ON.
Press the and to turn off the keypad lock.
When the keypad is locked you will still be able to answer
incoming calls. Once the call has ended the keypad will
remain locked. Only the key functions when the key lock
is on. When the keylock icon is on, calls may still be made to
the official emergency number programmed in to your phone,
key in the emergency number and press directly.
Repeat steps above to turn off the keypad lock.
Auto Answer On/Off
When set to ON, incoming calls can be answered by lifting
the handset out of the cradle (without pressing ).
1Press , then scroll or , or press to select
PHONE SETUP and press .
2Scroll or , or press to AUTO ANSWER and
press .
3Scroll or to select ON or OFF and press to
confirm.
Handset Name
1Press , then scroll or , or press to
PHONE SETUP and press .
2Scroll or , or press to HANDSET NAME
and press .
3Enter a name using the keypad and press to
confirm.
Reset to Default Settings
All the settings you have made will be restored to the
default settings if you reset.
1Press , then scroll or , or press to SET
DEFAULT and press .
2Scroll or to select YES and press to confirm.

me
89
Clock Settings
Set the time
1Press , then scroll or , or press to
select set TIME and press .
2Scroll or , or press to select CLOCK
SETTING and press .
3Enter the time using the keypad, press to toggle
AM/PM (for 12 hour clock) and press to confirm.
Setting caller ID display format
1Press , then scroll or , or press to
select SET TIME and press .
2Scroll or , or press to select DISPLAY
FORMAT and press .
3Scroll or to select 12/24 hour format and
press .
4Scroll or to select DD/MM (day/month) or
MM/DD (month/day) format and press to confirm.
Set the alarm
The icon is displayed when the alarm is set.
1Press , then scroll or , or press to select
SET TIME and press .
2Scroll or , or press to select ALARM and
press .
3Scroll or to select ON or OFF and press .
4Enter the alarm time and press to confirm.
For 12-hour-format, press to toggle AM/PM.
NETWORK SERVICES
IMPORTANT
TO USE ANY OF THE FEATURES DESCRIBED IN
THIS SECTION YOU MUST FIRST SUBSCRIBE TO THE
RELEVANT SERVICE VIA YOUR NETWORK PROVIDER.
Caller ID
When you receive an incoming call, the caller's number is
displayed so you can see who is calling before you answer.
If the caller's number is stored in the phonebook and an
exact number match is found, the caller's name will be
displayed instead.
If you do not subscribe to your network operators Caller ID
service your touch phone will still indicate the missed calls.
The display will indicate the number of missed calls but
when you scroll down no numbers will be displayed.
Call log
The call log stores details of the last 40 incoming calls
(numbers up to 16 digits and names up to 16 characters).
When the call log is full, a new call will replace the oldest
call. If the caller has withheld their number or the number
is unavailable the display will show UNAVAILABLE or
WITHHELD. If a call is new (has not been viewed before)
NEW will be displayed. If you have received more than
one new call from the same number, REPT (repeat) will
be displayed.
View/dial/edit from the call log
1During standby mode, press or to open the call
log. The number of new calls and the total (ALL) number of
calls logged entries will be displayed.
2Press or to scroll through the entries.
3With an entry displayed:
To dial: Press .
To edit the number: , then scroll or , or press
to select EDIT TO DIAL and press . Edit the number
using the keypad and then press to dial.
To delete digits press .
To return to standby without dialling: Press .
Store a number to the phonebook
1During standby mode, press or to open the
calls log.
2Press or to scroll to the entry you want.
3Press , ADD RECORD is displayed, press .
4Enter a name using the keypad and press .
5The number is displayed, press to store.

only
10 11
MULTI-HANDSET USE
Register a new handset
Register up to 4 handsets to your Touch base and register
your Touch handset with up to 4 bases. Handsets and bases
must be GAP compatible. New handsets must be fully charged.
1Press , then scroll or , or press to select
SECURITY SET and press .
2Scroll or , or press to select REGISTRATION and
press .
3Scroll or to select the base you want to register
to and press .
4Enter the 4 digit PIN code (default 0000) and press .
5Press and hold at the base. The base indicator
light flashes. The handset attempts to register with the base.
6When registration is complete REGISTRATION ACCEPTED
is displayed.
RETRY is displayed if registration fails, press to retry
or to exit. To test the handset is registered, press
on the base and the handset should ring. Press again
to stop the ring.
Select a base to use
1Press , then scroll or , or press to select
SECURITY SET and press .
2Scroll or , or press to select SELECT BASE
and press .
3Scroll or to select the base number and press
to confirm. ACCEPTED is displayed when the base has
been selected.
RETRY is displayed if base selection fails, press to retry
or to exit.
De-register a handset
1Press , then scroll or , or press to
select SECURITY SET and press .
2Scroll or , or press to select DEREGISTRATION
and press .
3Scroll or to select the handset you want to
de-register and press .
4ACCEPTED is displayed when the handset has de-registered.
RETRY is displayed if de-registration fails, press to retry
or to exit.
Make internal call
1Press and scroll or then press , or enter
the handset number directly you want to call.
2 The called handset rings and can press to answer
the call.
3Press to end the call.
Delete an entry/all entries
1 During standby mode, press or to open the
calls log.
2Press or to scroll to the entry you want.
For DELETE ALL, scroll and display any entry.
3 Press , then or to DELETE RECORD or
DELETE ALL and press to confirm.
Voice Message/Message Waiting
You have to subscribe to a voice message service (eg
Telstra Message Bank) provided by your service provider to
use this feature. When you receive a voice message your
Touch handset will display the symbol and the voice
message wait light on the base will flash to alert you when
you have new voice messages.
•To listen to your voice messages follow the instructions
given by your service provider.
•When you retrieve your messages the symbol
will turn off.
To clear the icon manually
1Press , then scroll or , or press to
select SECURITY SET and press .
2 Scroll or , or press to select CLEAR MSG
WAIT and press .
3Scroll or to select YES and press to
confirm.

touch
12 13
Transfer an external call
1 During a call, press .
2Scroll or then press , or enter the handset
number directly you want to call.
3The called handset can press to answer. The calling
handset can press to transfer the call.
3-Way conference call
While one handset is on an external call, a second internal
handset can join in and have a 3-way conference call.
1During an external call, press .
2Scroll or then press , or enter the handset
number directly you want to call.
3The called handset can press to answer. The calling
handset can press to start the conference call.
4Either internal handset can press at any time to leave
the conference call.
How does the ‘Touch Activated Keypad’ work?
The touch activated keypad will automatically disable when
you hold the handset receiver to your ear. The idea being, to
reduce the risk of accidental keypad presses while the
phone is held against the side of your face. Likewise, the
keypad also disables automatically 5 seconds after the last
key press. To ‘wake’ the keypad to enable you to dial further
digits, e.g. if you want to access the menu, you should touch
any of the number keys, wait for the backlight to come on
and then you can dial normally. It is very easy to tell when the
keypad is disabled, as the keypad backlight will not be on.
Troubleshooting
If you are experiencing problems with your Oricom Touch
Phone, firstly check that:
•the telephone line cord is correctly connected.
•the mains power cord is correctly connected and the
power switched on.
•the batteries are charged, polarities are correct and that
the batteries are not in need of replacing.
If you have more than one handset registered to your base
remember to check the connections on this too. If you are
still experiencing a problem, you are likely to find a solution
in the following:
SIMPLE SOLUTIONS
Cannot make a call
•Is the symbol missing? - move closer to the base.
•Is symbol displayed? if so unlock the keypad, see
page 6.
•If you have multi-handsets, another handset may already
be on a call. Ext in use will be shown on display.
Interference on the Touch when on a call
•If you have Broadband installed you MUST install high
quality line filters (not supplied) on all phone sockets. This
is not a problem with your Touch phone.
Handset does not ring/ring is low
•Check the ringer volume level, see page 5.
Handset is not charging properly
•Check that the handset is sitting correctly in the base or
charger. Clean the charging contacts with a dry cloth.
Buzzing noise on my radio, TV, computer or hearing aid
•Sometimes your phone may interfere with other electrical
equipment if it is placed too close. We recommend you
leave a distance of at least one metre to avoid this.
Caller’s details are not displayed
•Make sure you have subscribed to a Caller ID service via
your network provider.
•The caller may have withheld their details.
•Let the phone ring a couple of times as there may be a
delay in receiving the Caller ID information.
Accidental key press to the keypad may occur
• Always use manual key lock.
• When answering a call, always keep contact with your ear
and the receiver.
• Avoid touching the keypad area when handling.
Caller’s name is not displayed even though it is stored in
the phonebook
• The name will only be displayed if an exact number match
(including STD dialling code) is found.
Electrostatic discharge
If your Touch phone has been subjected to a large
electrostatic discharge or a power surge the unit may
need to be reset. Use the following procedure to
reset the system.
1Remove the batteries from all the cordless handsets
2Unplug the power and the phone line to the main base unit
3Leave it like this for approximately 15 minutes
4Put everything back together and try the handsets again
5If this does not fix the problem call our support line

me
15
14
IMPORTANT
This equipment is not designed for making emergency
telephone calls when the power fails. Alternative
arrangements should be made for access to emergency
services.
SAFETY
•The LCD display is made of glass and may break if the
handset is dropped. Place the phone securely on a stable
surface.
•Only use the power supply that came with the product.
Using an unauthorised power supply will invalidate your
guarantee and may damage the telephone.
CAUTION
Use only the AC adapter supplied with this telephone.
Incorrect adapter polarity or voltage can seriously damage
the unit.
Base: Charger:
Input: 240 VAC 50 Hz Input: 240 VAC 50 Hz
Output: 6 VDC 300 mA Output: 6 VDC 300 mA
Polarity: Centre positive Polarity: Centre positive
Battery Usage
IMPORTANT
THERE IS A RISK OF EXPLOSION IF BATTERY IS
REPLACED BY AN INCORRECT TYPE.
Never use non-rechargeable batteries; use the
recommended rechargeable type supplied with this
telephone. Ni-MH batteries must be disposed of in
accordance with the applicable waste disposal
regulations.
Battery requirements: Each handset requires three
rechargeable Ni-MH batteries, size AAA 1.2V 750mAh
•Use only the battery type listed in this user guide. Do not
use Alkaline or lithium batteries.
•Do not dispose of the batteries in a fire, as they can
explode.
•Do not open or mutilate the batteries. Released
electrolyte is corrosive and can cause damage to the eyes
or skin. It can be toxic if swallowed.
•Avoid contact with metal objects when handling the
batteries. These objects could short out the batteries or
cause the conductor to overheat resulting in burns.
•Do not attempt to recharge the batteries by heating them.
GENERAL INFORMATION
Sudden release of battery electrolyte can cause burns or
irritation to the eyes or skin.
•Observe the proper polarity, or direction, of any battery.
Reverse insertion of the batteries can result in leakage
or explosion.
•Remove the batteries if you do not plan to use the
product for several months at a time.
•Discard any “dead” batteries because they are likely to
leak into the product.
•Do not store this product or the batteries in a high
temperature area.
NOTE
Your Touch Handset will get warm during charging
and usage. This is normal. The handset may take a few
seconds to power up.
Cleaning your Oricom Touch Phone
Wipe the handset, base and charger with a soft anti-static
cloth (supplied). Never use a dry cloth as this may cause
a static shock. Never use household polish as this will
damage your product.

only
17
16 NOTES FOR OPERATION IN NEW ZEALAND
The grant of a Telepermit for any item of terminal
equipment indicates only that Telecom has accepted
that the item complies with the minimum conditions for
connection to its network. It indicates no endorsement of
the product by Telecom, nor does it provide any sort of
warranty. Above all, it provides no assurance that any item
will work correctly in all respects with another item of
Telepermitted equipment of a different make or model, nor
does it imply that any product is compatible with all of
Telecom's network services. This device may be subject to
ringing or bell tinkle when certain other devices are
connected to the same line. If this occurs, the problem
should not be referred to the Telecom Faults service.
This equipment shall not be set to make automatic calls to
the Telecom “111” Emergency Service. This equipment
may not provide for the effective hand-over of a call to
another device connected to the same line.
REN (RN for New Zealand)
The REN (Ringer Equivalence Number) or (RN) is of
significance only if you wish to connect more than 1
telephone to your telephone line. A standard telephone line
has a maximum REN capacity of 3 (RN of 5). It is possible
to connect 3(5) devices with a REN of 1 (RN of 1) with
no degradation to the product's performance. Exceeding
this limit may cause the volume of the ringer in any phone
to decrease or not ring at all.
Caller ID
Customers using non Telecom toll services should not
use the dial back feature for local calls as this will
incur a charge, only the 7 digit number should be dialled.
Some of the CID services listed may not be available in
New Zealand.
This telephone is not designed for making emergency
telephone calls when the power fails. Make alternative
arrangements for access to emergency services.
(a) Oricom warrants that the product is free from defects in
materials and workmanship for a period of 12 months
effective from the date of purchase. This warranty in no
way affects your statutory warranty under the Trade
Practices Act 1974 or any other similar legislation. It is
important that you read the Warranty Card as it
contains full and additional details of the warranty,
limitation of warranty and conditions for receiving the
warranty services during the warranty period. The Warranty
Card is located in the package.
(b) Exclusion and limitation of liability. Oricom will not be in
breach of a warranty or condition expressly stated in this
User Guide or the Warranty Card or implied by the Trade
Practices Act and excludes any liability arising under any
statutory or common law for damages or any other remedy
if the damage occurs as a result of:
(i) Failure by you to follow the instructions in the User
Guide for the installation and proper functioning of the
product.
(ii) Negligence on your part or misuse by you of the
product.
(iii) Any un-controlled external cause to the phone not
functioning including but not limited to electricity failure,
lighting, over voltage.
(iv) Non adherence by you to the warnings in the User
Guide and the User Guide generally; and
(v) Modification to the product or services carried out to
the product by anyone other than Oricom or on Oricom's
behalf.
Oricom will not be liable for consequential losses including
loss of profits arising from a cause of action in contract, tort
or any other statutory or common law (except where a
statute or any law prohibits this exclusion). The warranty
does not extend to damage caused by misuse, negligence,
excessive voltage, faults on the telephone line or
lightning. This warranty in no way affects your statutory
rights. Full details of the warranty are contained in the
enclosed warranty card.
WARRANTY

touch
18 19
Customer Support
If you feel this product is not working correctly please
consult the user guide and ensure that you are using the
product in accordance with the instructions. Remove
all extra telephone equipment and connect only this
telephone directly to the telephone socket. If the fault is
still present, connect another telephone (if available) to the
telephone socket. The results will show you whether the
fault lies with this unit or with the telephone line.
If the product is working correctly the fault is on the
telephone line. Please contact your network operator for
assistance.
To order spare parts, additional handsets, replacement
batteries and in case of any technical issues you may have
with the product please consult our website for further
information or send us an email for a prompt response to
your enquiry.
In the unlikely event of a fault developing, please contact
us for assistance. If the product is then found to be faulty
you will be asked to return it directly to us with a copy of
the purchase receipt.
