Orion SC242 User manual

INSTRUCTIONS FOR USE
IMPORTANT! PLEASE READ THESE INSTRUCTIONS CAREFULLY.
18CM LCD DIGITAL VIDEO RECORDER
WITH TWO DAY/NIGHT CAMERAS SC242
18cm COLOUR
LCD SCREEN
WITH IN-BUILT DIGITAL
VIDEO RECORDER AND
REMOTE CONTROL
18
cm
WIRELESS
WIRELESS VIDEO SIGNAL
TRANSMISSION WITH
DIGITAL ENCRYPTION
WITHOUT SIGNAL LOSS
WIRELESS
SURVEILLANCE SYSTEM
50 METRES
LONG TRANSMISSION
RANGE UNDER IDEAL
CONDITIONS*
SD CARD
STORE RECORDINGS
ONTO 8GB SD CARD
(INCLUDED)
NIGHT
VISION
24 INFRA-RED LEDs
FOR NIGHT VISION OF
UP TO 10m
W
I
RELESS
WIRELESS VIDEO SIGNAL
TRANSMISSION WITH
GHT CAMERAS
DIGITAL ENCRYPTION
WITHOUT SIGNAL LOSS
WIRELESS VIDEO SIGNAL
TRANSMISSION WITH
QUICK
START
GUIDE
ON BACK COVER

RF ANTENNA
POWER INPUT
LCD SCREEN
SD CARD
SOCKET
MINI USB
SOCKET
REMOTE CONTROL RECEIVER
BASE AND STAND
POWER BUTTON
CAMERA PAIRING
BUTTON
MICROPHONE
LED INDICATOR
MENU BUTTON
REC/STOP BUTTON
ENTER BUTTON
AV BUTTON
ANTENNA
WEATHER PROTECTOR
24PCS INFRARED LENS
CAMERA LENS
ADJUSTABLE
BALL JOINT
SCREW TABS
MOUNTING BRACKET
REMOTE
CONTROL
WIRELESS
SURVEILLANCE SYSTEM
2
18CM LCD DIGITAL VIDEO RECORDER WITH TWO DAY/NIGHT CAMERAS SC242
1IDENTIFICATION
MOUNTINGSCREWS & PLUGS
USER MANUAL
8GB SD CARD
4 X DETERRENT STICKERS
CONTENTS:
CONTENTS:
REMOTE
CONTROL
3 X POWER SUPPLIES
18cm
LCD DVR
WIRELESS
CAMERA X 2
Customer Service Phone: (03) 9982 5111 (Monday to Friday 8.30am – 5.30pm EST)
Email: [email protected]
For further information visit www.orionlive.com.au
PLEASE CONTACT IF YOU HAVE ANY
CONCERNS OR PROBLEMS WITH THIS PRODUCT
IMPORTANT BEFORE RETURNING THIS
PRODUCT TO THE RETAILER

›18cm 16:9 LCD screen.
›2.4 GHz digital frequency hopping spread
spectrum (FHSS).
›Wireless range up to 50 metres in open air,
line of sight.
›MPEG-4 compression.
›Single camera mode records VGA at 25FPS
(frames per second) or multiple camera
mode records QVGA at 30FPS/CH, VGA
resolution 640px x 480px.
›8GB micro SD card included, supports SDHC
memory card up to 32GB.
›Simultaneously preview and record from all
wireless cameras.
›Independent motion-detect recording with
adjustable mask zone on any of 4 cameras.
›Multiple recording mode selectable (manual
/ scheduled / motion detect).
›Built in microphone.
›24/7 scheduled recording.
›CMOS colour cameras with 24 IR LED’s for
up to 7 metres night vision.
›Camera has built-in IR cut filter for true
colour representation.
›Camera has IP43 weather proof rating.
› Please ensure this equipment is used
in accordance with any local laws or
regulations, especially if your device is
capable of audio recording. Users of this
equipment should at all times act responsibly
and consider the rights and reasonable
expectations of privacy of individuals.
Surveillance should be for a legitimate
purpose related to the activities of the
person or organisation conducting it.
We recommend that you clearly indicate
(written or otherwise) that surveillance is in
operation in the monitored area.
›Do not drop, puncture, or disassemble the
cameras or DVR.
›Do not tug the power adapter, use the plug
to remove it from the wall.
›Do not mount in position directly exposed to
sun, rain and avoid mounting near
radio transmitting devises, metal objects
or heat sources.
›Do not use DVR and cameras when there is a
storm or lightning in your area.
›Do not crush or damage the power cable.
›Do not cover the vents on the unit, leave
adequate space for ventilation.
›Use the cameras and DVR with care, avoid
unnecessary force or impact.
WIRELESS
SURVEILLANCE SYSTEM
3
18CM LCD DIGITAL VIDEO RECORDER WITH TWO DAY/NIGHT CAMERAS SC242
2FEATURES 3RESPONSIBLE USE
4WARNING

WIRELESS
SURVEILLANCE SYSTEM
4
5SYSTEM CONNECTION
Wireless
connection
to camera
Power
supply to
camera
Power
supply to
camera
Power supply to DVR
Wireless
connection
to camera
6DVR CONTROL PANEL
REMOTE
CONTROL
RECEIVER
DISPLAY
POWER
AV OUTPUT
CONTROL
SELECTION
CONFIRM
PLAY-PAUSE
INSTANT
RECORD
MENU
SETTING
MENU
NAVIGATION
18CM LCD DIGITAL VIDEO RECORDER WITH TWO DAY/NIGHT CAMERAS SC242

WIRELESS
SURVEILLANCE SYSTEM
5
7REMOTE CONTROL FUNCTION
BUTTON FUNCTION
Turn ON/OFF display screen
CH1 View channel 1 camera
on display
CH2 View channel 2 camera
on display
CH3 View channel 3 camera
on display
CH4 View channel 4 camera
on display
QUAD View all channel on display
AUTO Automatically rotate channel
1-4 camera on display
REC/
STOP
Press once to record, press
again to stop recording
AV
Press once to display audio and
visual to connected screen, the
DVR display will go black. Press
again to return to DVR display
8MENU LAYOUT
BUTTON FUNCTION
1. To scroll up and down to
select item in menu mode
2. To increase or decrease volume
in live or playback mode
1. To scroll left and right to
select item in menu mode
2. To fast-forward or rewind in
playback mode
3. To select channel 1-4 camera
on display in live mode
1. To play or pause the selected
recorded video in playback
mode file
2. To select SINGLE/QUAD/
AUTO display in live mode
MENU
Press once to enter into DVR
menu and setup, press again
to exit
DEL Press to delete
SD Format
Zoom
Upgrade
Load Default
Setting
Version
Play BackSystem SetupRecord SetupCamera Setup
MAIN MENU*
TV Out
Date Time
Setup
Pairing
Brightness
Quality
Volume
Activation
Motion
Sensitivity
Motion Record
Time
Schedule
Recording
SD Overwrite
Motion Detect
Activity
* ONCE IN THE “MENU”, USE THIS BUTTON
AS A “BACK” BUTTON.
18CM LCD DIGITAL VIDEO RECORDER WITH TWO DAY/NIGHT CAMERAS SC242

WIRELESS
SURVEILLANCE SYSTEM
6
›
IT IS RECOMMENDED TO SET UP AND TEST UNITS BEFORE FIXED MOUNTING INSTALLATION.
9SYSTEMINSTALLATION
1 1a
6
3
1 Install antenna on DVR unit and all
cameras.
2 Install stand on DVR unit.
DO NOT permanently mount cameras and
DVR during set up stage.
3 Connect power supply to a 240V power
point and DVR.
4 Install stands on all cameras.
5 Connect power supply to 240V power
point and all cameras.
5
4
5
2
18CM LCD DIGITAL VIDEO RECORDER WITH TWO DAY/NIGHT CAMERAS SC242

WIRELESS
SURVEILLANCE SYSTEM
7
7
8
9
10
11
18CM LCD DIGITAL VIDEO RECORDER WITH TWO DAY/NIGHT CAMERAS SC242
6 DVR screen will automatically turn on after
power supply connected.
7 The cameras come with the kit have already
paired to the DVR. Live image from camera
will be displayed on the DVR display screen
when power is connected.
8 Insert SD card into the DVR.
9 Format SD card: Menu> SYSTEM SETUP>
SD FORMAT> YES.
10 Wireless surveillance system is ready to use.
11 Mount DVR and cameras on suitable
locations.
6

WIRELESS
SURVEILLANCE SYSTEM
8
›TO SELECT DVR DISPLAY VIEW
Press “>||” button on the DVR control panel or
remote control to select “SINGLE/QUAD/AUTO“
display mode.
In SINGLE display mode, press “<”on the
DVR control panel or remote control to view
each camera display individually on the DVR
display screen.
In QUAD display mode, all connected cameras will
display on the DVR display screen.
In AUTO display mode, DVR will automatically
rotate channel 1-4 camera on display.
›AUTO DISPLAY MODE
Automatically rotate channel 1-4 camera on
display. To eliminate invalid channels:
MENU>CAMERA SETUP>ACTIVATION>OFF.
›SECTION 2: RECORDING MODE
SC242 kit comes with an 8 GB memory card that
can record up to 3 days of video, at VGA format.
Recording time depends on video format, VGA,
QVGA video format, and sound. VGA (640x480)
has higher resolution than QVGA (320x240).
Recording at VGA resolution improves clearness
and quality of video, but consumes more storage
space. Sound reduces the time available to
record from the memory card.
A suitable SD card must be inserted and
formatted before recording, SC242 supports up
to 32 GB SD card including SDHC type.
Recorded files are limited to 10 minutes
intervals. If continuously recording for more
than 10 minutes, a new recording file will be
automatically created until the SD card is full.
When SD card is full, recording will automatically
stop, or over write function can be enable to
over write:
MENU>RECORD SETUP>SD OVER WRITE>YES
10 OPERATION
18CM LCD DIGITAL VIDEO RECORDER WITH TWO DAY/NIGHT CAMERAS SC242
4 3 5 1
6 2
WIRELESS SIGNAL INDICATOR
Signal
Strength Indicator Possible Action
Perfect N/A
Good N/A
Fair
Low signal, recommended relocating
camera or DVR, check surrounding
interference, installation, power,
mounting location etc…
Low
Low signal, recommended relocating
camera or DVR, check surrounding
interference, installation, power,
mounting location etc…
No Signal No signal, please check trouble
shooting guide and warning
›SECTION 1: LIVE DISPLAY
The cameras come with the kit have already
paired to the DVR. When power connected to
DVR and all cameras, live display image should
be showing on the DVR display screen.
1. Wireless Signal Indicator
Shown on DVR top right hand corner. Please
ensure cameras are placed at a reasonable
distance (< 50m away from the DVR) and
location (see section 6).
2. Recording Indicator
Shown on the DVR bottom right hand corner.
When the DVR is recording, the red REC dot
indicator will be displayed.
3. SD Card Indicator
Shown on the DVR top left hand corner.
When suitable SD card is inserted and
detected, SD card indicator will be displayed.
4. Channel Indicator
Shown on the DVR top left hand corner.
The current channel number will be displayed.
Press ”CH1/CH2/CH3/CH4” on remote control
or “<” button on remote control and DVR
control panel to switch between channels.
5. Display Mode Indicator 1
Shown on the top of the DVR display. For
example 1for single display mode;
quad display mode; auto display mode.
6. Date and Time Indicator
2013/03/15 08:02:55
Shown at the bottom of the DVR display.

WIRELESS
SURVEILLANCE SYSTEM
9
›RECORDING LIVE:
Set DVR display mode to SINGLE or QUAD, by
pressing “>||” button on the DVR control panel
or remote control, DVR cannot record AUTO
display mode.
Press “REC” button on the DVR control
panel or remote control to record, press “REC”
button again to stop recording.
›SCHEDULED RECORDING MODE:
MENU>RECORD SETUP>SCHEDULE RECORDING
Set start time and end time, and select ON
by pressing “>||” when finish.
› MOTION DETECTION RECORDING MODE:
1. To enable motion detection
MENU>RECORD SETUP>MOTION DETECT
ACTIVITY>ON
2. Then setup motion detection sensitivity
MENU>RECORD SETUP>MOTION
SENSITIVITY>LOW/MEDIUM/HIGH
3. Finally setup motion record time duration
if motion detected
MENU>RECORD SETUP>MOTION RECORD
TIME>15SEC/30SEC/1MIN
›SECTION 3: PLAYBACK
Play back recorded video on DVR:
MENU>PLAY BACK>VIDEO>SELECT
DATE>SELECT TIME
PRESS “<” BUTTON ON THE DVR CONTROL
PANEL OR REMOTE CONTROL TO RETURN
TO PREVIOUS PAGE
PRESS “MENU” BUTTON ON THE DVR
CONTROL PANEL OR REMOTE CONTROL TO
RETURN TO MENU PAGE
Inside recorded video storage Use “^ or v”
button on the DVR control panel or remote
control to navigate, press “>||” button on the
DVR control panel or remote control to entre,
play or pause video.
While the video is playing, press “< or >” to fast-
forward and rewind the video.
To delete file:
Use “>” button on the DVR control panel or
remote control, or use “DEL” button on remote
control to delete selected file. After pressing “>”
button, the system will ask “ARE YOU SURE,
select “YES or NO” then press “>||” button
to confirm.
Play back recorded video on computer
Insert SD card containing recordings into
computer card reader.
Download latest version of VLC Media Player to
play back recorded files. www.videolan.org
›SECTION 4: CAMERA PAIRING
The cameras come with the kit have already
paired to the DVR.
Camera pairing function is necessary for
connecting additional cameras. Additional
cameras are assigned to a different channel on
the wireless channel; up to 4 cameras can be
connected.
* NOTE: please pair the camera before
permanent installation/mounting.
To pair a camera:
Ensure all cameras and DVR is powered.
Ensure all wireless channels are enabled for
adding additional camera.
MENU>Camera setup>Activation>CAM1/
CAM2/CAM3/CAM4>ON.
MENU>CAMERA SETUP>PAIRING>1/2/3/4>
press pairing button on the camera within
10 seconds.
›SECTION 5: AV OUTPUT
To display image on external screen press “AV”
button on the front control panel, press “AV”
button again to return to DVR display
In AV mode, DVR display screen will
automatically turn off.
Use supplied AV cable to connect to external
display screen
Please check external display screen format, PAL/
NTSC, SC242 DVR supports dual output
format.
PAL and NTSC, to change AV output format:
MENU> SYSTEM SETUP >TV OUT>PAL/NTSC
›SECTION 6: SD CARD
SD card required to format for first time use.
The DVR support SD card up to 32 GB
maximum, include SDHC type SD card.
MENU> SYSTEM SETUP> SD FORMAT> YES
›SECTION 7: FIRMWARE UPGRADE
Firmware upgrade is only for factory and
authorizes repairer use only, do not upgrade
the firmware.
11 OPERATION
18CM LCD DIGITAL VIDEO RECORDER WITH TWO DAY/NIGHT CAMERAS SC242
CAMERA PAIRING
BUTTON

WIRELESS
SURVEILLANCE SYSTEM
10
12 TROUBLESHOOTING GUIDE
PROBLEM POSSIBLE CAUSE SUGGESTED REMEDY
DVR/Camera has
no power or not
powering up
Power supply is loose or unplugged,
no power at socket outlet/power point
Check all cables and power supply connection.
Check power at socket outlet/power point.
SD Card is not
detected by DVR SD card not formatted Format SD card, please see “Operation Section 6”.
No picture
Camera out of range Relocate camera closer to DVR (vise versa).
Camera not paired Pair camera, please see “Operation Section 4”.
Signal interference Relocate camera and DVR, away from sun, rain, radio transmitting devices,
heat sources, metal objects or major obstacles.
No power at camera or no power at
socket outlet/power point Check all cables and power supply connection.
Frozen white screen - Disconnect power to DVR, then reconnect.
When IR night vision
is activated, screen
only displayed white.
Infra-red LED light is reflected off from
glass or reflective objects that causing
white light
Relocated camera away from windows, reflective and glass objects,
or remove obstacles.
When IR night vision
is activated, screen
only displayed black
and white
Infra-red LED light is activated This is normal, no action required.
DVR did not record
scheduled or motion
detected setting
DVR is not set up correctly, SD memory
card missing or not compliable
Check DVR date and time, scheduled setting date and time, and motion
detected setting setup.
Check SD memory card is inserted in the DVR and compliable to use.
SD memory card full Overwrite is not enabled Enable SD memory card overwrite, or reformat SD memory card,
or insert new SD memory card.
Recorded videos
does not have sound Mute is on
Turn off mute.
Note: Audio recording is prohibited or illegal in some states,
or required consent from both parties. Please consult your local legal
advisers before audio recording.
Channels
disappeared during
auto or manual scan
Channels has been turned OFF Turn camera channels ON, please see “Operation Section 4”.
Poor image quality Signal interference
Relocate camera and DVR, away from sun, rain, radio transmitting devices,
heat sources, metal objects or major obstacles.
Relocate camera closer to DVR (vise versa).
Check antenna connection.
Low or
unstable signal
Antenna Adjust antenna connection or relocate camera, closer to DVR (vise versa).
Signal interference
Relocate camera and DVR, away from sun, rain, radio transmitting devices,
heat sources, metal objects or major obstacles.
Strong radio emitting or transmitting
devices nearby
Strong electromagnetic interference
nearby
Too close to metal objects
Audio interference Camera and DVR are too close
Camera has a high sensitivity microphone, keep the camera and DVR at least
5 meters apart, if the camera must be within 5 meters of the DVR, reduce the
volume or turn on MUTE.
18CM LCD DIGITAL VIDEO RECORDER WITH TWO DAY/NIGHT CAMERAS SC242

WIRELESS
SURVEILLANCE SYSTEM
11
14 WARRANTY
Arlec guarantees this product in accordance with the Australian
Consumer Law.
Arlec also warrants to the original first purchaser of this product (“you”)
from a retailer that this product will be free of defects in materials and
workmanship for a period of 12 months from the date of purchase;
provided the product is not used other than for the purpose, or in a
manner not within the scope of the recommendations and limitations,
specified by Arlec, is new and not damaged at the time of purchase,
has not been subjected to abuse, misuse, neglect or damage, has not
been modified or repaired without the approval of Arlec and has not
been used for commercial purposes (“Warranty”).
If you wish to claim on the Warranty, you must, at your own expense,
return the product, and provide proof of original purchase and your
name, address and telephone number, to Arlec at the address below or
the retailer from whom you originally purchased the product within 12
months from the date of purchase.
Arlec will (or authorise the retailer to) assess any claim you may make
on the Warranty in the above manner and if, in Arlec’s reasonable
opinion, the Warranty applies, Arlec will at its own option and expense
(or authorise the retailer to) replace the product with the same or similar
product or repair the product and return it to you or refund the price
you paid for the product. Arlec will bear its own expenses of doing
those things, and you must bear any other expenses of claiming on
the Warranty.
The Warranty is in addition to other rights and remedies you may have
under a law in relation to the product to which the Warranty relates.
Our goods come with guarantees that cannot be excluded under the
Australian Consumer Law. You are entitled to a replacement or refund
for a major failure and for compensation for any other reasonably
foreseeable loss or damage. You are also entitled to have the goods
repaired or replaced if the goods fail to be of acceptable quality and
the failure does not amount to a major failure.
18CM LCD DIGITAL VIDEO RECORDER WITH TWO DAY/NIGHT CAMERAS SC242
13 SPECIFICATIONS
DIGITAL VIDEO RECORDER CAMERA
Arlec Australia Pty. Ltd. ACN 009 322 105 (“Arlec”) gives the Warranty.
Arlec’s telephone number, address and email address are:
Customer Service: (03) 9982 5111
New Zealand Toll Free: 0800 003 329
Building 3, 31 – 41 Joseph Street, Blackburn North, Victoria, 3130
Blackburn North LPO, P.O. Box 1065, Blackburn North, 3130
* Range depends on location and temperature.
›DISPLAY
Screen 18cm [7”] TFT LCD [16:9]
Resolution 800 [H] x RGB x 480 [V]
›WIRELESS VIDEO& AUDIOINPUT
Frequency Range 2.400GHz ~ 2.483GHz
Wireless Range Up to 50m*
Receiving Sensitivity -85dBm
›AV OUTPUT
Video Format PAL or NTSC
Video Output 1ch CVBS 1.0Vp-p, Impedance 75Ω
Audio Output 1ch Audio Ouput, Impedance 600Ω
›RECORDING
Compression Format MPEG4
Recording Resolution
VGA/QVGA
Recording Mode Manual / Schedule / Motion Detection
Frame Rate 25fps@VGA / 30fps@QVGA
Data Storage SD Card (8GB Included)
›CONNECTOR
USB Mini USB 2.0
SD Card 32G Max
›GENERAL
Power Supply DC 5V 1A
Power Consumption
4W Max
Dimensions
183(L) x 136(W) x 30(H) mm
Weight
450g
Operating Temp. 0°C ~ 40°C
Operating Humidity 10% ~ 90%
›VIDEO
Sensor Colour CMOS Sensor
Image Resolution 640 x 480
Lens F: 2.5mm
Electronic Shutter 1/60 ~1/15.000 sec
Gain Control Auto
White Balance Auto
›NIGHT VISION
Infra-red Light 24 IR LEDs
Range Up to 10m
IR Cut Filter Yes
›GENERAL
Power Supply DC 5V 1A
Power Consumption 3W Max
IP Rating IP43
Dimensions 100(L) x 80(W) x 80(H) mm
Weight 245g
Operating Temperature 0°C ~ 40°C
Operating Humidity 10% ~ 90%

WIRELESS
SURVEILLANCE SYSTEM
QUICK START GUIDE
01 02 03
Install antenna
on DVR unit and
all cameras.
Install stand
on DVR unit.
Do not permanently
mount cameras and
DVR at this stage.
Connect power
supply to a 240V
power point
and DVR.
05 Connect power
supply to 240V
power points and
cameras.
08 Insert SD card into
the DVR.
04 Install stands on all
cameras.
11 Mount DVR and
cameras on suitable
locations.
09 Format SD card:
Menu>
SYSTEM SETUP>
SD FORMAT> YES
10 Wireless surveillance
system is ready
to use.
06 DVR screen will
automatically turn on
after power supply
connected.
07 Cameras and DVR
are paired. Camera
live images displayed
on DVR screen after
start up.
Table of contents
Other Orion Security System manuals
