osann Beebop User manual

17
Thank you for your trust and that you made the decision to
purchase this child’s pushchair. It conforms to the DIN EN
1888 Standard and fulfils all the conditions for the safe and
comfortable transport of a small child! You will certainly have
a lot of pleasure with the pushchair.
The pushchair inset is suitable for children aged between
about 6 months and 4-years-old, or up to a weight of 17 kg;
the carrycot can be used for babies up to a size of 76 cm
long, or a weight of 9 kg.
Please read through the user manual carefully before instal-
ling and using your new pushchair and follow the advice
given in the directions for use. In this way you will quickly
familiarise yourself with all the possible uses and the safest
way to use the pushchair. We recommend that you retain the
user manual (and the sales receipt) in a suitable place for a
future reference.
Please always bear in mind that the pushchair has been
constructed exclusively for the transport of a child, and is not
suitable for sports purposes such as racing or roller-skating,
and under no circumstances must it be used as a car seat.
We wish you and your child all the best with this pushchair
and hope that it always lives up to your expectations and
serves your needs.
Carrying handle
Chassis
Inflated wheels
Swivel
wheels Foot brake
Parking brake
Frame Swivel
handle
Fastening straps
Frame mounting
Locking button
ENGLISH
ENGLISH
Dear Parents,
Text_alle_black.indd 17 02.02.2010 11:23:25 Uhr

18
Contents
I.) Delivery contents ........................................P. 19
1.) Basic equipment ...............................................P. 19
2.) Accessory range ................................................P. 19
II.) Assembly .....................................................P. 20
1.) Chassis ..............................................................P. 20
2.) Swivel wheels (front wheels) ..............................P. 20
3.) Inflated wheels (rear wheels) .............................P. 20
4.) Swivel handle ....................................................P. 21
5.) Frame ................................................................P. 21
a.) Assembly ......................................................P. 21
b.) Adjustment ...................................................P. 21
c.) Removal ........................................................P. 22
6.) Carrying handle .................................................P. 22
7.) Soft carrycot ......................................................P. 22
8.) Seating unit .......................................................P. 23
a.) Mounting ......................................................P. 23
b.) Tightening ....................................................P. 23
c.) Locking .........................................................P. 23
9.) Stowing bag ......................................................P. 24
10.) Canopy ............................................................P. 24
III.) Usage .........................................................P. 25
1.) Baby carrycot ....................................................P. 25
2.) Child seat ..........................................................P. 25
3.) Canopy ..............................................................P. 26
4.) Brake pedal .......................................................P. 26
5.) Parking brake ....................................................P. 26
IV.) Storage and transportation .......................P. 27
1.) Baby carrycot ....................................................P. 27
2.) Child seat ..........................................................P. 27
3.) Removing wheels ..............................................P. 27
a.) Swivel wheels (front wheels) .........................P. 27
b.) Inflated wheels (rear wheels) ........................P. 27
4.) Chassis ..............................................................P. 27
Text_alle_black.indd 18 02.02.2010 11:23:25 Uhr

19
I. Delivery Contents
Please check before putting your pushchair into operati-
on, whether absolutely all the individual parts are present.
Should anything be missing, please contact your stockist.
1.) Basic equipment
1 user manual
1 cushioned board
1 chassis (including brake pedal an
d locking brake)
2 rear wheels
1 mattress
1 frame (for the attachment of soft carrycot or seating unit)
2 swivel wheels (front wheels)
1 seating unit (for mounting in the frame)
1 soft carrycot (for mounting in the frame)
1 stowing basket 1 carrying handle / protective rail
1 canopy
2.) Accessory range
The following accessories are not included in the basic
equipment but can be purchased separately.
• Adaptor for the baby car seat models OSANN
BEONE SP, FERRARI BEONE SP, MAXI COSI
CABRIO FIX and MAXI COSI PEBBELS
• Baby snuggle bag
• Insect protection net
• Rain cover
For further details and for possible applications
please ask your stockist.
I. Delivery Contents
Please unfold the envelope on the left twice then
you will be able to see pictures with the following
information. 01 41
-
ENGLISH
Text_alle_black.indd 19 02.02.2010 11:23:25 Uhr

20
II. ASSEMBLY
II. Montage
The pushchair is easy to assemble. All the parts fit toge-
ther precisely and can be assembled without needing to
use much force.
1.) Chassis
The chassis is the basis of the pushchair. The wheels, the
frame, as well as the soft carrycot or the seating unit are
attached to it. First, unfold the chassis completely. Pull
the handle upward and the front axle toward the front. All
the chassis hinges must click into place.
2.) Swivel wheels (front wheels)
Attach both the swivel wheels to the front axle. In additi-
on push each of the pins into the wheel mountings. The
swivel wheels are engaged as soon as a clicking sound is
heard.
The swivel wheels can be locked by pushing the locking
bars, which are mounted on the front side of the wheel
mounting:
• When the locking bar is pushed up-
wards the wheel can be swivelled
• When the locking bar is pushed downwards the
wheel is locked
In order to be able to lock the swivel wheels, they must be
aligned in the direction of travel.
3.) Inflated wheels (rear wheels)
Insert the rear wheels into the wheel mounting at the ends
of the rear axle. Make sure that the wheels are tightly
connected to the chassis. Depending on the version of
your pushchair it may be fitted with inflated wheels. Upon
delivery these are already pumped up to a pressure of 1
Bar, which guarantees optimum suspension. Should the
wheels have lost some pressure, pump them up with a
bicycle pump (max. 1 Bar).
01 03
-
04 05
-
05
06 07
-
Text_alle_black.indd 20 02.02.2010 11:23:26 Uhr

21
ENGLISH
II. Montage
4.) Swivel handle
Adjust the height of the pushing handle to your require-
ments. To do this release the white locking buttons on the
inner side of the handle. Once the handle is at the desired
height push the buttons back into the original position.
Make sure that the locking buttons are securely engaged.
The handle can be positioned completely to the opposite
side of the chassis. To do this, unlock the two sleeves be-
low the locking buttons by pulling them upwards simulta-
neously. Now swivel the handle to the opposite side.
5.) Frame
The soft carrycot or the seating unit are attached to the
frame.
a.) Assembly
Before you insert the frame into the chassis, open both
the frame mounting brackets completely, until they are
at right angles to the frame. Turn the frame so that the
frame holders point downwards. Now bring the frame into
a horizontal position and then push the frame mounting
brackets into the insertion slots on the chassis. The frame
and chassis are tightly fastened together when you hear
an audible clicking sound from both sides.
b.) Adjustment
The soft carrycot can be used only in the horizontal
position (‘lying down’), for the seating unit three different
adjustable positions are available:
08 11
-
12 13
-
14 15
-
Text_alle_black.indd 21 02.02.2010 11:23:26 Uhr

22
• Lying down
• Reclining
• Sitting
To adjust the frame, simultaneously press both the white
knobs on the frame mounting. Now you can adjust the tilt
angle of the frame. The frame will perceptibly snap into
one of the three possible positions.
c.) Removal
Bring the frame into a horizontal position. Simultaneously
push both the white knobs on the hinges of the pushing
handle. Now lift the frame vertically upwards, the frame
mounting will slide out of the insertion slots.
6.) Carrying handle
The carrying handle is attached centrally to the frame.
To attach press both the white knobs at the ends of the
handle, keep these pushed down and then insert the
handle into the lugs, on the left and right of the frame. As
soon as you hear a clicking sound the carrying handle is
locked in place, and can be used.
To remove the carrying handle, push both the white knobs
at the ends of the handle simultaneously and pull it verti-
cally upwards.
7.) Soft carrycot
For use as a pram (from birth up to about 6 months) install
the soft carrycot into the frame.
Hang the soft carrycot in the frame and fasten it with the
Velcro strips. To maintain a rigid construction, proceed
from the outside inwards: first attach the Velcro strips at
the head and feet ends, then the bands next to them, left
and right, at each end, finally the fasteners in the middle.
Now fasten the soft carrycot to the chassis and hang both
the suspension straps in the notches provided on the
frame mounting.
II. Montage
16 17
-
18 19
-
20 24
-
Text_alle_black.indd 22 02.02.2010 11:23:26 Uhr

23
ENGLISH
Now place the cushioned board into the soft carrycot and
then place the mattress onto the board.
Finally attach the protective cover to the foot end of the
soft carrycot by means of the zip fastener.
8.) Seating unit
For use as a pushchair (about 6 months up to 4-years-old)
install the seating unit in the frame.
The seating unit is fitted with a 5-point harness. The hip
straps of the harness are already attached to the frame
and must be threaded through two slots in the unit.
a.) Mounting
Pull the seating unit tightly and evenly over the edge of
the frame. Make sure that the head and foot ends of the
unit and the frame join with each other correspondingly.
b.) Tightening
Draw together the tension strap under the frame and
join both ends of the strap. The tension strap is secure-
ly closed when you hear a clicking sound. Now pull the
tension strap tight.
c.) Locking
Pull the left and right hip straps attached to the frame
through the slots in the seating unit. Insert the ends into
the harness buckle, which is attached to the crotch strap.
Likewise, insert both ends of the shoulder straps. The lock
is equivalent to a ‘5-point harness’.
II. Montage
25
26
28 30
-
Text_alle_black.indd 23 02.02.2010 11:23:26 Uhr

24
9.) Stowing basket
The stowing basket serves as a storage area for small
items under the baby carrycot or the child seat. It is desig-
ned for a maximum weight of 4 kg.
Attach the stowing basket to the chassis with the Velcro
fasteners.
10.) Canopy
Attach the hood to the head end of the frame, and click
the canopy mounting onto the frame at the left and the
right.
II. Montage
31 34
-35 36
-
Text_alle_black.indd 24 02.02.2010 11:23:26 Uhr

25
ENGLISH
1.) Baby carrycot
The baby carrycot is suitable for babies from birth up to
about 6 months and up to a weight of 17 kg.
Your baby will lie safe and comfortable in the baby carrycot.
You can choose to turn the baby carrycot within the chassis
so that your baby either faces you or the direction of travel.
Please always pay attention to the following:
• Only use the baby carrycot mounted in the chas-
sis or on a horizontal, stable and dry surface.
• The baby carrycot must be placed in a horizon-
tal position, otherwise the baby could slip out.
• The baby carrycot is not a car seat
and must not be used as such.
• Only use the baby carrycot when the soft car-
rycot is securely fastened into the frame
and all the fasteners are tightly secured.
• Check whether the carrying hand-
le is properly attached to the frame be-
fore you lift the baby carrycot.
2.) Pushchair unit
The pushchair unit is suitable for children aged from about
6 months to 4-years-old and up to a weight of 17 kg.
When the pushchair unit is fixed into the chassis, three
different adjustable positions are available:
• Lying down
• Reclining
• Sitting
The posture of the child, i.e. the angle between the backrest
and seat cushion, will remain unchanged in all three positions.
Ohne Fahrgestell lässt sich der Kindersitz freistehend auf
dem Boden benutzen. Klappen Sie dafür die Rahmenhal-
ter komplett um. Verwenden Sie die Gurte, wenn sich Ihr
Kind alleine aufrichten kann.
III. Usage
III. Usage
Text_alle_black.indd 25 02.02.2010 11:23:26 Uhr

26
III. Usage
You can choose to turn the pushchair unit within the
chassis so that your child either faces you or the direction
of travel. In doing so always fasten all the harness straps
– this will prevent your child from falling out of the seat.
Using the harness system:
• Make sure that the crotch strap, with the
buckle, passes between your child’s legs.
• Now join both the hip and shoulder harnes-
ses together in front of the child and click
the harnesses into the harness buckle.
• Make sure that the hip and shoulder har-
nesses fit the child tightly and comfortably
and that the harnesses are securely faste-
ned into the buckle with a ‘click’ sound.
3.) Canopy
Babies have very sensitive skin. Protect your child from
direct sunlight – close the canopy in strong sunshine.
4.) Brake pedal
The brake pedal is located at the centre of the rear axle
and is operated with the foot:
• When you press the pedal down
the rear wheels will lock.
• To release the lock, press the pedal upwards again.
5.) Parking brake
If the parking brake is off, the brake lever will lie flat
against the pushing handle. To lock the rear wheels, press
the brake lever away from the pushing handle fully, until
the lever cannot be moved any further.
To release the lock, press the white knob at the side of the
brake lever hinge. The lever will automatically return to the
original position, the parking brake is now released.
40 41
-
39
37 38
-
Text_alle_black.indd 26 02.02.2010 11:23:26 Uhr

27
ENGLISH
IV. Storage and transportation
Your pushchair can be folded quickly and easily, as well
as to save space, for example, when transported in the
boot of your car.
1.) Baby carrycot
Pull the baby carrycot out of the chassis by pushing both
the white knobs on the hinge of the pushing handle and
then lift the carrycot vertically upwards out of the chassis.
2.) Pushchair unit
Pull the pushchair unit out of the chassis, by pushing both
the white knobs on the hinge of the pushing handle and
then lifting the seat vertically upwards out of the chassis.
3.) Removing wheels
a.) Swivel wheels (front wheels)
To remove a swivel wheel squeeze the catch located
above the wheel mounting, and pull the wheel out of the
mounting.
b.) Rear wheels
To remove a rear wheel, push the release button located
on the axle, and simultaneously pull the wheel off.
4.) Chassis
To be able to fold down the chassis, the pushing handle
must be positioned above the rear wheels. If necessary,
swivel the handle into this position.
Unlock both the sleeves below the locking buttons, while
pulling these upwards simultaneously. Now push the
pushing handle downwards in the direction of the rear
axle.
So that the chassis can be folded down completely, press
both the central metal struts together (central axis), using
both hands, and pull the whole chassis upwards.
IV. Storage and transportation
Text_alle_black.indd 27 02.02.2010 11:23:26 Uhr
