paasche EZ-STARTER User manual

INSTRUCTIONS AND PARTS LIST EZ-STARTER AIRBRUSH 8/16/2019
EZ-STARTER
Single Action–External Mix–Siphon Feed
Instruction Manual & Replacment Parts
OPERATING INSTRUCTIONS:
Approximate Working Pressures:
• 20lbs.orLess:Stippleandgranulatede󰀨ects,pressurewillvarywithviscosityofuid.
• 20to30lbs.:Mediumconsistencywatercolors,inks&dyes.
• 30 lbs. or More:Heavyuids,acrylics,reducedlacquers,varnishes,paintsorceramicglaze.
1.Attachhosetoairsupplyandallowairtoblowafewseconds.Shuto󰀨beforeattachingtoAirbrush.Thisprocedurewill
removedirtfromairlineandhose.
Caution: Hold rmly and point away from face.
2.Attachhosecouplingtotheairbrush.
3.AttachColorCuporBottleto#6NeedlebyexertingarmtwistingmotiontottaperedtubesecurelyintotaperedNeedleinlet.
4.FillBottle1/2to3/4full.Useeyedropperorbrushforaddingsmallamountsofcolortometalcolorcup.Ventholemustbekept
open.
5.ToSpray,holdAirbrushlikeapencilcomfortablybetweenthumbandforengerusingmiddlengerasaguideandsupport.
Likewriting,holdforengereasilyonButtonandPresstoopenairvalve.
6.Regulatevolumeofcolorandsizeofspraybyrotating #5Tipclockwisetoincreaseandcounterclockwisetodecreaseow
ofcolor.
CARE AND CLEANING:
1.Pouranyremainingcolorbackintoitsoriginalcontainer.
2.WipeBottleclean,usingclothmoistenedwithpropersolvent.
3.HoldAirbrushatadownwardangleandputafewdropsofsolventthrough#6Needle,orllbottlewithPaintCleanertospray.
ToushouttheremainingcolorintheHColorAdjustingPartAssembly,applypressuretothe Button.
HOW TO OPEN CLOGGED FLUID PASSAGES:
1.AgitatecolorinBottleAssemblybyplacingngermomentarilyover#1AircapwhileairispassingthroughtheAirbrush.This
willblowcolorbackintobottlethusopeningcloggeduidpassages.
2.ShouldTiporNeedlebecomeclogged,pull#8Clip,unscrewTipfromNeedle,gentlypullbackthroughsupportandremove
Tip.
3.CleanPartscarefully,usingnothingharderthanawoodentoothpick&yourpaintcleaner.
4.Toreassemble,reversethisprocedure.
5.Iftheneedleandtiparecompletelyclogged,Remove#7“O”Ring(rst)thensoakinaclosedbottleofpropersolventuntil
clean.

2
EZ-STARTER AIRBRUSH MODEL REPLACEMENT PARTS
Part No. Description
1.  Aircap
2. O - Ring
3.   Bushing
4.   Body
5.   FluidTip
6. Needle
7. O -Ring
8.   ClipWasher
9.   Spraybottle
10.  StorageBottle
11.  AirHose
12.  PressureCanRegulator
13.  CompressorAdapter
H-1/4-OZ
(1/4oz Metal)
H-3-OZ
(3oz Glass)
H-1-OZ
(1oz Glass)
HP-3-OZ
(3oz Plastic)
H-2-OZ
(2oz Metal)
WARNING: Spray materialsmay beharmful ifinhaledor
allowedtocomeintocontactwiththeskinoreyes.Consult
theproductlabelandMaterialSafetyDataSheetsupplied
for the spray material.  Follow all safety precautions.
CAUTION: Well Ventilated Area Required to remove
fumes,dustoroverspray.Maximum Air Pressure 50 P.S.I.
HP-8-OZ
(8oz Plastic)
BA-30-3P
(3oz Plastic)
BA-30-1P
(1oz Plastic)
BA-30-4P
(3oz Plastic)
BA-30-2P
(1oz Plastic)
e BA bottle assemblies are a new cover conguration and all use plastic
bottle. e 2P and 4P are narrow neck and work with most airbrush paint
bottles like Createx and Paasche
