Panasonic S-36PU1E5A Manual

TECHNICAL DATA & SERVICE MANUAL
85464849331002 REFERENCE NO. SM830231-02
R410A Models
Model No.
Indoor Units
50 60 71 100 125 140
Outdoor Units
–
–
U-60PE1E5A U-71PE1E5A U-100PE1E5A U-125PE1E5A U-140PE1E5A
U-71PE1E8A U-100PE1E8A U-125PE1E8A U-140PE1E8A
U-50PE1E5
Type
PE1
PEY1
–––
Outdoor Units Type
Single Split (1-phase)
Single Split (3-phase)
Single Split (1-phase)
Single Split (3-phase) U-100PEY1E8 U-125PEY1E8
U-60PEY1E5
–
U-71PEY1E5 U-100PEY1E5 U-125PEY1E5 –
U-140PEY1E8
Indoor Unit Outdoor Unit
Wall Mounted
Ceiling
Low Silhouette Ducted
4-Way Cassette
4-Way Cassette 60 x 60
Ducted
Order No. SBPAC1403009CE
Indoor
Units Type 36 45 50 60 71 100 125 140
4-Way Cassette S-36PU1E5A S-45PU1E5A S-50PU1E5A S-60PU1E5A S-71PU1E5A
S-100PU1E5A S-125PU1E5A S-140PU1E5A
S-36PF1E5A S-45PF1E5A S-50PF1E5A S-60PF1E5A S-71PF1E5A S-100PF1E5A S-125PF1E5A S-140PF1E5A
S-36PN1E5A S-45PN1E5A S-50PN1E5A S-60PN1E5A S-71PN1E5A S-100PN1E5A S-125PN1E5A S-140PN1E5A
S-36PT2E5A S-45PT2E5A S-50PT2E5A S-60PT2E5A S-71PT2E5A S-100PT2E5A
S-100PK1E5A
S-125PT2E5A S-140PT2E5A
––
––– ––
S-36PK1E5A S-45PK1E5A S-50PK1E5A S-60PK1E5A S-71PK1E5A
Wall Mounted
Low Silhouette
Ducted
Ducted
S-36PY2E5A S-45PY2E5A S-50PY2E5A
4-Way
Cassette 60 x 60
Y2
Type
U1
K1
F1
N1
T2 Ceiling
SM830231-02Single欧州.indb1SM830231-02Single欧州.indb1 2014/09/1117:38:462014/09/1117:38:46

i
IMPORTANT!
Please Read Before Starting
This air conditioner must be installed by the sales dealer
or installer.
This information is provided for use only by authorized
persons.
For safe installation and trouble-free operation, you must:
Carefully read this instruction booklet before beginning.
Follow each installation or repair step exactly as shown.
This air conditioner shall be installed in accordance with
National Wiring Regulations.
Pay close attention to all warning and caution notices
given in this manual.
WARNING
This symbol refers to a hazard or unsafe
practice which can result in severe
personal injury or death.
CAUTION
This symbol refers to a hazard or unsafe
practice which can result in personal
injury or product or property damage.
If Necessary, Get Help
These instructions are all you need for most installation
sites and maintenance conditions. If you require help for a
special problem, contact our sales/service outlet or your
certified dealer for additional instructions.
In Case of Improper Installation
The manufacturer shall in no way be responsible for
improper installation or maintenance service, including
failure to follow the instructions in this document.
SPECIAL PRECAUTIONA
WARNING
When Wiring
ELECTRICAL SHOCK CAN
CAUSE SEVERE PERSONAL
INJURY OR DEATH. ONLY A
QUALIFIED, EXPERIENCED
ELECTRICIAN SHOULD
ATTEMPT TO WIRE THIS SYS-
TEM.
• Do not supply power to the unit until
all wiring and tubing are completed or
reconnected and checked.
• Highly dangerous electrical voltages are
used in this system.
Carefully refer to the wiring diagram and
these instructions when wiring. Improper
connections and inadequate grounding
can cause accidental injury or death.
• Connect all wiring tightly. Loose wiring
may cause overheating at connection
points and a possible fire hazard.
•To prevent possible hazards from
insulation failure, the unit must be
grounded.
•Provide a power outlet exclusively for
each unit, and full disconnection means
having a contact separation in all poles
must be incorporated in the fixed wiring
in accordance with the wiring rules.
• This equipment is strongly recommended
to be installed with Earth Leakage Circuit
Breaker (ELCB) or Residual Current
Device (RCD). Otherwise, it may cause
electrical shock and fire in case of
equipment breakdown or insulation
breakdown.
When Transporting
Be careful when picking up and moving
the indoor and outdoor units. Get a partner
to help, and bend your knees when lifting
to reduce strain on your back. Sharp
edges or thin aluminum fins on the air
conditioner can cut your fingers.
When Installing…
Select an installation location which is
rigid and strong enough to support or hold
the unit, and select a location for easy
maintenance.
…In a Room
Properly insulate any tubing run inside a
room to prevent “sweating” that can cause
dripping and water damage to walls and
floors.
CAUTION
Keep the fire alarm and
the air outlet at least 1.5
m away from the unit.
…In Moist or Uneven Locations
Use a raised concrete pad or concrete
blocks to provide a solid, level foundation
for the outdoor unit. This prevents water
damage and abnormal vibration.
…In an Area with High Winds
Securely anchor the outdoor unit down
with bolts and a metal frame. Provide a
suitable air baffle.
…In a Snowy Area (for Heat Pump-type
Systems)
Install the outdoor unit on a raised platform
that is higher than drifting snow. Provide
snow vents.
…At least 2.5 m
Indoor unit of this air conditioner shall be
installed in a height of at least 2.5 m.
…In laundry rooms
Do not install in laundry rooms. Indoor unit
is not drip proof.
SM830231-02Single欧州.indbSec1:iSM830231-02Single欧州.indbSec1:i 2014/09/1117:38:522014/09/1117:38:52

When Connecting Refrigerant Tubing
WARNING
• When performing piping work do not
mix air except for specified refrigerant
(R410A) in refrigeration cycle. It
causes capacity down, and risk of
explosion and injury due to high
tension inside the refrigerant cycle.
• Refrigerant gas leakage may cause
fire.
Do not add or replace refrigerant other
than specified type. It may cause
product damage, burst and injury, etc.
•
• Ventilate the room well, in the event that is
refrigerant gas leaks during the installation.
Be careful not to allow contact of the
refrigerant gas with a flame as this will
cause the generation of poisonous gas.
• Keep all tubing runs as short as possible.
• Use the flare method for connecting tubing.
• Apply refrigerant lubricant to the matching
surfaces of the flare and union tubes before
connecting them, then tighten the nut with a
torque wrench for a leak-free connection.
• Check carefully for leaks before starting
the test run.
• Do not leak refrigerant while piping work
for an installation or re-installation, and
while repairing refrigeration parts.
Handle liquid refrigerant carefully as it
may cause frostbite.
When Servicing
• Turn the power OFF at the main
power box (mains) before opening
the unit to check or repair electrical
parts and wiring.
• Keep your fingers and clothing away
from any moving parts.
• Clean up the site after you finish,
remembering to check that no metal
scraps or bits of wiring have been left
inside the unit being serviced.
WARNING
•
•
•
This product must not be modified
or disassembled under any
circumstances. Modified or
disassembled unit may cause fire,
electric shock or injury.
Do not clean inside the indoor and
outdoor units by users. Engage
authorized dealer or specialist for
cleaning.
In case of malfunction of this
appliance, do not repair by
yourself. Contact the sales dealer
or service dealer for repair.
CAUTION
•
•
Do not touch the air inlet or
the sharp aluminum fins of the
outdoor unit. You may get injured.
Ventilate any enclosed areas when
installing or testing the refrigeration
system. Escaped refrigerant gas,
on contact with fire or heat, can
produce dangerously toxic gas.
• Confirm after installation that no
refrigerant gas is leaking. If the gas
comes in contact with a burning
stove, gas water heater, electric
room heater or other heat source,
it can cause the generation of
poisonous gas.
Others
WARNING
CAUTION
•
•
•
Do not sit or step on the unit,
you may fall down
accidentally.
Do not touch the air inlet or
the sharp aluminum fins of
the outdoor unit. You may get
injured.
Do not stick any object into
the FAN CASE.
You may be injured and the
unit may be damaged.
ii
SM830231-02Single欧州.indbSec1:iiSM830231-02Single欧州.indbSec1:ii 2014/09/1117:38:522014/09/1117:38:52

iii
RoHS
· This product does not contain any hazardous
substances prohibited by the RoHS Directive.
WARNING
· You are requested to use RoHS compliant for
maintenance or repair.
2. The standards for minimum room volume are as follows.
(1) No partition (shaded portion)
(2) When there is an effective opening with the adjacent room
for ventilation of leaking refrigerant gas (opening without
a door, or an opening 0.15% or larger than the respective
floor spaces at the top or bottom of the door).
(3) If an indoor unit is installed in each partitioned room and
the refrigerant tubing is interconnected, the smallest room
of course becomes the object. But when mechanical
ventilation is installed interlocked with a gas leakage
detector in the smallest room where the density limit is
exceeded, the volume of the next smallest room becomes
the object.
3. The minimum indoor floor space compared with the
amount of refrigerant is roughly as follows (for room with
2.7 m high ceiling):
40
35
30
25
20
15
10
5
010 20 30
m
2
Check of Density Limit
The room in which the air conditioner is to be installed
requires a design that in the event of refrigerant gas
leaking out, its density will not exceed a set limit.
The refrigerant (R410A), which is used in the air conditioner,
is safe, without the toxicity or combustibility of ammonia, and
is not restricted by laws imposed to protect the ozone layer.
However, since it contains more than air, it poses the risk of
suffocation if its density should rise excessively. Suffocation
from leakage of refrigerant is almost non-existent. With the
recent increase in the number of high density buildings,
however, the installation of multi air conditioner systems is
on the increase because of the need for effective use of floor
space, individual control, and energy conservation by curtailing
heat and carrying power, etc.
Most importantly, the multi air conditioner system is able
to replenish a large amount of refrigerant compared to
conventional individual air conditioners. If a single unit of the
multi air conditioner system is to be installed in a small room,
select a suitable model and installation procedure so that if the
refrigerant accidentally leaks out, its density does not reach the
limit (and in the event of an emergency, measures can be made
before injury can occur).
In a room where the density may exceed the limit, create an
opening with adjacent rooms, or install mechanical ventilation
combined with a gas leak detection device. The density is as
given below.
Total amount of refrigerant (kg)
Min. volume of the indoor unit installed room (m3)
< Density limit (kg/m3)
The density limit of refrigerant which is used in multi air
conditioners is 0.3 kg/m3(ISO 5149).
NOTE
1. If there are 2 or more refrigerating systems in a single
refrigerating device, the amount of refrigerant should be as
charged in each independent device.
For the amount of charge in this example:
The possible amount of leaked refrigerant gas in rooms A,
B and C is 10 kg.
The possible amount of leaked refrigerant gas in rooms D,
E and F is 15 kg.
e.g., charged
amount (10 kg)
Indoor unit
Outdoor unit
e.g., charged
amount (15 kg)
Room A Room B Room C Room D Room E Room F
Outdoor unit
Refrigerant tubing
Indoor unit
Mechanical ventilation device – Gas leak detector
Refrigerant tubing
Outdoor unit
Indoor unit
Very
small
room
Small
room
Medium
room
Large room
Total amount of refrigerant
Min. indoor floor space
Range above the
density limit of 0.3 kg/m3
(countermeasures needed)
kg
Range below the
density limit of 0.3 kg/m3
(countermeasures not
needed)
SM830231-02Single欧州.indbSec1:iiiSM830231-02Single欧州.indbSec1:iii 2014/09/1117:38:522014/09/1117:38:52

iv
IMPORTANT INFORMATION REGARDING THE REFRIGERANT USED
This product contains fluorinated greenhouse gases covered by the Kyoto Protocol. Do not vent gases into the atmosphere.
Refrigerant type: R410A
GWP(1)
value: 1975
(1) GWP = global warming potential
Periodical inspections for refrigerant leaks may be required depending on European or local legislation.
Please contact your local dealer for more information.
Please fill in with indelible ink,
1the factory refrigerant charge of the product
2the additional refrigerant amount charged in the field and
1+ 2the total refrigerant charge
on the refrigerant charge label supplied with the product.
The filled out label must be adhered in the proximity of the product charging port (e.g. onto the inside of the service cover).
1
4
2
3
56
1. Factory refrigerant charge of the product: see unit name plate
2. Additional refrigerant amount charged in the field
3. Total refrigerant charge
4. Contains fluorinated greenhouse gases covered by the Kyoto Protocol
5. Outdoor unit
6. Refrigerant cylinder and manifold for charging
*
English text printed on this label is original. Each
language label will be sealed on this original text.
kg
kg
kg
SM830231-02Single欧州.indbSec1:ivSM830231-02Single欧州.indbSec1:iv 2014/09/1117:38:522014/09/1117:38:52

v
Combination of Indoor and Outdoor Units
Single-phase
PE1
U1
36 45 50 60 71 100 125 140
S-140PU1E5A
U-140PE1E5A
S-45PU1E5A x3
U-125PE1E5A
S-50PU1E5A x3
U-140PE1E5A
S-60PU1E5A
U-60PE1E5A
S-36PU1E5A x4
U-125PE1E5A
S-36PU1E5A x2
U-71PE1E5A
S-36PU1E5A x3
U-100PE1E5A
S-60PU1E5A x2
U-125PE1E5A
S-50PU1E5A
U-50PE1E5
S-50PU1E5A x2
U-100PE1E5A
S-71PU1E5A
U-71PE1E5A
S-71PU1E5A x2
U-140PE1E5A
S-100PU1E5A
U-100PE1E5A
S-125PU1E5A
U-125PE1E5A
P2
P3
P4
P5 P6 P9 P14P11 P13
P12
P15
P7 P10
P8
T2
S-140PT2E5A
U-140PE1E5A
S-45PT2E5A x3
U-125PE1E5A
S-50PT2E5A x3
U-140PE1E5A
S-60PT2E5A
U-60PE1E5A
S-36PT2E5A x4
U-125PE1E5A
S-36PT2E5A x2
U-71PE1E5A
S-36PT2E5A x3
U-100PE1E5A
S-60PT2E5A x2
U-125PE1E5A
S-50PT2E5A
U-50PE1E5
S-50PT2E5A x2
U-100PE1E5A
S-71PT2E5A
U-71PE1E5A
S-71PT2E5A x2
U-140PE1E5A
S-100PK1E5A
U-100PE1E5A
S-125PT2E5A
U-125PE1E5A
P28
P29
P30
P31 P32 P35 P40P37
P65
P38
P41
P33 P36
P34
F1
S-140PF1E5A
U-140PE1E5A
S-45PF1E5A x3
U-125PE1E5A
S-50PF1E5A x3
U-140PE1E5A
S-60PF1E5A
U-60PE1E5A
S-36PF1E5A x4
U-125PE1E5A
S-36PF1E5A x2
U-71PE1E5A
S-36PF1E5A x3
U-100PE1E5A
S-60PF1E5A x2
U-125PE1E5A
S-50PF1E5A
U-50PE1E5
S-50PF1E5A x2
U-100PE1E5A
S-71PF1E5A
U-71PE1E5A
S-71PF1E5A x2
U-140PE1E5A
S-100PF1E5A
U-100PE1E5A
S-125PF1E5A
U-125PE1E5A
P76
P77
P78
P79 P80 P83 P88P85 P87
P86
P89
P81 P84
P82
N1
S-140PN1E5A
U-140PE1E5A
S-45PN1E5A x3
U-125PE1E5A
S-50PN1E5A x3
U-140PE1E5A
S-60PN1E5A
U-60PE1E5A
S-36PN1E5A x4
U-125PE1E5A
S-36PN1E5A x2
U-71PE1E5A
S-36PN1E5A x3
U-100PE1E5A
S-60PN1E5A x2
U-125PE1E5A
S-50PN1E5A
U-50PE1E5
S-50PN1E5A x2
U-100PE1E5A
S-71PN1E5A
U-71PE1E5A
S-71PN1E5A x2
U-140PE1E5A
S-100PN1E5A
U-100PE1E5A
S-125PN1E5A
U-125PE1E5A
P102
P103
P104
P105 P106 P109 P114P111 P113
P112
P115
P107 P110
P108
Y2
S-45PY2E5A x3
U-125PE1E5A
S-50PY2E5A x3
U-140PE1E5A
S-36PY2E5A x4
U-125PE1E5A
S-36PY2E5A x2
U-71PE1E5A
S-36PY2E5A x3
U-100PE1E5A
S-50PY2E5A
U-50PE1E5
S-50PY2E5A x2
U-100PE1E5A
P128
P129
P130
P131 P132
P133
P134
K1
S-45PK1E5A x3
U-125PE1E5A
S-50PK1E5A x3
U-140PE1E5A
S-60PK1E5A
U-60PE1E5A
S-36PK1E5A x4
U-125PE1E5A
S-36PK1E5A x2
U-71PE1E5A
S-36PK1E5A x3
U-100PE1E5A
S-60PK1E5A x2
U-125PE1E5A
S-50PK1E5A
U-50PE1E5
S-50PK1E5A x2
U-100PE1E5A
S-71PK1E5A
U-71PE1E5A
S-71PK1E5A x2
U-140PE1E5A
P54
P55
P56
P57 P58 P61 P63
P64
P59 P62
P60
S-100PT2E5A
U-100PE1E5A
P39
SM830231-02Single欧州.indbSec1:vSM830231-02Single欧州.indbSec1:v 2014/09/1117:38:522014/09/1117:38:52

vi
Combination of Indoor and Outdoor Units
PE1
S-140PU1E5A
U-140PE1E8A
S-45PU1E5A x3
U-125PE1E8A
S-60PU1E5A x2
U-125PE1E8A
S-36PU1E5A x4
U-125PE1E8A
S-36PU1E5A x2
U-71PE1E8A
S-36PU1E5A x3
U-100PE1E8A
S-50PU1E5A x2
U-100PE1E8A
S-50PU1E5A x3
U-140PE1E8A
S-71PU1E5A
U-71PE1E8A
S-71PU1E5A x2
U-140PE1E8A
S-100PU1E5A
U-100PE1E8A
S-125PU1E5A
U-125PE1E8A
P16
P17
P18
P19 P20 P22 P26P23 P25
P24
P27
P21
3-phase
U1
36 45 50 60 71 100 125 140
S-140PF1E5A
U-140PE1E8A
S-45PF1E5A x3
U-125PE1E8A
S-60PF1E5A x2
U-125PE1E8A
S-36PF1E5A x4
U-125PE1E8A
S-36PF1E5A x2
U-71PE1E8A
S-36PF1E5A x3
U-100PE1E8A
S-50PF1E5A x2
U-100PE1E8A
S-50PF1E5A x3
U-140PE1E8A
S-71PF1E5A
U-71PE1E8A
S-71PF1E5A x2
U-140PE1E8A
S-100PF1E5A
U-100PE1E8A
S-125PF1E5A
U-125PE1E8A
P90
P91
P92
P93 P94 P96 P100P97 P99
P98
P101
P95
S-140PN1E5A
U-140PE1E8A
S-45PN1E5A x3
U-125PE1E8A
S-60PN1E5A x2
U-125PE1E8A
S-36PN1E5A x4
U-125PE1E8A
S-36PN1E5A x2
U-71PE1E8A
S-36PN1E5A x3
U-100PE1E8A
S-50PN1E5A x2
U-100PE1E8A
S-50PN1E5A x3
U-140PE1E8A
S-71PN1E5A
U-71PE1E8A
S-71PN1E5A x2
U-140PE1E8A
S-100PN1E5A
U-100PE1E8A
S-125PN1E5A
U-125PE1E8A
P116
P117
P118
P119 P120 P122 P126P123 P125
P124
P127
P121
S-45PK1E5A x3
U-125PE1E8A
S-60PK1E5A x2
U-125PE1E8A
S-36PK1E5A x4
U-125PE1E8A
S-36PK1E5A x2
U-71PE1E8A
S-36PK1E5A x3
U-100PE1E8A
S-50PK1E5A x2
U-100PE1E8A
S-50PK1E5A x3
U-140PE1E8A
S-71PK1E5A
U-71PE1E8A
S-71PK1E5A x2
U-140PE1E8A
P66
P67
P68
P69 P70 P72 P73
P74
P71
T2
S-140PT2E5A
U-140PE1E8A
S-45PT2E5A x3
U-125PE1E8A
S-36PT2E5A x4
U-125PE1E8A
S-36PT2E5A x2
U-71PE1E8A
S-36PT2E5A x3
U-100PE1E8A
S-60PT2E5A x2
U-125PE1E8A
S-50PT2E5A x2
U-100PE1E8A
S-50PT2E5A x3
U-140PE1E8A
S-71PT2E5A
U-71PE1E8A
S-71PT2E5A x2
U-140PE1E8A
S-100PT2E5A
U-100PE1E8A
S-125PT2E5A
U-125PE1E8A
P42
P43
P44
P45 P46 P48 P52P49 P51
P50
P53
P47
F1
N1
S-45PY2E5A x3
U-125PE1E8A
S-36PY2E5A x4
U-125PE1E8A
S-36PY2E5A x2
U-71PE1E8A
S-36PY2E5A x3
U-100PE1E8A
S-50PY2E5A x2
U-100PE1E8A
S-50PY2E5A x3
U-140PE1E8A
P135
P136
P137
P138 P139
P140
Y2
K1
S-100PK1E5A
U-100PE1E8A
P75
SM830231-02Single欧州.indbSec1:viSM830231-02Single欧州.indbSec1:vi 2014/09/1117:38:532014/09/1117:38:53

vii
Combination of Indoor and Outdoor Units
Single-phase
U1
PEY1
36
S-36PU1E5A x2
U-71PEY1E5
P141
50 60 71 100 125 140
S-60PU1E5A
U-60PEY1E5
S-60PU1E5A x2
U-125PEY1E5
S-50PU1E5A x2
U-100PEY1E5
S-71PU1E5A
U-71PEY1E5
S-100PU1E5A
U-100PEY1E5
S-125PU1E5A
U-125PEY1E5
P142 P143 P147P145 P146
P144
U1
36 50 60 71 100 125 140
S-60PU1E5A x2
U-125PEY1E8
S-50PU1E5A x2
U-100PEY1E8
S-71PU1E5A x2
U-140PEY1E8
S-100PU1E5A
U-100PEY1E8
S-125PU1E5A
U-125PEY1E8
P148 P149 P152P150 P151
S-140PU1E5A
U-140PEY1E8
P153
F1
S-60PF1E5A x2
U-125PEY1E8
S-50PF1E5A x2
U-100PEY1E8
S-71PF1E5A x2
U-140PEY1E8
S-100PF1E5A
U-100PEY1E8
S-125PF1E5A
U-125PEY1E8
P184 P185 P188P186 P187
S-140PF1E5A
U-140PEY1E8
P189
N1
S-60PN1E5A x2
U-125PEY1E8
S-50PN1E5A x2
U-100PEY1E8
S-71PN1E5A x2
U-140PEY1E8
S-100PN1E5A
U-100PEY1E8
S-125PN1E5A
U-125PEY1E8
P197 P198 P201
S-140PN1E5A
U-140PEY1E8
P202P199 P200
Y2
S-50PY2E5A x2
U-100PEY1E8
P205
T2
S-60PT2E5A x2
U-125PEY1E8
S-50PT2E5A x2
U-100PEY1E8
S-71PT2E5A x2
U-140PEY1E8
S-100PK1E5A
U-100PEY1E8
S-125PT2E5A
U-125PEY1E8
P161 P162 P165
S-140PT2E5A
U-140PEY1E8
P166P163
P176
K1
S-60PK1E5A x2
U-125PEY1E8
S-50PK1E5A x2
U-100PEY1E8
S-71PK1E5A x2
U-140PEY1E8
P173 P174 P175
3-phase
F1
S-36PF1E5A x2
U-71PEY1E5
P177
S-60PF1E5A
U-60PEY1E5
S-60PF1E5A x2
U-125PEY1E5
S-50PF1E5A x2
U-100PEY1E5
S-71PF1E5A
U-71PEY1E5
S-100PF1E5A
U-100PEY1E5
S-125PF1E5A
U-125PEY1E5
P178 P179 P183P181 P182
P180
N1
S-36PN1E5A x2
U-71PEY1E5
P190
S-60PN1E5A
U-60PEY1E5
S-60PN1E5A x2
U-125PEY1E5
S-50PN1E5A x2
U-100PEY1E5
S-71PN1E5A
U-71PEY1E5
S-100PN1E5A
U-100PEY1E5
S-125PN1E5A
U-125PEY1E5
P191 P192 P196P194 P195
P193
Y2
S-36PY2E5A x2
U-71PEY1E5
P203
S-50PY2E5A x2
U-100PEY1E5
P204
T2
S-36PT2E5A x2
U-71PEY1E5
P154
S-60PT2E5A
U-60PEY1E5
S-60PT2E5A x2
U-125PEY1E5
S-50PT2E5A x2
U-100PEY1E5
S-71PT2E5A
U-71PEY1E5
S-100PK1E5A
U-100PEY1E5
S-125PT2E5A
U-125PEY1E5
P155 P156 P160P158
P172
P157
K1
S-36PK1E5A x2
U-71PEY1E5
P167
S-60PK1E5A
U-60PEY1E5
S-60PK1E5A x2
U-125PEY1E5
S-50PK1E5A x2
U-100PEY1E5
S-71PK1E5A
U-71PEY1E5
P168 P169 P171
P170
S-100PT2E5A
U-100PEY1E5
P159
S-100PT2E5A
U-100PEY1E8
P164
SM830231-02Single欧州.indbSec1:viiSM830231-02Single欧州.indbSec1:vii 2014/09/1117:38:532014/09/1117:38:53

1-1
1
1. SPECIFICATIONS
1-1. ...................................................................................................
1-21. 4-Way Cassette Type (U1)
PE1
...............................................................................................................
1-2
2. Ceiling Type (T2) 1-28
3. Wall Mounted Type (K1) 1-54
1-764. Low Silhouette Ducted Type (F1)
5. Ducted Type (N1)
..............................................................................................................................
...................................................................................................................
.....................................................................................................
............................................................................................................................. 1-102
6. 4-Way Cassette 60 x 60 Type (Y2) .................................................................................................. 1-128
1-1411. 4-Way Cassette Type (U1)
PEY1
...............................................................................................................
1-206
1-216
1-2.
Unit Specifications
Dimensional Data .....................................................................................................
(A) Indoor Units ....................................................................................................................................
(B) Outdoor Units ..................................................................................................................................
1-3.
1-4.
1-5.
1-6.
1-7. 1-250
1-8.
1-9.
1-10. 1-267
1-11.
Refrigerant Flow Diagram
Operating Range
Capacity Correction Graph According to Temperature Condition
Noise Criterion Curves
Indoor Fan Performance
Airflow Distance Chart
Fresh Air Intake
Electrical Wiring
Installation Instructions
.......................................................................................
......................................................................................................
......................
............................................................................................
..........................................................................................
............................................................................................
........................................................................................................
.......................................................................................................
..........................................................................................
1-219
1-206
1-222
1-223
1-234
1-251
1-262
1-273
1. 4-Way Cassette Type (U1) ..............................................................................................................
.............................................................................................................................
...........................
1-342
1-354
1-273
1-273
1-322
......................................................................................................................................Outdoor Unit
1-342......................................................................................................................................Indoor Unit
2. Ceiling Type (T2) 1-154
3. Wall Mounted Type (K1) 1-167
1-1774. Low Silhouette Ducted Type (F1)
5. Ducted Type (N1)
U-50PE1E5, U-60PEY1E5, U-71PEY1E5.......................................................................................
U-60PE1E5A ~ U-140PE1E5A, U-71PE1E8A ~ U-140PE1E8A
U-100PEY1E5, U-125PEY1E5, U-100PEY1E8, U-125PEY1E8, U-140PEY1E8
..............................................................................................................................
...................................................................................................................
.....................................................................................................
............................................................................................................................. 1-190
6. 4-Way Cassette 60 x 60 Type (Y2) .................................................................................................. 1-203
3. Wall Mounted Type (K1)
4. Low Silhouette Ducted Type (F1)
5. Ducted Type (N1)
...................................................................................................................
.....................................................................................................
................................................................................................
................................................................................................
..............................................................................................................................
1-360
1-369
1-381
6. 4-Way Cassette 60 x 60 Type (Y2) ................................................................................................... 1-393
1. Cooling Capacity Performance Data 1-405
1-4412. Heating Capacity Performance Data
1-13. 1-405
1-14. 1-464
1-4011-12.
Capacity Table ..........................................................................................................
Product Fiche ...........................................................................................................
How to select AHU system ......................................................................................
2. Ceiling Type (T2)
SM830231-02Single欧州.indb1SM830231-02Single欧州.indb1 2014/09/1913:20:042014/09/1913:20:04

1-128
1Simultaneous (Twin) -Type
1-1. Unit Specifications
PE1
6. 4-Way Cassette 60×60 Type S-36PY2E5A×2 / U-71PE1E5A
INDOOR MODEL S-36PY2E5A ×2
PANEL MODEL (CZ-KPY3A / CZ-KPY3B) ×2
OUTDOOR MODEL U-71PE1E5A
Branch pipe MODEL CZ-P155BK1
PERFORMANCE TEST CONDITION ISO5151 / EN14511 / EN14825 / EN12102
POWER SUPPLY ø, Hz 1ø 50Hz 1ø 50Hz
V 220 230 240 220 230 240 Min Max
C
O
O
L
I
N
G
CAPACITY kW 7.1 7.1 7.1 2.5 8.0
BTU/h 24200 24200 24200 8500 27300
CURRENT A 0.30 x 2 9.60 9.30 9.00 - -
INPUT POWER W 40 x 2 1.985k 1.985k 1.985k - -
TOTAL W - 2.065k 2.065k 2.065k 450 2.650k
ANNUAL CONSUMPTION TOTAL kWh *4 - - - - 1032.5 - - -
EER/EER CLASS
TOTAL(W/W)*5/("A"~"G") - - - 3.44 3.44/A 3.44 5.56 3.02
Erp
*6
Pdsign kW - - - - 7.1 -
SEER (W/W) - - - - 6.2 -
Annual consumption kWh - - - - 401 -
Class - - - - A++ -
POWER FACTOR % - - - 94 93 92
NOISE INDOOR
(H/M/L)
dB-A 36/32/26(31)*7
Power Level dB 51/47/41(46)*7
NOISE OUTDOOR
(H/L)
dB-A 48/-
Power Level dB 65/-
H
E
A
T
I
N
G
CAPACITY kW 8.0 8.0 8.0 2.0 9.0
BTU/h 27300 27300 27300 6800 30700
CURRENT A 0.30 x 2 10.0 9.70 9.40 - -
INPUT POWER W 35 x 2 2.080k 2.080k 2.080k - -
TOTAL W - 2.150k 2.150k 2.150k 400 2.900k
COP/COP CLASS
TOTAL(W/W)*5/("A"~"G") - - - 3.72 3.72/A 3.72 5.00 3.10
Erp
*6
Pdsign kW - - - - 7.1 -
Tbivalen °C - - - - -7 -
SCOP (W/W) - - - - 3.8 -
Annual consumption kWh - - - - 2616 -
Class - - - - A -
POWER FACTOR % - - - 95 93 92
NOISE INDOOR
(H/M/L)
dB-A 36/32/26(31)*7 -
Power Level dB 51/47/41(46)*7 -
NOISE OUTDOOR
(H/L)
dB-A - 50/-
Power Level dB - 67/-
EXTRA LOW TEMP Total CAPACITY(kW)/INPUT POWER(W)/COP -
MAX CURRENT(A)/MAX INPUT POWER(W) 0.35/50 x 2 18.0/3.80k 18.0/3.93k 18.0/4.06k
STARTING CURRENT(A)/COMP OUTPUT(W) - - - 10.0/2.0k 9.70/2.0k 9.40/2.0k
NETWORK IMPEDANCE (ΩMAX.) - -
FM OUTPUT (W) 40 x 2 90
MOISTURE REMOVAL VOLUME L/h(Pt/h) 4.2 (2.1×2) (8.8) -
I/D AIR
FLOW
COOL m3/min (ft3/min)
9.7×2/8.0×2/6.0×2*7 (343)×2/(283)×2/(212)×2
HEAT m3/min (ft3/min) 9.9×2/8.2×2/6.0×2*7 (350)×2/(290)×2/(212)×2
O/D AIR
FLOW
COOL m3/min (ft3/min) 60 (2119)
HEAT m3/min (ft3/min) 60 (2119)
REFRIGERANT TYPE, AMOUNT g(oz) R410A 2.35k (82.9)
P
R
O
D
I
M
HEIGHT : H mm(inch) 260<265 + 23> (10-1/4) 996 (39-7/32)
WIDTH : W mm(inch) 575<583> (22-21/32) 940 (37-1/32)
DEPTH : D mm(inch) 575<583> (22-21/32) 340 (13-13/32)
Panel : H×W×D mm 3A:31 × 700 × 700, 3B:31 × 625 × 625 -
P
A
C
D
I
M
HEIGHT : H mm 345 (13-19/32) 1136
WIDTH : W mm 691 (27-7/32) 1055
DEPTH : D mm 691 (27-7/32) 485
MASS
(NET) kg(lb) 18 (40) 69 (152)
(GROSS) kg(lb) 23 (51) 77 (170)
Panel : (NET) kg(lb) 2.4 (5.3) -
LAYERS LIMIT (actually) 11 (12) 2 (3)
Operation
Condition
Cool (DBT) 18°C ~ 32°C -15°C ~ 46°C
Heat (DBT) 16°C ~ 30°C -20°C ~ 24°C
P
I
P
I
N
G
PIPE DIAMETER mm (inch) (Liquid)ø6.35(1/4) (Gas)ø12.7(1/2) (Liquid) ø 9.52(3/8) (Gas) ø 15.88(5/8)
CONNECT METHOD, STD LENGTH m (ft) fl ared type, 5.0 (16.4) fl ared type, 5.0 (16.4)
PIPE LENGTH RANGE m (ft) 5 ~ 50 (16.4 ~ 164.0)
I/D&O/D HEIGHT DIFFERENCE m (ft) 15(OD located lower)/30(OD located higher) (49.2/98.4)
ADD GAS AMOUNT
g
/m (oz/ft) 50 (0.538)
PIPE LENGTH FOR ADDITIONAL GAS m (ft) 30 (98.4)
*1: In case it is necessary to indicate the air flow volume in (l/s), the value in (m3/min.) shall be multiplied by 16.7 and rounded down the decimal point.
*2: If the EUROVENT Certified models can be operated under the "extra-low" temperature condition, -7°C dry bulb and -8°C wet-bulb temperatures with rated voltage 230V
shall be used.
*3: Network Impedance shall be applicable for EUROPE and CHINA models.
*4: The annual consumption is calculated by multiplying the input power at 230V(400V) by an average of 500 hours per year in cooling mode.
*5: EER and COP classification is at 230V(400V) only in accordance with EU directive 2002/31/EC.
*6: SEER and SCOP classification is at 230V(400V) only in accordance with EN-14825. For heating, SCOP indicates the value of only Average heating season, Other fiche
data indicates in an attached sheet.
*7: Noise and air flow rate of L are indicated by the values at FAN mode. ( ):Normal operation Cooling/Heating noise value. Normal operation Cooling/Heating air flow rate are
7.6 (m3/min).
SM830231-02Single欧州.indb128SM830231-02Single欧州.indb128 2014/09/1913:21:082014/09/1913:21:08

1-129
1
Simultaneous (Triple) -Type
1-1. Unit Specifications
PE1
6. 4-Way Cassette 60×60 Type S-36PY2E5A×3 / U-100PE1E5A
INDOOR MODEL S-36PY2E5A ×3
PANEL MODEL (CZ-KPY3A / CZ-KPY3B) ×3
OUTDOOR MODEL U-100PE1E5A
Branch pipe MODEL CZ-P3HPC2BM
PERFORMANCE TEST CONDITION ISO5151 / EN14511 / EN14825 / EN12102
POWER SUPPLY ø, Hz 1ø 50Hz 1ø 50Hz
V 220 230 240 220 230 240 Min Max
C
O
O
L
I
N
G
CAPACITY kW 10.0 10.0 10.0 3.3 12.5
BTU/h 34100 34100 34100 11300 42700
CURRENT A 0.30 × 3 12.2 11.8 11.3 - -
INPUT POWER W 40 × 3 2.560k 2.560k 2.560k - -
TOTAL W - 2.680k 2.680k 2.680k 840 3.700k
ANNUAL CONSUMPTION TOTAL kWh *4----1340 - - -
EER/EER CLASS
TOTAL(W/W)*5/("A"~"G") - - - 3.73 3.73/A 3.73 3.93 3.38
Erp
*6
Pdsign kW ----10.0 -
SEER (W/W) ----6.5-
Annual consumption kWh----538-
Class ----A++-
POWER FACTOR % - - - 95 94 94
NOISE INDOOR
(H/M/L)
dB-A 36/32/26(31)*7
Power Level dB 51/47/41(46)*7
NOISE OUTDOOR
(H/L)
dB-A 52/-
Power Level dB 69/-
H
E
A
T
I
N
G
CAPACITY kW 11.2 11.2 11.2 4.1 14.0
BTU/h 38200 38200 38200 14000 47800
CURRENT A 0.30 × 3 13.4 13.0 12.6 - -
INPUT POWER W 35 × 3 2.825k 2.825k 2.825k - -
TOTAL W - 2.930k 2.930k 2.930k 900 4.400k
COP/COP CLASS
TOTAL(W/W)*5/("A"~"G") - - - 3.82 3.82/A 3.82 4.56 3.18
Erp
*6
Pdsign kW ----9.5-
Tbivalen °C -----10-
SCOP (W/W) ----3.8-
Annual consumption kWh----3500 -
Class ----A-
POWER FACTOR % - - - 96 94 93
NOISE INDOOR
(H/M/L)
dB-A 36/32/26(31)*7 -
Power Level dB 51/47/41(46)*7 -
NOISE OUTDOOR
(H/L)
dB-A - 52/-
Power Level dB - 69/-
EXTRA LOW TEMP Total CAPACITY(kW)/INPUT POWER(W)/COP -
MAX CURRENT(A)/MAX INPUT POWER(W) 0.35/50 × 3 25.0/5.35k 25.0/5.55k 25.0/5.75k
STARTING CURRENT(A)/COMP OUTPUT(W) - - - 13.4/3.0k 13.0/3.0k 12.6/3.0k
NETWORK IMPEDANCE (ΩMAX.) - -
FM OUTPUT (W) 40 × 3 90 × 2
MOISTURE REMOVAL VOLUME L/h(Pt/h) 6.0 (2.0×3) (12.6) -
I/D AIR
FLOW
COOL m3/min (ft3/min)
9.7 × 3/8.0 × 3/6.0 × 3*7 (343) × 3/(283) × 3/(212) × 3
HEAT m3/min (ft3/min) 9.9 × 3/8.2 × 3/6.0 × 3*7 (350) × 3/(290) × 3/(212) × 3
O/D AIR
FLOW
COOL m3/min (ft3/min) 110 (3885)
HEAT m3/min (ft3/min) 95 (3355)
REFRIGERANT TYPE, AMOUNT g(oz) R410A 3.40k (119.9)
P
R
O
D
I
M
HEIGHT : H mm(inch) 260<265 + 23> (10-1/4) 1416 (55-3/4)
WIDTH : W mm(inch) 575<583> (22-21/32) 940 (37-1/32)
DEPTH : D mm(inch) 575<583> (22-21/32) 340 (13-13/32)
Panel : H×W×D mm 3A:31 × 700 × 700, 3B:31 × 625 × 625 -
P
A
C
D
I
M
HEIGHT : H mm 345 (13-19/32) 1556
WIDTH : W mm 691 (27-7/32) 1055
DEPTH : D mm 691 (27-7/32) 485
MASS
(NET) kg(lb) 18 (40) 98 (216)
(GROSS) kg(lb) 23 (51) 108 (238)
Panel : (NET) kg(lb) 2.4 (5.3) -
LAYERS LIMIT (actually) 11 (12) 1 (2)
Operation
Condition
Cool (DBT) 18°C ~ 32°C -15°C ~ 46°C
Heat (DBT) 16°C ~ 30°C -20°C ~ 24°C
P
I
P
I
N
G
PIPE DIAMETER mm (inch) (Liquid)ø6.35(1/4) (Gas)ø12.7(1/2) (Liquid) ø 9.52(3/8) (Gas) ø 15.88(5/8)
CONNECT METHOD, STD LENGTH m (ft) fl ared type, 5.0 (16.4) fl ared type, 5.0 (16.4)
PIPE LENGTH RANGE m (ft) 5 ~ 75 (16.4 ~ 246.1)
I/D&O/D HEIGHT DIFFERENCE m (ft) 15(OD located lower)/30(OD located higher) (49.2/98.4)
ADD GAS AMOUNT
g
/m (oz/ft) 50 (0.538)
PIPE LENGTH FOR ADDITIONAL GAS m (ft) 20 (65.6)
*1: In case it is necessary to indicate the air flow volume in (l/s), the value in (m3/min.) shall be multiplied by 16.7 and rounded down the decimal point.
*2: If the EUROVENT Certified models can be operated under the "extra-low" temperature condition, -7°C dry bulb and -8°C wet-bulb temperatures with rated voltage 230V
shall be used.
*3: Network Impedance shall be applicable for EUROPE and CHINA models.
*4: The annual consumption is calculated by multiplying the input power at 230V(400V) by an average of 500 hours per year in cooling mode.
*5: EER and COP classification is at 230V(400V) only in accordance with EU directive 2002/31/EC.
*6: SEER and SCOP classification is at 230V(400V) only in accordance with EN-14825. For heating, SCOP indicates the value of only Average heating season, Other fiche
data indicates in an attached sheet.
*7: Noise and air flow rate of L are indicated by the values at FAN mode. ( ):Normal operation Cooling/Heating noise value. Normal operation Cooling/Heating air flow rate are
7.6 (m3/min).
SM830231-02Single欧州.indb129SM830231-02Single欧州.indb129 2014/09/1913:21:082014/09/1913:21:08

1-130
1Simultaneous (Double-Twin) -Type
1-1. Unit Specifications
PE1
6. 4-Way Cassette 60×60 Type S-36PY2E5A×4 / U-125PE1E5A
INDOOR MODEL S-36PY2E5A ×4
PANEL MODEL (CZ-KPY3A / CZ-KPY3B) ×4
OUTDOOR MODEL U-125PE1E5A
Branch pipe MODEL CZ-P155BK1
PERFORMANCE TEST CONDITION ISO5151 / EN14511 / EN14825 / EN12102
POWER SUPPLY ø, Hz 1ø 50Hz 1ø 50Hz
V 220 230 240 220 230 240 Min Max
C
O
O
L
I
N
G
CAPACITY kW 12.5 12.5 12.5 3.3 14.0
BTU/h 42700 42700 42700 11300 47800
CURRENT A 0.30 × 4 17.5 16.9 16.4 - -
INPUT POWER W 40 × 4 3.680k 3.680k 3.680k - -
TOTAL W - 3.840k 3.840k 3.840k 840 4.600k
ANNUAL CONSUMPTION TOTAL kWh *4 - - - - 1920 - - -
EER/EER CLASS
TOTAL(W/W)*5/("A"~"G") - - - 3.26 3.26/A 3.26 3.93 3.04
Erp
*6
Pdsign kW - - - - - -
SEER (W/W) - - - - - -
Annual consumption kWh------
Class - - - - - -
POWER FACTOR % - - - 96 95 93
NOISE INDOOR
(H/M/L)
dB-A 36/32/26(31)*7
Power Level dB 51/47/41(46)*7
NOISE OUTDOOR
(H/L)
dB-A 53/-
Power Level dB 70/-
H
E
A
T
I
N
G
CAPACITY kW 14.0 14.0 14.0 4.1 16.0
BTU/h 47800 47800 47800 14000 54600
CURRENT A 0.30 × 4 17.9 17.3 16.8 - -
INPUT POWER W 35 × 4 3.750k 3.750k 3.750k - -
TOTAL W - 3.890k 3.890k 3.890k 900 5.200k
COP/COP CLASS
TOTAL(W/W)*5/("A"~"G") - - - 3.60 3.60/A 3.60 4.56 3.08
Erp
*6
Pdsign kW - - - - - -
Tbivalen °C - - - - - -
SCOP (W/W) - - - - - -
Annual consumption kWh------
Class - - - - - -
POWER FACTOR % - - - 95 94 93
NOISE INDOOR
(H/M/L)
dB-A 36/32/26(31)*7 -
Power Level dB 51/47/41(46)*7 -
NOISE OUTDOOR
(H/L)
dB-A - 53/-
Power Level dB - 70/-
EXTRA LOW TEMP Total CAPACITY(kW)/INPUT POWER(W)/COP -
MAX CURRENT(A)/MAX INPUT POWER(W) 0.35/50 × 4 28.0/6.00k 28.0/6.20k 28.0/6.40k
STARTING CURRENT(A)/COMP OUTPUT(W) - - - 17.9/3.0k 17.3/3.0k 16.8/3.0k
NETWORK IMPEDANCE (ΩMAX.) - -
FM OUTPUT (W) 40 × 4 90 × 2
MOISTURE REMOVAL VOLUME L/h(Pt/h) 7.9 (1.975×4) (16.6) -
I/D AIR
FLOW
COOL m3/min (ft3/min)
9.7×4/8.0×4/6.0×4*7 (343)×4/(283)×4/(212)×4
HEAT m3/min (ft3/min) 9.9×4/8.2×4/6.0×4*7 (350)×4/(290)×4/(212)×4
O/D AIR
FLOW
COOL m3/min (ft3/min) 130 (4591)
HEAT m3/min (ft3/min) 110 (3885)
REFRIGERANT TYPE, AMOUNT g(oz) R410A 3.40k (119.9)
P
R
O
D
I
M
HEIGHT : H mm(inch) 260<265 + 23> (10-1/4) 1416 (55-3/4)
WIDTH : W mm(inch) 575<583> (22-21/32) 940 (37-1/32)
DEPTH : D mm(inch) 575<583> (22-21/32) 340 (13-13/32)
Panel : H×W×D mm 3A:31 × 700 × 700, 3B:31 × 625 × 625 -
P
A
C
D
I
M
HEIGHT : H mm 345 (13-19/32) 1556
WIDTH : W mm 691 (27-7/32) 1055
DEPTH : D mm 691 (27-7/32) 485
MASS
(NET) kg(lb) 18 (40) 98 (216)
(GROSS) kg(lb) 23 (51) 108 (238)
Panel : (NET) kg(lb) 2.4 (5.3) -
LAYERS LIMIT (actually) 11 (12) 1(2)
Operation
Condition
Cool (DBT) 18°C ~ 32°C -15°C ~ 46°C
Heat (DBT) 16°C ~ 30°C -20°C ~ 24°C
P
I
P
I
N
G
PIPE DIAMETER mm (inch) (Liquid)ø6.35(1/4) (Gas)ø12.7(1/2) (Liquid) ø 9.52(3/8) (Gas) ø 15.88(5/8)
CONNECT METHOD, STD LENGTH m (ft) fl ared type, 5.0 (16.4) fl ared type, 5.0 (16.4)
PIPE LENGTH RANGE m (ft) 5 ~ 75 (16.4 ~ 246.1)
I/D&O/D HEIGHT DIFFERENCE m (ft) 15(OD located lower)/30(OD located higher) (49.2/98.4)
ADD GAS AMOUNT
g
/m (oz/ft) 50 (0.538)
PIPE LENGTH FOR ADDITIONAL GAS m (ft) 20 (65.6)
*1: In case it is necessary to indicate the air flow volume in (l/s), the value in (m3/min.) shall be multiplied by 16.7 and rounded down the decimal point.
*2: If the EUROVENT Certified models can be operated under the "extra-low" temperature condition, -7°C dry bulb and -8°C wet-bulb temperatures with rated voltage 230V
shall be used.
*3: Network Impedance shall be applicable for EUROPE and CHINA models.
*4: The annual consumption is calculated by multiplying the input power at 230V(400V) by an average of 500 hours per year in cooling mode.
*5: EER and COP classification is at 230V(400V) only in accordance with EU directive 2002/31/EC.
*6: SEER and SCOP classification is at 230V(400V) only in accordance with EN-14825. For heating, SCOP indicates the value of only Average heating season, Other fiche
data indicates in an attached sheet.
*7: Noise and air flow rate of L are indicated by the values at FAN mode. ( ):Normal operation Cooling/Heating noise value. Normal operation Cooling/Heating air flow rate are
7.6 (m3/min).
SM830231-02Single欧州.indb130SM830231-02Single欧州.indb130 2014/09/1913:21:092014/09/1913:21:09

1-131
1
Simultaneous (Triple) -Type
1-1. Unit Specifications
PE1
6. 4-Way Cassette 60×60 Type S-45PY2E5A×3 / U-125PE1E5A
INDOOR MODEL S-45PY2E5A ×3
PANEL MODEL (CZ-KPY3A / CZ-KPY3B) ×3
OUTDOOR MODEL U-125PE1E5A
Branch pipe MODEL CZ-P3HPC2BM
PERFORMANCE TEST CONDITION ISO5151 / EN14511 / EN14825 / EN12102
POWER SUPPLY ø, Hz 1ø 50Hz 1ø 50Hz
V 220 230 240 220 230 240 Min Max
C
O
O
L
I
N
G
CAPACITY kW 12.5 12.5 12.5 3.3 14.0
BTU/h 42700 42700 42700 11300 47800
CURRENT A 0.32 × 3 17.5 16.9 16.4 - -
INPUT POWER W 40 × 3 3.680k 3.680k 3.680k - -
TOTAL W - 3.800k 3.800k 3.800k 840 4.600k
ANNUAL CONSUMPTION TOTAL kWh *4 - - - - 1900 - - -
EER/EER CLASS
TOTAL(W/W)*5/("A"~"G") - - - 3.29 3.29/A 3.29 3.93 3.04
Erp
*6
Pdsign kW - - - - - -
SEER (W/W) - - - - - -
Annual consumption kWh------
Class - - - - - -
POWER FACTOR % - - - 96 95 93
NOISE INDOOR
(H/M/L)
dB-A 38/34/28(32)*7
Power Level dB 53/49/43(47)*7
NOISE OUTDOOR
(H/L)
dB-A 53/-
Power Level dB 70/-
H
E
A
T
I
N
G
CAPACITY kW 14.0 14.0 14.0 4.1 16.0
BTU/h 47800 47800 47800 14000 54600
CURRENT A 0.30 × 3 17.9 17.3 16.8 - -
INPUT POWER W 35 × 3 3.750k 3.750k 3.750k - -
TOTAL W - 3.860k 3.860k 3.860k 900 5.200k
COP/COP CLASS
TOTAL(W/W)*5/("A"~"G") - - - 3.63 3.63/A 3.63 4.56 3.08
Erp
*6
Pdsign kW - - - - - -
Tbivalen °C - - - - - -
SCOP (W/W) - - - - - -
Annual consumption kWh------
Class - - - - - -
POWER FACTOR % - - - 95 94 93
NOISE INDOOR
(H/M/L)
dB-A 38/34/28(32)*7 -
Power Level dB 53/49/43(47)*7 -
NOISE OUTDOOR
(H/L)
dB-A - 53/-
Power Level dB - 70/-
EXTRA LOW TEMP Total CAPACITY(kW)/INPUT POWER(W)/COP -
MAX CURRENT(A)/MAX INPUT POWER(W) 0.37/50 × 3 28.0/6.00k 28.0/6.20k 28.0/6.40k
STARTING CURRENT(A)/COMP OUTPUT(W) - - - 17.9/3.0k 17.3/3.0k 16.8/3.0k
NETWORK IMPEDANCE (ΩMAX.) - -
FM OUTPUT (W) 40 × 3 90 × 2
MOISTURE REMOVAL VOLUME L/h(Pt/h) 7.9 (2.63×3) (16.6) -
I/D AIR
FLOW
COOL m3/min (ft3/min)
10.0×3/8.8×3/7.0 ×3*7 (353)×3/(311)×3/(247)×3
HEAT m3/min (ft3/min) 10.3×3/9.2×3/7.0 ×3*7 (364)×3/(325)×3/(247)×3
O/D AIR
FLOW
COOL m3/min (ft3/min) 130 (4591)
HEAT m3/min (ft3/min) 110 (3885)
REFRIGERANT TYPE, AMOUNT g(oz) R410A 3.40k (119.9)
P
R
O
D
I
M
HEIGHT : H mm(inch) 260<265 + 23> (10-1/4) 1416 (55-3/4)
WIDTH : W mm(inch) 575<583> (22-21/32) 940 (37-1/32)
DEPTH : D mm(inch) 575<583> (22-21/32) 340 (13-13/32)
Panel : H×W×D mm 3A:31 × 700 × 700, 3B:31 × 625 × 625 -
P
A
C
D
I
M
HEIGHT : H mm 345 (13-19/32) 1556
WIDTH : W mm 691 (27-7/32) 1055
DEPTH : D mm 691 (27-7/32) 485
MASS
(NET) kg(lb) 18 (40) 98 (216)
(GROSS) kg(lb) 23 (51) 108 (238)
Panel : (NET) kg(lb) 2.4 (5.3) -
LAYERS LIMIT (actually) 11 (12) 1 (2)
Operation
Condition
Cool (DBT) 18°C ~ 32°C -15°C ~ 46°C
Heat (DBT) 16°C ~ 30°C -20°C ~ 24°C
P
I
P
I
N
G
PIPE DIAMETER mm (inch) (Liquid)ø6.35(1/4) (Gas)ø12.7(1/2) (Liquid) ø 9.52(3/8) (Gas) ø 15.88(5/8)
CONNECT METHOD, STD LENGTH m (ft) fl ared type, 5.0 (16.4) fl ared type, 5.0 (16.4)
PIPE LENGTH RANGE m (ft) 5 ~ 75 (16.4 ~ 246.1)
I/D&O/D HEIGHT DIFFERENCE m (ft) 15(OD located lower)/30(OD located higher) (49.2/98.4)
ADD GAS AMOUNT
g
/m (oz/ft) 50 (0.538)
PIPE LENGTH FOR ADDITIONAL GAS m (ft) 20 (65.6)
*1: In case it is necessary to indicate the air flow volume in (l/s), the value in (m3/min.) shall be multiplied by 16.7 and rounded down the decimal point.
*2: If the EUROVENT Certified models can be operated under the "extra-low" temperature condition, -7°C dry bulb and -8°C wet-bulb temperatures with rated voltage 230V
shall be used.
*3: Network Impedance shall be applicable for EUROPE and CHINA models.
*4: The annual consumption is calculated by multiplying the input power at 230V(400V) by an average of 500 hours per year in cooling mode.
*5: EER and COP classification is at 230V(400V) only in accordance with EU directive 2002/31/EC.
*6: SEER and SCOP classification is at 230V(400V) only in accordance with EN-14825. For heating, SCOP indicates the value of only Average heating season, Other fiche
data indicates in an attached sheet.
*7: Noise and air flow rate of L are indicated by the values at FAN mode. ( ):Normal operation Cooling/Heating noise value. Normal operation Cooling/Heating air flow rate are
8.2 (m3/min).
SM830231-02Single欧州.indb131SM830231-02Single欧州.indb131 2014/09/1913:21:092014/09/1913:21:09

1-132
1Single -Type
1-1. Unit Specifications
PE1
6. 4-Way Cassette 60×60 Type S-50PY2E5A / U-50PE1E5
INDOOR MODEL S-50PY2E5A
PANEL MODEL CZ-KPY3A / CZ-KPY3B
OUTDOOR MODEL U-50PE1E5
Branch pipe MODEL -
PERFORMANCE TEST CONDITION ISO5151 / EN14511 / EN14825 / EN12102
POWER SUPPLY ø, Hz 1ø 50Hz 1ø 50Hz
V 220 230 240 220 230 240 Min Max
C
O
O
L
I
N
G
CAPACITY kW 5.0 5.0 5.0 1.5 5.6
BTU/h 17100 17100 17100 5100 19100
CURRENT A 0.35 7.80 7.50 7.20 - -
INPUT POWER W 45 1.595k 1.595k 1.595k - -
TOTAL W - 1.640k 1.640k 1.640k 260 2.450k
ANNUAL CONSUMPTION TOTAL kWh *4 - - - 820 820 820 - -
EER/EER CLASS
TOTAL(W/W)*5/("A"~"G") - - - 3.04 3.04/B 3.04 5.77 2.29
Erp
*6
Pdsign kW - - - - 5.0 -
SEER (W/W) - - - - 5.9 -
Annual consumption kWh - - - - 297 -
Class - - - - A+ -
POWER FACTOR % - - - 93 92 92
NOISE INDOOR
(H/M/L)
dB-A 40/37/33
Power Level dB 55/52/48
NOISE OUTDOOR
(H/L)
dB-A 46/-
Power Level dB 65/-
H
E
A
T
I
N
G
CAPACITY kW 5.6 5.6 5.6 1.5 6.3
BTU/h 19100 19100 19100 5100 21500
CURRENT A 0.35 8.60 8.20 7.90 - -
INPUT POWER W 40 1.750k 1.750k 1.750k - -
TOTAL W - 1.790k 1.790k 1.790k 220 2.570k
COP/COP CLASS
TOTAL(W/W)*5/("A"~"G") - - - 3.12 3.12/D 3.12 6.82 2.45
Erp
*6
Pdsign kW - - - - 4.0 -
Tbivalen °C - - - - -10 -
SCOP (W/W) - - - - 3.8 -
Annual consumption kWh - - - - 1474 -
Class - - - - A -
POWER FACTOR % - - - 92 93 92
NOISE INDOOR
(H/M/L)
dB-A 40/37/33 -
Power Level dB 55/52/48 -
NOISE OUTDOOR
(H/L)
dB-A - 50/-
Power Level dB - 69/-
EXTRA LOW TEMP Total CAPACITY(kW)/INPUT POWER(W)/COP -
MAX CURRENT(A)/MAX INPUT POWER(W) 0.40/55 12.0/2.46k 12.0/2.57k 12.0/2.68k
STARTING CURRENT(A)/COMP OUTPUT(W) - - - 8.60/0.9k 8.20/0.9k 7.90/0.9k
NETWORK IMPEDANCE (ΩMAX.) - -
FM OUTPUT (W) 40 90
MOISTURE REMOVAL VOLUME L/h(Pt/h) 2.8 (5.9) -
I/D AIR
FLOW
COOL m3/min (ft3/min) 11.1 / 9.8 / 8.5 (392) / (346) / (300)
HEAT m3/min (ft3/min) 11.1 / 9.8 / 8.7 (392) / (346) / (307)
O/D AIR
FLOW
COOL m3/min (ft3/min) 30 (1059)
HEAT m3/min (ft3/min) 35 (1236)
REFRIGERANT TYPE, AMOUNT g(oz) R410A 1.65k (58.2)
P
R
O
D
I
M
HEIGHT : H mm(inch) 260<265 + 23> (10-1/4) 569 (22-13/32)
WIDTH : W mm(inch) 575<583> (22-21/32) 790 (31-7/64)
DEPTH : D mm(inch) 575<583> (22-21/32) 285 (11-7/32)
Panel : H×W×D mm 3A:31 × 700 × 700, 3B:31 × 625 × 625 -
P
A
C
D
I
M
HEIGHT : H mm 345 (13-19/32) 645
WIDTH : W mm 691 (27-7/32) 921
DEPTH : D mm 691 (27-7/32) 386
MASS
(NET) kg(lb) 18 (40) 42 (93)
(GROSS) kg(lb) 23 (51) 46 (101)
Panel : (NET) kg(lb) 2.4 (5.3) -
LAYERS LIMIT (actually) 11(12) 4(5)
Operation
Condition
Cool (DBT) 18°C ~ 32°C -15°C ~ 46°C
Heat (DBT) 16°C ~ 30°C -20°C ~ 24°C
P
I
P
I
N
G
PIPE DIAMETER mm (inch) (Liquid)ø6.35(1/4) (Gas)ø12.7(1/2) (Liquid)ø6.35(1/4) (Gas)ø12.7(1/2)
CONNECT METHOD, STD LENGTH m (ft) fl ared type, 5.0 (16.4) fl ared type, 5.0 (16.4)
PIPE LENGTH RANGE m (ft) 5 ~ 40 (16.4 ~ 131.2)
I/D&O/D HEIGHT DIFFERENCE m (ft) 15(OD located lower)/30(OD located higher) (49.2/98.4)
ADD GAS AMOUNT
g
/m (oz/ft) 20 (0.215)
PIPE LENGTH FOR ADDITIONAL GAS m (ft) 30 (98.4)
*1: In case it is necessary to indicate the air flow volume in (l/s), the value in (m3/min.) shall be multiplied by 16.7 and rounded down the decimal point.
*2: If the EUROVENT Certified models can be operated under the "extra-low" temperature condition, -7°C dry bulb and -8°C wet-bulb temperatures with rated voltage 230V
shall be used.
*3: Network Impedance shall be applicable for EUROPE and CHINA models.
*4: The annual consumption is calculated by multiplying the input power at 230V(400V) by an average of 500 hours per year in cooling mode.
*5: EER and COP classification is at 230V(400V) only in accordance with EU directive 2002/31/EC.
*6: SEER and SCOP classification is at 230V(400V) only in accordance with EN-14825. For heating, SCOP indicates the value of only Average heating season, Other fiche
data indicates in an attached sheet.
SM830231-02Single欧州.indb132SM830231-02Single欧州.indb132 2014/09/1913:21:092014/09/1913:21:09

1-133
1
Simultaneous (Twin) -Type
1-1. Unit Specifications
PE1
6. 4-Way Cassette 60×60 Type S-50PY2E5A×2 / U-100PE1E5A
INDOOR MODEL S-50PY2E5A ×2
PANEL MODEL (CZ-KPY3A / CZ-KPY3B) ×2
OUTDOOR MODEL U-100PE1E5A
Branch pipe MODEL CZ-P155BK1
PERFORMANCE TEST CONDITION ISO5151 / EN14511 / EN14825 / EN12102
POWER SUPPLY ø, Hz 1ø 50Hz 1ø 50Hz
V 220 230 240 220 230 240 Min Max
C
O
O
L
I
N
G
CAPACITY kW 10.0 10.0 10.0 3.3 12.5
BTU/h 34100 34100 34100 11300 42700
CURRENT A 0.35 × 2 12.2 11.8 11.3 - -
INPUT POWER W 45 × 2 2.560k 2.560k 2.560k - -
TOTAL W - 2.650k 2.650k 2.650k 840 3.700k
ANNUAL CONSUMPTION TOTAL kWh *4 - - - - 1325 - - -
EER/EER CLASS
TOTAL(W/W)*5/("A"~"G") - - - 3.77 3.77/A 3.77 3.93 3.38
Erp
*6
Pdsign kW - - - - 10.0 -
SEER (W/W) - - - - 6.5 -
Annual consumption kWh - - - - 538 -
Class - - - - A++ -
POWER FACTOR % - - - 95 94 94
NOISE INDOOR
(H/M/L)
dB-A 40/37/33
Power Level dB 55/52/48
NOISE OUTDOOR
(H/L)
dB-A 52/-
Power Level dB 69/-
H
E
A
T
I
N
G
CAPACITY kW 11.2 11.2 11.2 4.1 14.0
BTU/h 38200 38200 38200 14000 47800
CURRENT A 0.35 × 2 13.4 13.0 12.6 - -
INPUT POWER W 40 × 2 2.825k 2.825k 2.825k - -
TOTAL W - 2.910k 2.910k 2.910k 900 4.400k
COP/COP CLASS
TOTAL(W/W)*5/("A"~"G") - - - 3.85 3.85/A 3.85 4.56 3.18
Erp
*6
Pdsign kW - - - - 9.5 -
Tbivalen °C - - - - -10 -
SCOP (W/W) - - - - 3.8 -
Annual consumption kWh - - - - 3500 -
Class - - - - A -
POWER FACTOR % - - - 96 94 93
NOISE INDOOR
(H/M/L)
dB-A 40/37/33 -
Power Level dB 55/52/48 -
NOISE OUTDOOR
(H/L)
dB-A - 52/-
Power Level dB - 69/-
EXTRA LOW TEMP Total CAPACITY(kW)/INPUT POWER(W)/COP -
MAX CURRENT(A)/MAX INPUT POWER(W) 0.40/55 × 2 25.0/5.35k 25.0/5.55k 25.0/5.75k
STARTING CURRENT(A)/COMP OUTPUT(W) - - - 13.4/3.0k 13.0/3.0k 12.6/3.0k
NETWORK IMPEDANCE (ΩMAX.) - -
FM OUTPUT (W) 40 × 2 90 × 2
MOISTURE REMOVAL VOLUME L/h(Pt/h) 6.0 (3.0×2) (12.6) -
I/D AIR
FLOW
COOL m3/min (ft3/min)
11.1×2/9.8×2/8.5×2 (392)×2/(346)×2/(300)×2
HEAT m3/min (ft3/min) 11.1×2/9.8×2/8.7×2 (392)×2/(346)×2/(307)×2
O/D AIR
FLOW
COOL m3/min (ft3/min) 110 (3885)
HEAT m3/min (ft3/min) 95 (3355)
REFRIGERANT TYPE, AMOUNT g(oz) R410A 3.40k (119.9)
P
R
O
D
I
M
HEIGHT : H mm(inch) 260<265 + 23> (10-1/4) 1416 (55-3/4)
WIDTH : W mm(inch) 575<583> (22-21/32) 940 (37-1/32)
DEPTH : D mm(inch) 575<583> (22-21/32) 340 (13-13/32)
Panel : H×W×D mm 3A:31 × 700 × 700, 3B:31 × 625 × 625 -
P
A
C
D
I
M
HEIGHT : H mm 345 (13-19/32) 1556
WIDTH : W mm 691 (27-7/32) 1055
DEPTH : D mm 691 (27-7/32) 485
MASS
(NET) kg(lb) 18 (40) 98 (216)
(GROSS) kg(lb) 23 (51) 108 (238)
Panel : (NET) kg(lb) 2.4 (5.3) -
LAYERS LIMIT (actually) 11 (12) 1 (2)
Operation
Condition
Cool (DBT) 18°C ~ 32°C -15°C ~ 46°C
Heat (DBT) 16°C ~ 30°C -20°C ~ 24°C
P
I
P
I
N
G
PIPE DIAMETER mm (inch) (Liquid)ø6.35(1/4) (Gas)ø12.7(1/2) (Liquid)ø9.52(3/8) (Gas)ø15.88(5/8)
CONNECT METHOD, STD LENGTH m (ft) fl ared type, 5.0 (16.4) fl ared type, 5.0 (16.4)
PIPE LENGTH RANGE m (ft) 5 ~ 75 (16.4 ~ 246.1)
I/D&O/D HEIGHT DIFFERENCE m (ft) 15(OD located lower)/30(OD located higher) (49.2/98.4)
ADD GAS AMOUNT
g
/m (oz/ft) 50 (0.538)
PIPE LENGTH FOR ADDITIONAL GAS m (ft) 30 (98.4)
*1: In case it is necessary to indicate the air flow volume in (l/s), the value in (m3/min.) shall be multiplied by 16.7 and rounded down the decimal point.
*2: If the EUROVENT Certified models can be operated under the "extra-low" temperature condition, -7°C dry bulb and -8°C wet-bulb temperatures with rated voltage 230V
shall be used.
*3: Network Impedance shall be applicable for EUROPE and CHINA models.
*4: The annual consumption is calculated by multiplying the input power at 230V(400V) by an average of 500 hours per year in cooling mode.
*5: EER and COP classification is at 230V(400V) only in accordance with EU directive 2002/31/EC.
*6: SEER and SCOP classification is at 230V(400V) only in accordance with EN-14825. For heating, SCOP indicates the value of only Average heating season, Other fiche
data indicates in an attached sheet.
SM830231-02Single欧州.indb133SM830231-02Single欧州.indb133 2014/09/1913:21:092014/09/1913:21:09

1-134
1Simultaneous (Triple) -Type
1-1. Unit Specifications
PE1
6. 4-Way Cassette 60×60 Type S-50PY2E5A×3 / U-140PE1E5A
INDOOR MODEL S-50PY2E5A ×3
PANEL MODEL (CZ-KPY3A / CZ-KPY3B) ×3
OUTDOOR MODEL U-140PE1E5A
Branch pipe MODEL CZ-P3HPC2BM
PERFORMANCE TEST CONDITION ISO5151 / EN14511 / EN14825 / EN12102
POWER SUPPLY ø, Hz 1ø 50Hz 1ø 50Hz
V 220 230 240 220 230 240 Min Max
C
O
O
L
I
N
G
CAPACITY kW 14.0 14.0 14.0 3.3 15.5
BTU/h 47800 47800 47800 11300 52900
CURRENT A 0.35 × 3 21.5 20.8 20.1 - -
INPUT POWER W 45 × 3 4.565k 4.565k 4.565k - -
TOTAL W - 4.700k 4.700k 4.700k 840 6.000k
ANNUAL CONSUMPTION TOTAL kWh *4 - - - - 2350 - - -
EER/EER CLASS
TOTAL(W/W)*5/("A"~"G") - - - 2.98 2.98/C 2.98 3.93 2.58
Erp
*6
Pdsign kW - -----
SEER (W/W) - -----
Annual consumption kWh------
Class - -----
POWER FACTOR % - - - 97 95 95
NOISE INDOOR
(H/M/L)
dB-A 40/37/33
Power Level dB 55/52/48
NOISE OUTDOOR
(H/L)
dB-A 54/-
Power Level dB 71/-
H
E
A
T
I
N
G
CAPACITY kW 16.0 16.0 16.0 4.1 18.0
BTU/h 54600 54600 54600 14000 61400
CURRENT A 0.35 × 3 22.2 21.4 20.8 - -
INPUT POWER W 40 × 3 4.700k 4.700k 4.700k - -
TOTAL W - 4.820k 4.820k 4.820k 900 5.900k
COP/COP CLASS
TOTAL(W/W)*5/("A"~"G") - - - 3.32 3.32/C 3.32 4.56 3.05
Erp
*6
Pdsign kW - -----
Tbivalen °C - -----
SCOP (W/W) - -----
Annual consumption kWh------
Class - -----
POWER FACTOR % - - - 96 95 94
NOISE INDOOR
(H/M/L)
dB-A 40/37/33 -
Power Level dB 55/52/48 -
NOISE OUTDOOR
(H/L)
dB-A - 55/-
Power Level dB - 71/-
EXTRA LOW TEMP Total CAPACITY(kW)/INPUT POWER(W)/COP -
MAX CURRENT(A)/MAX INPUT POWER(W) 0.40/55 × 3 30.0/6.45k 30.0/6.65k 30.0/6.85k
STARTING CURRENT(A)/COMP OUTPUT(W) - - - 22.2/3.0k 21.4/3.0k 20.8/3.0k
NETWORK IMPEDANCE (ΩMAX.) - -
FM OUTPUT (W) 40 × 3 90 × 2
MOISTURE REMOVAL VOLUME L/h(Pt/h) 9.0 (3.0×3) (18.9) -
I/D AIR
FLOW
COOL m3/min (ft3/min)
11.1×3/9.8×3/8.5×3 (392)×3/(346)×3/(300)×3
HEAT m3/min (ft3/min) 11.1×3/9.8×3/8.7×3 (392)×3/(346)×3/(307)×3
O/D AIR
FLOW
COOL m3/min (ft3/min) 135 (4767)
HEAT m3/min (ft3/min) 120 (4238)
REFRIGERANT TYPE, AMOUNT g(oz) R410A 3.40k (119.9)
P
R
O
D
I
M
HEIGHT : H mm(inch) 260<265 + 23> (10-1/4) 1416 (55-3/4)
WIDTH : W mm(inch) 575<583> (22-21/32) 940 (37-1/32)
DEPTH : D mm(inch) 575<583> (22-21/32) 340 (13-13/32)
Panel : H×W×D mm 3A:31 × 700 × 700, 3B:31 × 625 × 625 -
P
A
C
D
I
M
HEIGHT : H mm 345 (13-19/32) 1556
WIDTH : W mm 691 (27-7/32) 1055
DEPTH : D mm 691 (27-7/32) 485
MASS
(NET) kg(lb) 18 (40) 98 (216)
(GROSS) kg(lb) 23 (51) 108 (238)
Panel : (NET) kg(lb) 2.4 (5.3) -
LAYERS LIMIT (actually) 11 (12) 1 (2)
Operation
Condition
Cool (DBT) 18°C ~ 32°C -15°C ~ 46°C
Heat (DBT) 16°C ~ 30°C -20°C ~ 24°C
P
I
P
I
N
G
PIPE DIAMETER mm (inch) (Liquid)ø6.35(1/4) (Gas)ø12.7(1/2) (Liquid)ø9.52(3/8) (Gas)ø15.88(5/8)
CONNECT METHOD, STD LENGTH m (ft) fl ared type, 5.0 (16.4) fl ared type, 5.0 (16.4)
PIPE LENGTH RANGE m (ft) 5 ~ 75 (16.4 ~ 246.1)
I/D&O/D HEIGHT DIFFERENCE m (ft) 15(OD located lower)/30(OD located higher) (49.2/98.4)
ADD GAS AMOUNT
g
/m (oz/ft) 50 (0.538)
PIPE LENGTH FOR ADDITIONAL GAS m (ft) 20 (65.6)
*1: In case it is necessary to indicate the air flow volume in (l/s), the value in (m3/min.) shall be multiplied by 16.7 and rounded down the decimal point.
*2: If the EUROVENT Certified models can be operated under the "extra-low" temperature condition, -7°C dry bulb and -8°C wet-bulb temperatures with rated voltage 230V
shall be used.
*3: Network Impedance shall be applicable for EUROPE and CHINA models.
*4: The annual consumption is calculated by multiplying the input power at 230V(400V) by an average of 500 hours per year in cooling mode.
*5: EER and COP classification is at 230V(400V) only in accordance with EU directive 2002/31/EC.
*6: SEER and SCOP classification is at 230V(400V) only in accordance with EN-14825. For heating, SCOP indicates the value of only Average heating season, Other fiche
data indicates in an attached sheet.
SM830231-02Single欧州.indb134SM830231-02Single欧州.indb134 2014/09/1913:21:102014/09/1913:21:10

1-135
1
Simultaneous (Twin) -Type
1-1. Unit Specifications
PE1
6. 4-Way Cassette 60×60 Type S-36PY2E5A×2 / U-71PE1E8A
INDOOR MODEL S-36PY2E5A ×2
PANEL MODEL (CZ-KPY3A / CZ-KPY3B) ×2
OUTDOOR MODEL U-71PE1E8A
Branch pipe MODEL CZ-P155BK1
PERFORMANCE TEST CONDITION ISO5151 / EN14511 / EN14825 / EN12102
POWER SUPPLY ø, Hz 1ø 50Hz 1ø 50Hz
V 220 230 240 380 400 415 Min Max
C
O
O
L
I
N
G
CAPACITY kW 7.1 7.1 7.1 3.2 8.0
BTU/h 24200 24200 24200 10900 27300
CURRENT A 0.30 × 2 3.20 3.10 3.00 - -
INPUT POWER W 40 × 2 1.985k 1.985k 1.985k - -
TOTAL W - 2.065k 2.065k 2.065k 560 2.650k
ANNUAL CONSUMPTION TOTAL kWh *4 - - - - 1032.5 - - -
EER/EER CLASS
TOTAL(W/W)*5/("A"~"G") - - - 3.44 3.44/A 3.44 5.71 3.02
Erp
*6
Pdsign kW - - - - 7.1 -
SEER (W/W) - - - - 5.8 -
Annual consumption kWh - - - - 428 -
Class - - - - A+ -
POWER FACTOR % - - - 94 92 92
NOISE INDOOR
(H/M/L)
dB-A 36/32/26(31)*7
Power Level dB 51/47/41(46)*7
NOISE OUTDOOR
(H/L)
dB-A 48/-
Power Level dB 65/-
H
E
A
T
I
N
G
CAPACITY kW 8.0 8.0 8.0 2.8 9.0
BTU/h 27300 27300 27300 9600 30700
CURRENT A 0.30 × 2 3.35 3.25 3.15 - -
INPUT POWER W 35 × 2 2.080k 2.080k 2.080k - -
TOTAL W - 2.150k 2.150k 2.150k 500 2.900k
COP/COP CLASS
TOTAL(W/W)*5/("A"~"G") - - - 3.72 3.72/A 3.72 5.60 3.10
Erp
*6
Pdsign kW - - - - 7.1 -
Tbivalen °C - - - - -7 -
SCOP (W/W) - - - - 3.8 -
Annual consumption kWh - - - - 2616 -
Class - - - - A -
POWER FACTOR % - - - 94 92 92
NOISE INDOOR
(H/M/L)
dB-A 36/32/26(31)*7 -
Power Level dB 51/47/41(46)*7 -
NOISE OUTDOOR
(H/L)
dB-A - 50/-
Power Level dB - 67/-
EXTRA LOW TEMP Total CAPACITY(kW)/INPUT POWER(W)/COP -
MAX CURRENT(A)/MAX INPUT POWER(W) 0.35/50 × 2 7.0/4.15k 7.0/4.36k 7.0/4.53k
STARTING CURRENT(A)/COMP OUTPUT(W) - - - 3.35/2.0k 3.25/2.0k 3.15/2.0k
NETWORK IMPEDANCE (ΩMAX.) - -
FM OUTPUT (W) 40 × 2 90
MOISTURE REMOVAL VOLUME L/h(Pt/h) 4.2 (2.1×2) (8.8) -
I/D AIR
FLOW
COOL m3/min (ft3/min)
9.7×2/8.0×2/6.0×2*7 (343)×2/(283)×2/(212)×2
HEAT m3/min (ft3/min) 9.9×2/8.2×2/6.0×2*7 (350)×2/(290)×2/(212)×2
O/D AIR
FLOW
COOL m3/min (ft3/min) 60 (2119)
HEAT m3/min (ft3/min) 60 (2119)
REFRIGERANT TYPE, AMOUNT g(oz) R410A 2.35k (82.9)
P
R
O
D
I
M
HEIGHT : H mm(inch) 260<265 + 23> (10-1/4) 996 (39-7/32)
WIDTH : W mm(inch) 575<583> (22-21/32) 940 (37-1/32)
DEPTH : D mm(inch) 575<583> (22-21/32) 340 (13-13/32)
Panel : H×W×D mm 3A:31 × 700 × 700, 3B:31 × 625 × 625 -
P
A
C
D
I
M
HEIGHT : H mm 345 (13-19/32) 1136
WIDTH : W mm 691 (27-7/32) 1055
DEPTH : D mm 691 (27-7/32) 485
MASS
(NET) kg(lb) 18 (40) 71 (157)
(GROSS) kg(lb) 23 (51) 79 (174)
Panel : (NET) kg(lb) 2.4 (5.3) -
LAYERS LIMIT (actually) 11 (12) 2 (3)
Operation
Condition
Cool (DBT) 18°C ~ 32°C -15°C ~ 46°C
Heat (DBT) 16°C ~ 30°C -20°C ~ 24°C
P
I
P
I
N
G
PIPE DIAMETER mm (inch) (Liquid)ø6.35(1/4) (Gas)ø12.7(1/2) (Liquid)ø9.52(3/8) (Gas)ø15.88(5/8)
CONNECT METHOD, STD LENGTH m (ft) fl ared type, 5.0 (16.4) fl ared type, 5.0 (16.4)
PIPE LENGTH RANGE m (ft) 5 ~ 50 (16.4 ~ 164)
I/D&O/D HEIGHT DIFFERENCE m (ft) 15(OD located lower)/30(OD located higher) (49.2/98.4)
ADD GAS AMOUNT
g
/m (oz/ft) 50 (0.538)
PIPE LENGTH FOR ADDITIONAL GAS m (ft) 30 (98.4)
*1: In case it is necessary to indicate the air flow volume in (l/s), the value in (m3/min.) shall be multiplied by 16.7 and rounded down the decimal point.
*2: If the EUROVENT Certified models can be operated under the "extra-low" temperature condition, -7°C dry bulb and -8°C wet-bulb temperatures with rated voltage 230V
shall be used.
*3: Network Impedance shall be applicable for EUROPE and CHINA models.
*4: The annual consumption is calculated by multiplying the input power at 230V(400V) by an average of 500 hours per year in cooling mode.
*5: EER and COP classification is at 230V(400V) only in accordance with EU directive 2002/31/EC.
*6: SEER and SCOP classification is at 230V(400V) only in accordance with EN-14825. For heating, SCOP indicates the value of only Average heating season, Other fiche
data indicates in an attached sheet.
*7: Noise and air flow rate of L are indicated by the values at FAN mode. ( ):Normal operation Cooling/Heating noise value. Normal operation Cooling/Heating air flow rate are
7.6 (m3/min).
SM830231-02Single欧州.indb135SM830231-02Single欧州.indb135 2014/09/1913:21:102014/09/1913:21:10

1-136
1Simultaneous (Triple) -Type
1-1. Unit Specifications
PE1
6. 4-Way Cassette 60×60 Type S-36PY2E5A×3 / U-100PE1E8A
INDOOR MODEL S-36PY2E5A ×3
PANEL MODEL (CZ-KPY3A / CZ-KPY3B) ×3
OUTDOOR MODEL U-100PE1E8A
Branch pipe MODEL CZ-P3HPC2BM
PERFORMANCE TEST CONDITION ISO5151 / EN14511 / EN14825 / EN12102
POWER SUPPLY ø, Hz 1ø 50Hz 3ø 50Hz
V 220 230 240 380 400 415 Min Max
C
O
O
L
I
N
G
CAPACITY kW 10.0 10.0 10.0 3.3 12.5
BTU/h 34100 34100 34100 11300 42700
CURRENT A 0.30 × 3 4.20 4.00 3.90 - -
INPUT POWER W 40 × 3 2.560k 2.560k 2.560k - -
TOTAL W - 2.680k 2.680k 2.680k 840 3.700k
ANNUAL CONSUMPTION TOTAL kWh *4 - - - - 1340 - - -
EER/EER CLASS
TOTAL(W/W)*5/("A"~"G") - - - 3.73 3.73/A 3.73 3.93 3.38
Erp
*6
Pdsign kW - - - - 10.0 -
SEER (W/W) - - - - 6.3 -
Annual consumption kWh - - - - 555 -
Class - - - - A++ -
POWER FACTOR % - - - 93 92 91
NOISE INDOOR
(H/M/L)
dB-A 36/32/26(31)*7
Power Level dB 51/47/41(46)*7
NOISE OUTDOOR
(H/L)
dB-A 52/-
Power Level dB 69/-
H
E
A
T
I
N
G
CAPACITY kW 11.2 11.2 11.2 4.1 14.0
BTU/h 38200 38200 38200 14000 47800
CURRENT A 0.30 × 3 4.60 4.40 4.30 - -
INPUT POWER W 35 × 3 2.825k 2.825k 2.825k - -
TOTAL W - 2.930k 2.930k 2.930k 900 4.400k
COP/COP CLASS
TOTAL(W/W)*5/("A"~"G") - - - 3.82 3.82/A 3.82 4.56 3.18
Erp
*6
Pdsign kW - - - - 9.5 -
Tbivalen °C - - - - -10 -
SCOP (W/W) - - - - 3.8 -
Annual consumption kWh - - - - 3500 -
Class - - - - A -
POWER FACTOR % - - - 93 93 91
NOISE INDOOR
(H/M/L)
dB-A 36/32/26(31)*7 -
Power Level dB 51/47/41(46)*7 -
NOISE OUTDOOR
(H/L)
dB-A - 52/-
Power Level dB - 69/-
EXTRA LOW TEMP Total CAPACITY(kW)/INPUT POWER(W)/COP -
MAX CURRENT(A)/MAX INPUT POWER(W) 0.35/50 × 3 9.0/5.55k 9.0/5.85k 9.0/6.10k
STARTING CURRENT(A)/COMP OUTPUT(W) - - - 4.60/3.0k 4.40/3.0k 4.30/3.0k
NETWORK IMPEDANCE (ΩMAX.) - -
FM OUTPUT (W) 40 × 3 90 × 2
MOISTURE REMOVAL VOLUME L/h(Pt/h) 6.0 (2.0×3) (12.6) -
I/D AIR
FLOW
COOL m3/min (ft3/min)
9.7×3/8.0×3/6.0×3*7 (343)×3/(283)×3/(212)×3
HEAT m3/min (ft3/min) 9.9×3/8.2×3/6.0×3*7 (350)×3/(290)×3/(212)×3
O/D AIR
FLOW
COOL m3/min (ft3/min) 110 (3885)
HEAT m3/min (ft3/min) 95 (3355)
REFRIGERANT TYPE, AMOUNT g(oz) R410A 3.40k (119.9)
P
R
O
D
I
M
HEIGHT : H mm(inch) 260<265 + 23> (10-1/4) 1416 (55-3/4)
WIDTH : W mm(inch) 575<583> (22-21/32) 940 (37-1/32)
DEPTH : D mm(inch) 575<583> (22-21/32) 340 (13-13/32)
Panel : H×W×D mm 3A:31 × 700 × 700, 3B:31 × 625 × 625 -
P
A
C
D
I
M
HEIGHT : H mm 345 (13-19/32) 1556
WIDTH : W mm 691 (27-7/32) 1055
DEPTH : D mm 691 (27-7/32) 485
MASS
(NET) kg(lb) 18 (40) 98 (216)
(GROSS) kg(lb) 23 (51) 108 (238)
Panel : (NET) kg(lb) 2.4 (5.3) -
LAYERS LIMIT (actually) 11 (12) 1(2)
Operation
Condition
Cool (DBT) 18°C ~ 32°C -15°C ~ 46°C
Heat (DBT) 16°C ~ 30°C -20°C ~ 24°C
P
I
P
I
N
G
PIPE DIAMETER mm (inch) (Liquid)ø6.35(1/4) (Gas)ø12.7(1/2) (Liquid)ø9.52(3/8) (Gas)ø15.88(5/8)
CONNECT METHOD, STD LENGTH m (ft) fl ared type, 5.0 (16.4) fl ared type, 5.0 (16.4)
PIPE LENGTH RANGE m (ft) 5 ~ 75 (16.4 ~ 246.1)
I/D&O/D HEIGHT DIFFERENCE m (ft) 15(OD located lower)/30(OD located higher) (49.2/98.4)
ADD GAS AMOUNT
g
/m (oz/ft) 50 (0.538)
PIPE LENGTH FOR ADDITIONAL GAS m (ft) 20 (65.6)
*1: In case it is necessary to indicate the air flow volume in (l/s), the value in (m3/min.) shall be multiplied by 16.7 and rounded down the decimal point.
*2: If the EUROVENT Certified models can be operated under the "extra-low" temperature condition, -7°C dry bulb and -8°C wet-bulb temperatures with rated voltage 230V
shall be used.
*3: Network Impedance shall be applicable for EUROPE and CHINA models.
*4: The annual consumption is calculated by multiplying the input power at 230V(400V) by an average of 500 hours per year in cooling mode.
*5: EER and COP classification is at 230V(400V) only in accordance with EU directive 2002/31/EC.
*6: SEER and SCOP classification is at 230V(400V) only in accordance with EN-14825. For heating, SCOP indicates the value of only Average heating season, Other fiche
data indicates in an attached sheet.
*7: Noise and air flow rate of L are indicated by the values at FAN mode. ( ):Normal operation Cooling/Heating noise value. Normal operation Cooling/Heating air flow rate are
7.6 (m3/min).
SM830231-02Single欧州.indb136SM830231-02Single欧州.indb136 2014/09/1913:21:102014/09/1913:21:10

1-137
1
Simultaneous (Double-Twin) -Type
1-1. Unit Specifications
PE1
6. 4-Way Cassette 60×60 Type S-36PY2E5A×4 / U-125PE1E8A
INDOOR MODEL S-36PY2E5A ×4
PANEL MODEL (CZ-KPY3A / CZ-KPY3B) ×4
OUTDOOR MODEL U-125PE1E8A
Branch pipe MODEL CZ-P155BK1
PERFORMANCE TEST CONDITION ISO5151 / EN14511 / EN14825 / EN12102
POWER SUPPLY ø, Hz 1ø 50Hz 3ø 50Hz
V 220 230 240 380 400 415 Min Max
C
O
O
L
I
N
G
CAPACITY kW 12.5 12.5 12.5 3.3 14.0
BTU/h 42700 42700 42700 11300 47800
CURRENT A 0.30 × 4 6.00 5.70 5.50 - -
INPUT POWER W 40 × 4 3.680k 3.680k 3.680k - -
TOTAL W - 3.840k 3.840k 3.840k 840 4.600k
ANNUAL CONSUMPTION TOTAL kWh *4 - - - - 1920 - - -
EER/EER CLASS
TOTAL(W/W)*5/("A"~"G") - - - 3.26 3.26/A 3.26 3.93 3.04
Erp
*6
Pdsign kW - - - - - -
SEER (W/W) - - - - - -
Annual consumption kWh------
Class - - - - - -
POWER FACTOR % - - - 93 93 93
NOISE INDOOR
(H/M/L)
dB-A 36/32/26(31)*7
Power Level dB 51/47/41(46)*7
NOISE OUTDOOR
(H/L)
dB-A 53/-
Power Level dB 70/-
H
E
A
T
I
N
G
CAPACITY kW 14.0 14.0 14.0 4.1 16.0
BTU/h 47800 47800 47800 14000 54600
CURRENT A 0.30 × 4 6.20 5.90 5.70 - -
INPUT POWER W 35 × 4 3.750k 3.750k 3.750k - -
TOTAL W - 3.890k 3.890k 3.890k 900 5.200k
COP/COP CLASS
TOTAL(W/W)*5/("A"~"G") - - - 3.60 3.60/A 3.60 4.56 3.08
Erp
*6
Pdsign kW - - - - - -
Tbivalen °C - - - - - -
SCOP (W/W) - - - - - -
Annual consumption kWh------
Class - - - - - -
POWER FACTOR % - - - 92 92 92
NOISE INDOOR
(H/M/L)
dB-A 36/32/26(31)*7 -
Power Level dB 51/47/41(46)*7 -
NOISE OUTDOOR
(H/L)
dB-A - 53/-
Power Level dB - 70/-
EXTRA LOW TEMP Total CAPACITY(kW)/INPUT POWER(W)/COP -
MAX CURRENT(A)/MAX INPUT POWER(W) 0.35/50 × 4 10.0/6.20k 10.0/6.50k 10.0/6.75k
STARTING CURRENT(A)/COMP OUTPUT(W) - - - 6.20/3.0k 5.90/3.0k 5.70/3.0k
NETWORK IMPEDANCE (ΩMAX.) - -
FM OUTPUT (W) 40 × 4 90 × 2
MOISTURE REMOVAL VOLUME L/h(Pt/h) 7.9 (1.975×4) (16.6) -
I/D AIR
FLOW
COOL m3/min (ft3/min)
9.7×4/8.0×4/6.0×4*7 (343)×4/(283)×4/(212)×4
HEAT m3/min (ft3/min) 9.9×4/8.2×4/6.0×4*7 (350)×4/(290)×4/(212)×4
O/D AIR
FLOW
COOL m3/min (ft3/min) 130 (4591)
HEAT m3/min (ft3/min) 110 (3885)
REFRIGERANT TYPE, AMOUNT g(oz) R410A 3.40k (119.9)
P
R
O
D
I
M
HEIGHT : H mm(inch) 260<265 + 23> (10-1/4) 1416 (55-3/4)
WIDTH : W mm(inch) 575<583> (22-21/32) 940 (37-1/32)
DEPTH : D mm(inch) 575<583> (22-21/32) 340 (13-13/32)
Panel : H×W×D mm 3A:31 × 700 × 700, 3B:31 × 625 × 625 -
P
A
C
D
I
M
HEIGHT : H mm 345 (13-19/32) 1556
WIDTH : W mm 691 (27-7/32) 1055
DEPTH : D mm 691 (27-7/32) 485
MASS
(NET) kg(lb) 18 (40) 98 (216)
(GROSS) kg(lb) 23 (51) 108 (238)
Panel : (NET) kg(lb) 2.4 (5.3) -
LAYERS LIMIT (actually) 11 (12) 1 (2)
Operation
Condition
Cool (DBT) 18°C ~ 32°C -15°C ~ 46°C
Heat (DBT) 16°C ~ 30°C -20°C ~ 24°C
P
I
P
I
N
G
PIPE DIAMETER mm (inch) (Liquid)ø6.35(1/4) (Gas)ø12.7(1/2) (Liquid)ø9.52(3/8) (Gas)ø15.88(5/8)
CONNECT METHOD, STD LENGTH m (ft) fl ared type, 5.0 (16.4) fl ared type, 5.0 (16.4)
PIPE LENGTH RANGE m (ft) 5 ~ 75 (16.4 ~ 246.1)
I/D&O/D HEIGHT DIFFERENCE m (ft) 15(OD located lower)/30(OD located higher) (49.2/98.4)
ADD GAS AMOUNT
g
/m (oz/ft) 50 (0.538)
PIPE LENGTH FOR ADDITIONAL GAS m (ft) 20 (65.6)
*1: In case it is necessary to indicate the air flow volume in (l/s), the value in (m3/min.) shall be multiplied by 16.7 and rounded down the decimal point.
*2: If the EUROVENT Certified models can be operated under the "extra-low" temperature condition, -7°C dry bulb and -8°C wet-bulb temperatures with rated voltage 230V
shall be used.
*3: Network Impedance shall be applicable for EUROPE and CHINA models.
*4: The annual consumption is calculated by multiplying the input power at 230V(400V) by an average of 500 hours per year in cooling mode.
*5: EER and COP classification is at 230V(400V) only in accordance with EU directive 2002/31/EC.
*6: SEER and SCOP classification is at 230V(400V) only in accordance with EN-14825. For heating, SCOP indicates the value of only Average heating season, Other fiche
data indicates in an attached sheet.
*7: Noise and air flow rate of L are indicated by the values at FAN mode. ( ):Normal operation Cooling/Heating noise value. Normal operation Cooling/Heating air flow rate are
7.6 (m3/min).
SM830231-02Single欧州.indb137SM830231-02Single欧州.indb137 2014/09/1913:21:112014/09/1913:21:11

1-138
1Simultaneous (Triple) -Type
1-1. Unit Specifications
PE1
6. 4-Way Cassette 60×60 Type S-45PY2E5A×3 / U-125PE1E8A
INDOOR MODEL S-45PY2E5A ×3
PANEL MODEL (CZ-KPY3A / CZ-KPY3B) ×3
OUTDOOR MODEL U-125PE1E8A
Branch pipe MODEL CZ-P3HPC2BM
PERFORMANCE TEST CONDITION ISO5151 / EN14511 / EN14825 / EN12102
POWER SUPPLY ø, Hz 1ø 50Hz 3ø 50Hz
V 220 230 240 380 400 415 Min Max
C
O
O
L
I
N
G
CAPACITY kW 12.5 12.5 12.5 3.3 14.0
BTU/h 42700 42700 42700 11300 47800
CURRENT A 0.32 × 3 6.00 5.70 5.50 - -
INPUT POWER W 40 × 3 3.680k 3.680k 3.680k - -
TOTAL W - 3.800k 3.800k 3.800k 840 4.600k
ANNUAL CONSUMPTION TOTAL kWh *4 - - - - 1900 - - -
EER/EER CLASS
TOTAL(W/W)*5/("A"~"G") - - - 3.29 3.29/A 3.29 3.93 3.04
Erp
*6
Pdsign kW - - - - - -
SEER (W/W) - - - - - -
Annual consumption kWh------
Class - - - - - -
POWER FACTOR % - - - 93 93 93
NOISE INDOOR
(H/M/L)
dB-A 38/34/28(32)*7
Power Level dB 53/49/43(47)*7
NOISE OUTDOOR
(H/L)
dB-A 53/-
Power Level dB 70/-
H
E
A
T
I
N
G
CAPACITY kW 14.0 14.0 14.0 4.1 16.0
BTU/h 47800 47800 47800 14000 54600
CURRENT A 0.30 × 3 6.20 5.90 5.70 - -
INPUT POWER W 35 × 3 3.750k 3.750k 3.750k - -
TOTAL W - 3.860k 3.860k 3.860k 900 5.200k
COP/COP CLASS
TOTAL(W/W)*5/("A"~"G") - - - 3.63 3.63/A 3.63 4.56 3.08
Erp
*6
Pdsign kW - - - - - -
Tbivalen °C - - - - - -
SCOP (W/W) - - - - - -
Annual consumption kWh------
Class - - - - - -
POWER FACTOR % - - - 92 92 92
NOISE INDOOR
(H/M/L)
dB-A 38/34/28(32)*7 -
Power Level dB 53/49/43(47)*7 -
NOISE OUTDOOR
(H/L)
dB-A - 53/-
Power Level dB - 70/-
EXTRA LOW TEMP Total CAPACITY(kW)/INPUT POWER(W)/COP -
MAX CURRENT(A)/MAX INPUT POWER(W) 0.37/50 × 3 10.0/6.20k 10.0/6.50k 10.0/6.75k
STARTING CURRENT(A)/COMP OUTPUT(W) - - - 6.20/3.0k 5.90/3.0k 5.70/3.0k
NETWORK IMPEDANCE (ΩMAX.) - -
FM OUTPUT (W) 40 × 3 90 × 2
MOISTURE REMOVAL VOLUME L/h(Pt/h) 7.9 (2.63×3) (16.6) -
I/D AIR
FLOW
COOL m3/min (ft3/min)
10.0×3/8.8×3/7.0×3*7 (353)×3/(311)×3/(247)×3
HEAT m3/min (ft3/min) 10.3×3/9.2×3/7.0×3*7 (364)×3/(325)×3/(247)×3
O/D AIR
FLOW
COOL m3/min (ft3/min) 130 (4591)
HEAT m3/min (ft3/min) 110 (3885)
REFRIGERANT TYPE, AMOUNT g(oz) R410A 3.40k (119.9)
P
R
O
D
I
M
HEIGHT : H mm(inch) 260<265 + 23> (10-1/4) 1416 (55-3/4)
WIDTH : W mm(inch) 575<583> (22-21/32) 940 (37-1/32)
DEPTH : D mm(inch) 575<583> (22-21/32) 340 (13-13/32)
Panel : H×W×D mm 3A:31 × 700 × 700, 3B:31 × 625 × 625 -
P
A
C
D
I
M
HEIGHT : H mm 345 (13-19/32) 1556
WIDTH : W mm 691 (27-7/32) 1055
DEPTH : D mm 691 (27-7/32) 485
MASS
(NET) kg(lb) 18 (40) 98 (216)
(GROSS) kg(lb) 23 (51) 108 (238)
Panel : (NET) kg(lb) 2.4 (5.3) -
LAYERS LIMIT (actually) 11(12) 1(2)
Operation
Condition
Cool (DBT) 18°C ~ 32°C -15°C ~ 46°C
Heat (DBT) 16°C ~ 30°C -20°C ~ 24°C
P
I
P
I
N
G
PIPE DIAMETER mm (inch) (Liquid)ø6.35(1/4) (Gas)ø12.7(1/2) (Liquid)ø9.52(3/8) (Gas)ø15.88(5/8)
CONNECT METHOD, STD LENGTH m (ft) fl ared type, 5.0 (16.4) fl ared type, 5.0 (16.4)
PIPE LENGTH RANGE m (ft) 5 ~ 75 (16.4 ~ 246.1)
I/D&O/D HEIGHT DIFFERENCE m (ft) 15(OD located lower)/30(OD located higher) (49.2/98.4)
ADD GAS AMOUNT
g
/m (oz/ft) 50 (0.538)
PIPE LENGTH FOR ADDITIONAL GAS m (ft) 20 (65.6)
*1: In case it is necessary to indicate the air flow volume in (l/s), the value in (m3/min.) shall be multiplied by 16.7 and rounded down the decimal point.
*2: If the EUROVENT Certified models can be operated under the "extra-low" temperature condition, -7°C dry bulb and -8°C wet-bulb temperatures with rated voltage 230V
shall be used.
*3: Network Impedance shall be applicable for EUROPE and CHINA models.
*4: The annual consumption is calculated by multiplying the input power at 230V(400V) by an average of 500 hours per year in cooling mode.
*5: EER and COP classification is at 230V(400V) only in accordance with EU directive 2002/31/EC.
*6: SEER and SCOP classification is at 230V(400V) only in accordance with EN-14825. For heating, SCOP indicates the value of only Average heating season, Other fiche
data indicates in an attached sheet.
*7: Noise and air flow rate of L are indicated by the values at FAN mode. ( ):Normal operation Cooling/Heating noise value. Normal operation Cooling/Heating air flow rate are
8.2 (m3/min).
SM830231-02Single欧州.indb138SM830231-02Single欧州.indb138 2014/09/1913:21:112014/09/1913:21:11
