Panasonic MJ-DJ01 User manual

Operating Instructions / 使用說明書
Arahan Pengendalian
ง้ัตดิตรากะลแคู่มือการใช้งาน / Hướng dẫn Sử dụng
Juicer(Household Use) / 榨汁機(家庭用)
Pengisar Jus(Kegunaan Di Rumah)
เครื่องคั้นน้ำผลไม้ (เครื่องใช้ภายในครัวเรือน)
Máy ép trái cây(Sử Dụng Trong Gia Ðình)
MJ-DJ01
MJ-SJ01
MJ-SJ01
MJ-DJ01
Thank you for purchasing this Panasonic product.
• This product is intended for household use only.
• Please read these instructions carefully in order to use this product correctly and safely.
• Before using this product please give your special attention to the section "SAFETY PRECAUTIONS" (Page 3-4).
• Please keep these Operating Instructions for future use.
感謝您購買Panasonic的產品。
•本產品只限於家庭使用。
•請仔細閱讀本使用說明書，以確保正確安全使用本產品。
•使用本產品前，請您特別留意“安全注意事項”(10-11頁)。
•請妥善保存本使用說明書，以備將來用途。
Terima kasih kerana membeli produk Panasonic.
•Produk ini hanya adalah untuk kegunaan di rumah.
•Sila baca arahan ini dengan telitinya supaya produk ini dapat digunakan dengan cara yang betul dan selamat.
•Sebelum menggunakan produk ini sila beri perhatian khas kepada ” LANGKAH-LANGKAH KESELAMATAN ” (muka surat 17-18)
•Sila simpan Arahan Pengendalian ini untuk kegunaan di masa depan.
)คินซโานาพ(cinosanaP์ฑณัภติลผอ้ืซกอืลเ่ีทณุคบอข น้ันา่ทเนอืรเวัรคนใ้ชใอ่ืพเ้วไีม้ีน์ฑณัภติลผ•ยัภดอลปะลแงอ้ตกูถงา่ยอ้ีน์ฑณัภติลผ้ชใอ่ืพเดยีอเะลงา่ยอ้ีนา่ลหเำนะนแำคนา่อดรปโ•ษศเิพน็ปเ(หน้า 24-25)"ยัภดอลปมาวคอ่ืพเงัวะรรวคอ้ข" ่ีทจในสมาวค้หใดรปโ้ีน์ฑณัภติลผ้ชในอ่ก • ตคานอนใ้ชใ้วไ้ีนนาง้ชใรากำนะนแำคบ็กเดรปโ•
Cảm ơn quý vị đã mua sản phẩm của Panasonic.
•Sản phẩm này chỉ được thiết kế để sử dụng trong gia đình.
• Xin đọc các hướng dẫn này cẩn thận để sử dụng sản phẩm đúng cách và an toàn.
• Trước khi sử dụng sản phẩm này xin đặc biệt chú ý đến "ĐỀ PHÒNG AN TOÀN" (Trang 31-32).
• Xin giữ Hướng dẫn Sử dụng này để sử dụng trong tương lai. M
Model No.
型號.
No. Model.
Kiểu Máy.
รุ่น.
1000
1250
1500
mL
750
500
250
oz
53
50
40
30
20
10
1000
1250
1500
mL
750
500
250
oz
53
50
40
30
20
10

PART NAMES
1 MJ-DJ01
2 MJ-SJ01
Maximum amount
approx. 1.5 L
5
*The shape of the Plug may be different from illustration.
1000
1250
1500
mL
750
500
250
oz
53
50
40
30
20
10
M
N
A
B
C
E
D
FG
H
I
J
K
L
P
O
A Food Pusher
B Feeding Tube
CContainer Cover
D Spinner Pad
ESpinner
FContainer Unit
G Rotatable Container
H Spout
IPulp Container
JClamps
K Motor Housing
L Switch 1 MJ-DJ01
2 MJ-SJ01
M Cup Cover
N Juice Jug
O *Plug
P Cord

6
DISASSEMBLY
CIRCUIT BREAKER PROTECTION
1 Lift up the Container
Cover and the Food
Pusher.
2 Detach the Pulp
Container.
1 Release the Clamps.
1
1Lift up the Container
Unit. 1 Lift up the Spinner.
2 3
When the Circuit Breaker automatically stops the motor due to overloading, follow the directions
below.
1. Turn off the Switch to " 0 / O " position, (refer to Page 5).
2. Remove food residue from the Spinner and cut ingredients into smaller pieces.
3. Attach parts again (refer to Page 7) and resume operation. Push them gently into the Feeding Tube
using the Food Pusher.
2 Remove the Spinner
Pad.
1 Pull upper part A of the
Rotatable Container until
the hook part B is as
illustrated.
2 Press the hook part B as
illustrated and pull upwards
to detach it.
3 To attach the Container Unit
again by reversing steps 1
to 2.
Note: If difficult to wash the Container Unit, it can be detached.
A
B

7
HOW TO USE
Wash all detachable parts and dry well before using the appliance for the first time, refer to page 8.
Unplug when assembling the unit. Before plugging in, ensure the Switch is switched to off.
Place the Container Unit
onto the Motor Housing.
a Make sure the Spout is
as shown.
a Make sure the Container
Unit sits properly on the
Motor Housing.
11 Place the Spinner
in the Container
Unit and fix it into
position.
2 Place the Container
Cover onto the
Container Unit.
3Attach the Pulp
Container and make
sure it is fully
aligned with the
body.
2
3
1Push the Clamps
as shown until a
locking sound is
heard.
a If the Clamps are
not clamped
correctly, the motor
will not operate.
4
Place the Juice Jug as
shown.
aMake sure the Spout
is in the downward
position when juicing.
Note:
*The Spout can be
rotated freely for 120°
when the Spout is in the
upward position.
Note:
• Ingredients that are not recommended:
Soft fruits that produce puree and can clog the Spinner – e.g. bananas, peaches, apricots etc.
Low juice ingredients which can block the product – e.g. fresh basil leaf for etc.
• Empty the Pulp Container when food residue is accumulated, as it may enter the juice or cause malfunction.
• Make sure all parts are correctly mounted before you switch on the appliance.
• Please use the Juice Jug with the Cup Cover to avoid juice splashing. Make sure to align the Juice Jug opening
to the Spout when juicing.
• For model MJ-DJ01, speed 2 is suitable for hard type fruits e.g. apples, carrots etc. while speed 1 is suitable for
softer type fruits e.g. watermelons, oranges etc.
51Plug in and switch on.
2Insert the ingredients
and push them into the
Feeding Tube using the
Food Pusher.
3 Align the Food Pusher
into the Feeding Tube
as illustrated.
6After use, switch off
and unplug.
aWhile removing the
Juice Jug, ensure
the Spout is
pulled up to prevent
juice from dripping.
1000
1250
1500
mL
750
500
250
oz
53
50
40
30
20
10
120°
1000
1250
1500
mL
750
500
250
oz
53
50
40
30
20
10
1000
1250
1500
mL
750
500
250
oz
53
50
40
30
20
10

9
Model Name
Power Supply
Power Consumption
Operation Rating
Dimensions(HxWxD) (Approx.)
Weight (Approx.)
Switch
Capacity (Approx.)
MJ-DJ01 MJ-SJ01
220 - 240 V 50-60 Hz
240 - 270 W
Continuous
{Repetition 2 min. On, then 2 min. OFF}
384 mm x 216 mm x 305 mm
4.1 kg 3.9 kg
2 Speed 1 Speed
1.5L Juice Cup, 2.0L Pulp Container
SPECIFICATION
