Juicer / Blender
Model No. MJ-J176PWTC
Destination : UAE , PGF
TABLE OF CONTENTS PAGE PAGE
1 Safety Precautions----------------------------------------------- 2
2 Specifications ----------------------------------------------------- 3
2.1. MJ-J176PWTC--------------------------------------------- 3
3 Location of Controls and Components ------------------- 4
4 Operating Instructions------------------------------------------ 5
4.1. How to use -------------------------------------------------- 5
4.2. Safety--------------------------------------------------------- 7
4.3. How to clean------------------------------------------------ 8
5 Troubleshooting Guide----------------------------------------- 9
5.1. The Juicer, the Blender commons -------------------- 9
5.2. The Juicer --------------------------------------------------- 9
5.3. The blender ------------------------------------------------11
6 Disassembly and Assembly Instructions ---------------12
6.1. Coupler------------------------------------------------------12
6.2. Bottom plate and motor---------------------------------12
6.3. Carbon brush----------------------------------------------12
6.4. Power cord-------------------------------------------------12
6.5. Clamps A and B------------------------------------------12
6.6. Switch, Switch plate-------------------------------------12
6.7. Clearance adjustment-----------------------------------13
6.8. Glass container and cutting blade -------------------14
6.9. Mill container and mill cutter---------------------------15
7 Wiring Connection Diagram---------------------------------16
7.1. Schematic diagram--------------------------------------16
7.2. Basic wiring diagram------------------------------------16
8 Exploded View and Replacement Parts List-----------17
8.1. MJ-J176PWTC -------------------------------------------17

2
1 Safety Precautions
CAUTION
• Maximum capacity : 1,000ml. (Blender)
• Do not crush ice cubes alone.
• Dice solid foods first. Blend with liquid.
• Do not operate blender longer than 3 minutes at one time.
Stop for 1 minutes, then resume.

3
2 Specifications
2.1. MJ-J176PWTC
Specifications are subject to change without notice.
Using Juicer Using Blender Using Dry mill
Power supply 220-240V 50-60Hz
Power consumption 210-230W
Power Cord 0.9m(With S3 plug)---WTZ
0.9m(With C2 plug)---WTC
Rotation Speed (Juicer) 12,000-13,100r.p.m.
(Blender) 11,700-12,700r.p.m.
Switch Control (Juicer) ON / OFF Push button type
(Blender) 2 Speed Push button and pulse
Operation rating Continuous
(Repetition 2 min. ON, 2 min. OFF) Continuous (Repetition 3 min. ON, 1 min. OFF) Continuous (60 seconds at a time)
Container capacity - Maximum 1,000ml Maximum 50g
Dimensions (H x W x D) approx. 32.3 x 28.8 x 21.2cm approx. 38.2 x 28.8 x 17.1cm approx. 26.4 x 28.8 x 17.1cm
Weight approx. 3.2kg approx.3.5kg approx.2.7kg
Attachment Cleaning brush

4
3 Location of Controls and Components

5
4 Operating Instructions
4.1. How to use

6

7
4.2. Safety

8
4.3. How to clean

9
5 Troubleshooting Guide
5.1. The Juicer, the Blender commons
5.1.1. SYMPTOM : Motor doesn ’ t rotate.
5.1.2. SYMPTOM : Motor “ roars ” but doesn ’ t rotate.(Turn the switch off immediately.)
5.1.3. SYMPTOM : Motor overheats.
5.1.4. SYMPTOM : Unusual odor
5.2. The Juicer
5.2.1. SYMPTOM : Motor “ roars ” but doesn ’ t rotate (switch off immediately)
5.2.2. SYMPTOM : Noise, vibration
Cause Remedy
Switch malfunction Replace the switch
Cord cut or disconnected Replace the cord
Cause Remedy
Motor bearing rushed Disassemble and apply oil, or replace the motor
Cause Remedy
High voltage Adjust it
Shorted motor Replace the motor
Eccentric main shaft gear part Replace the part
Main shaft is hard to operate Disassemble and adjust it or replace it
Unloaded operation Be sure that something is in the container before operating
Overload (rotation is impeded by a hard object, or a high viscosity sub-
stance in the container) Refer to operation
Cause Remedy
Overheating Refer to the section concerning overheating of the motor
Liquid leaking into motor Refer to the section concerning liquid leakage
Motor absorbing moisture Dry the motor or replace it
Cause Remedy
The spinner is contacting bottom of inlet After removing cutter base, decrease the number of adjustment rings
Foreign materials are clogged between the spinner and the cutter Remove them
Hard materials or seeds are clogged between the inlet bottom and the
cutter Remove them
Case Remedy
Deformation of spinner Replace the spinner
Residue has collected unevenly Clean the spinner
Incompletely fastened clasp Fasten it completely Replace it
The fastening part of the container cover clasp is worn out Replace the cover
Incompletely fastened back cover Fasten it completely
Incorrect placement of the main unit Inspect the rubber feet
Use on a level surface

10
5.2.3. SYMPTOM : The spinner is difficult to install and remove
5.2.4. SYMPTOM : Juice is poorly extracted
5.2.5. SYMPTOM : Juice contains too much residue
5.2.6. SYMPTOM : Cutter rubs against inlet bottom
5.2.7. SYMPTOM : Leakage of juice
Cause Remedy
The clutch pin of the cutter base doesn’t operate smoothly Examine the clutch pin; replace it if necessary
Foreign materials are clogged between the cutter base and the spinner
base Remove them
Cause Remedy
Cutter doesn’t operate well Replace complete spinner
Spinner is broken Replace complete spinner
Continuous use for a long period Remove the residue
Too large a gap between inlet bottom and cutter blade Adjust it within the range of 0.5 - 0.9mm
Cause Remedy
Cutter blade is worn out Replace the spinner (complete)
Gap between inlet bottom and cutter blade is too large Use two or three adjusting washers on the motor shaft
Cause Remedy
Gear incompletely engaged between cutter base and spinner Engage the gear
Too many adjustment rings on the motor shaft Decrease the number of adjustment rings and adjust the gap within the
range of 0.5 - 0.9mm
Cause Remedy
Container and/or cover deformed or broken Replace the container or cover
Incorrect clasp fastening Examine the clasp; adjust the fastening force
Foreign materials are clogged between the container cover and the
container Clean it and remove them
Excessive vibration Clean it and adjust the spinner balance

11
5.3. The blender
5.3.1. SYMPTOM : Cutter won ’ t rotate
5.3.2. SYMPTOM : Motor rotates but cutter doesn ’ t rotate
5.3.3. SYMPTOM : Noise, vibration
5.3.4. SYMPTOM : Juice leakage
(Notes)
Do not attempt to clean parts with boiling water.
Do not attempt to use fire to quickly dry parts.
Orange juice stains, etc. can be removed by using alcohol or detergent. Avoid using volatile substances when cleaning.
Cause Remedy
Main shaft binding Disassemble and oil, or replace
Cause Remedy
Gear is worn out Replace the gear (cutter base)
Cause Remedy
Bad gearing of container and motor Make the gearing correct
Gear is eccentric (bearing) Repair or replacement (bearing)
Deformed or broken cutter Repair or replacement
Cause Remedy
Broken container Replace the container
Bad container base Replace the packing
Loose fastened part Fasten it tightly
Main shaft is worn out Replace the main shaft and bearing

12
6 Disassembly and Assembly Instructions
6.1. Coupler
1. Remove the coupler cap.
2. With the coupler fixed, remove the coupler nut by using a
screwdriver.
3. Remove the coupler by pulling it upward.
6.2. Bottom plate and motor
1. The bottom plate can be detached by removing the 4 set-
screws.
2. Pull out the connection terminal of the AC motor. Then
the motor can be detached.
6.3. Carbon brush
1. Remove the AC motor.
2. Raise the carbon brush terminal claws to detach the car-
bon brush.
Cautions for Replacement
• Replace the right and left carbon brushes simulta-
neously.
6.4. Power cord
1. Remove the bottom plate.
2. Remove the power cord from the AC motor housing and
replace it with new one.
6.5. Clamps A and B
1. Remove the bottom plate.
2. Detach the E-clip for each clamp.
Then the clamps can be replaced.
• Clamps A and B are marked with "A" and "B" on the rear
side respectively. Therefore, check the marks and install
the clamps A and B in correct positions.
6.6. Switch, Switch plate
1. Remove the bottom plate.
2. Remove the 1 setscrew of the switch.
3. Pull out the connection terminal of the switch.
4. To remove the switch plate, remove the switch before-
hand. Next, remove the two claws of the switch plate out
of the motor housing.

13
6.7. Clearance adjustment
1. Insert the clearance gauge between the upper cutter surface of spinner (extractor) and the bottom of feeder opening.
2. when the thinner side (1/51''... 0.5mm) can be inserted and the thicker side (1/28''... 0.9mm) cannot, the clearance is appropri-
ate.
3. If the thicker side (1/28''... 0.9mm) can be inserted, the clearance is too large.
In that case, remove the coupler and add some adjustment washers onto the motor shaft.
4. In the thinner side (1/51''... 0.5mm) cannot be inserted, the clearance is too narrow.
In that case, remove the coupler and take off some adjustment washers from the motor shaft.

14
6.8. Glass container and cutting blade
1. Remove the cover, then turn the glass container up-side-
down.
2. Secure the glass cup and turn the mounting ring counter-
clockwise.
3. The gasket (upper) can be removed.
4. Wrap the cutting blade with a cloth for protection and
secure it.
5. Turn the upper connector clockwise with long nose pliers.
Then the cutting blade, and upper connector can be
removed.
• The parts can be assembled by reversing the disassem-
bly procedure.

15
6.9. Mill container and mill cutter
1. Remove the cover, then turn the mill container up-side-
down.
2. Secure the glass cup and turn the mounting ring counter-
clockwise.
3. Wrap the cutting blade with a cloth for protection and
secure it.
4. Turn the upper connector clockwise with long nose pliers.
Then the mill cutter, and upper connector can be
removed.
• The parts can be assembled by reversing the disassem-
bly procedure.

16
7 Wiring Connection Diagram
7.1. Schematic diagram
7.2. Basic wiring diagram

17
8 Exploded View and Replacement Parts List
8.1. MJ-J176PWTC
8.1.1. PARTS LOCATION

18
8.1.2. REPLACEMENT PARTSLIST
Notes:Important safety notice
• Components identified by mark have special characteristics important for safety.
• " When replacing any of these components use only manufacturer's specified parts."
Model No. MJ-J176PWTC
Safety Ref. No. Part No. Part Name & Description Pcs/Set Remarks
J176PWTC
<PARTS LIST>
1 AJD08-129-W Food pusher 1
2 AJD93-129-H Container cover 1
3 AJA04-144 Strainer 1
4 AJD98-129-W Container 1
5 AJD07-129-W Spout cover 1
6 AJF03-123 Coupler cap 1
7 AJF02-108 Coupler nut 1
8 AMJ18C-600 Lock washer 1
9 AMJ99C-A00 Coupler 1
10 AJG04-129-W Clamp B 1
11 AJA02-144-W0 Motor housing 1
12 AJG01-142 Leaf spring 1
13 AJB04-142-W0 Safty device 1
14 AJY02-129-W Caution label 1
15 AJG03-129-W Clamp A 1
16 AJB03-129-G0 Switch plate 1
17 AJN99J129-A Switch 1
18 AJG94-129 Clamp link B unit 1
19 AMJ50G-C30 Seal cap 1
20 AJG93-129 Clamp link A unit 1
21 AJG09-129 Spacer 2
22 AMJ09C-A00 Adjustment washer A 0-3
23 AMU64C-J710 Adjustment washer 0-1
24 AMX56A-980 Motor screw 3
25 AMJ26A-530 Support plate for motor 3
26 AJF11-129 Carbon brush 1
27 AJA08J129-0S AC Motor 1
28 AMJ16F-K70-2 Carbon brush 1 It supplies by two sets.
29 AMJ31A-440 Motor support rubber 1
30 AJB98-129-0S Bottom plate 1
31 AJY03Y144 Name plate 1
32 AJB05-108-H Foot 4
33 AMJ14Q-F60W Cleaning brush 1
34 AMJ51B-421W Brush 1
35 AJP99-129-W Power cord 1 C-2.AC220V-240V
36 AVA03-223-W0 Glass container assy 1
37 AVE44-180-X Cover B 1
38 AVE02-180-W Cover A 1
39 AMX03B-R60 Glass container 1
40 AMX05B-831 Gasket 1
41 AVA05-223 Cutting blade 1
42 AMX13B-451 Wave washer 1
43 AMX27B-692 Washer 2
44 AVE86-219-W0 Mounting ring 1
45 AVE18-180 Spring for slide peace 3
46 AVE17-219-W0 Slide peace 1
47 AMX27B-A10 Washer 2
48 AMX94B-H10R Connector 2
49 AVA14-223-W0 Mill conteiner assy 1
50 AMX61B-L50 Mill conteiner 1
51 AMX95B-Q90 Mill cutter 1
52 AVE88-219-W0 Mounting ring 1
53 AVE18-180 Spring for slide peace 3
54 AVE17-219-W0 Slide peace 1
<SMALL STANDARDIZED METAL PARTS>
A XTN4+16BFJ Screw 1 For switch
B XTN4+20BFJ Screw 4 For bottom plate
C XTN4+16BFJ Screw 2 For clamp unit
D XTN4+16BFJ Screw 1 For safty device
E XUE6FPJ U-clip 1 For motor
F XUC7FJ E-clip 2 For clamp
<PACKING SPECIFICATIONS>
AJZ48Y14400S Individual carton 1 POS Label set
AJZ02-129 Carton filler(upper) 1
AJZ03-129 Carton filler(lower) 1

19
AJZ50Y144 Operating instructions 1
AJZ05-108 Protect of cutter 1
AMJ70Z-K60 Protect plate 1
XZB15X55A015 Plastic bag 1 For cord
Safety Ref. No. Part No. Part Name & Description Pcs/Set Remarks
J176PWTC

20
8.1.3. PACKING INSTRUCTION
