Panasonic KX- TAW848 Owner's manual

Thank you for purchasing a Panasonic Advanced Hybrid & Wireless PBX.
Please read this manual carefully before using this product and save this manual for future use.
PSMPR Software File Version 4.0000 or later
Document Version: 2007-02-01
KX-TAW848
Advanced Hybrid & Wireless PBX
PC Programming Manual
Panasonic Telephone Systems
Panasonic KX-TAW848, KX TAW848, KXTAW848, TAW848
www.voicesonic.com
Phone [phone]

2 PC Programming Manual
Introduction
About this Programming Manual
The PC Programming Manual is designed to serve as a system programming reference for the
Panasonic Advanced Hybrid & Wireless PBX. It explains how to program this PBX using the KX-
TAW848 Maintenance Console software.
The PC Programming Manual is divided into the following sections:
Section 1, Overview
Provides an overview of programming the PBX.
Section 2, KX-TAW848 Maintenance Console Operating Instructions
Serves as reference operating instructions when using the KX-TAW848 Maintenance Console
software to program the PBX.
Section 3, Appendix
Provides a list of all related PC programming items for each feature as Feature Programming
References.
References Found in the PC Programming Manual
Programming Manual References
Related sections of the PC Programming Manual are listed for your reference.
Feature Manual References
The Feature Manual explains what the PBX can do, as well as how to obtain the most of its many
features and facilities. Sections from the Feature Manual are listed throughout this manual for your
reference.
Installation Manual References
The Installation Manual provides instructions detailing the installation and maintenance of the PBX.
Sections from the Installation Manual are listed throughout this manual for your reference.
Links to Other Pages and Manuals
If you are viewing this manual with a PC, certain items are linked to different sections of this and other
PBX manuals. Click on a link to jump to that section.
Linked items include:
• Installation Manual References
• PC Programming Manual References
• Feature Manual References
WARNING
Unplug the PBX from the AC outlet if it emits smoke, an abnormal smell or makes
unusual noise. These conditions can cause fire or electric shock. Confirm that
smoke has stopped and contact an authorized Panasonic Factory Service Center.

PC Programming Manual 3
Trademarks
• Microsoft and Windows are either registered trademarks or trademarks of Microsoft Corporation
in the United States and/or other countries.
• Intel and Celeron are trademarks or registered trademarks of Intel Corporation or its subsidiaries
in the United States and other countries.
• All other trademarks identified herein are the property of their respective owners.
• Screen shots reprinted with permission from Microsoft Corporation.
NOTES
• The contents of this manual apply to PBXs with a certain software version, as indicated on the
cover of this manual. To confirm the software version of your PBX, see How do I confirm the
software version of the PBX or installed cards? in 2.6.1 Frequently Asked Questions
(FAQ).
• Some optional service cards, PTs, and features are not available in some areas. Additionally,
some optional service cards and features are not available for some PBX models. Please consult
your dealer for more information.
• Product specifications are subject to change without notice.
In some cases, additional information, including updates to this and other manuals, is included
in the KX-TAW848 Maintenance Console's Information before programming. Install the latest
version of Maintenance Console to view this information.

4 PC Programming Manual
Table of Contents
1 Overview.................................................................................................. 9
1.1 Introduction ....................................................................................................................10
1.1.1 Introduction ......................................................................................................................10
1.1.2 Entering Characters .........................................................................................................10
1.2 PC Programming............................................................................................................12
1.2.1 Installing and Starting the Maintenance Console.............................................................12
1.2.2 Password Security............................................................................................................15
2 KX-TAW848 Maintenance Console Operating Instructions ..............17
2.1 Introduction ....................................................................................................................18
2.1.1 Starting Maintenance Console and Software Modes.......................................................18
2.1.2 Access Levels ..................................................................................................................20
2.1.3 Software Interface ............................................................................................................23
2.1.4 Card Status ......................................................................................................................26
2.1.5 Display Options ................................................................................................................27
2.1.6 Extension Number Setting ...............................................................................................27
2.2 File ...................................................................................................................................29
2.2.1 File—New.........................................................................................................................29
2.2.2 File—Open ....................................................................................................................... 29
2.2.3 File—Close.......................................................................................................................30
2.2.4 File—Save........................................................................................................................30
2.2.5 File—Save As...................................................................................................................30
2.2.6 File—Exit..........................................................................................................................30
2.3 Connect...........................................................................................................................32
2.3.1 Connect—RS-232C .........................................................................................................32
2.3.2 Connect—USB.................................................................................................................32
2.3.3 Connect—Modem ............................................................................................................33
2.3.4 Connect—Profile Setup....................................................................................................34
2.3.5 Connect—Profile Editor....................................................................................................34
2.3.6 Connect—Disconnect ......................................................................................................36
2.4 Tool..................................................................................................................................37
2.4.1 Tool—SD memory backup ...............................................................................................37
2.4.2 Tool—Simplified Voice Message—Delete All Recordings ................................................37
2.4.3 Tool—Simplified Voice Message—Check Current Usage ................................................37
2.4.4 Tool—Extension List View................................................................................................37
2.4.5 Tool—Import.....................................................................................................................38
2.4.6 Tool—Export ....................................................................................................................40
2.4.7 Tool—System Data Convert.............................................................................................41
2.5 Utility ...............................................................................................................................42
2.5.1 Utility—Diagnosis .............................................................................................................42
2.5.2 Utility—File Transfer PC to PBX (SD Card)......................................................................43
2.5.3 Utility—File Transfer PBX (SD Card) to PC......................................................................44
2.5.4 Utility—SD Card File View and Load ...............................................................................45
2.5.5 Utility—SD Card File Delete.............................................................................................46
2.5.6 Utility—Message File Transfer PC to PBX .......................................................................46
2.5.7 Utility—Message File Transfer PBX to PC .......................................................................46
2.5.8 Utility—Error Log..............................................................................................................47

PC Programming Manual 5
2.5.9 Utility—CS Information.....................................................................................................48
2.5.10 Utility—PS Information..................................................................................................... 49
2.5.11 Utility—System Reset—Reset by the Command ............................................................. 49
2.6 Help ................................................................................................................................. 51
2.6.1 Frequently Asked Questions (FAQ).................................................................................. 51
2.7 [1] Configuration ............................................................................................................60
2.7.1 [1-1] Slot........................................................................................................................... 60
2.7.2 [1-1] Slot—Summary ....................................................................................................... 61
2.7.3 [1-1] Slot—Extension Card Property................................................................................ 63
2.7.4 [1-1] Slot—Extension Port................................................................................................ 67
2.7.5 [1-1] Slot—Extension Port—Port Command .................................................................... 72
2.7.6 [1-1] Slot—Extension Port—Port Type View .................................................................... 73
2.7.7 [1-1] Slot—LCO Card Property ........................................................................................ 74
2.7.8 [1-1] Slot—LCO Port ........................................................................................................84
2.7.9 [1-1] Slot—LCO Port—Port Command ............................................................................ 88
2.7.10 [1-1] Slot—DPH Card Property........................................................................................ 89
2.7.11 [1-1] Slot—DPH Port Command ...................................................................................... 92
2.7.12 [1-2] Portable Station ....................................................................................................... 93
2.7.13 [1-3] Option ...................................................................................................................... 96
2.8 [2] System....................................................................................................................... 99
2.8.1 [2-1] Date & Time/Daylight Saving ................................................................................... 99
2.8.2 [2-1] Date & Time/Daylight Saving—Date & Time Setting ............................................. 100
2.8.3 [2-2] Operator & BGM .................................................................................................... 101
2.8.4 [2-3] Timers & Counters................................................................................................. 103
2.8.5 [2-4] Week Table ............................................................................................................ 122
2.8.6 [2-4] Week Table—Time Setting .................................................................................... 122
2.8.7 [2-5] Holiday Table ......................................................................................................... 125
2.8.8 [2-6-1] Numbering Plan—Main ...................................................................................... 127
2.8.9 [2-6-2] Numbering Plan—Quick Dial.............................................................................. 151
2.8.10 [2-6-3] Numbering Plan—B/NA DND Call Feature ........................................................ 152
2.8.11 [2-7-1] Class of Service—COS Settings ........................................................................ 156
2.8.12 [2-7-2] Class of Service—External Call Block................................................................ 168
2.8.13 [2-7-3] Class of Service—Internal Call Block................................................................. 169
2.8.14 [2-8-1] Ring Tone Patterns—Call from CO..................................................................... 169
2.8.15 [2-8-2] Ring Tone Patterns—Call from Doorphone ........................................................ 170
2.8.16 [2-8-3] Ring Tone Patterns—Call from Others ............................................................... 170
2.8.17 [2-9] System Options ..................................................................................................... 173
2.8.18 [2-10] Extension CID Settings........................................................................................ 189
2.8.19 [2-11-1] Audio Gain—Paging/MOH................................................................................ 193
2.8.20 [2-11-2] Audio Gain—Card ............................................................................................ 194
2.9 [3] Group....................................................................................................................... 196
2.9.1 [3-1-1] Trunk Group—TRG Settings............................................................................... 196
2.9.2 [3-1-2] Trunk Group—Local Access Priority................................................................... 203
2.9.3 [3-2] Extension Group .................................................................................................... 203
2.9.4 [3-3] Call Pickup Group.................................................................................................. 204
2.9.5 [3-3] Call Pickup Group—All Setting .............................................................................. 205
2.9.6 [3-4] Paging Group......................................................................................................... 206
2.9.7 [3-4] Paging Group—All Setting..................................................................................... 207
2.9.8 [3-4] Paging Group—External Pager ............................................................................. 208
2.9.9 [3-5-1] Incoming Call Distribution Group—Group Settings ............................................ 209

6 PC Programming Manual
2.9.10 [3-5-2] Incoming Call Distribution Group—Queuing Time Table ....................................226
2.9.11 [3-5-3] Incoming Call Distribution Group—Miscellaneous..............................................226
2.9.12 [3-5-4] Incoming Call Distribution Group—Member .......................................................227
2.9.13 [3-6] Extension Hunting Group.......................................................................................228
2.9.14 [3-6] Extension Hunting Group—Member List ...............................................................230
2.9.15 [3-7-1] VM(DPT) Group—System Settings ....................................................................231
2.9.16 [3-7-2] VM(DPT) Group—Unit Settings..........................................................................232
2.9.17 [3-7-2] VM(DPT) Group—Unit Settings—Member List ..................................................234
2.9.18 [3-8-1] VM(DTMF) Group—System Settings .................................................................236
2.9.19 [3-8-2] VM(DTMF) Group—Group Settings ...................................................................246
2.9.20 [3-8-2] VM(DTMF) Group—Group Settings—Member List ............................................248
2.9.21 [3-9] PS Ring Group.......................................................................................................249
2.9.22 [3-9] PS Ring Group—Member List ...............................................................................250
2.10 [4] Extension.................................................................................................................252
2.10.1 [4-1-1] Wired Extension—Extension Settings ................................................................252
2.10.2 [4-1-2] Wired Extension—FWD/DND .............................................................................296
2.10.3 [4-1-3] Wired Extension—Speed Dial ............................................................................301
2.10.4 [4-1-4] Wired Extension—Flexible Button ...................................................................... 302
2.10.5 [4-1-4] Wired Extension—Flexible Button—Flexible Button Data Copy .........................312
2.10.6 [4-1-5] Wired Extension—PF Button ..............................................................................312
2.10.7 [4-1-6] Wired Extension—Simplified Voice Message ..................................................... 313
2.10.8 [4-2-1] Portable Station—Extension Settings................................................................. 316
2.10.9 [4-2-2] Portable Station—FWD / DND............................................................................343
2.10.10 [4-2-3] Portable Station—Flexible Button .......................................................................348
2.10.11 [4-2-3] Portable Station—Flexible Button—Flexible Button Data Copy..........................358
2.10.12 [4-2-4] Portable Station—Simplified Voice Message......................................................358
2.10.13 [4-3] DSS Console—Flexible Button ..............................................................................360
2.10.14 [4-3] DSS Console—Flexible Button—Flexible button Data Copy..................................371
2.11 [5] Optional Device.......................................................................................................372
2.11.1 [5-1] Doorphone .............................................................................................................372
2.11.2 [5-2] External Pager .......................................................................................................375
2.11.3 [5-3-1] Voice Message—DISA System ..........................................................................376
2.11.4 [5-3-2] Voice Message—DISA Message........................................................................381
2.11.5 [5-3-3] Voice Message—SVM ........................................................................................ 384
2.11.6 [5-4] External Relay........................................................................................................388
2.11.7 [5-5] External Sensor .....................................................................................................391
2.12 [6] Feature.....................................................................................................................394
2.12.1 [6-1] System Speed Dial ................................................................................................394
2.12.2 [6-2] Caller ID Modification.............................................................................................395
2.12.3 [6-3] Verification Code....................................................................................................397
2.12.4 [6-4] Second Dial Tone...................................................................................................399
2.12.5 [6-5] Absent Message ....................................................................................................400
2.12.6 [6-6] Tenant ....................................................................................................................401
2.12.7 [6-7] Dialing Plan............................................................................................................403
2.12.8 [6-7] Dialing Plan—Auto Assign .....................................................................................404
2.12.9 [6-8] Hotel....................................................................................................................... 405
2.13 [7] TRS........................................................................................................................... 407
2.13.1 [7-1] Denied Code ..........................................................................................................407
2.13.2 [7-2] Exception Code......................................................................................................407
2.13.3 [7-3] Special Carrier Code..............................................................................................408

PC Programming Manual 7
2.13.4 [7-4] Emergency Dial ..................................................................................................... 409
2.13.5 [7-5] Miscellaneous ........................................................................................................ 409
2.14 [8] ARS .......................................................................................................................... 413
2.14.1 [8-1] System Settings..................................................................................................... 413
2.14.2 [8-2] Leading Number .................................................................................................... 414
2.14.3 [8-3] Routing Plan Time ................................................................................................. 415
2.14.4 [8-3] Routing Plan Time—Time Setting ......................................................................... 415
2.14.5 [8-4] Routing Plan Priority.............................................................................................. 416
2.14.6 [8-5] Carrier.................................................................................................................... 417
2.14.7 [8-6] Leading Number Exception ................................................................................... 420
2.14.8 [8-7] Authorization Code for TRG................................................................................... 420
2.15 [9] CO & Incoming Call ................................................................................................ 422
2.15.1 [9-1] CO Line Settings.................................................................................................... 422
2.15.2 [9-2] DIL Table & Port Settings....................................................................................... 423
2.15.3 [9-3] Miscellaneous ........................................................................................................ 428
2.16 [10] Maintenance.......................................................................................................... 430
2.16.1 [10-1] Main ..................................................................................................................... 430
2.16.2 [10-2] PT Programming Access ..................................................................................... 447
3 Appendix ............................................................................................. 449
3.1 Revision History........................................................................................................... 450
3.1.1 KX-TAW848 PSMPR Software File Version 4.0xxx........................................................ 450
3.2 Feature Programming References ............................................................................. 451

8 PC Programming Manual

PC Programming Manual 9
Section 1
Overview
This section provides an overview of programming the PBX.

1.1 Introduction
10 PC Programming Manual
1.1 Introduction
1.1.1 Introduction
These programming instructions are designed to serve as an overall system programming reference
for the Panasonic Advanced Hybrid & Wireless PBX. Each feature in the PBX has default settings
that can be changed to customize the PBX to your requirements. These settings control the functions
of the PBX, and changing them is referred to as "system programming".
Only one person can perform system programming at a time. Any other users trying to enter
programming mode will be denied access.
Ways to Program
There are two programming methods:
•PC (Personal Computer) Programming
All features and settings of the PBX can be programmed through PC programming with KX-
TAW848 Maintenance Console. Installing and starting the Maintenance Console is
described in Section 1.2 PC Programming. Individual PC programming items are described
in KX-TAW848 Maintenance Console Operating Instructions.
•PT (Proprietary Telephone) Programming
A subset of the features and settings of the PBX can be programmed using a PT. PT
programming is described in the PT Programming Manual.
1.1.2 Entering Characters
The characters on a white background below can be used when storing a name, message, password
or other text entry data using a PC. The available characters vary according to the model of PBX.

1.1 Introduction
PC Programming Manual 11

1.2 PC Programming
12 PC Programming Manual
1.2 PC Programming
1.2.1 Installing and Starting the Maintenance Console
System programming, diagnosis and administration can be performed with a PC using the KX-
TAW848 Maintenance Console.
This section briefly describes how to install and start the Maintenance Console when the PC and the
PBX are connected by USB cable.
System Requirements
Required Operating System
• Microsoft Windows 98 SE, Windows Me, Windows 2000, or Windows XP
Minimum Hardware Requirements
• CPU: 300 MHz Intel Celeron microprocessor
• HDD: 100 MB of available hard disk space
• RAM: 128 MB of available RAM
®®
®®

1.2 PC Programming
PC Programming Manual 13
Installing the Maintenance Console
Notes
• To install or uninstall the software on a PC running Windows 2000 Professional or Windows
XP Professional, you must be logged in as a user in either the "Administrators" or "Power
Users" group.
• To connect the PC to the PBX via USB, the KX-TDA USB driver must be installed. Follow
the instructions of the wizard to install the KX-TDA USB driver. When the PBX is first
connected to the PC via USB, you may be asked to select the appropriate USB driver.
Browse for and select the KX-TDA USB driver that was installed previously.
Starting the KX-TAW848 Maintenance Console and Assigning the Basic
Items (Quick Setup)
When you start the KX-TAW848 Maintenance Console with the Installer Level Programmer Code and
connect to the PBX for the first time after initialization (with the factory default setting), Quick Setup
will launch automatically. During Quick Setup, you will set up the following basic items:
• Date and Time of the PBX. The date and time set to the PC's clock will be used.
• System Password for installer for PC programming.
• Operator and manager settings. Operator extensions for all time modes (day/lunch/break/
night) can be assigned.
• Flexible Numbering plan to Type 1 or Type 2. If Type 1 (with ) is selected, " " must prefix
all feature numbers (except access numbers) when an extension user wants to use a
feature.
• Operator call and Idle Line Access/ARS numbers.
• Remote Maintenance Dial Number. Enter the complete telephone number of the PBX. When
necessary, this number will be used to access the PBX from a remote location for
maintenance purposes.
1. Copy the setup file of the KX-TAW848 Maintenance
Console to your PC. (Its icon is shown here, on the left.)
2. Double-click the setup file to run the installer.
3. Follow the on-screen instructions provided by the
installation wizard.
1. Connect the PC to the PBX with a USB cable.
2. Start Maintenance Console from the Start menu.
3. "Information before programming" appears.
a. Carefully read this important additional information,
which includes updates to this and other manuals.
b. Click [OK] to close this window.

1.2 PC Programming
14 PC Programming Manual
Notice
1. During a long programming session, it is highly recommended that you periodically save the
system data to the SD Memory Card. If the PBX undergoes a sudden power failure or if the
system is reset for some reason, all the system data in RAM will be lost. However, if system
data has been saved to the SD Memory Card, it can be easily restored.
To save the system data to the SD Memory Card, (1) click the "SD Memory Backup" icon
before resetting the PBX or turning off the power, or (2) exit the Maintenance Console so
that the PBX automatically saves the system data.
4. Enter the Installer Level Programmer Code (default:
INSTALLER).
The Programmer Code authorizes different programming
levels, and the Quick Setup is only available when you start
the KX-TAW848 Maintenance Console with the Installer
Level Programmer Code.
Note
There are 2 other Programmer Codes with limited
authorization: Administrator Level (default: ADMIN),
and User Level (default: USER). (→1.2.2 Password
Security)
5. a. Click the check box to connect to the PBX. Options will
appear as shown here, on the left.
b. Enter the system password for installer (default:
1234).
c. Select "USB", then click [OK].
Note
To connect to the PBX via USB, the KX-TDA USB
driver must be installed on the PC, as explained above
in "Installing the Maintenance Console".
6. Follow the instructions of the Quick Setup wizard and
assign the basic items.
The program menu appears. You may now begin
programming the PBX.

1.2 PC Programming
PC Programming Manual 15
2. The PC will not perform any shutdown operation, or enter the power-saving system standby
mode while the Maintenance Console is connected to the PBX.
To perform either of the operations above, first close the connection to the PBX.
CAUTION
Do not remove the SD Memory Card while power is supplied to the PBX. Doing so may cause
the PBX to fail to start when you try to restart the system.
1.2.2 Password Security
To maintain system security, system passwords are required to access certain programming
functions of the PBX. By giving different users access to different passwords, it is possible to control
the amount of programming that each user is able to perform.
The following types of system passwords are available:
For more information about programmer codes, see 2.1.2 Access Levels.
Warning to the Administrator or Installer regarding the system password
1. Please provide all system passwords to the customer.
2. To avoid unauthorized access and possible abuse of the PBX, keep the passwords secret,
and inform the customer of the importance of the passwords, and the possible dangers if
they become known to others.
3. The PBX has default passwords preset. For security, change these passwords the first time
that you program the PBX.
4. Change the passwords periodically.
5. It is strongly recommended that passwords of 10 numbers or characters be used for
maximum protection against unauthorized access. For a list of numbers and characters that
can be used in system passwords, see 1.1.2 Entering Characters.
6. If a system password is forgotten, it can be found by loading a backup of the system data
into a PC, and checking the password using the Maintenance Console software. If you do
not have a backup of the system data, you must reset the PBX to its factory defaults and
reprogram it. Therefore, we strongly recommend maintaining a backup of the system data.
For more information on how to back up the system data, refer to the on-line help of the
Maintenance Console.
However, as system passwords can be extracted from backup copies of the system data file,
do not allow unauthorized access to these files.
Password Description Format
System Password for User Used with the user-level programmer code to access
user-level PC programming. The installer can specify
which system programming settings are available.
4 – 10
characters
System Password for
Administrator
Used with the administrator-level programmer code to
access administrator-level PC programming. The
installer can specify which system programming
settings are available.
System Password for
Installer
Used with the installer-level programmer code to access
installer-level PC programming. All system
programming settings are available.

1.2 PC Programming
16 PC Programming Manual

PC Programming Manual 17
Section 2
KX-TAW848 Maintenance Console Operating
Instructions
This section serves as reference operating instructions when
using the KX-TAW848 Maintenance Console software to
program the PBX.

2.1 Introduction
18 PC Programming Manual
2.1 Introduction
2.1.1 Starting Maintenance Console and Software Modes
Every time Maintenance Console is started, a dialog box will appear. From here, you can enter any
of the 3 available software modes.
• Initial mode
Initial mode describes the state when Maintenance Console is not connected to the PBX,
and no data files are open. In Initial mode, most options of Maintenance Console are
unavailable. For details, see 2.1.2 Access Levels.
• Batch mode
Batch mode allows you to create new system data files, and make modifications to system
data files stored on your PC, without being connected to the PBX. When you connect to the
PBX, the modified data will be uploaded at one time.
• Interactive mode
Interactive mode allows you to directly modify the system data and settings stored in the
PBX's memory from a PC that is connected to the PBX. This mode displays the system data
that is currently being used by the PBX, rather than the system data stored on the SD
memory card. Data can be modified and results displayed in real time.
To start Maintenance Console in Initial mode
1. Enter the relevant programmer code.
2. Click OK.
Maintenance Console will start.
To start Maintenance Console in Batch mode
1. Enter the relevant programmer code.
2. Click OK.
Maintenance Console will start.
3. Select an option from the File menu.
• Select New to create a new system data file.
• Select Open to open an existing system data file.
To start Maintenance Console in Interactive mode
1. Enter the relevant programmer code.
2. Select the Connect to PBX check box.
Connection options will be displayed.
• Select the Use profile check box if you want to use a pre-saved profile. This option is only
available when one or more profiles have been previously stored.
a. Select the profile to use from the drop-down list.
The Setup button will become unavailable.
b. If the system password for the PBX has not been stored with the profile, enter it.
If the system password has been stored with the selected profile, it does not need to be
entered.
• Select the method of connecting to the PBX if you do not want to use a stored profile.

2.1 Introduction
PC Programming Manual 19
a. Enter the system password for the PBX.
b. Click Setup.
c. Specify the settings as required. For more details, see the tables below.
d. Click OK.
3. Click OK.
Maintenance Console will start, and automatically connect to the PBX. If this is the first time that
Maintenance Console has connected to the PBX, and the date and time of the PBX have not yet
been set, the Quick Setup wizard will run. For more details, see Starting the KX-TAW848
Maintenance Console and Assigning the Basic Items (Quick Setup).
Connection Settings for RS-232C
Setting Values Explanation
Port COMx Specify the number of the COM port assigned
to the PC's RS-232C interface. Only available
COM ports are displayed.
Baud Rate (bps) 2400bps, 4800bps,
9600bps, 19200bps,
38400bps, 57600bps,
115200bps
Specify the speed of data transmission.
Connection Settings for Modem
Setting Values Explanation
Dial Number 1-9, 0, *, #, "," [comma],
T, P, W
Enter the telephone number to be dialed to
access the PBX.
T: Converts the Dial Type from Pulse to Tone.
"," [comma], P, W: Inserts a pause.
Dial Type Auto(Tone),
Auto(Pulse), Manual
Specify the outgoing dialing method.
If Manual is chosen, dialing must be done with
a connected telephone.
Comment – Enter a comment to identify the set of values.
Port COMx Specify the number of the COM port assigned
to the PC's modem interface.
Only available COM ports will be displayed.
Baud Rate 1200bps, 2400bps,
4800bps, 9600bps,
19200bps, 38400bps
Specify the speed of data transmission.
Modem Initialize – Enter the modem initialize command, and click
Initialize to send the command to the modem.
For more details, refer to your modem's
instruction manual.

2.1 Introduction
20 PC Programming Manual
2.1.2 Access Levels
There are three main levels of access to the Maintenance Console: User, Administrator and Installer.
Each level has its own Programmer Code, which must be entered to run the Maintenance Console.
The allowed format for each programmer code is as follows:
Access to menu options within the Maintenance Console is restricted depending on the Programmer
Code, and the current software mode (see 2.1.1 Starting Maintenance Console and Software
Modes). When a menu option is limited to certain access levels, this is noted in this manual in the
initial description of that menu option, for example:
"This option is only available at Installer level."
If a sentence like this does not appear under the heading, the menu option is available at all levels.
The target users for each access level are as follows:
The options available in each mode and access level are shown below.
The access levels are abbreviated as follows:
U: User; A: Administrator; I: Installer
A check mark indicates that the menu option is available for that access level.
Item Length
User Level Programmer Code 0 – 16 characters
Administrator Level Programmer Code 4 – 16 characters
Installer Level Programmer Code 4 – 16 characters
Access Level User
User For end users
Administrator For system administrators
Installer For dealers and system installers
File
Menu Option Initial Batch Interactive
UA I UA I UA I
New
Open
Close
Save
Save As
Exit
