Panasonic External Presentation unit 1728 Parts list manual

Technical Description
MEW01297
Revision 2
External Presentation unit 1728,
ver. 1.4.x
Author: Jan Pettersson
Date of issue: 2010-04-08
Date of rev: 2011-08-15

This page has deliberately been left blank.

Panasonic Electric Works Nordic AB
MEW01297 Rev: 2 Technical Description External Presentation Unit 1728, ver. 1.4.x
1
Table of contents
1Introduction________________________________ 3
2Definitions / Explanations ____________________ 4
3General description _________________________ 5
3.1 Ext. Presentation Unit 1728 __________________________ 5
3.1.1 SW mode 1728 - 1587___________________________ 5
3.1.2 SW mode 1728 - 1582___________________________ 5
4Selective alarm presentation __________________ 7
4.1 Ext. Presentation unit 1728___________________________ 7
5LED indicators, Push buttons, etc. _____________ 9
5.1 Ext. Presentation Unit 1728 __________________________ 9
6SW mode & Address setting _________________ 12
6.1 SW mode setting__________________________________ 12
6.1.1 SW mode setting via jumper "J4" _________________ 13
6.2 Address setting ___________________________________ 13
6.2.1 Address setting mode via the c.i.e. ________________ 14
6.3 Flow chart _______________________________________ 14
7User definable text messages (alarm texts)______ 16
8Commissioning a new unit / SSD download_____ 17
9Restart ___________________________________ 19
10 Fault messages_____________________________ 21
10.1 Fault messages in the Ext. Presentation Unit (EPU) ______ 21
10.2 Fault messages in the c.i.e. __________________________ 21
10.2.1 System EBL512 ______________________________ 21
10.2.2 System EBL128 ______________________________ 22
10.2.3 System EBL512 G3____________________________ 22
11 Disablement message _______________________ 24
12 Software (S/W) ____________________________ 25
12.1 S/W version______________________________________ 25
12.2 S/W download____________________________________ 26
13 Operation_________________________________ 27
14 Connections_______________________________ 29
15 Technical data_____________________________ 31
15.1 Power supply_____________________________________ 31
15.2 RS485 __________________________________________ 31
15.2.1 Cable _______________________________________ 31
15.3 RS232 __________________________________________ 31
15.4 Connection ______________________________________ 31
15.5 Current consumption_______________________________ 32

Panasonic Electric Works Nordic AB
MEW01297 Rev: 2 Technical Description External Presentation Unit 1728, ver. 1.4.x
2
16 Revision history____________________________ 33
This page has deliberately been left blank.

Panasonic Electric Works Nordic AB
MEW01297 Rev: 2 Technical Description External Presentation Unit 1728, ver. 1.4.x
3
1 Introduction
This document
1
describes the External Presentation unit 1728
(Informationstablå). The shorter expression EPU will also be used in
this document.
The 1728 unit can run in one of two SW modes:
SW mode 1728 - 1587
or
SW mode 1728 - 1582
See chapter "General description", page 5.
System EBL128 and EBL512
This document is valid for the 1728 software version 1.4.x, which
require a software version > 2.3.2 in EBL512 and a software version >
1.0.5 in EBL128 only if the functions described below are to be used.
The 1728 software version 1.4.x can be used in the systems EBL512
and EBL128 with lower versions but then without the possibility to
use these functions.
Functions
2
:
- The buzzer will sound (continuously) for any not acknowledged fault
in the system or a fault in the unit.
- Push button "Silence buzzer" will silence the buzzer.
- Disablement(s) in the system will be presented as "General
disablement in system".
System EBL512 G3
The 1728 software version 1.4.x has to be used in the system EBL512
G3.
1
Original file name: L:\User documents\EBL\Doc\Eng\MEW01297 (Rev
2).doc
2
Not valid for the Swedish convention (SBF).

Panasonic Electric Works Nordic AB
MEW01297 Rev: 2 Technical Description External Presentation Unit 1728, ver. 1.4.x
4
2 Definitions / Explanations
Definitions / explanations / abbreviations / etc. frequently used or not
explained elsewhere in the document.
EPU External Presentation Unit
C.i.e. Control and indicating equipment (=control unit)
C.U. Control unit (=Control and indicating equipment)
S/W Software
H/W Hardware

Panasonic Electric Works Nordic AB
MEW01297 Rev: 2 Technical Description External Presentation Unit 1728, ver. 1.4.x
5
3 General description
The ext. Presentation unit is intended for pre-warning, co-incidence,
fire and heavy smoke / heat alarm presentation. Any fault in the
system will be presented as "General fault in system".
Any disablement in the system will be presented as "General
disablement in system".2
3.1 Ext. Presentation Unit 1728
Figure 1. Left: The External Presentation Unit 1728SE has a
Swedish front. Right: 1728UK has an English front.
The enclosure is made of grey (RAL 7035) high impact ABS, with
temperature resistance up to 85° C. Fitted with a supplementary "O"
ring gasket, it will comply with IP65, in respect of dust and moisture.
Dimensions (W x H x D): 220 x 145 x 50 mm.
The Ext. Presentation unit shall be wall mounted.
3.1.1 SW mode 1728 - 1587
This SW mode has the highest performance with regard to
functionality, response time, ability to store fire alarms, etc.
The Ext. Presentation unit 1728SE, running in SW mode 1728 –1587,
is intended to succeed the existing Display unit 2236SE and the
External presentation display 2428SE.
In system EBL512, 1728 units running in SW mode 1728 –1587 have
to be connected to an Ext. FBP / DU interface board 1587 mounted
in the EBL512 c.i.e. EBL512 software version > 2.2 is required.
In system EBL128, 1728 units running in SW mode 1728 –1587 are
connected directly to the main board but an optional RS485
transceiver component 4552 is required on the main board.
In system EBL512 G3, 1728 units running in SW mode 1728 –1587
are connected directly to the main board connector "J4".
3.1.2 SW mode 1728 - 1582
The Ext. Presentation unit 1728SE, running in SW mode 1728 –1582,
is intended to be a spare part for the existing External presentation

Panasonic Electric Works Nordic AB
MEW01297 Rev: 2 Technical Description External Presentation Unit 1728, ver. 1.4.x
6
display 2428SE. Note, the functionality / performance is the same but
the size, the look and the front layout are different.
In system EBL512, 1728 units running in SW mode 1728 –1582 have
to be connected to an Ext. FBP interface board 1582 mounted in the
EBL512 c.i.e.
In systems EBL128 and EBL512 G3, 1728 units running in SW mode
1728 –1582 can NOT be connected.

Panasonic Electric Works Nordic AB
MEW01297 Rev: 2 Technical Description External Presentation Unit 1728, ver. 1.4.x
7
4 Selective alarm presentation
Normally all fire alarms will be presented in the c.i.e:s, ext. FBPs and
Presentation units, etc. There are some possibilities to select which
alarms that shall be presented in each unit. It is also programmable, if
the fire alarm presentation shall be according to EN54, i.e. when only
one point in a zone is in alarm status it will be presented as a point
alarm (zone and address), else presented as a zone alarm.
4.1 Ext. Presentation unit 1728
The alarm presentation in 1728 will be like in the c.i.e. that it is
connected to, i.e. point alarm or zone alarm presentation. See the
Operating Instructions, chapter "Fire alarm" for the system
respectively.
Via Win512 / Win128 / Win512 G3, it is possible to select which
alarms that shall be presented in the unit respectively. For example, if
there are many buildings in an installation, the units in one specific
building shall only present alarms activated within this building.
The following, so called operands are available (CU alternatives not
valid for EBL128):
1. Control unit (CU)
2. Consecutive control units (CU1, CU2)
3. Zone (zone)
4. Consecutive zones (zone1, zone2)
5. Zone –address (zone, addr)
6. Consecutive zone –addresses (zone1, addr1, zone2, addr2)
Explanations:
1. CU = Control unit number (c.i.e. no. 00-29)
2. CU1 = The first control unit number in the sequence. CU2 = The
last control unit number in the sequence.
3. zone = Zone number (001-999) In EBL128 (01-32).
4. zone1 = The first zone number in the sequence. zone2 = The last
zone number in the sequence.
5. zone, addr = Zone number and address within the zone (001, 01 –
999, 99)
6. zone1, addr1 = The first zone number and address in the sequence.
zone2, addr2 = The last zone number and address in the sequence.
Up to 50 operands can be used to make a, so called selector for an ext.
Presentation unit. Here follows a selector example:
Control unit (00), Consecutive zones (100, 500), Zone –address
(900, 01) In this 1728 unit will only be presented alarms that origin
from the c.i.e. no. 00 or from zone 100 up to and including zone 500
or from the alarm point 900-01.

Panasonic Electric Works Nordic AB
MEW01297 Rev: 2 Technical Description External Presentation Unit 1728, ver. 1.4.x
8
Default in systems EBL512 and EBL512 G3 is: Control units (00,
29), i.e. all alarms from all c.i.e:s will be presented in all ext.
Presentation units 1728.
Default in system EBL128: Zones (01 - 32), i.e. all alarms will be
presented in all ext. Presentation units 1728.

Panasonic Electric Works Nordic AB
MEW01297 Rev: 2 Technical Description External Presentation Unit 1728, ver. 1.4.x
9
5 LED indicators, Push buttons, etc.
The functions of the LEDs, push buttons, display and buzzer are
described below.
5.1 Ext. Presentation Unit 1728
Figure 2. The Ext. Presentation unit 1728SE front has the
designation texts in Swedish. Explanations and English texts,
see the following tables.
The following is valid in quiescent (normal) condition:
The LED "L6" (Operation) is turned on if 24 V DC is
connected and the communication with the c.i.e. is working
normally, else it is turned off.
Buzzer is silent.
No text in the display and no back-light.
No button is possible to use.

Panasonic Electric Works Nordic AB
MEW01297 Rev: 2 Technical Description External Presentation Unit 1728, ver. 1.4.x
10
Table of LED indicators:
LED indicator
Colour
Indicating
L1
Fire (Brand)
2 x Red
Blinking+
Buzzer
(interm.)
Fire alarm. (Also indicating heavy
smoke / heat alarm the same way as in
the c.i.e.)
L2
Alarms queued
(Flera larm)
2 x Red
Blinking
More than one alarm (also pre-warning
and co-incidence alarms)3. Use push
button "P1" (Alarms queued) to scroll.
L3
Extinguishing
(Släckanläggning
aktiverad)
Red
Cont.
Outputs for Extinguishing equipment are
activated. 4
L4
Ventilation
(Brandventilation
aktiverad)
Yellow
Cont.
Outputs for (fire / smoke) ventilation
equipment are activated. 4
L5
Fire brigade tx
(Larmsändare
aktiverad)
Red
Cont.
Output(s) for fire brigade tx (routing
equipment) is/are activated. 4
L6
Operation (Drift)
Green
Cont.
24 V DC is connected and the
communication with the c.i.e. is working
normally, i.e. the Ext. Presentation unit
is in operation.
NOTE! Regarding "L2", see also chapter "SW mode & Address
setting, page 12.
3
Co-incidence alarms = 2-zone / address dependence.
4
Indicating the same way, as in the c.i.e. the Presentation unit is connected
to, i.e. by activated output(s) of the corresponding type alternatively an
activated input for the LED respectively.

Panasonic Electric Works Nordic AB
MEW01297 Rev: 2 Technical Description External Presentation Unit 1728, ver. 1.4.x
11
Table of push buttons:
Push button
Colour
Operation / function
P1
Alarms queued
(Flera larm)
Black
Used, when LED "L2" (Alarms queued) is turned on,
to scroll through the queued alarms. (The first alarm
will automatically be shown again after 20 seconds,
if no button is used during that time.)
P2
Silence buzzer
(Summer tyst)
Yellow
Used to silence the buzzer in the Ext. Presentation
unit. The buzzer will re-sound for an alarm from
another zone.5
NOTE! Regarding "P1" and "P2", see also chapter "SW mode &
Address setting, page 12. See also chapter "S/W version", page 25.
Table of others:
Component
Indicating
Buzzer6
Intermittent
Fire alarm, pre-warning and co-incidence3,
like in the c.i.e.
Continuously2
Not acknowledged fault in the system or a
fault in the unit.
Cont. + All LEDs
turned off as well.
There is a CPU / memory fault in the unit.
Display
Pre-warning, co-incidence3, Fire alarm and Heavy smoke / heat
alarm presentation like in the c.i.e. the Ext. Presentation unit is
connected to including a user definable text message (alarm
text), if programmed.
Fault(s) in the system (not corrected / serviced and not
acknowledged) will be presented as "General fault in system".
(NOTE! A fault message may be shown, indicating a
communication fault (i.e. no connection between the unit and
the c.i.e. All LEDs are turned off as well.).
Disablement(s) in the system will be presented as "General
disablement in system".2
NOTE! Regarding the Display, see also chapter "SW mode &
Address setting, page 12.
5
When point alarm presentation is valid (set via Win512) the buzzer will re-
sound for an alarm from another alarm point.
6
The buzzer may be programmed as "disabled" (via Win128 / Win512 /
WinG3), i.e. it will never sound.

Panasonic Electric Works Nordic AB
MEW01297 Rev: 2 Technical Description External Presentation Unit 1728, ver. 1.4.x
12
6 SW mode & Address setting
Each Ext. Presentation unit can in system EBL512 run in SW mode
1728 - 1587 or SW mode 1728 –1582, i.e. it can be used as two
different types of units. It shall also have a unique address on the
RS485 line connected to the 1587 or 1582 board in the EBL512 c.i.e.
See EBL512 Planning Instructions.
The SW mode 1728 –1587 shall be used in system EBL128 and an
optional RS485 transceiver component 4552 is required on the main
board in the EBL128 c.i.e. It shall also have a unique address on the
RS485 line connected to the main board connector "J1". See EBL128
Planning Instructions.
The SW mode 1728 –1587 shall be used in system EBL512 G3. It
shall also have a unique address on the RS485 line connected to the
main board connector "J4". See EBL512 G3 Planning Instructions.
6.1 SW mode setting
A brand new ext. Presentation unit has no SW mode. It is factory set
to "Not selected" (and is hereby not addressable). When it is
powered it will automatically be ready for the "SW mode setting".
As an alternative, an ext. Presentation unit in operation
7
can be ready
for the "SW mode setting" via the jumper "J4" in the unit. See the
following chapter.
When the ext. Presentation unit is ready for the "SW mode setting"
this is indicated by the LED "L2" (Alarms queued). The back-light is
turned on and the following information is shown in the display:
MODE SETTING! Change = Black
Type xxxxxxxxxxxx Store = Yellow
XXXXXXXXXXXX can be changed to one of the following:
- 1735 –1587
- 1736 –1587
- 1826 –1587 2nd Cab
- 1826 –1582 2nd Cab
- 1826/28 –1587
- 1826/28 –1582
- 1728 –1587
- 1728 –1582 (Not for systems EBL128 & EBL512 G3.)
- Not selected
Scroll to the wanted SW mode with the push button "P1" (black).
Store the selected SW mode with the push button "P2" (yellow) and
the unit will automatically be ready for the "Address setting ", see
below.
7
Also when a unit not in operation but with the mode and address set before,
is powered.

Panasonic Electric Works Nordic AB
MEW01297 Rev: 2 Technical Description External Presentation Unit 1728, ver. 1.4.x
13
NOTE!
If the stored SW mode is 1728 –1582 a language has to be set before
the address can be set
8
. The following information will be shown in
the display:
LANGUAGE SETTING! Change = Black
Language: xxxxxxx Store = Yellow
XXXXXXX can be changed to one of the following languages:
- English
- Danish
- Swedish
Scroll to the wanted language with the push button "P1" (black).
Store the selected language with the push button "P2" (yellow) and the
unit will automatically be ready for the "Address setting ", see below.
6.1.1 SW mode setting via jumper "J4"
An ext. Presentation unit in operation7will be ready for the "SW
mode setting" via the jumper "J4" in the unit. Shunt "J4"
momentarily.
9
When the ext. Presentation unit is ready for the "SW mode setting"
this is indicated by the LED "L2" (Alarms queued). The back-light is
turned on and the following information is shown in the display:
MODE SETTING! Change = Black
Type: xxxxxxxxxxxx Store = Yellow
Continue in accordance with chapter "SW mode setting", page 12.
6.2 Address setting
After the SW mode setting or after the language setting (see above),
the ext. Presentation unit is ready for the "address setting".
As an alternative, one
10
ext. Presentation unit in operation can be
ready for the "address setting" directly via a c.i.e. menu. See the
following chapter.
When the ext. Presentation unit is ready for the "address setting" this
is indicated by the LED "L2" (Alarms queued). The back-light is
turned on and the following information is shown in the display:
ADDRESS SETTING Change = Black
Address: XX Store = Yellow
XX can be changed to the following:
8
If the stored SW mode is 1728 –1587 a language will be downloaded via
the c.i.e.
9
If "J4" is not removed, the ext. Presentation unit will not enter its normal
operation mode after the restart but start from the beginning again, ready for
the SW mode setting.
10
Or all the ext. Presentation units connected to the same Ext. FBP / DU
interface board 1587.

Panasonic Electric Works Nordic AB
MEW01297 Rev: 2 Technical Description External Presentation Unit 1728, ver. 1.4.x
14
For an ext. Presentation unit with SW mode 1728 - 1587, the address
can be set to 00-15.
11
(Default is "00".)
For an ext. Presentation unit with SW mode 1728 - 1582, the address
can be set to 01-08. (Default is "01".)
Scroll to the wanted address with the push button "P1" (black).
Store the selected address with the push button "P2" (yellow) and the
unit will automatically restart and enter its normal operation mode.
12
6.2.1 Address setting mode via the c.i.e.
One specific ext. Presentation unit or all the ext. Presentation units
connected to the same line (RS485) can, in normal operation, from the
c.i.e. receive a command and get ready for the "Address setting"
directly. This is done via menu H5/A9 (A7 in system EBL512 G3),
see Operating instructions for the system respectively.
6.3 Flow chart
On the following page is a flow chart, showing the SW mode setting,
Language setting, Address setting, etc.
11
Normally should not more than eight units be connected to one Ext. FBP /
DU interface board 1587, if not ext. power supply is used.
12
If the unit has no SW mode, i.e. "Not selected", it will not enter its normal
operation mode after the restart but start from the beginning again, ready for
the SW mode setting.

Panasonic Electric Works Nordic AB
MEW01297 Rev: 2 Technical Description External Presentation Unit 1728, ver. 1.4.x
15
Power on / Restart /
Reset via "JP1"
"J4" ON?
Yes
No
Yes
No
Normal operation
SW mode
setting
SW mode
xxxx - 1587?
No
Yes
Address
command from
c.i.e.
Language
setting
Address
setting
SW mode
selected?
"J4" ON?
No
No
Yes
Yes

Panasonic Electric Works Nordic AB
MEW01297 Rev: 2 Technical Description External Presentation Unit 1728, ver. 1.4.x
16
7 User definable text messages
(alarm texts)
The user definable text messages (alarm texts) are depending on
which mode the unit is running in.
In SW mode 1728 - 1587
In the c.i.e., each alarm point (zone –address) and each zone can have
an individual user definable text message (alarm text)
13
presented in
the display by fire alarm, see the Planning and Operating Instructions
for the system respectively.
The alarm texts shown in the c.i.e. will also be sent to each ext.
Presentation unit and shown in its display.
As an alternative, text messages for all or selected alarm points / zones
can be stored in each ext. Presentation unit
14
. If so, these alarm texts
will be shown instead of the alarm texts sent out from the c.i.e.
The priority order is as follows:
1. Point alarm text stored in the ext. Presentation unit.
2. Zone alarm text stored in the ext. Presentation unit.
3. Default alarm text stored in the ext. Presentation unit.
4. Text sent out from the c.i.e.
When alarm texts shall be stored in all or in some ext. Presentation
units, the unique alarm texts are created in Win512 / Win128 /
Win512 G3 and downloaded when the c.i.e. site specific data (SSD) is
downloaded.
NOTE! It is also possible to select which fire alarms that shall be
presented in the ext. Presentation unit respectively, see chapter
"Selective alarm presentation", page 7.
In SW mode 1728 - 1582
The user definable text messages (alarm texts) shown in the c.i.e. will
also be sent out to each ext. Presentation unit and shown in its display.
13
Each alarm text (up to 40 alphanumeric characters) will be shown on the
second row. The texts are created and downloaded via Win512 / Win128 /
Win512 G3.
14
At least 617 text messages can be stored in each unit.

Panasonic Electric Works Nordic AB
MEW01297 Rev: 2 Technical Description External Presentation Unit 1728, ver. 1.4.x
17
8 Commissioning a new unit / SSD
download
The cable (RS485 line) to the ext. Presentation unit(s)
15
shall be
connected.
In the EBL512 c.i.e. the 1582 / 1587 board shall be mounted. Remove
the fuse "F1" on the 1582 / 1587 board.
The EBL128 c.i.e. shall be powerless and the "RS485 transceiver
component 4552" shall be plugged on the main board (4556).
On the EBL512 G3 main board (5010) remove the fuse "F19".
The SW mode and the address have to be set in each new unit
according to chapter "SW mode & Address setting", page 12. Here
follows a brief summary (a recommended sequence of actions):
1. Connect the cable from the c.i.e. to the ext. Presentation unit's
terminal block "J1".
2. When all connections are done put back the fuse "F1" on the
1582 / 1587 board in the EBL512 c.i.e. / power up the
EBL128 c.i.e. / put back the fuse "F19" on the main board
(5010) in the EBL512 G3 c.i.e., i.e. the ext. Presentation
unit(s) will now be powered up.
3. A brand new unit will automatically be ready for the SW mode
setting.
4. After SW mode and address setting press "P2" (yellow) and the
unit will restart, see chapter "Restart", page 19.
5. Since the SSD is not downloaded in the c.i.e. there will be a
fault message in the ext. Presentation unit's display:
"No contact with Control unit".
All LEDs in the ext. Presentation unit will be turned off.
6. Now the SSD have to be downloaded via Win512 / Win128 /
Win512 G3.
16
Connect the PC to the c.i.e. In the "Win512 /
Win128 / Win512 G3 download SSD" dialog box, verify that
the "Download FBP / AAU" checkbox is marked. Start the
download of SSD.
15
One or more ext. Presentation units and/or ext. FBPs and/or Alert
Annunciation Units can be connected.
16
Via Win512 is the 1582 / 1587 board programmed (incl. its address). Via
Win512 / Win128 / Win512 G3 is each unit (e.g. an ext. Presentation unit)
programmed regarding the Address, Selective alarm presentation and if the
buzzer should be disabled. When required, also "User definable text
messages" (alarm texts).

Panasonic Electric Works Nordic AB
MEW01297 Rev: 2 Technical Description External Presentation Unit 1728, ver. 1.4.x
18
7. When the download of SSD to the c.i.e. is finished, it will
restart. Then the download of SSD to the ext. Presentation
unit(s) will take place. During the download to an ext.
Presentation unit the following will be shown in its display:
"SSD download in progress....."
8. After the download of SSD to an ext. Presentation unit, there
will be shown in its display (very quickly):
"SSD Download Memory OK"
or
"SSD Download Memory Fault"
After that the ext. Presentation unit will restart, see chapter
"Restart", page 19.
9. The unit will then start working in normal operation mode.
