Paradox K32LCD+ User manual

Printed in Canada | 02/2019 PARADOX.COM
Technical Specifications
Warranty
Warranty: For complete warranty information on this product, please refer to the Limited Warranty
Statement found on paradox.com. Your use of the Paradox product signifies your acceptance of all
warranty terms and conditions.
© 2019 Paradox Ltd. All rights reserved. Specifications may change without prior notice.
This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and
(2) This device must accept any interference received, including interference that may cause undesired
operation.
K32LCD+ Keypad
Quick Install Guide
The K32LCD+ keypad allows you to configure your Paradox system through its
interface.
Installation
1. Using a flathead screwdriver, pry the front housing assembly from the
backplate.
Figure 1: Opening the K32LCD+
Operating Voltage 9 to 16Vdc
Operating Temp. -10 to 55°C (14 to 131°F)
Power Consumption Maximum current - 150mA
Dimensions 15 x 12.6 x 2.7 cm (6 x 4.9 x 1.06 in.)
Weight 230g (8.1 oz)
Humidity 5-93%
Compatibility Compatible with MG5000, MG5050, and Spectra SP series
V2.31 or higher and SP4000, SP65 V4.90 or higher.
Compliance EN50131-3 Grade 2; Environmental Class II
K32LCD+-EI01

2. If using surface mounted cabling, you will need to knock out the plastic tab (#1)
at the top or bottom of the K32LCD+ backplate in order to for the cable to pass
through, refer to Figure 3.
3. Insert needle nose pliers into the appropriate plastic tab and carefully break off.
Figure 2: Surface-mount cabling plastic tab removal
4. Mount the backplate to the wall by securing a M3.5 #6 screw in each of the
dedicated mounting holes and tamper hole while ensuring that the top is up, as
shown in Figure 3. For EN installations, use the designated mounting holes (#3).
Figure 3: K32LCD+ Backplate
5. Connect the 4-wire combus wires to the connector bus, as shown.
Figure 4: Wiring
6. Assemble both items by joining the hooks on the backplate to their respected
slots on the front housing assembly.
7. Secure the front housing to the backplate by snapping it into place.
The installation process is now complete.
Compatibility
The K32LCD+ is compatible with Magellan and Spectra Series control panels only.
Please refer to the Technical Specifications section for more details.
1
2 2
3
1
2
33
3
Cable pass-through
2
EN Wall Tamper
Plastic tab
EN mounting holes
Mounting holes
3
