Paradox SPECTRA 1727 User manual

SPECTRA1727
USER’SGUIDE

Spectra 1727 1
TABLE OF CONTENTS
1.0 INTRODUCTION ..................................3
2.0 BASIC OPERATION ............................4
2.1 Auditory Feedback .................................4
2.2 Keypad Indicator Lights .........................6
2.3 Zone Display† ........................................6
2.4 Alarm Memory Display ..........................6
3.0 PROGRAMMING ACCESS CODES ....7
3.1 System Master Code .............................7
3.2 Programming Access Codes .................7
4.0 ARMING & DISARMING ......................9
4.1 Exit Delay ..............................................9
4.2 Disarming & Deactivating an Alarm .......9
4.3 Regular Arming .....................................10
4.4 Stay Arming ..........................................10
4.5 Force Arming ........................................11
4.6 Bypass Programming ...........................12
4.7 One-Touch Arming ...............................13

2 User’s Guide
5.0 ADDITIONAL FEATURES .................14
5.1 Programming Chime Zones .................14
5.2 Keypad Muting .....................................15
5.3 Panic Alarms ........................................15
5.4 PGM Button (Programmable Outputs) .15
6.0 FIRE ALARMS ....................................16
7.0 TESTING & MAINTENANCE ..............18
8.0 SYSTEM CHECKLIST ........................19

Spectra 1727 3
1.0 INTRODUCTION
Thank you for selecting the Spectra 1727 Security
System from Paradox Security Systems. The Spectra
1727 will give you peace of mind by providing simple and
reliable security protection. The Spectra System can
also realize your dreams of home automation. Consult
your installer to take full advantage of your Spectra
system’s capabilities.
This advanced technology security system provides you
with reliable protection and useful features that anyone
can use without memorizing complex and confusing
codes. The system consists of the Spectra Control
Panel, one Spectra Keypad, and various devices such
as motion detectors, door contacts, sirens, and lights.
The elegant and user-friendly Spectra 1686H and
1686V LED Keypads allow you to easily access your
security system's functions and provide you with an
easy-to-understand display of your security system's
alarm and operational status. All the actions performed
in your security system will be executed and displayed
through the keypad. Therefore, before using your
security system, we highly recommend you read this
manual carefully and have your installer explain basic
system operation to you.

4 User’s Guide
2.0 BASIC OPERATION
Both the Spectra 1686H and 1686V LED Keypads
function and display information the same way. The
following sections provide you with an introduction to the
buttons and indicator lights on your keypad.
The installer must enable many of the system’s
features. If the feature is not programmed, the
keypad will emit a Rejection Beep and the action
will be cancelled. Refer to System Checklist in
section 8.0 for details.
2.1 AUDITORYFEEDBACK
When you enter information on the keypad, it will guide
you with beep tones that communicate acceptance or
rejection of your entries:
Confirmation Beep: When an operation (i.e. arming/
disarming) is successfully entered or when the system
switches to a new status/mode, the keypad emits an
intermittent beep (BEEP-BEEP-BEEP-BEEP).
Rejection Beep: When the system reverts to previous
status or when an operation is incorrectly entered, the
keypad emits a continuous beep tone (BEEEEEEEEP).

Spectra 1727 5
Figure 2-1: Overview of the LED Keypad

6 User’s Guide
2.2 KEYPADINDICATORLIGHTS
All Spectra LED Keypads include colored lights which
convey your system’s current status. As explained in
Figure 2-1 on page 5, the state of each light represents a
specific condition in your system.
2.3 ZONEDISPLAY†
The numerical buttons on the 1686V/H Keypads are
designed to communicate the status of the zones in your
system. Each button corresponds to a zone in your
system. If a button’s light is off (extinguished), the
corresponding zone is closed. If a button’s light is on
(illuminated), the corresponding zone is open (i.e. open
door, movement detected, etc.).
2.4 ALARMMEMORYDISPLAY
If an alarm has occurred on a zone, the [MEM]button will
illuminate. All zones where alarms occurred will be
stored in the memory. After disarming the system, press
the [MEM]button to illuminate the buttons corresponding
to the zones that were in alarm (see section 2.3). To exit
the Alarm Memory Display, press the [CLEAR]button.
The system will erase the contents of the Alarm Memory
every time the system is armed.
†patented. See page21.

Spectra 1727 7
3.0 PROGRAMMING ACCESS CODES
Access Codes are personal identification numbers that
allow you to arm, disarm, and enter certain programming
modes. The Spectra 1727 security system supports the
following:
1 System Master Code
7 User Access Codes
For information on how each Access Code can arm or
disarm the system, refer to the table on page8.
3.1 SYSTEMMASTERCODE
The System Master Code can arm or disarm the system
using any of the methods described in section 4.0 and
can create, modify or delete any User Access Code (see
section 3.2). (Default: 123456)
3.2 PROGRAMMINGACCESS CODES
Your system can use either 4- or 6-digit Access Codes
(see page19), where each digit can be any value from 0
to 9. Six-digit codes are considered more difficult to
“crack” and, therefore, more secure. Avoid programming
simple or obvious access codes, such as your telephone
number, address or codes such as 1234.

8 User’s Guide
How Do I Program Access Codes?
1) Press [ENTER]
2) Enter the [SYSTEMMASTERCODE]
3) Enter the 2-digit [SECTION](see Table below)
4) Enter a new 4- or 6-digit [ACCESS CODE]
[ENTER]flashes. Return to step 3 to program another code.
5) Press [CLEAR] to exit
Section User Code Change Code Regular Arm Can Disarm Bypass Arm Stay Arm Force Arm
[02] Master 333333
[03] 01 33333
[04] 02 33333
[05] 03 33333
[06] 04 3 3
[07] 05 3 3
[08] 06 3 3
[09] 07 3

Spectra 1727 9
4.0 ARMING & DISARMING
Take full advantage of your Spectra 1727 system by
familiarizing yourself with all the arming methods.
4.1 EXITDELAY
Before arming, the system starts the Exit Delay to give
you enough time to exit the protected area. The READY
Light will flash during the Exit Delay and the keypad may
beep.
4.2 DISARMING& DEACTIVATINGANALARM
To disarm an armed system or an alarm, enter your
access code. An entry point, like the front door, will be
programmed with an Entry Delay. When an entry point is
opened, your alarm system will not generate an alarm
until the Entry Delay elapses or you disarm the system.
Any code can disarm the system except User Code 7
(Regular Arm Only).
How Do I Deactivate an Alarm?
Enter your [ACCESS CODE]

10 User’s Guide
4.3 REGULARARMING
This method, commonly used for day-to-day arming, will
arm all the zones in the system.
When you have correctly armed the system, the Exit
Delay (see section 4.1) will start and the ARMLight will
turn on. Please note that you can Regular Arm by using
One-Touch Arming (see section 4.7).
4.4 STAYARMING
This method allows you to remain in the protected area
while partially arming the system. Certain zones are
programmed as Stay Zones, which are bypassed when
Stay Arming. For example, when you go to sleep at
How Do I Disarm the System?
For a Stay Armed system, go to Step 2.
1) Enter through an entry point (i.e. front door).
2) Enter your [ACCESS CODE]
After the Confirmation Beep, the ARMLight will turn off.
How Do I Regular Arm?
1) Close all zones in the system.
2) Enter your [ACCESS CODE]

Spectra 1727 11
night, doors and windows can be armed without arming
other zones like motion detectors.
When you have correctly Stay Armed the system, the
Exit Delay will start (see section 4.1). The ARMLight will
flash when the Exit Delay elapses. Also, you can Stay
Arm by using One-Touch Arming (see section 4.7).
4.5 FORCEARMING
Force Arming allows you to arm the system without
waiting for all zones in the system to close. Certain
zones are programmed as Bypass Enabled Zones, which
are bypassed when Force Arming. When Force Arming,
a Bypass Enabled Zone is considered deactivated until it
closes. Once it closes, the zone is armed.
Force Arming is commonly used when a motion detector
is protecting the area occupied by a keypad. For
example, when you are in the path of a Bypass Enabled
motion detector, use Force Arming to arm the system.
How Do I Stay Arm?
1) Close all zones except Stay Zones.
2) Press the [STAY]button
3) Enter your [ACCESS CODE]

12 User’s Guide
When you have correctly Force Armed the system, the
Exit Delay will start (see section 4.1) and the ARMLight
will turn on.
4.6 BYPASS PROGRAMMING
Bypass Programming allows you to program the system
to ignore (deactivate) specified zones the next time the
system is armed. For example, you can bypass certain
zones when you are renovating. The Fire Zone and
zones that are not Bypass Enabled by your installer
cannot be bypassed.
How Do I Force Arm?
1) Close all zones except Bypass Enabled Zones.
2) Press the [FORCE]button
3) Enter your [ACCESS CODE]
How do I Bypass Zones?
1) Press the [BYP]button.
2) Key in a valid [ACCESS CODE]
3) Press the button(s) corresponding to the zones that
you want to bypass. Illuminated buttons represent
bypassed zones. To unbypass a zone, press its
corresponding button to extinguish it.
4) Press [ENTER].

Spectra 1727 13
4.6.1 Bypass Recall
Bypass Recall allows you to bypass the same zones that
were bypassed previously at the touch of a button.
4.7 ONE-TOUCH ARMING
One-Touch Arming allows you to arm the system without
using an access code. Your installer can program One-
touch Arming to either Regular or Stay Arm your system.
You can use this feature to allow specific individuals like
service personnel (i.e. cleaners) to arm without giving
them access to any other alarm system operations. For
details on Regular Arming, see section 4.3. For details
on Stay Arming, see section 4.4.
How do I use Bypass Recall?
1) Press the [BYP]button.
2) Key in a valid [ACCESS CODE]
3) Press the [BYP]button.
If desired, you can modify the entries by pressing the
button(s) corresponding to the zones that you want
to change.
4) Press [ENTER].
How do I use One-touch Arming?
Press and hold the [ENTER]button for 2 seconds.

14 User’s Guide
5.0 ADDITIONAL FEATURES
Keypad Chimes and Muting must be re-
programmed if your system suffers a total power
loss.
When you press and hold the button (as
described in section 5.1 and section 5.2) and the
keypad emits a Confirmation Beep, the Chime
feature has been enabled for that zone or Keypad
Muting has been enabled for that keypad. If the
keypad emits a Rejection Beep, these features
have been disabled.
5.1 PROGRAMMINGCHIMEZONES
This feature allows you to program which zones will be
Chime Enabled. A Chime Enabled zone will advise you
every time it is opened by causing your keypad to emit a
rapid intermittent beep tone (BEEP-BEEP-BEEP-BEEP).
Press and hold any button from [1] to [6] for 3 seconds
to activate or deactivate Chiming for zones 1 to 6 (also
see note above). For example, press and hold the [1]
button to enable Chiming on zone 1.

Spectra 1727 15
5.2 KEYPADMUTING
Press and hold the [CLEAR]button for 3 seconds to
enable or disable keypad muting (also see note on
page14). When muted, the keypad will only emit the
Confirmation Beep, the Rejection Beep, and beep when
a button is pressed.
5.3 PANICALARMS
In case of emergency, the Spectra 1727 system can
provide a panic alarm that can immediately generate an
alarm after simultaneously pressing and holding the [1]
and [3] buttons for two seconds.
5.4 PGM BUTTON(PROGRAMMABLEOUTPUTS)
Your Spectra 1727 system may include one or two
programmable outputs (PGMs). When a specific event
or condition occurs in the system, the PGM can be used
to reset smoke detectors, activate light switches in your
home or office, open/close garage doors and more. A
PGM can also be programmed to activate whenever the
[PG]button is pressed.

16 User’s Guide
6.0 FIRE ALARMS
Upon a fire alarm, the bell/siren will squawk every 0.5
seconds until silenced or reset by entering a valid access
code.
Minimizing Fire Hazards
The three most common causes of fires:
•Cooking is the leading cause of home fires in the U.S
and the leading cause of fire injuries. Cooking fires
often result from unattended cooking and human error
rather than mechanical failure of stoves or ovens.
•Careless smoking is the leading cause of fire deaths.
Smoke detectors and smolder-resistant bedding and
upholstered furniture are significant fire deterrents.
•Heating is the second leading cause of residential
fires. However, heating fires are a larger problem in
single family homes than in apartments since the
heating systems in single family homes are often not
professionally maintained.
What do I do if a Fire Zone was set off accidentally?
1) Enter your [ACCESS CODE].
2) Try to correct the problem.
3) If the problem persists, the alarm will sound again.
Enter the [ACCESS CODE]again.

Spectra 1727 17
Fire Safety Tips
•In the event of a fire, remember time is the biggest
enemy and every second counts! Escape first, then
call for help. Develop a home fire escape plan and
designate a meeting place outside. Make sure
everyone in the family knows two ways to escape
from every room. Practice feeling your way out with
your eyes closed. Never stand up in a fire, always
crawl under the smoke and try to keep your mouth
covered. Never return to a burning building for any
reason; it may cost you your life.
•Having at least one working smoke alarm dramatically
increases your chances of surviving a fire. Remember
to practice a home escape plan frequently with your
family.
Providing a Fire Warning System
Household fires are especially dangerous at night. Fires
produce smoke and deadly gases that can overcome
occupants while they sleep. To warn against fire, smoke
detectors should be installed outside each separate
sleeping area in the immediate vicinity of the bedrooms
and on each additional story of the family living unit,
including basements.

18 User’s Guide
7.0 TESTING & MAINTENANCE
With the system disarmed and the READYLight on,
activate motion detectors by walking in the protected
area. Open and close protected doors and verify that the
corresponding button illuminates. Do not use an open
flame or burning materials to test your fire detection
devices. Your installer can advise you of the best way to
test your particular system.
Under normal use, your system requires virtually no
maintenance other than regular testing. It is
recommended that the standby battery be changed
every three years. Speak to your installer about the
necessary tests and at what frequency they should be
performed.
