Parker SciLog SciPres Assembly instructions

SciLog®SciPres®
Pressure Monitor & Sensor
Installation, Operating & Maintenance Instructions

2
Parker domnick hunter has a continuous policy of product development and although the Company reserves the right to change
specification, it attempts to keep customers informed of any alterations. This publication is for general information only and
customers are requested to contact our Process Filtration Sales Department for detailed information and advice on a product’s
suitability for specific applications. All products are sold subject to the company’s Standard conditions of sale.
SciLog®and SciPres®are registered trademarks of Parker Hannifin Corporation.

Contents
Maintenance & Cleaning.............................................................................................................. 7
SciPres®Specifications - Monitor ............................................................................................... 8
SciPres®Specifications - Sensors .............................................................................................. 9
SciDoc Documentation Software for PC ................................................................................... 10
Part A: SciPres®Pressure Sensor Hardware............................................................................ 11
1.0 Overview................................................................................................................................ 11
2.0 Front Panel: Data Entry & Display....................................................................................... 12
3.0 Back Panel: Interface Options ............................................................................................. 13
4.0 Pin Out of the DB25 Female ‘Output’ Connector................................................................. 14
5.0 Single-Use Pressure Sensors.............................................................................................. 16
Part B: SciPres®Pressure Sensor Monitor Software............................................................... 17
1.0 Software Overview................................................................................................................ 17
2.0 Main Menu ........................................................................................................................... 18
3.0 Custom Calibration ............................................................................................................. 20
4.0 Reduced Pump Pulsation: Improved Sensor Precision .................................................... 22
5.0 SciPres®Pressure Sensor Printout Format ...................................................................... 23
Part C: SciPres®Data................................................................................................................. 24
1.0 Data Collection .................................................................................................................... 24
1.1 SciPres®SciDoc Data Collection Software......................................................................... 24
1.2 PC Terminal Program Settings........................................................................................... 28
3

DISCONNECT ALL POWER TO THIS UNIT BEFORE
INSTALLING, SERVICING, CLEANING OR REMOVING
THE FUSE. FAILURE TO DO SO COULD RESULT IN
BODILY HARM AND/OR PROPERTY DAMAGE.
Precautions
WARNING
OBSERVE PRECAUTIONS FOR HANDLING
ELECTROSTATIC SENSITIVE DEVICES.
CAUTION
ONLY PERMIT QUALIFIED PERSONNEL TO SERVICE
THIS EQUIPMENT. EXERCISE CARE WHEN MAKING
CHECKS, TEST AND ADJUSTMENTS THAT MUST BE
MADE WITH POWER ON. FAILING TO OBSERVE THESE
PRECAUTIONS CAN RESULT IN BODILY HARM.
WARNING
FOR CONTINUED PROTECTION AGAINST SHOCK
HAZARD, CONNECT TO PROPERLY GROUNDED
OUTLET ONLY. DO NOT REMOVE THE GROUND PRONG.
WARNING
READ this manual BEFORE operating or servicing this equipment.
FOLLOW these instructions carefully.
SAVE this manual for future reference.
DO NOT allow untrained personnel to operate, clean, inspect, service or tamper with
this equipment.
ALWAYS DISCONNECT this equipment from the power source before cleaning or
performing maintenance.
Contact Parker domnick hunter for parts, information and service.
4
USE ONLY CLASS 2 LISTED AC/DC POWER SUPPLIES
WITH THIS DEVICE.
Parker domnick hunter # 070017TOR, OR ITS
EQUIVALENT IS RECOMMENDED.
CAUTION

Précautions
5
DÉBRANCHEZ TOUT COURANT DE CETTE UNITÉ AVANT DE FAIRE
L’INSTALLATION, D’EFFECTUER L’ENTRETIEN, LE NETTOYAGE OU
AVANT DE RETIRER LE FUSIBLE. NE PAS OBSERVER CES
PRÉCAUTIONS RISQUERAIT DE CAUSER DES BLESSURES
CORPORELLES OU/ET D’ENDOMMAGER L’ÉQUIPEMENT.
ATTENTION
SOYEZ PRUDENT LORSQUE VOUS MANIPULEZ DES
APPAREILS SENSIBLES À L’ÉLECTROSTATIQUE.
PRUDENCE
AUTORISEZ SEULEMENT LE PERSONNEL QUALIFIÉ À ENTRETENIR
CET ÉQUIPEMENT. SOYEZ PRUDENT LORSQUE DES VÉRIFICATIONS,
TESTS ET AJUSTEMENTS DOIVENT ÊTRE EFFECTUÉS SOUS TENSION.
NE PAS OBSERVER CES PRÉCAUTIONS RISQUERAIT DE CAUSER DES
BLESSURES CORPORELEES.
ATTENTION
POUR ASSURER UNE PROTECTION CONTINUE CONTRE UNE DÉCHARGE
ÉLECTRIQUE, BRANCHEZ UNIQUEMENT SUR UNE PRISE CORRECTE-
MENT RELIÉE Á LA TERRE. NE RETIREZ PAS LA FICHE DE TERRE.
ATTENTION
LISEZ ce manual AVANT de faire fonctionner ou d’entretenir cet équipment.
SUIVEZ attentivement ces instructions.
CONSERVEZ ce manuel pour future référence.
NE LAISSEZ PAS du personnel non qualifié utiliser, nettoyer, inspecter, entretenir, réparer
ou manipuler cet équipement.
DÉBRANCHEZ TOUJOURS cet équipement de la source de courant avant de nettoyer ou
d’exécuter l’entretien.
APPELEZ PARKER pour pièces détachées, renseignements et entretien.
UTILISEZ UNIQUEMENT LA CLASSE 2 CI ALIMENTATIONS AC /
DC AVEC CET APPAREIL .
Parker domnick hunter # 070017TOR, OU SON ÉQUIVALENT
EST RECOMMANDÉ.
PRUDENCE

Introduction
You will find the SciPres®pressure sensors easy to use. The state-of-the-art hardware and
software design of the SciPres®pressure sensor and monitor combination allows you to measure
and document the pressure of many filtration / separation processes. With proper maintenance,
the SciPres®pressure monitor will provide many years of excellent service and performance.
Please read the following instructions carefully!
Inspections: Remove the products carefully from the shipping container. Check the contents against
the purchase order to verify that all parts are included and undamaged.
Please do the inspection now, even if the products are not used immediately. Many carriers must
receive damage claims within seven days of delivery. Please retain all packing material so unit may
be shipped safely, if necessary.
Customer Service: Parker domnick hunter customer service: If assistance is required, please contact
us at:
Parker Hannifin Manufacturing Ltd Parker Hannifin Corporation
Parker domnick hunter Parker domnick hunter
Process Filtration - Europe Process Filtration - North America
Durham Road 2340 Eastman Avenue
Birtley, Co. Durham Oxnard, California, USA 93030
DH3 2SF, England toll free: 877 784 2234
phone [phone] phone: [phone]
fax [phone] fax: [phone]
email: [e-mail] email: [e-mail]
www.parker.com/dhpharma www.parker.com/dhsingleuse
Parker domnick hunter customer service personnel will be able to serve you more efficiently if you
have the following information:
• Serial number and model name of the equipment
• Installation procedure being used
• Concise list of symptoms
• List of operating procedures and conditions in use when problem arose
Calibration
The SciPres®monitor is a calibrated device, and is calibrated with test equipment that is traceable to NIST.
A Calibration Certificate is included with each unit, and has a one year expiration date.
It is highly recommended that the monitor be calibrated on an annual basis or more often if your
Metrology Department deems it necessary.
Parker domnick hunter provides this Calibration Service, complete with a new certificate, showing the
“as found” and “as left” data.
Contact your local Parker domnick hunter representative.
6

Warranty
Country specific information can be found at: www.parker.com/termsandconditions
Standards
The SciPres®monitor and sensor conform
to the following standards:
• EN 61326-1:2006, Class B
• EN 6100-3-2:2006
• EN 6100-3-3:1995 +A1:2001 +A2:2006
• EN 61010-1 Issued: 2001/03/01
• UL 61010-1 Issued: 2004/07/12 Ed.2
• And is certified to: CAN/CSA-C22.2 No 61010-1 Ed.2
Installation & Start Up
Installation of the SciLog®SciPres®monitor must be carried out only by trained personnel in
accordance with the relevant regulations and this operations manual.
Make sure that the technical specifications and input ratings of the SciPres®pressure sensor are
observed. See “SciPres®Pressure Sensor Specifications”.
The protection provided by this equipment may be impaired if the SciPres®pressure sensor is used in
a manner inconsistent with this manual or for purposes not specified by the manufacturer.
Maintenance & Cleaning
The SciPres®pressure monitor is maintenance free. The single-use SciPres®sensors come
pre-calibrated from the factory and require no maintenance.
To remove dust, dirt and stains, the outer surfaces of the SciPres®pressure monitor may be wiped
using a soft, non-fluffing cloth moistened with water. If required, you may also use a mild detergent
or 2-propanol.
The single-use sensors may be sanitized with 0.1 Molar NaOH, or 2-propanol. They may be
autoclaved up to 2 times, or gamma-irradiated with exposure up to 45 kGy.
7
Caution: The maximum recommended pressure for the sensors is 60 psi.
If this is exceeded, problems with leakage and functionality can occur.

Hardware
Specifications - Monitor
Dimensions W: 6.0¨ (15.2 cm); Height 2.75¨ (7.0 cm); D: 5.5¨ (14.0 cm)
Weight 1.5 lb (0.69 Kg)
Enclosure Molded Plastic / Stainless Steel
Electrical
Power 110-120 or 220-240 V , 60/50 Hz AC Adaptor, 12 VDC, 500 ma Output,
Centre positive. Use only Class 2 listed AC/DC power supplies.
Operational
Range 6 to 60 ° C, 100% Humidity.
Sensor Choice of five sizes: Luer, 3/8" Barb, 1/2” Barb,
3/4” Tri-Clover (TC) Sanitary and 1” Tri-Clover (‘Ladish’) Sanitary.
I/O Port - 1
‘P1, P2 and P3’ Female Switchcraft 9 pin twist-lock,
connectors for sensor cables.
Note: Please use care connecting the monitor end of the sensor cable to
these ports as the male cable end can be damaged if mishandled.
I/O Port - 2 ‘Output’ - Female DB25, four TTL outputs for alarms, four 4-20 ma Analog
output signals, 18 bit resolution.
I/O Port - 3 ‘Printer / PC’ - Female DB9, RS-232 output for serial printer or PC.
I/O Port - 4 ‘Serial I/O’ - Female DB9 (disabled).
I/O Port - 5 ‘RS-485’ - 3 wire terminal block. RS-485 output (disabled).
I/O Port - 6 ‘12VDC 500ma’ - DC Input for AC Adaptor.
Software
Two
Operational
Modes
Pressure
Mode
Captures stored calibration data from the sensors, digital display of up to
three pressure sensor values and either Differential or Trans Membrane
pressure, with four user-definable alarms.
Custom
Calibration
Mode
Used to perform custom calibrations, selecting User-Defined Zero
and Calibration Pressure.
8

Specifications - Sensors
Power 5 VDC provided by SciPres®Pressure Monitor.
Fluid Connections Choice of five sizes: Luer, 3/8” Barb, 1/2” Barb,
3/4” Tri-Clover (TC) Sanitary and 1” Tri-Clover (‘Ladish’) Sanitary.
Wetted Materials Polysulphone meets USP Class VI and FDA 21 CFR 177.1520, all wetted
materials made with animal-free compounds.
Sensor Type Medical grade, silicone piezoresistive sensing element
with on-chip temperature compensation.
Sensor Isolation Insoluble silicone dielectric gel isolates sensing element from process
solution. The gel is a non-toxic, non-allergenic elastomeric system.
Pressure Range -5 to 60 psi (-0.34 to 4.14 bar).
Accuracy +/- 0.30 psi at -5 to 30 psi for 2 point calibrated sensors (can be improved
to -5 to 60 psi with 3 point calibration, also available)
Resolution 0.01 psi (0.001 bar).
Temperature Range 0 to 60 °C (0 to 140 °F).
Sensor Microchip EPROM, Stores Sensor ID, and Calibration Factor.
Sensor Connector & Cables Lockable and Waterproof.
9

SciDoc Documentation Software for PC
SciPres®Pressure Sensor System Documentation Software Package - purchased separately.
• Excel spreadsheet with custom macros for data compilation.
Includes WinWedge interface software. Sent ready-to-use.
• Complete process analysis with graphing of data.
• Real-time verification and documentation of process parameters.
• Includes graph of: Pressure versus Time.
Spreadsheet example:
10

Part A: SciPres®
Pressure Sensor Hardware
1.0 Overview
The SciLog®SciPres®pressure sensor system consists of two major components, the SciPres®
pressure monitor, with its power supply, and the single-use SciPres®pressure sensor, with its cable.
The monitor is a small desktop package with a backlit display and seven buttons for easy interface and
menu selections. It displays up to three measured pressures and one calculated pressure in real time.
The monitor’s output signals are in both analog and digital forms. It comes with a small wall adapter
as a universal power supply.
The monitor reads and utilizes calibration data from SciPres®sensors that have been calibrated to two
points, 0 and 30 psi, or three points, 0, 54 and 6 psi depending upon the sensor purchased. It has also
been equipped with a Supervisor Password, a Max Pressure Watchdog, and a Noise Filter setting.
The “Max Pressure Watchdog” feature records in the sensor’s memory the maximum pressure seen
by the sensor while it is connected to the SciPres®Monitor. This value is displayed for a few seconds
along with the Sensor ID and calibration information when the Monitor is powered up after a sensor is
connected.
The Filter setting is used to average the pressure signals when peristaltic pump heads are used. This
makes the display readings easier to interpret, and produces cleaner graphs that are easier to read. At
the lowest setting, the data is “live”, and at the highest, it is averaged over a four second period.
The SciPres®pressure sensors utilize a silicone piezoresisitive sensing element in a polysulphone tube
available in five sizes: Luer, 3/8" or 1/2" Barb, 3/4" and 1" ‘Ladish’ Sanitary TC connections.
All sensors are pre-calibrated at the factory, and retain the calibration data on a small chip embedded
in the sensor body. The following information is retained and is accessed upon connection to the
sensor:
• ID number (Contains Size, Lot number, Mfr Code, and Calibration date)
• Calibration Factors
• Calibration Points
• Pressure Zero Offset
• Max Pressure Value
Caution: Disconnection and reconnection of the sensor while in operation may cause
corruption of the sensor’s memorys and consequent loss of calibration. Please turn the
monitor off when connecting / disconnecting the sensors.
11
Note: The maximum recommended pressure for the sensors is 60 psi (4.14 bar). If this is
exceeded, problems with leakage and functionality can occur.

2.0Front Panel: Data Entry & Display
The front panel includes an alphanumeric display and a membrane keypad to select operational
modes and alarm settings. The display is a two line, 20 character, liquid crystal display (LCD). The
display is backlit to allow easy viewing over a wide range of lighting conditions.
The keypad consists of seven keys whose function does not change. These keys are used for basic
control and programming of the SciPres®pressure monitor. The basic key definitions are:
MENU: Allows entry into the parameter settings menu.
ENTER: Accepts the selected parameter setting.
EXIT: Exits the menu, returning to the main operational screen.
SENSOR: Recaptures the factory calibration settings stored on the sensor, and allows entry into the
custom calibration menu. This allows the user to zero and/or custom calibrate the upper span value
using equipment traceable to SI through NIST.
ON/STBY: Turns the monitor on and off.
Up and Down arrows used to change parameters within the menus.
One LED is also on the front panel, on the ON/STBY key. This indicates the monitor is connected to
power.
12

3.0 Back Panel: Interface Options
The SciPres®pressure sensor back panel provides interfacing ports for:
• Single-use SciPres®pressure sensor sensors: Female 9 pin twist-lock,
labelled “Sensor P1, P2, and P3”.
• Analog and TTL Output: Female DB25, labelled “Output”.
• RS-232 Data Output: Female DB9, labelled “Printer/PC”.
• 2nd RS-232: Female DB9, labelled “Serial I/O” (Disabled).
• RS-485: 3 wire terminal block, labelled “RS-485”, (Disabled).
• Input Power: Round male connector for AC Adapter, labelled “12 VDC / 500 mA”.
SENSOR PORTS: The single-use pressure sensors are connected to these three using the included
cables.
OUTPUT PORT: Provides four 4-20 mA analog outputs and TTL outputs for the four alarms,
Hi / Low for each pressure channel. TTL outputs provide a 0 / 5 VDC control signal, carry minimal
current. (See Pin out on next page.)
PRINTER / PC PORT: To connect the SciPres®pressure monitor to your PC for data archival.
Alternatively, you may connect to a serial printer via this port.
SERIAL I/O PORT: RS-232 – Disabled.
RS-485 PORT: Disabled.
POWER INPUT JACK: Connect the AC adapter here.
Note: Please use care connecting the monitor end of the cable to these ports as the male cable
end can be damaged if mishandled.
13

4.0 Pin Out of the DB25 Female ‘Output’ Connector
Analog Outputs
For 4-20 ma output of Pressure at P1 (Analog 1), use pins 2 (4-20 -) and 14 (4-20 +). If excitation is
needed in the loop, connect pin 1 (Vpwr) to pin 14 (4-20 +), and connect the output cable to pin 2
(4-20 -) and pin 15 (Gnd).
For 4-20 ma output of Pressure at P2 (Analog 2), use pins 4 (4-20 -) and 16 (4-20 +). If excitation is
needed in the loop, connect pin 3 (Vpwr) to pin 16 (4-20 +), and connect the output cable to pin 4
(4-20 -) and pin 17 (Gnd).
For 4-20 ma output of Pressure at P3 (Analog 3), use pins 6 (4-20 -) and 18 (4-20 +). If excitation is
needed in the loop, connect pin 5 (Vpwr) to pin 18 (4-20 +), and connect the output cable to pin 6
(4-20 -) and pin 19 (Gnd).
For 4-20 ma output of Pressure at TM or DP (Analog 4), use pins 8 (4-20 -) and 20 (4-20 +).
If excitation is needed in the loop, connect pin 7 (Vpwr) to pin 20 (4-20 +), and connect the output
cable to pin 8 (4-20 -) and pin 21 (Gnd).
14
1
1
2
2
3
3
4
4
D D
C C
B B
A A
Title
Number RevisionSize
A
Date: 4/1/2006 Sheet of
File: N:\1_Clients\..\Analog Main.SchDoc Drawn By:
Analog1+
Analog1-
F1
0.1A
Vpwr
Analog2+
Analog2-
Analog3+
Analog3-
Analog4+
Analog4-
1
20
2
21
3
22
4
23
5
24
6
25
7
8
9
10
11
12
13
14
15
16
17
18
19
27
26
P1
D Connector 25
OUT1N
OUT2N
OUT3N
OUT1
OUT2
OUT3
OUT4
OUT4N
1 2
R4 1.0K
1 2
R3 1.0K
1 2
R2 1.0K
1 2
R1 1.0K
ACLK
ADATA
ALATCH1
ALATCH2
ALATCH3
ALATCH4
Vpwr
+3.3V
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
P2
CON2X8
OUT1N
OUT2N
OUT3N
OUT4N
1 2
3
D3
MMBD1503A
+5.0V
+5.0V
1 2
3
D2
MMBD1503A
+5.0V
1 2
3
D1
MMBD1503A
+5.0V
1 2
3
D4
MMBD1503A
+5.0V
OUT1N OUT2N OUT3N OUT4N

The use of an end-user supplied analog loop power source is presented below:
TTL Alarm Outputs
P1 Hi / Lo Alarm: TTL 1 Pins 11 (Out0) and 13 (Gnd)
P2 Hi / Lo Alarm: TTL 2 Pins 24 (Out1) and 13 (Gnd)
P3 Hi / Lo Alarm: TTL 3 Pins 12 (Out2) and 13 (Gnd)
TM or DP Hi / Lo Alarm: TTL 4 Pins 25 (Out3) and 13 (Gnd)
TTL outputs are either 0 or 5 VDC, and carry minimal current. They are for TTL inputs on a PLC, or
control of a 5 VDC solid state relay, with an enable voltage of 3 VDC.
15

5.0Single-Use Pressure Sensors
Connector Type Part Code (Packs of 5) Compatible
Tubing Sizes
Max. Flow Rate* Max. Operating
Pressure
2-pt. Calibration 3-pt. Calibration (L / min) (gpm / psi) (m3 / h / bar)
Luer 080-699PSX-5 080-699PSX-3P-5 ID 0.03¨ to 0.31¨ 1.0 0.26 0.23 60 psi
3/8¨ Barb 080-694PSX-5 080-694PSX-3P-5 ID 0.31¨ to 0.38¨ 8.0 2.11 1.81 60 psi
1/2¨ Barb 080-695PSX-5 080-695PSX-3P-5 ID 0.50¨ 17.0 4.49 3.86 60 psi
3/4¨ Tri-Clover (TC) 080-696PSX-5 080-696PSX-3P-5 Tubing with 3/4¨ TC 31.0 8.19 7.03 60 psi
1¨ Tri-Clover ‘Ladish’ 080-697PSX-5 080-697PSX-3P-5 Tubing with 1¨ TC Ladish 60.0 15.9 13.6 60 psi
* Maximum flow rate at 1 psi
Luer 3/8¨ Barb 1/2¨ Barb 3/4¨ Tri-Clover 1¨ Tri-Clover ‘Ladish’
16

Part B: SciPres®Pressure Sensor Monitor Software
1.0 Software Overview
The SciPres®pressure monitor digitally displays inputs from up to three SciPres®pressure sensors
simultaneously, while also calculating and displaying either trans-membrane or differential pressure.
It has also been equipped with a “Supervisor Password”, a “Max Pressure Watchdog”, and a
“Filter”setting.
The “Max Pressure Watchdog” feature records in the sensor’s memory the maximum pressure seen
by the sensor while it is connected to the SciPres®monitor. The maximum recommended pressure
for the sensors is 60 psi (4.14 bar). If this is exceeded, problems with leakage and functionality can
occur. This value is displayed for a few seconds along with the Sensor ID and Cal information when
the monitor is powered up and a sensor connected.
The “Filter” setting is used to average the pressure signals when peristaltic pump heads are used.
This increases the sensor precision as well as accuracy and makes the display readings easier to
interpret when compared to ever changing values caused by pulsation. Thus it produces cleaner
graphs that are easier to read. At the lowest setting, the data is ‘live’, and at the highest, it is
averaged over a 4 second period. Please refer to the graph in section 4.0.
The “Supervisor Password” is a number between 1 and 9999 that must be entered to access the
Menu and its settings. Setting the password to 0 disables it.
The “Main Menu” allows you to change the pressure units, (psi, kPa, bar, mmHg are available) the
high and low analog range settings, adjust the baud rate and print time, change the mode between
trans-membrane, differential and none, adjust the “Filter” setting, as well as configure user-defined
hi / low pressure alarms for all four displayed values.
The SciPres®pressure monitor will also allow custom zero and single point full span calibration of
the sensors through the use of the “Sensor” button on the front panel. This is a modification of the
existing factory two or three point calibration. This can be reset or cleared if desired.
17

18
P1: 0.00 P2: 0.00
P3: 0.00 TM: 0.00
PRES UNITS: psi
RANGE HI: 100 psi
Analog out at 100%
RANGE LO: 0.0 psi
Analog out at 0%
SERIAL: BR: 9600
WL: 8 SB: 2 PT: N
PRINT TIME: 5 Seconds
MODE: TRANSMEMBRANE
TYPE: SCIPRES
CONSTANT PRESSURE:
OFF
FILTER: 9
See 3.1
See 3.2
See 3.3
See 3.4
See 3.5
See 3.6
See 3.7
See 3.8
1 min, 12 max
2.0 Main Menu
Main Screen
Menu
Menu
Menu
Menu
Menu
Menu
Menu
Menu
Menu
See 3.9
See 3.10
Off, P1, P2, P3, TM, DP
SciPres®, OEM
Transmembrane,
Differential, None
1 to 60 seconds
1200, 2400, 4800,
9600, 19200, 28800,
38400, 57600
Min 0.00
689.4 kPa, 6.80 bar
5171 mmHg
psi, kPa, bar, mmHg
HI-ALARM P1: 0.0 psi
LO-ALARM P1: 0.0 psi
SET TIME / DATE...
TIME: 16:10
MONTH: DECEMBER
DAY OF MONTH: 28
YEAR: 2006
FACTORY RESET: NO
YES & ENTER TO RESET
ARE YOU SURE: NO
PASSWORD: 0
See 3.11
See 3.12
See 3.13
See 3.14
See 3.15
See 3.16
See 3.17
See 3.18
Menu
Enter
Enter
Enter
Enter
Enter
Menu
Enter
Enter
See 3.19
Yes, No
Yes, No
24 Hour Time
Press Menu to
bypass to Password
Min: 0.00
Menu See HI Range above

2.0 Main Menu, Continued:
SUMMARY: This menu allows the setting of various parameters as they relate to your process.
Use “Menu” to scroll through the menu, the up/down arrow keys to scroll through choices, and
“Enter” to select the choice.
2.1 MAIN SCREEN: Displays all three pressures, P1, P2, P3 and the calculated Trans-Membrane
pressure, TM, or Differential pressure DP.
2.2 PRESSURE UNITS: Use the up / down arrows to select between psi (pounds/square inch),
kPa (kilo Pascal), bar, or mmHg (millimeters of Mercury). Default = psi.
2.3 RANGE HI: Use to set the upper range limit of the Analog output signal (100% full scale).
Allowable maximums are 100 psi, 689.4 kPa, 6.80 bar, 5171 mmHg. Default = 100.0 psi.
Do Not pressurize beyond 60 psi. (This setting is to make replacing a 0-100 psi transmitter
easy to replace without having to re-scale the interface.)
2.4 RANGE LO: Use to set lower range limit of the Analog output signal (0.0% of full scale).
Default minimum is 0.0 regardless of scale.
2.5 SERIAL: Displays the RS-232 serial output parameters. Only baud rate can be changed.
Available rates are 1200, 2400, 4800, 9600, 19200, 28800, 38400 and 57600. Default = 9600.
2.6 PRINT TIME: Used to set the data output interval, 1 to 60 sec. Default = 5 sec.
2.7 MODE: Use to set display and output mode. Trans-membrane will display and output TM,
Differential will display and output DP, None will only display and output P1, P2 and P3.
Default = TM.
2.8 TYPE: Sets type of pressure sensor in use, Default is Calibrated. OEM is under development.
2.9 CONSTANT PRESSURE: Controls 4-20 ma Analog Output 4 inversely as the pressure source
changes between the Hi and Lo Alarm settings. Default = OFF.
2.10 FILTER: Used to filter out (average) pulsations from peristaltic pumps. Pressure changes are
delayed slightly based on setting. Range is 1-12, with 1 = No filter, 12 = Max filter. Default = 9.
2.11 HI-ALARM P1: Used to set High Pressure Alarm, Max value of 60.0 psi. Hi-Alarms exist for all
four pressure outputs. Default = 0.0 psi.
2.12 LO-ALARM P1: Used to set Low Pressure Alarm. Lo-Alarms exist for all four pressure
outputs. Default = 0.0 psi.
2.13 SET TIME / DATE: Press “Enter” to enter this submenu, press Menu to bypass to Password.
2.14 TIME: Use up / down arrows to set current time in 24 hour format, HH:mm, and press “Enter”.
2.15 MONTH: Use up / down arrows to set current Month, and press “Enter”.
2.16 DAY OF MONTH: Use up / down arrows to set current Date, and press “Enter”.
2.17 YEAR: Use up / down arrows to set current Year, and press “Enter”.
2.18 FACTORY RESET: Used to restore the SciPres®pressure sensor pressure monitor to the
factory default values. Change No to Yes using the arrow keys and press “Enter” to reset,
change No to Yes on the “Are You Sure?” screen and press “Enter” again to finish the process.
2.19 PASSWORD: Used to set a Supervisor password. Requires entry of the password to enter the
Menus. Choose a number from 1-9999, setting of 0 disables the password feature.
19

20
SENSOR PORT: P1
CUSTOM CAL....
SENSOR PORT: P1
SENSOR ZERO: NO
YES & ENTER TO ZERO
CAL PRESS: 60.00 psi
CUSTOM CAL SENSOR
PRESS ENTER TO CAL
CALL IN PROGRESS
Please Wait: 1...2...
CUSTOM CAL FACTORS:
CF: 0.511 PZ: 0.0
CALIBRATION ERROR!
OUT OF RANGE
SENSOR RESET: NO
YES & ENTER TO RESET
See 3.1
See 3.2
See 3.3
See 3.4
See 3.5
See 3.6
3.0 Custom Calibration Menu
Press “Sensor” button. The
following will be displayed:
Enter
Enter
Enter
Enter
Enter
See 3.7
Press Enter
Use up / down arrows to
choose port, press “Enter”, and
calibration data will reload.
