Parker R34 Installation and maintenance instructions

Installation & Service Instructions:
1R110
R34 & RA34 1/8" & 1/4" Manifold
Miniature Regulators
ISSUED: February, 2010
Supersedes: September, 2008
Doc.# 1R110, EN# 100185, Rev. 3
Pneumatic Division
Richland, Michigan 49083
269-629-5000
WARNING
To avoid unpredictable system behavior that can cause personal injury
and property damage:
• Disconnect electrical supply (when necessary) before installation,
servicing, or conversion.
• Disconnectairsupplyanddepressurizeallairlinesconnectedtothis
product before installation, servicing, or conversion.
• Operate within the manufacturer’s specied pressure, temperature,
and other conditions listed in these instructions.
• Medium must be moisture-free if ambient temperature is below
freezing.
• Serviceaccordingtoprocedureslistedintheseinstructions.
• Installation, service, and conversion of these products must be
performed by knowledgeable personnel who understand how
pneumatic products are to be applied.
• Afterinstallation,servicing,orconversion,airandelectricalsupplies
(when necessary) should be connected and the product tested for
proper function and leakage. If audible leakage is present, or the
product does not operate properly, do not put into use.
• Warningsandspecicationsontheproductshouldnotbecoveredby
paint, etc. If masking is not possible, contact your local representative
for replacement labels.
!
WARNING
FAILURE OR IMPROPER SELECTION OR IMPROPER USE OF THE
PRODUCTSAND/ORSYSTEMSDESCRIBEDHEREINORRELATEDITEMS
CANCAUSEDEATH,PERSONALINJURYANDPROPERTYDAMAGE.
This document and other information from The Company, its subsidiaries
and authorized distributors provide product and/or system options for further
investigation by users having technical expertise. It is important that you
analyze all aspects of your application, including consequences of any failure
and review the information concerning the product or systems in the current
product catalog. Due to the variety of operating conditions and applications for
these products or systems, the user, through its own analysis and testing, is
solely responsible for making the final selection of the products and systems
and assuring that all performance, safety and warning requirements of the
application are met.
The products described herein, including without limitation, product features,
specifications, designs, availability and pricing, are subject to change by The
Company and its subsidiaries at any time without notice.
EXTRACOPIESOFTHESEINSTRUCTIONSAREAVAILABLEFORINCLUSION
INEQUIPMENT/MAINTENANCEMANUALSTHATUTILIZETHESEPRODUCTS.
CONTACTYOURLOCALREPRESENTATIVE.
!
WARNING
Product rupture can cause serious injury.
Do not connect regulator to bottled gas.
Do not exceed maximum primary pressure rating.
!
Safety Guide
For more complete information on recommended application
guidelines, see the Safety Guide section of Pneumatic Division
catalogs or you can download the Pneumatic Division Safety Guide
at: www.parker.com/safety
➤
➤
➤
➤
➤
➤
Relieving Regulator
Adjustable
Non-Relieving Regulator
Adjustable
Introduction
Follow these instructions when installing, operating, or servicing the
product.
Application Limits
Maximum Inlet Pressure kPa PSIG bar
2068 300 21.0
Ambient Temperature Range: -40°C to 65.5°C (-40°F to 150°F)
Symbols
Installation
1. The regulator should be installed with reasonable accessibility for
service whenever possible - repair service kits are available. Keep pipe
and tubing lengths to a minimum with inside clean and free of dirt and
chips. Pipe joint compound should be used sparingly and applied only
to the male pipe - never into the female port. Do not use PTFE tape to
seal pipe joints - pieces have a tendency to break off and lodge inside
unit, possibly causing malfunction.
2. Install regulator so that media flow is in the direction of arrow (on
R342’s, R344’s & RA4’s), and into port labelled “IN”. Installation must
be upstream (high pressure) side and as close to the devices it is to
service (valve, cylinder, tool, etc.). Mounting may be in any position.
3. Gauge ports are located on both sides of the regulator body for your
convenience. It is necessary to install a gauge or pipe plugs into each
port during installation.
4. For protection against rust, pipe scale, and other foreign matter, install
a filter on the upstream (high pressure) side as close to the regulator
as possible.
Operation
1. Before turning on the media source, disengage the Adjusting Knob
by pulling upward. Turn the Adjusting Knob counterclockwise until
compression is released from the Control Spring. Then turn on media
source and adjust regulator to desired secondary pressure by turning
Adjusting Knob clockwise. This permits pressure to build up slowly,
preventing any unexpected operation of the valve, cylinders, tools, etc.,
attached to the line. Adjustment to desired secondary pressure can be
made only with primary pressure applied to the regulator.
2. To decrease regulator pressure setting, always reset from a pressure
lower than the final setting desired. For example, lowering the secondary
pressure from 550 to 410 kPa (80 to 60 PSIG) is best accomplished by
dropping the secondary pressure to 350 kPa (50 PSIG), then adjusting
upward to 410 kPa (60 PSIG).
Push the Adjusting Knob down to lock the pressure setting.
R342’s&R344’sReducedPressureSpringRanges
“A” Range = 1 – 25 PSI
“B” Range = 2 – 60 PSI
“C” Range = 2 – 125 PSI
RA4’sDiaphragmFunction
“C” or “P” = 1 – 25 PSI
“D” or “W” = 2 – 60 PSI
“F” or “R” = 2 – 125 PSI

R34 & RA4 Regulators 1R110
Lightly grease with provided lubricant.
Inspect for nicks, scratches, and surface imperfections.
If present, reduced service life is probable and future
replacement should be planned.
Clean with lint-free cloth.
Service
!
CAUTION:     
SHUT OFF MEDIA SOURCE and exhaust the primary and
secondary pressure before disassembling regulator unit. (Turning
the Knob counterclockwise reduces regulator’s setting, but does
not vent downstream pressure on non-relieving regulators.)
!
CAUTION:    
Lubricate parts with a mineral based oil / grease or silicone
grease. DO NOT use synthetic oils / greases such as esters.
A. ServicingtheBonnetandDiaphragmassembly-
1. Disengage the Adjusting Knob by pulling upward.Turn Adjusting Knob
counterclockwise until the compression is released from the Pressure
Control Spring.
2. Unscrew the threaded Bonnet Assembly. Next, disassemble, clean,
and carefully inspect parts for wear and / or damage. If replacement is
necessary, use parts from service kits.
3. Lubricate O-ring and Lip Seals with grease (supplied with kits).
4. Install Diaphragm Assembly into Body. Then install Bonnet Assembly
to Body and tighten to 11.3 to 13.6 Nm (100 to 120 in. lb.).
B. ServicingthePoppetAssembly-
1. Exhaust system media pressure as previously described. Then remove
Bonnet by unscrewing it from Body. Next, remove Valve Seat, Poppet
Return Spring and Poppet Assembly.
2. Next, disassemble, clean, and carefully inspect parts for wear and / or
damage. If replacement is necessary, use parts from service kits.
3. Lubricate O-ring and sliding surfaces using grease supplied with
service kit.
4. Install Diaphragm Assembly into Body Assembly. Assemble Bonnet
Assembly into Body and tighten per Figure 1.
5. Turn on media source and adjust to desired secondary pressure as
described in the Operation section.
Turn on media pressure and check regulator for leakage. If leakage
occurs, DO NOT OPERATE — conduct repairs again.
If you have questions concerning how to service this unit, contact your
local authorized dealer or your customer service representative.
Knob
Bonnet - Torque:
11.3 to 13.6 Nm (100 to 120 in. lb.)
Adjusting Screw Assembly
Control Spring
Spring, Return
Diaphragm Assembly
(Includes Upper Diaphragm Plate
& Lower Diaphragm Button and Sea
l
Inner Valve
Assembly (Poppet)
Body
Valve Seat
ManifoldVersionShown
Figure 1
Service / Parts Kits Available
Description R34 1/8", 1/4" & Manifold
Gauge, 0 to 60 (0 to 4 bar) K4515N18060
Gauge, 0 to 160 (0 to 11 bar) K4515N18160
Mounting Bracket / Nut SA161X57
Panel Mount Nut R05X51
Regulator Repair Kit
(Relieving) GRP-96-725
Regulator Repair Kit
(Non-Relieving) GRP-96-726
Spring, 0-25 PSIG (0 to 1.7 bar) GRP-95-111
Spring, 0-60 PSIG (0 to 4 bar) GRP-96-718
Spring, 0-125 PSIG (0 to 8.6 bar) GRP-96-717
