Parker AC15 Series Assembly instructions

DOC-0017-03-EN: AC15 Series - Hardware Installation Manual
1 (125) DOC-0017-03-EN-B 04.04.2023
DOC-0017-03-EN-B
04.04.2023
AC15 Series
Variable Speed Drive
Hardware Installation Manual

DOC-0017-03-EN: AC15 Series - Hardware Installation Manual
2 (125) DOC-0017-03-EN-B 04.04.2023
1 Safety Requirements
IMPORTANT: Please read this information BEFORE installing the equipment.
The contents of this manual have been verified against the associated hardware and software. Although
every effort has been taken to ensure the accuracy of this document, it may be necessary without notice, to
make amendments or correct omissions.
Parker Hannifin Manufacturing cannot accept responsibility for damage, injury, or expenses resulting there
from.
1.1 Intended Users
This manual is to be made available to all persons who are required to install, configure or service
equipment described herein, or any other associated operation.
The information given is intended to highlight safety issues, and to enable the user to obtain maximum
benefit from the equipment.
1.2 Application Area
The equipment described is intended for industrial motor speed control utilising AC induction motors or PMAC
motors.
1.3 Personnel
Installation, operation and maintenance of the equipment should be carried out by competent personnel. A
competent person is someone who is technically qualified and familiar with all safety information and
established safety practices; with the installation process, operation and maintenance of this equipment;
and with all the hazards involved.
1.4 Product Warnings, Cautions and Information notices
Special attention must be paid to the information presented in warning, caution and information notices when
they appear in this manual. Definitions of caution, warning and information notices are shown below:
DANGER
Risk of electric shock
WARNING
Hot surfaces
WARNING
Warns of danger to personnel. Refer to documentation.
CAUTION
Warns of danger to equipment. Refer to documentation.
EARTH / GROUND
Protective Earth Conductor Terminal
INFORMATION
Read further information before proceeding.

DOC-0017-03-EN: AC15 Series - Hardware Installation Manual
DOC-0017-03-EN-B 04.04.2023 3 (125)
1.5 Hazards
Electric Shocks
DANGER!
Ignoring the following may result in injury:
•This equipment can endanger life by exposure to rotating machinery
and high voltages.
•The equipment must be permanently earthed due to the high earth
leakage current, and the inverter motor must be connected to an
appropriate safety earth.
•Ensure all incoming supplies are isolated before working on the
equipment. Be aware that there may be more than one supply
connection to the inverter.
•There may still be dangerous voltages present at power terminals
(motor output, supply input phases, DC bus and the brake, where
fitted) when the motor is at standstill or is stopped.
•For measurements use only a meter to IEC 61010 (CAT III or higher).
Always begin using the highest range.
CAT I and CAT II meters must not be used on this product.
•Allow at least 10 minutes for the inverter's capacitors to discharge to
safe voltage levels (<50V). Use the specified meter capable of
measuring up to 1000V dc & ac rms to confirm that less than 50V is
present between all power terminals and between power terminals and
earth.
•Unless otherwise stated, this product must NOT be dismantled. In the
event of a fault the inverter must be returned. Refer to "Routine
Maintenance and Repair".

DOC-0017-03-EN: AC15 Series - Hardware Installation Manual
4 (125) DOC-0017-03-EN-B 04.04.2023
Safety & EMC Requirements
Where there is a conflict between safety and EMC requirements, personnel safety shall always take
precedence.
Safety
WARNING!
Ignoring the following may result in injury or
damage to equipment:
•Never perform high voltage resistance checks on the wiring without
first disconnecting the inverter from the circuit being tested.
•Whilst ensuring ventilation is sufficient, provide guarding and /or
additional safety systems to prevent injury or damage to equipment.
•When replacing an inverter in an application and before returning to
use, it is essential that all user defined parameters for the product’s
operation are correctly installed.
•When replacing an inverter in an application and before returning to
use, it is essential that all user defined parameters for the product’s
operation are correctly installed.
•All control and signal terminals are SELV, i.e. protected by double
insulation. Ensure all external wiring is rated for the highest system
voltage.
•Thermal sensors contained within the motor must have at least basic
insulation.
•All exposed metalwork in the Inverter is protected by basic insulation
and bonded to a safety earth.
•RCDs are not recommended for use with this product but, where their
use is mandatory, only Type B RCDs should be used.
EMC
WARNING!
Ignoring the following may result in injury or
damage to equipment:
•In a domestic environment this product may cause radio interference in
which case supplementary mitigation measures may be required.
•This equipment contains electrostatic discharge (ESD) sensitive parts.
Observe static control precautions when handling, installing and
servicing this product.
•This is a product of the restricted sales distribution class according to
IEC 61800-3. It is designated as “professional equipment” as defined in
EN61000-3-2 for AC15: Frame sizes 1 (all), 2 (3ø products only) & 3
(400V products only). Permission of the supply authority shall be
obtained before connection to the public low voltage supply.
For all other Frame sizes not specified above, connection to the public
LV supply must be agreed case by case between manufacturer,
installer or user and distribution network operator.

DOC-0017-03-EN: AC15 Series - Hardware Installation Manual
DOC-0017-03-EN-B 04.04.2023 5 (125)
Application Risk & Risk Assessment
Application Risk
CAUTION!
•The specifications, processes and circuitry described herein are for
guidance only and may need to be adapted to the user’s specific
application.
•Parker cannot guarantee the suitability of the equipment described in
this Manual for individual applications.
Risk Assessment
CAUTION!
•Under fault conditions, power loss or unintended operating conditions,
the inverter may not operate as intended. In particular:
oStored energy might not discharge to safe levels as quickly as
suggested and can still be present even though the inverter
appears to be switched off.
oThe motor's direction of rotation might not be controlled.
oThe motor speed might not be controlled.
oThe motor might be energized.
•An inverter is a component within an inverter system that may
influence its operation or effects under a fault condition. Consideration
must be given to:
oStored energy
oSupply disconnects
oSequencing logic
o
Unintended operation

DOC-0017-03-EN: AC15 Series - Hardware Installation Manual
6 (125) DOC-0017-03-EN-B 04.04.2023
2 Manufacturing Location
Germany
Parker Hannifin Manufacturing Germany GmbH & Co. KG
Electric Motion & Pneumatic Division (EMPD)
Robert-Bosch-Strasse 22
77656 Offenburg (Germany)
Tel.: + 49 (0781) 509-0
Website: www.parker.com/eme
Certified according to ISO 9001:2015
Parker Hannifin Manufacturing Germany GmbH & Co. KG - Sitz: Bielefeld - Amtsgericht: Bielefeld HRA 15699
persönlich haftende Gesellschafterin: Parker Hannifin GmbH - Sitz: Bielefeld - Amtsgericht Bielefeld HRB 35489
Geschäftsführung der Parker Hannifin GmbH: Ulrich Jochem, Achim Kohler, Andreas Paulsen, Kirsten Stenvers
Vorsitzender des Aufsichtsrates: Dr.-Ing. Gerd Scheffel

DOC-0017-03-EN: AC15 Series - Hardware Installation Manual
DOC-0017-03-EN-B 04.04.2023 7 (125)
3 Table of Contents
1Safety Requirements........................................................................................................................... 2
1.1 Intended Users............................................................................................................................ 2
1.2 Application Area .......................................................................................................................... 2
1.3 Personnel .................................................................................................................................... 2
1.4 Product Warnings, Cautions and Information notices................................................................. 2
1.5 Hazards....................................................................................................................................... 3
Electric Shocks................................................................................................................................................. 3
Safety & EMC Requirements ........................................................................................................................... 4
Application Risk & Risk Assessment ............................................................................................................... 5
2Manufacturing Location...................................................................................................................... 6
3Table of Contents ................................................................................................................................ 7
4Introduction........................................................................................................................................ 10
4.1 About this Hardware Installation Manual .................................................................................. 10
Users.............................................................................................................................................................. 10
Manual Organisation ...................................................................................................................................... 10
Manual Revision............................................................................................................................................. 10
4.2 Before You Start… .................................................................................................................... 10
Equipment Inspection .................................................................................................................................... 10
Equipment Storage ........................................................................................................................................ 10
Initial Steps..................................................................................................................................................... 11
Unpacking the Product................................................................................................................................... 11
5Product Overview.............................................................................................................................. 12
6Installation.......................................................................................................................................... 15
6.1 Mechanical ................................................................................................................................ 15
Product Dimensions & Weights ..................................................................................................................... 15
Product Fixing Dimensions ............................................................................................................................ 16
Lifting the Inverter .......................................................................................................................................... 17
Mounting the Inverter ..................................................................................................................................... 17
Ventilation Clearance Requirements ............................................................................................................. 18
Wiring Bracket (Optional) ............................................................................................................................... 19
6.2 Electrical.................................................................................................................................... 20
Power Stack Wiring........................................................................................................................................ 20
Control Board Wiring...................................................................................................................................... 28
Control Board Communications Wiring.......................................................................................................... 33
6.3 µSD Memory Card .................................................................................................................... 34
Installation ...................................................................................................................................................... 34
6.4 Remote Mounted 6901 MMI ..................................................................................................... 35
Order Codes................................................................................................................................................... 35
Installation ...................................................................................................................................................... 35
Cable Connection........................................................................................................................................... 36
7Associated Equipment...................................................................................................................... 37
7.1 AC Line Fuses........................................................................................................................... 38
1ø, 230V Products ......................................................................................................................................... 38
3ø, 230V Products ......................................................................................................................................... 38
3ø, 400V Products ......................................................................................................................................... 38
7.2 External EMC Filters ................................................................................................................. 39
7.3 AC Line Chokes ........................................................................................................................ 39
1ø, 230V Products ......................................................................................................................................... 39
3ø, 230V Products ......................................................................................................................................... 39
3ø, 400V Products ......................................................................................................................................... 40
Calculation ..................................................................................................................................................... 40
7.4 Dynamic Braking Resistor......................................................................................................... 41
Resistor Power Requirement Calculation ...................................................................................................... 41
Resistor Protection Devices........................................................................................................................... 42
7.5 AC Motor Chokes...................................................................................................................... 43
1ø, 230V Products ......................................................................................................................................... 43
3ø, 230V Products ......................................................................................................................................... 44
3ø, 400V Products ......................................................................................................................................... 44
Calculation ..................................................................................................................................................... 45

DOC-0017-03-EN: AC15 Series - Hardware Installation Manual
8 (125) DOC-0017-03-EN-B 04.04.2023
8Safe Torque Off (STO): SIL2, PLd.................................................................................................... 46
8.1 Overview ................................................................................................................................... 46
Introduction .................................................................................................................................................... 46
STO Functional Description ........................................................................................................................... 47
8.2 Alignment to European Standards............................................................................................ 47
EN ISO13849-1:2015 (Safety of machinery – Safety-related parts of control systems) ................................ 47
EN61800-5-2:2017 (Adjustable speed electrical power drive systems) & EN61508:2010 (Functional safety of
electrical/electronic/programmable electronic safety-related systems).......................................................................... 48
8.3 Specification.............................................................................................................................. 48
Safety ............................................................................................................................................................. 48
EMC ............................................................................................................................................................... 49
8.4 STO Operation .......................................................................................................................... 49
Terminal Identifications .................................................................................................................................. 49
Input State Truth Table .................................................................................................................................. 50
Example Applications..................................................................................................................................... 50
Technical Specification .................................................................................................................................. 55
8.5 STO Safety Warnings & Limitations.......................................................................................... 55
8.6 STO Functional Checks ............................................................................................................ 57
Comprehensive Checks ................................................................................................................................. 58
Test Protocol Specimen ................................................................................................................................. 60
Regular Checks.............................................................................................................................................. 60
8.7 STO Troubleshooting................................................................................................................ 61
9Basic Drive Operation....................................................................................................................... 62
9.1 ‘Local’ Operation ....................................................................................................................... 62
Minimum Connections.................................................................................................................................... 62
Onboard Drive Keypad & Display Overview .................................................................................................. 63
6901 Remote Keypad & Display Overview .................................................................................................... 64
Keypad Menu Navigation Examples .............................................................................................................. 66
Basic Drive Setup........................................................................................................................................... 67
9.2 ‘Remote’ Operation (Using Pre-Defined Macro’s) .................................................................... 74
Enable ‘Remote’ Control Mode ...................................................................................................................... 74
Selecting & Loading A Macro......................................................................................................................... 74
Running The Drive ......................................................................................................................................... 75
Application ‘1’: Standard (Basic Speed Control) ............................................................................................ 76
Application ‘2’: Auto / Manual......................................................................................................................... 77
Application ‘3’: Presets................................................................................................................................... 78
Application ‘4’: Raise / Lower ......................................................................................................................... 79
Application ‘5’: PID ......................................................................................................................................... 80
Application ‘6’: Aux Comms ........................................................................................................................... 81
10 Routine Maintenance & Repair ........................................................................................................ 82
10.1 Routine Maintenance ................................................................................................................ 82
10.2 Preventative Maintenance ........................................................................................................ 82
Main Duct Cooling Fans................................................................................................................................. 82
DC Link Capacitors ........................................................................................................................................ 82
10.3 Repair........................................................................................................................................ 82
11 Compliance ........................................................................................................................................ 83
11.1 Applicable Standards ................................................................................................................ 83
11.2 European Compliance............................................................................................................... 83
CE Marking .................................................................................................................................................... 83
EMC Compliance ........................................................................................................................................... 85
EMC Standards.............................................................................................................................................. 85
EMC Installation Guidance ............................................................................................................................ 92
Harmonic Information..................................................................................................................................... 98
11.3 North American & Canadian Compliance ............................................................................... 107
North American Compliance ........................................................................................................................ 107
Canadian Compliance.................................................................................................................................. 107
North American & Canadian Compliance Information ................................................................................. 107
11.4 Environmental Compliance ..................................................................................................... 109
REACH (Restriction, Evaluation, Authorisation & Restriction of Chemicals) ............................................... 109
RoHS (Restriction of Hazardous Substances)............................................................................................. 109
WEEE (Waste Electrical & Electronic Equipment)....................................................................................... 109
12 AC15 Series Product Codes........................................................................................................... 110

DOC-0017-03-EN: AC15 Series - Hardware Installation Manual
DOC-0017-03-EN-B 04.04.2023 9 (125)
13 Technical Information ..................................................................................................................... 111
13.1 General Product Ratings......................................................................................................... 111
Environment ................................................................................................................................................. 111
Safety ........................................................................................................................................................... 111
Earthing........................................................................................................................................................ 111
Mains Supply................................................................................................................................................ 111
13.2 AC Line Fed Power Stack Ratings.......................................................................................... 112
1ø, 230V Products ....................................................................................................................................... 112
3ø, 230V Products ....................................................................................................................................... 112
3ø, 400V Products ....................................................................................................................................... 112
13.3 Internal Brake Switch Ratings................................................................................................. 113
1ø, 230V Products ....................................................................................................................................... 113
3ø, 230V Products ....................................................................................................................................... 113
3ø, 400V Products ....................................................................................................................................... 114
13.4 Control Board Ratings............................................................................................................. 114
Analogue Inputs ........................................................................................................................................... 114
Analogue Outputs ........................................................................................................................................ 115
Digital Inputs ................................................................................................................................................ 115
High Speed Digital Inputs ............................................................................................................................ 116
Digital Outputs.............................................................................................................................................. 116
Relay Outputs .............................................................................................................................................. 116
Motor Thermistor Input................................................................................................................................. 116
User +24V Output ........................................................................................................................................ 117
External +24V Auxiliary Input....................................................................................................................... 117
STO Inputs ................................................................................................................................................... 117
Appendix A: Power Stack Circuit Overview ........................................................................................... 118
1ø, 230V Products ....................................................................................................................................................... 118
3ø, 230V Products ....................................................................................................................................................... 119
3ø, 400V Products ....................................................................................................................................................... 121

DOC-0017-03-EN: AC15 Series - Hardware Installation Manual
10 (125) DOC-0017-03-EN-B 04.04.2023
4 Introduction
4.1 About this Hardware Installation Manual
Users
This Manual is intended for use by the installer of the AC15 series Inverters. It assumes a reasonable level
of understanding in this discipline.
There is a separate Software Reference Manual – DOC-0017-05 “AC15 Series - Software Reference
Manual”, that is intended for use by the user and programmer of the AC15 series Inverters.
Manual Organisation
This Hardware Installation Manual is organised into chapters, indicated by the numbering on the edge of
each page.
If the manual is to be printed, it is designed so that it should be printed double-sided using the long-edge for
binding.
The Manual is ordered in a sequence that takes the user through the product installation process, resulting
in the basic operation of the drive.
Information for the full AC15 product is referred to as “the Inverter” or “drive” throughout the manual.
Product coding: Any “x” within a product code indicates there are variants. See ‘Chapter 12: AC15 Series
Product Codes’ section for more information.
Manual Revision
This revision replaces all previous revisions of this document. Parker has made every effort to ensure that
this document is complete and accurate at the time of printing. In accordance with our policy of continuous
product improvement, all data in this document is subject to change or correction without prior notice.
4.2 Before You Start…
Equipment Inspection
At the point of receipt of your product, check:
- For signs of transit damage.
- That the product code on the box label matches your order.
Equipment Storage
If the product is not being installed immediately, store the unit:
- In a well-ventilated place.
- Away from high temperatures and humidity,
- Away from dust or metal particles.
Storage Temperature:
-25°C to 55°C
Shipping Temperature:
-25°C to 70°C

DOC-0017-03-EN: AC15 Series - Hardware Installation Manual
DOC-0017-03-EN-B 04.04.2023 11 (125)
Initial Steps
Use this Hardware Installation Manual to help plan the following:
1. Installation
Know your requirements:
- Certification, i.e. CE, UL, CUL compliance (Chapter 11: Compliance).
- Conformance to local installation requirements.
- Supply and Cabling requirements (Chapter 6: Installation).
2. Motor Considerations
It is important to consider that:
- The motor used with the Inverter is suitable for Inverter duty.
- The rated current of the motor used with the Inverter is not less than 25% of the Inverter
current rating. It this is the case, poor motor control or autotune problems may occur.
Unpacking the Product
When unpacking the product:
- Save the packaging. In case of the need to return the product, improper packaging can result in
transit damage.
- Use safe and suitable lifting procedure when moving the unit. Never lift the unit by its terminal
connections.
- Prepare a clear, flat surface to receive the inverter before attempting to move it. Do not damage
any terminal connections when putting the unit down.
- Refer to ‘Chapter 6: Installation’ for further details on handling the products.

DOC-0017-03-EN: AC15 Series - Hardware Installation Manual
12 (125) DOC-0017-03-EN-B 04.04.2023
5 Product Overview
General Overview:
Power Range:
0.37 – 30kW
Frame Sizes:
5 (Frames 1 – 5)
Power Supply:
1ø 220 – 240Vac ±10%, (Frames 1 - 2: 0.37 – 2.2kW)
3ø 220 – 240Vac ±10%, (Frames 1 - 5: 0.37 – 11kW)
3ø 380 – 480Vac ±10%, (Frames 1 - 5: 1.5 – 30kW)
Input Frequency:
50/60Hz ±10%
Output Frequency:
0.5 – 590Hz
Safe Torque Off (STO):
SIL2, PLd
Environment:
Temperature:
Frame 1, 1ø 230V, 0.37kW (Fan-less):
- 0 - 40°C
All other products:
- 0 - 40°C (derate output current above 40°C by 2% per °C, up to
maximum of 45°C)
Altitude:
0 – 1000m (derate output current above 1000m by 1% per 100m, up to
maximum of 2000m)

DOC-0017-03-EN: AC15 Series - Hardware Installation Manual
DOC-0017-03-EN-B 04.04.2023 13 (125)
General Power Stack Features:
Switching Frequency:
Minimum: 1kHz
Default: 4kHz
Maximum: 10kHz
Linear derating of output current will apply above the default switching
frequency (varies by power rating. Refer to Chapter 13: Technical
Information for values).
Output Frequency:
Induction Motors:
- Maximum = Switching Frequency 8
PMAC Motors:
- Maximum = Switching Frequency 6
Note: Output frequency is limited to a maximum frequency of 590Hz
due to export rules.
Duty Rating:
Heavy Duty (HD)
Power Stack Protection Features:
Trip Conditions:
Output Short Circuit
Overcurrent: 220% Rated Output Current
Motor Stall
Overvoltage / Undervoltage:
- 230V products = 420Vdc / 220Vdc
- 400V products = 840Vdc / 410Vdc
Heatsink Overtemperature
Motor Thermistor Overtemperature
Three Phase OK (Missing Line Phase Detection):
- 3ø 230V products: Frames 3 – 5 only
- 3ø 400V products: Frames 4 & 5 only
Current Limit:
Adjustable up to 150%
Overload Rating:
150% for 60s (Inverse Time / Motor I*t)
User Terminals:
Line Input:
3x Three phase / 2x Single phase AC input terminals: L1/L, L2/N, L3
Motor Output:
3x AC output terminals: U, V, W
Brake Output:
2x DC output terminals: DC+, DBR
PE:
Minimum of 2x Protective earth connections
General Control Features:
Motor Control Modes:
Induction Motors:
- V/F Control (V/Hz)
- Sensorless Vector Control
PMAC Motors:
- Sensorless Vector Control
Voltage Boost for V/F
Control:
0-25%
Skip Frequencies:
Skip frequencies with adjustable skip band width
Preset Speeds:
User selectable preset speeds
Stopping Modes:
Ramp, Coast, DC Injection, Fast Stop
Linear & S Ramps:
Symmetric or asymmetric ramp up and down rates
Raise/Lower:
Programmable Motorised Potentiometer (MOP) function
Jog:
Programmable jog speed
Diagnostics:
Real-time drive feedback monitoring and fault diagnostics

DOC-0017-03-EN: AC15 Series - Hardware Installation Manual
14 (125) DOC-0017-03-EN-B 04.04.2023
Base Control Board I/O:
Analogue Inputs:
Frame 1:
- 2x Configurable Inputs: Voltage Mode (0-10V) / Current Mode (0-
20mA, 4-20mA)
Frames 2 – 5:
- 2x Configurable Inputs: Voltage Mode (± 10V, 0-10V) / Current
Mode (0-20mA, 4-20mA)
Analogue Outputs:
Frame 1:
- 2x Configurable Outputs: 2x Voltage Mode (0-10V) / Current
Mode (0-20mA)
Frames 2 – 5:
- 3x Configurable Outputs: 2x Voltage Mode (0-10V) / Current
Mode (0-20mA), 1x Voltage Mode (± 10V, 0-10V)
Digital Inputs:
Frames 1:
- Up to 6x Configurable 24Vdc Inputs (4x Dedicated Inputs with
common selectable pull-ups for active low operation)
Frames 2 – 5:
- Up to 8x Configurable 24Vdc Inputs (6x Dedicated Inputs with
common selectable pull-ups for active low operation)
Digital Outputs:
Up to 2x Configurable 24Vdc Outputs
Relay Outputs:
1x Configurable Relay Outputs
User +24V Output:
1x User +24V Reference Voltage Output
External +24V Auxiliary
Input: 1x +24Vdc Input (PELV)
Base Communication Ports:
Ethernet:
1x RJ45 Port
Frame 1:
- DSELite / Web HTTP Server / Modbus TCP
Frames 2 – 5:
- DSELite / Web HTTP Server / Modbus TCP / EtherNet/IP
RS232:
1x RJ11 Port for remote 6901 MMI

DOC-0017-03-EN: AC15 Series - Hardware Installation Manual
DOC-0017-03-EN-B 04.04.2023 15 (125)
6 Installation
IMPORTANT
Please ensure that you have read and are familiar with the ‘Compliance’
chapter before installing the unit.
6.1 Mechanical
Product Dimensions & Weights
Optional Wiring Bracket shown for reference only
Frame
Size
Product Dimensions
WeightH H1 H2 W D
1
138.0
(5.43)
151.0
(5.94)
175.1
(6.89)
81.5
(3.21)
144.3
(5.68)
1.1
(2.43)
2
180.0
(7.09)
193.0
(7.60)
227.5
(8.96)
108.4
(4.27)
185.0
(7.28)
2.0
(4.41)
3
237.5
(9.35)
248.0
(9.76)
281.9
(11.10)
141.6
(5.57)
184.0
(7.24)
3.3
(7.28)
4
265.0
(10.43)
283.0
(11.14)
321.4
(12.65)
161.0
(6.34)
196.0
(7.72)
4.4
(9.70)
5
340.0
(13.39)
358.0
(14.09)
401.4
(15.80)
210.0
(8.27)
220.2
(8.67)
8.0
(17.64)
All dimensions in millimeters (inches)
All weights in kilograms (lbs)

DOC-0017-03-EN: AC15 Series - Hardware Installation Manual
16 (125) DOC-0017-03-EN-B 04.04.2023
Product Fixing Dimensions
Frame
Size
Fixing Dimensions
Slot Size
Fixings
H3
H4
W1
W2
K
R1
R2
1
128.0
(5.04)
5.0
(0.20)
70.0
(2.76)
5.7
(0.22)
5.0
(0.20)
2.3
(0.09)
4.7
(0.19)
M4
2
170.0
(6.69)
5.0
(0.20)
94.0
(3.70)
7.2
(0.28)
5.0
(0.20)
2.3
(0.09)
4.7
(0.19)
M4
3
225.0
(8.86)
6.5
(0.26)
126.0
(4.96)
7.8
(0.31)
6.0
(0.24)
3.0
(0.12)
5.3
(0.21)
M5
4
255.0
(10.04)
5.0
(0.20)
146.0
(5.75)
7.5
(0.30)
5.0
(0.20)
2.5
(0.10)
4.6
(0.18)
M5
5
329.0
(12.95)
5.5
(0.22)
194.0
(7.64)
8.0
(0.31)
6.0
(0.24)
3.0
(0.12)
5.5
(0.22)
M5
All dimensions in millimeters (inches)

DOC-0017-03-EN: AC15 Series - Hardware Installation Manual
DOC-0017-03-EN-B 04.04.2023 17 (125)
Lifting the Inverter
These products can be lifted by an individual. Care must be taken when handling the products to avoid
injury.
Mounting the Inverter
These products are intended to be mounted vertically inside a suitable enclosure.
1. Mark out the fixing hole positions on the cubicle back
panel as per the Fixing Dimensions listed in the table
above.
2. Drill the fixing holes as per the Slot Size and required
Fixing as listed in the table above.
3. Screw the fixings part way into the cubicle back panel.
4. Lift the inverter into position and onto the fixings using the
keystone slots at the top of the product to hang the
inverter into position.
5. Secure the product by fully tightening the fixings.
6. The inverter is now ready for wiring.

DOC-0017-03-EN: AC15 Series - Hardware Installation Manual
18 (125) DOC-0017-03-EN-B 04.04.2023
Ventilation Clearance Requirements
The inverter gives off heat in normal operation and must therefore be mounted to allow the free flow of air
through the ventilation slots and heatsink:
- Maintain minimum clearances for ventilation as given in the tables below to ensure adequate
cooling of the inverter, and that heat generated by other adjacent equipment is not transmitted to
the inverter.
- Be aware that other equipment may have its own clearance requirements.
- When mounting two or more inverters together, these clearances are additive.
- Ensure that the mounting surface is normally cool.
- The inverter must be mounted in a suitable cubicle.
Minimum Air Clearance for Product:
Frame 3 is shown for illustration only.
Frame
Size
Product Clearances
A
B
C
D
1
10.0
(0.39)
150.0
(5.91)
150.0
(5.91)
50.0
(1.97)
2
10.0
(0.39)
150.0
(5.91)
150.0
(5.91)
50.0
(1.97)
3
10.0
(0.39)
150.0
(5.91)
150.0
(5.91)
50.0
(1.97)
4
10.0
(0.39)
150.0
(5.91)
150.0
(5.91)
50.0
(1.97)
5
10.0
(0.39)
150.0
(5.91)
150.0
(5.91)
50.0
(1.97)
All dimensions in millimeters (inches)
Note: The optional wiring bracket does not affect the clearance dimension below the product (dimension C).
Forced Air
Flow
Natural Air Flow

DOC-0017-03-EN: AC15 Series - Hardware Installation Manual
DOC-0017-03-EN-B 04.04.2023 19 (125)
Wiring Bracket (Optional)
Optional wiring brackets are available for the AC15 product range. These brackets support the cabling to
and from the drive, as well as providing a convenient means to achieve a 360° connection to the cable
screen.
Order Codes
Order Code
Description
ASP-0039-01
AC15 Wiring Bracket Kit - Frame 1
ASP-0039-02
AC15 Wiring Bracket Kit - Frame 2
ASP-0039-03
AC15 Wiring Bracket Kit - Frame 3, 400V
ASP-0039-04
AC15 Wiring Bracket Kit - Frame 4, 400V
ASP-0039-05
AC15 Wiring Bracket Kit - Frame 5, 400V
ASP-0039-06
AC15 Wiring Bracket Kit - Frame 3, 230V
ASP-0039-07
AC15 Wiring Bracket Kit - Frame 4, 230V
ASP-0039-08
AC15 Wiring Bracket Kit - Frame 5, 230V
ASP-0039-01
ASP-0039-02
ASP-0039-03
ASP-0039-04
ASP-0039-05
ASP-0039-06
ASP-0039-07
ASP-0039-08
Installation
The Wiring Brackets mount to the chassis earthing points using the clamps and fixings pre-installed to the
drive. Frame 2 is shown for illustration only:
For the Frame 3, 4 & 5 230V products:
1. Remove the fixings of the ‘L’ brackets (with the earth clamps attached), from the heatsink.
2. Replace the ‘L’ brackets with the wiring bracket, reusing the heatsink fixings.
3. Move the earth clamps across from the ‘L’ brackets and fit onto the wiring bracket.
1. Unscrew and remove the necessary
chassis PE clamps.
2. Align and place the wiring bracket
onto the bare chassis PE tabs.
3. Secure the wiring bracket to the
chassis with the previously removed
clamps and screws (from step 1).

DOC-0017-03-EN: AC15 Series - Hardware Installation Manual
20 (125) DOC-0017-03-EN-B 04.04.2023
6.2 Electrical
IMPORTANT
Please ensure that you have read and are familiar with the ‘Safety’
chapter before proceeding with the electrical installation.
DANGER!
RISK OF ELECTRIC SHOCK
Terminal covers, main covers, and cover fixings must remain in place
while the drive is energised.
These should only ever be removed once the supply to the unit and/or
system has been disconnected, and the residual energy in the DC link
capacitors has been discharged.
- All activities covered in this chapter should be carried out when there is no power to the
inverter.
- If the drive has been powered up, ensure enough time has elapsed that the inverter has
discharged its residual energy.
- Always check that the voltages on the user terminals are at a safe level (<50V) before
carrying out any of these activities.
- STO always overrides any attempt to start the inverter. If one or both STO control inputs is
requesting the STO function, the inverter will not start.
- Refer to ‘Chapter 8: Safe Torque Off (STO): SIL2, PLd’ for further information.
Power Stack Wiring
Terminal Identification
Frame 1:
Label
Description
L3 / PE
Supply Input Phase L3 / Protective Earth
L2 / N
Supply Input Phase L2 / Neutral
L1 / L
Supply Input Phase L1 / Live
DC+
DC+ / Dynamic Brake Resistor Connection (+)
DBR
Dynamic Brake Resistor Connection (-)
U
Motor Output Phase U
V
Motor Output Phase V
W
Motor Output Phase W
