Parkside PLLA 12 B2 User manual

CORDLESS LED WORK LIGHT PLLA 12 B2
CORDLESS LED WORK LIGHT
Translation of the original instructions
AKKU-LED-ARBEITSLICHT
Originalbetriebsanleitung
IAN 323150_1901

GB/IE/NI Translation of the original instructions Page 1
DE/AT/CH Originalbetriebsanleitung Seite 25
Before reading, unfold the page containing the illustrations and familiarise
yourself with all functions of the device.
Klappen Sie vor dem Lesen die Seite mit den Abbildungen aus und machen
Sie sich anschließend mit allen Funktionen des Gerätes vertraut.

Charging
times
Charging
currents
2 Ah
Battery pack
PAPK 12 A1
2 Ah
Battery pack
PAPK 12 A2
4 Ah
Battery pack
PAPK 12 B1
max. 2.4 A
Charger
PLGK 12 A1
60 min
2.4 A
60 min
2.4 A
120 min
2.4 A
max. 4.5 A
Charger
PLGK 12 B2
60 min
2.4 A
45 min
3.5 A
60 min
4.5 A

12V max.
10,8V
All Parkside devices and chargers PLGK 12 A1 / PLGK 12 B2
The X12V Team Series are with the
Battery packs PAPK 12 A1 / PAPK 12 A2 / PAPK 12 B1 compatible.

PLLA 12 B2 GB│IE│NI │ 1 ■
Contents
Introduction .................................. 2
Intended use..........................................2
Features .............................................2
Package contents ......................................3
Technical specifications .................................3
General power tool safety warnings ............. 5
1. Work area safety ....................................5
2. Electrical safety .....................................6
3. Personal safety......................................7
4. Power tool use and care ..............................8
5. Use and handling of the cordless electrical power tool.......9
6. Service ...........................................10
Safety guidelines for battery chargers .....................11
Safety instructions for cordless lamps......................12
Before use .................................. 13
Removing/charging/inserting the battery pack ..............13
Operation .................................. 14
Switching on and off ..................................14
Battery charge level ...................................14
Swivelling the cordless LED working light...................14
Magnetic holder......................................15
Belt clip.............................................15
Tripod thread ........................................15
Maintenance and cleaning ..................... 15
Disposal .................................... 16
Disposal of the appliance...............................16
Kompernass Handels GmbH warranty........... 18
Service ..................................... 20
Importer ............................................21
Translation of the original Conformity Declaration . 22
Ordering a replacement battery ................ 24
Telephone ordering ...................................24

PLLA 12 B2
■ 2 │ GB│IE│NI
CORDLESS LED WORK LIGHT PLLA 12 B2
Introduction
Congratulations on the purchase of your new appliance.
You have chosen a high-quality product. The operating
instructions are part of this product. They contain important
information about safety, usage and disposal. Before using the
product, please familiarise yourself with all of the operating and
safety instructions. Use the product only as described and for the
range of applications specified. Please also pass these operating
instructions on to any future owner.
Intended use
This cordless LED working light is used to illuminate dry, poorly lit
interior areas, such as garages, cellars or attics.
The cordless LED working light is not suitable for lighting rooms in hous-
es. Any other usage or modification of the cordless LED working light
is deemed to be improper and carries a significant risk of accidents.
The manufacturer accepts no responsibility for damage attributable to
misuse. This appliance is not intended for commercial use.
Features
Cordless LED working light

ON/OFF switch
Battery display LED
Release buttons
Battery pack
Belt clip
Magnet
1/4" internal thread for tripod

PLLA 12 B2 GB│IE│NI │ 3 ■
High-speed battery charger
Control LED
Charge level indicator LED
Package contents
1 cordless LED working light
1 high-speed battery charger
1 battery pack
1 set of operating instructions
Technical specifications
Cordless LED working light PLLA 12 B2:
Rated voltage: 12 V (DC)
Rated power Pmax: 5 W
Number of LEDs: 10
Luminous flux:
480 lm
Brightness levels: 2
Protection class: III/
(protection through extra-low voltage)
Protection Class: IP20
protection against dust and water splashes
suitable for difficult conditions

PLLA 12 B2
■ 4 │ GB│IE│NI
Battery: PAPK 12 A2
Type:
LITHIUM ION
Rated voltage: 12 V (DC)
Capacity: 2000 mAh/24 Wh
Cells: 3
High-speed battery charger: PLGK 12 A1
INPUT:
Rated voltage: 220–240 V ~ (AC), 50–60 Hz
Power consumption: 50 W
OUTPUT:
Rated voltage: 12 V (DC)
Rated current: 2.4 A
Charging time: approx. 60 min
Fuse (internal): 2 A
T2A
Protection class: II/ (double insulation)

PLLA 12 B2 GB│IE│NI │ 5 ■
General power tool safety
warnings
WARNING!
► Read all safety warnings and all instructions. Failure to follow
the warnings and instructions may result in electric shock, fire
and/or serious injury.
Save all warnings and instructions for future reference.
The term "power tool" in the safety instructions refers to your
mains-operated (with power cord/AC adapter) power tools or
battery-operated (cordless) power tool.
1. Work area safety
a) Keep work area clean and well lit. Cluttered or dark areas invite
accidents.
b) Do not operate power tools in explosive atmospheres, such as
in the presence of flammable liquids, gases or dust. Power tools
create sparks which may ignite the dust or fumes.
c) Keep children and bystanders away while operating a power
tool. Distractions can cause you to lose control of the appliance.

PLLA 12 B2
■ 6 │ GB│IE│NI
2. Electrical safety
a) Power tool plugs must match the outlet. Never modify the
plug in any way. Do not use any adapter plugs with earthed
(grounded) power tools. Unmodified plugs and matching outlets
will reduce risk of electric shock.
b) Avoid body contact with earthed or grounded surfaces, such
as pipes, radiators, ranges and refrigerators. There is an in-
creased risk of electric shock if your body is earthed or grounded.
c) Do not expose power tools to rain or wet conditions. Water en-
tering a power tool will increase the risk of electric shock.
d) Do not abuse the cord. Never use the cord for carrying, pull-
ing or unplugging the power tool. Keep cord away from heat,
oil, sharp edges or moving parts. Damaged or entangled cords
increase the risk of electric shock.
e) When operating a power tool outdoors, use an extension cord
suitable for outdoor use. Use of a cord suitable for outdoor use
reduces the risk of electric shock.
f) If operating a power tool in a damp location is unavoidable,
use a residual current device (RCD) protected supply. Use of an
RCD reduces the risk of electric shock.

PLLA 12 B2 GB│IE│NI │ 7 ■
3. Personal safety
a) Stay alert, watch what you are doing and use common sense
when operating a power tool. Do not use a power tool while
you are tired or under the influence of drugs, alcohol or medi-
cation. A moment of inattention while operating power tools may
result in serious personal injury.
b) Use personal protective equipment. Always wear eye protec-
tion. Protective equipment such as dust mask, non-skid safety
shoes, hard hat, or hearing protection used for appropriate condi-
tions will reduce personal injuries.
c) Prevent unintentional starting. Ensure the switch is in the off-po-
sition before connecting to power source and/or battery pack,
picking up or carrying the tool. Carrying power tools with your
finger on the switch or energising power tools that have the switch
on invites accidents.
d) Remove any adjusting key or wrench before turning the power
tool on. A wrench or a key left attached to a rotating part of the
power tool may result in personal injury.
e) Do not overreach. Keep proper footing and balance at all
times. This enables better control of the power tool in unexpected
situations.
f) Dress properly. Do not wear loose clothing or jewellery. Keep
your hair, clothing and gloves away from moving parts. Loose
clothes, jewellery or long hair can be caught in moving parts.
g) If devices are provided for the connection of dust extraction
and collection facilities, ensure these are connected and prop-
erly used. Use of dust collection can reduce dust-related hazards.

PLLA 12 B2
■ 8 │ GB│IE│NI
4. Power tool use and care
a) Do not force the power tool. Use the correct power tool for
your application. The correct power tool will do the job better
and safer at the rate for which it was designed.
b) Do not use the power tool if the switch does not turn it on and
off. Any power tool that cannot be controlled with the switch is
dangerous and must be repaired.
c) Disconnect the plug from the power source and/or the battery
pack from the power tool before making any adjustments, chang-
ing accessories, or storing power tools. Such preventive safety
measures reduce the risk of starting the power tool accidentally.
d) Store idle power tools out of the reach of children and do not
allow persons unfamiliar with the power tool or these
instructions to operate the power tool. Power tools are
dangerous in the hands of untrained users.
e) Maintain power tools. Check for misalignment or binding of
moving parts, breakage of parts and any other condition that
may affect the power tool’s operation. If damaged, have the
power tool repaired before use. Many accidents are caused by
poorly maintained power tools.
f) Keep cutting tools sharp and clean. Properly maintained cutting
tools with sharp cutting edges are less likely to bind and are easier
to control.
g) Use the power tool, accessories and tool bits etc. in accor-
dance with these instructions, taking into account the working
conditions and the work to be performed. Use of the power
tool for operations different from those intended could result in a
hazardous situation.

PLLA 12 B2 GB│IE│NI │ 9 ■
5. Use and handling of the cordless electrical
power tool
a) Charge a rechargeable battery unit using only the charger rec-
ommended by the manufacturer. Chargers are often designed for
a particular type of rechargeable battery unit. There is the danger
of fire if other types of rechargeable battery units are used.
b) Only the rechargeable battery units supplied are to be used
with an electrical power tool. The use of other rechargeable
batteries may lead to a risk of injury or fire.
c) When they are not being used, store rechargeable battery
units away from paperclips, coins, keys, nails, screws or other
small metal objects that could cause the contacts to be bridged.
Short-circuiting the contacts of a rechargeable battery unit may
result in heat damage or fire.
d) Fluids may leak out of rechargeable battery units if they are
misused. If this happens, avoid contact with the fluid. If contact
occurs, flush the affected area with water. Seek additional
medical help if any of the fluid gets into your eyes. Escaping
battery fluid may cause skin irritation or burns.

PLLA 12 B2
■ 10 │ GB│IE│NI
CAUTION! RISK OF EXPLOSION! Never charge
non-rechargeable batteries.
Protect the rechargeable battery from heat; for
example, from continuous exposure to sunlight,
fire, water and moisture. There is a risk of explosion.
6. Service
a) Have your power tool serviced by a qualified repair person using only
identical replacement parts. This will ensure that the safety of the power
tool is maintained.

PLLA 12 B2 GB│IE│NI │ 11 ■
Safety guidelines for battery chargers
■ This appliance may be used by children
aged 8 years and above and by persons
with limited physical, sensory or mental capa-
bilities or lack of experience and knowledge,
provided that they are under supervision or
have been told how to use the appliance
safely and are aware of the potential risks.
Do not allow children to use the appliance as
a toy. Cleaning and user maintenance tasks
may not be carried out by children unless
they are supervised.
■ To avoid potential risks, damaged mains cables
should be replaced by the manufacturer, their
customer service department or a similarly quali-
fied person.
The charger is suitable for indoor use only.

PLLA 12 B2
■ 12 │ GB│IE│NI
WARNING!
■ Do not operate the appliance with a damaged cable,
power cord or mains plug. Damaged power cords can
result in danger to life due to electric shock.
■ Do not use any accessories that are not recommended by
PARKSIDE. This can lead to an electric shock or fire.
NOTE!
► This charger can only charge the following batteries:
PAPK 12 A1 / PAPK 12 A2 / PAPK 12 B1.
► A current list of battery compatibility can be found at
www.Lidl.de/Akku.
Safety instructions for cordless lamps
■Do not cover the appliance during operation.The cordless LED
working light heats up during operation and may cause burns.
■Do not look into the light beam. Do not direct the light beam
at people or animals.
■Do not allow children to use the appliance. You could inadver-
tently dazzle other people or yourself.
■Keep the appliance away from magnetically sensitive devices
and magnetic data media. The magnet may cause irreversible
loss of data.
■Check the durability of the appliance fastening. Dropping the
appliance may cause injury.
■ The light source of this appliance cannot be replaced. Once the
light source has reached the end of its lifespan, the entire lamp
must be replaced.

PLLA 12 B2 GB│IE│NI │ 13 ■
Before use
Removing/charging/inserting the battery pack
CAUTION!
► Always unplug the appliance before you remove the battery
pack from or connect the battery pack to the high-speed
battery charger .
NOTE
► The battery pack is supplied partially charged. Before first use,
charge the battery pack in the high-speed battery charger
for at least 1 hour. This ensures maximum performance of
the battery pack . You can charge the lithium-ion battery
at any time without shortening its service life. Interrupting the
charging process does not damage the battery pack .
► If the battery pack overheats during operation, it cannot
be charged. Allow it to cool down first.
■ Never charge the battery pack if the ambient temperature is
below 10°C or above 40°C.
1. To remove the battery pack , press the release buttons and
pull the battery pack out of the appliance.
2. Insert the battery pack into the high-speed battery charger .
3. Insert the mains plug into the socket. The control LED lights up
red .
4. The green charge level indicator LED indicates that the
charging process is complete and the battery pack is ready
for use.
5. Insert the battery pack into the appliance.

PLLA 12 B2
■ 14 │ GB│IE│NI
Operation
Never use the appliance for purposes other than those for which
it was designed and only with original parts/accessories. Using
attachments or accessory tools other than those recommended in the
operating instructions can lead to a risk of injury.
Switching on and off
Switching on:
♦ Press the ON/OFF switch .
The appliance lights up at maximum brightness.
♦ To reduce the brightness, hold down the ON/OFF switch for
approx. 2 seconds.
To switch back to maximum brightness, press the ON/OFF
switch again for approx. 2 seconds.
Switching off:
♦ Press the ON/OFF switch .
Battery charge level
■ The status will be shown on the battery display LED as follows:
RED/ORANGE/GREEN = maximum charge
RED / ORANGE = medium charge
RED = low charge – charge the battery
Swivelling the cordless LED working light
The cordless LED working light can be swivelled/adjusted into
8positions.
♦ Swivel the cordless LED working light by clicking it into one
of the 8 positions.

PLLA 12 B2 GB│IE│NI │ 15 ■
Magnetic holder
NOTE!
■ Bear in mind that sliding the appliance may scratch the
magnetic surface!
You can use the magnets to fix the appliance onto magnetic
surfaces.
Belt clip
You can use the belt clip to attach the appliance to a belt or
similar.
Tripod thread
You can use the 1/4" internal thread to screw the appliance onto
a tripod (not included).
Maintenance and cleaning
WARNING! RISK OF INJURY! Always switch the
appliance off and remove the battery before
carrying out any work on the appliance.
■ The appliance is maintenance-free.
■ Remove all dirt from the appliance. Use a soft, dry cloth for this
purpose.
■ Do not allow any liquids to get into the appliance.
