Parrot CK3100 Series User manual

This document is a tool to assist with the installation of a Parrot product and is supplied purely for information. Any installation performed in
compliance with the instructions appearing in this document is done under the sole responsibility of the installer, who is entirely responsible
for the quality of the installation. All rights reserved © Copyright 2011 PARROT SA RCS PARIS 394 149 496. May not be reproduced without
the authorisation of Parrot SA. Pictures for information only.
Installation manual:
Parrot MKi + Parrot
CK3100 range
The brand name KIA PICANTO and the KIA logo are the property of KIA MOTORS.
This document is only valid for the vehicle model PICANTO® year 2011, excluding all other models in the same range and excluding later
modifications made to the vehicle by the manufacturer.
The Parrot brand name and logos are the exclusive property of Parrot SA.

This document is a tool to assist with the installation of a Parrot product and is supplied purely for information. Any installation performed in
compliance with the instructions appearing in this document is done under the sole responsibility of the installer, who is entirely responsible
for the quality of the installation. All rights reserved © Copyright 2011 PARROT SA RCS PARIS 394 149 496. May not be reproduced without
the authorisation of Parrot SA. Pictures for information only.
Accessories required
Disassembly 20min
Mounting kit 30min
Refitting 20min
Testing 15min
Total 1h25min
YES +APC
NO ISO
N/A UNIKA
FRONT SPEAKER TEL mode
ALL MUSIC mode
Fitting time (estimated) / Main features
Tools
- Phillips screwdriver
- Multimeter or Test lamp
- Wire tie
- Round file (or a knife)
"Please contact your wholesaler to purchase
accessories. List of wholesalers available at
www.certified.parrot.com." »
Kram ref. Dealer ref.
CK range 86394 N/A
MKi range 84394X389 N/A
Photos for illustration purposes
CK range MKi range
To get the most out of your hands-free kit, we recommend that you update your software
regularly. The procedure for doing this can be found at
www.parrot.com/usa/support/downloads
Updating
Plastic trim removal tools
FACOM / BOJO

This document is a tool to assist with the installation of a Parrot product and is supplied purely for information. Any installation performed in
compliance with the instructions appearing in this document is done under the sole responsibility of the installer, who is entirely responsible
for the quality of the installation. All rights reserved © Copyright 2011 PARROT SA RCS PARIS 394 149 496. May not be reproduced without
the authorisation of Parrot SA. Pictures for information only.
Disassembly

This document is a tool to assist with the installation of a Parrot product and is supplied purely for information. Any installation performed in
compliance with the instructions appearing in this document is done under the sole responsibility of the installer, who is entirely responsible
for the quality of the installation. All rights reserved © Copyright 2011 PARROT SA RCS PARIS 394 149 496. May not be reproduced without
the authorisation of Parrot SA. Pictures for information only.
Disassembly
Using the plastic trim tools, firmly
unclip the radio cover and the air
vents and remove the radio
Unscrew screws 1 and 2 located
on the left side of the radio
Unscrew screws 3 and 4 located on
the right side of the radio
Pull and lift the radio
disconnecting the connectors
and the antenna
Using the plastic trim tools,
unclip the cover located on the
right side of the dashboard
Remove the passenger side door
seal
1
3
2
4
5 6
1
2
3
4

This document is a tool to assist with the installation of a Parrot product and is supplied purely for information. Any installation performed in
compliance with the instructions appearing in this document is done under the sole responsibility of the installer, who is entirely responsible
for the quality of the installation. All rights reserved © Copyright 2011 PARROT SA RCS PARIS 394 149 496. May not be reproduced without
the authorisation of Parrot SA. Pictures for information only.
Using the plastic trim tools, run
the cable under the head liner
Microphone passage
Glue the bracket (supplied) to
the windscreen, after having
thoroughly degreased the
surface
Run the cable replacing the seal
on the passenger door
Pass the cable into the
dashboard on the right side
Run it behind the glove box Then pass the cable towards the
radio
1
3
2
4
5 6

This document is a tool to assist with the installation of a Parrot product and is supplied purely for information. Any installation performed in
compliance with the instructions appearing in this document is done under the sole responsibility of the installer, who is entirely responsible
for the quality of the installation. All rights reserved © Copyright 2011 PARROT SA RCS PARIS 394 149 496. May not be reproduced without
the authorisation of Parrot SA. Pictures for information only.
Feeding the accessory cable
In the glove box, using a semi-
rigid guide
Pass the cable from the top right
towards the radio
Be careful to leave enough
length
1 2
3

This document is a tool to assist with the installation of a Parrot product and is supplied purely for information. Any installation performed in
compliance with the instructions appearing in this document is done under the sole responsibility of the installer, who is entirely responsible
for the quality of the installation. All rights reserved © Copyright 2011 PARROT SA RCS PARIS 394 149 496. May not be reproduced without
the authorisation of Parrot SA. Pictures for information only.
ISO adapter
Fitting the hands-free system 1 / 2
Connect the adaptor (86394 for the CK or
84394X389 for the Mki) to the original connector
and connect all of the wires to the blue box as
shown in the diagram below. Test the assembly
before reassembly and then slide everything
behind the air conditioning control unit
1

This document is a tool to assist with the installation of a Parrot product and is supplied purely for information. Any installation performed in
compliance with the instructions appearing in this document is done under the sole responsibility of the installer, who is entirely responsible
for the quality of the installation. All rights reserved © Copyright 2011 PARROT SA RCS PARIS 394 149 496. May not be reproduced without
the authorisation of Parrot SA. Pictures for information only.
Fitting the hands-free system 2 / 2
Glue the bracket to the top left of
the screen, after carefully
degreasing the surface
Using a drill or file, make a notch in
the air vent cover at the top
opposite the screen mounting
2 3

This document is a tool to assist with the installation of a Parrot product and is supplied purely for information. Any installation performed in
compliance with the instructions appearing in this document is done under the sole responsibility of the installer, who is entirely responsible
for the quality of the installation. All rights reserved © Copyright 2011 PARROT SA RCS PARIS 394 149 496. May not be reproduced without
the authorisation of Parrot SA. Pictures for information only.
Testing
Before refitting the system, switch the kit on using the
ignition (or by starting the car). By pushing the central knob
of the remote control, check:
1 - that the menu is displayed on the screen (language or
iPod etc)
2 - that the radio system is muted when the kit is in use (click
in the blue box)
3 - that the sound through all speakers is properly muted
4 - that there is sound through the front speakers for spoken
menus
5 - then turn off the ignition, verify that the kit turns off and
that the message “goodbye” is displayed on the screen
(otherwise reverse the fuses on the kit power supply
harness)
6 - pair a telephone with the kit and make a call (check that
both the microphone and the kit are working)

This document is a tool to assist with the installation of a Parrot product and is supplied purely for information. Any installation performed in
compliance with the instructions appearing in this document is done under the sole responsibility of the installer, who is entirely responsible
for the quality of the installation. All rights reserved © Copyright 2011 PARROT SA RCS PARIS 394 149 496. May not be reproduced without
the authorisation of Parrot SA. Pictures for information only.
Refitting
Refit the system using the following procedure:
1 - reinstall the radio reconnecting the adaptor and the antenna
2 - refit the 4 screws (1, 2, 3 and 4) around the radio
3 - re-clip the cover with the air vents placing the screen cable in the notch (pay
ATTENTION to avoid cutting the cable)
4 - refit the right dashboard panel
