Instruction Sheet
012-06070B
Electroscope
SF-9069
®
800-772-8700 (US) [phone]
www.pasco.com [email protected]
Hardware
Introduction
The SF-9069 Electroscope is used for detecting and
demonstrating static electric charge. When the electro-
scope is charged, the lightweight conductive rod rotates to
indicate the magnitude of the charge. The apparatus
includes a Charge Sampler for transferring charge to the
electroscope.
Additional Equipment Recommended
• Classic Electrostatic Materials Kit SF-9068
• Banana Plug Patch Cord
1. Shrouded Red Patch Cords
2. Shrouded Black Patch Cords
• Shrouded Red Patch Cords EM-9740
• Shrouded Black Patch Cords EM-9471
Check the PASCO Web page at
www.pasco.com
Setup and Operation
• Plug the Charge
Sampler into the top
of the Electroscope.
• Plug a patch cord
into the Grounding
Port on the base of
the Electroscope.
Connect the patch
cord to something
that is grounded.
Item Number
Charge Sampler 1
Conductive Rod 2
Grounding Port 3
1.
2.
3.
12

®
Electroscope SF-9069
2012-06070B
• Charge an object such as a PVC plastic rob by rub-
bing it vigorously with a wool cloth.
• Transfer the charge to the Electroscope by touching
the Charge Sampler with the charged object.
• Remove the charged object and observe what hap-
pens to the Electroscope.
Grounding the Electroscope
NOTE: Discharge (“ground”) the Electroscope by touching
the Charge Sampler with your finger or with the end of a
patch cord that is connected to ground.
Technical Support
For assistance with any PASCO product, contact PASCO
at:
The Reference Guide will be updated periodically. For the
latest revision of this Instruction Sheet, visit the PASCO
Web site at
www.pasco.com/manuals
and enter the product number, SF-9069, in the text
window.
Replacement Parts
For information about possible replacement parts, contact
Technical Support:
Limited Warranty
For a description of the product warranty, see the PASCO catalog. For
more information visit www.pasco.com/legal
Copyright
This PASCO scientific
Instruction Sheet is copyrighted with all rights
reserved. Permission is granted to non-profit educational institutions for
reproduction of any part of this manual, providing the reproductions are
used only in their laboratories and classrooms, and are not sold for profit.
Reproduction under any other circumstances, without the written consent
of PASCO scientific, is prohibited. Version 23-07-2016.
Trademarks
PASCO, PASCO scientific, PASCO Capstone, PASPORT, and
SPARKvue are trademarks or registered trademarks of PASCO scientific,
in the United States and/or in other countries. All other brands, products,
or service names are or may be trademarks or service marks of, and are
used to identify, products or services of their respective owners. For more
information visit www.pasco.com/legal.
Wool cloth
Plastic (PVC) rod
