Paser CONVERSO MUTE Reference manual

PASER CONVERSO MUTE
MANUAL OF INSTALLATION AND USE rev 1.0 12
INSTALLATION
The installation is simple due to the fact that it must to be equipped with the P&P harness.
The operation to follow are:
Remove the OEM radio.
Connect the P&P harness.
Connect the Parrot MKi9X00 central unit.
Lay down the microphone.
Lay down the harness.
1
2
3
4
5 6
7
Connection diagram
1. MKi9X00 CAR KIT
2. “FAKRA” PLUG CONNECT TO THE RADIO
3. “FAKRA” PLUG CONNECT TO THE RADIO
4. CONVERSO MUTE MODULE
5. MICROPHONE
6. CONNECT TO THE CAR KIT
7. IPOD, USB, AUX IN CONNECTIONS
8. INSERT THE DISPLAY OF THE CAR KIT (ONLY MKi9100)
OTHERWIES KEEP THE CAP CONNECTED
8
1 2 3 4 5 6 7 8
BMW / MINI
SETTING
1 2 3 4 5 6 7 8
ALTEA / LEON /
ALHAMBRA
SETTING
1 2 3 4 5 6 7 8
IBIZA MODE B -
EVOLVED
SETTING
1 2 3 4 5 6 7 8
AUDI A1
SETTING
Paser Converso Mute was studied to equip the cars listed as compatible, with Parrot Bluetooth car kit.
The unit allows the user to control the function of the car kit trough the steering wheel commands without interact with the OEM radio.
In fact the module is able to create a virtual MUTE by filtering, during the use of the car kit, the steering wheel commands usually sent
to the OEM radio.
The kit is composed PASER CONVERSO MUTE adapter, the plug and play harness it is not included , please refer to the list of com-
patibility below.
With Paser Converso Mute it’s possible to control the music functions such as iPod, USB and AUX input.
1 2 3 4 5 6 7 8
BMW X3
SETTING
The information in this guide are purely for information purposes, therefore, are subject to change without notice. At the time of publication the information is
correct and reliable. However Paser can not be held responsible for any consequences resulting from errors or omissions in this manual. Paser reserves the
right to improve / change the product or manual without obligation to notify users.

Phone Button
Volume Buttons SEEK Buttons
Phone Button
Volume Buttons SEEK Buttons
Answer a call TEL (short)
Refuse a call TEL (long)
Vocal call TEL (short)
Redial Last number TEL (long)
Volume call Increase
Volume MP3 Increase
V+
Volume call Decrease
Volume MP3 Decrease
V-
Discrete mode TEL (short)
Back from discrete mode TEL (short)
Close Call TEL (long)
Select MENU SEQUENCE S+S-S+S-
Scroll MENU Onward S+ (short)
Scroll MENU Backward S- (short)
Confirm MENU choice TEL (short)
Next Track MP3 S+ (short)
Previous Track MP3 S- (short)
Play - Pause MP3 SEQUENCE S– S+
MENU Back TEL (long)
Mute Microphone SEQUENCE S– S+
Phone Button
Volume Buttons SEEK Buttons
Phone Button
Volume Buttons SEEK Buttons
Select MENU (FOR BMW GT5 ONLY) SEQUENCE V- V+ V- V+
Scroll MENU Onward (FOR BMW GT5 ONLY) V+ (short)
Scroll MENU Backward (FOR BMW GT5 ONLY) V- (short)
Next Track MP3 (FOR BMW GT5 ONLY) V+ (short) V- (short)
Previous Track MP3 (FOR BMW GT5 ONLY) V- (short) V+(short)
Mute Microphone (FOR BMW GT5 ONLY) PRESS
TEL twice
Play - Pause MP3 (FOR BMW GT5 ONLY) PRESS
TEL twice
Change mobile phone SEQUENCE V- V+
3 times
H/F PROFILE CONTROLLED BY 1 PHONE BUTTON (MODE C)
The information in this guide are purely for information purposes, therefore, are subject to change without notice. At the time of publication the information is cor-
rect and reliable. However Paser can not be held responsible for any consequences resulting from errors or omissions in this manual. Paser reserves the right to
improve / change the product or manual without obligation to notify users.

MODE Button
Volume Button SEEK Button
Answer a call PRESS MODE (short)
Refuse a call PRESS MODE (long)
Vocal call PRESS MODE (short)
Redial Last number PRESS E MODE
(long)
Volume call Increase
Volume MP3 Increase
V+
Volume call Decrease
Volume MP3 Decrease
V-
Discrete mode PRESS MODE (short)
Back from discrete mode PRESS MODE (short)
Close Call PRESS MODE (long)
Select MENU SEQUENCE
V-V+V-V+
Scroll MENU Onward S+ (short)
Scroll MENU Backward S- (short)
Confirm MENU choice PRESS MODE (short)
Next Track MP3 S+ (short)
Previous Track MP3 S- (short)
Play - Pause MP3 SEQUENCE
S– S+
MENU Back PRESS MODE (long)
Mute Microphone SEQUENCE
S– S+
Change mobile phone SEQUENCE V- V+
3 times
Control of the system with MODE button (SEAT IBIZA Mode B evolved)
ATTENTION! With this unit to change the source of the radio it must to press the
MODE button twice.
The information in this guide are purely for information purposes, therefore, are subject to change without notice. At the time of publication the information is cor-
rect and reliable. However Paser can not be held responsible for any consequences resulting from errors or omissions in this manual. Paser reserves the right to
improve / change the product or manual without obligation to notify users.

IF YOU NEED TO ERASE THE MEMORY OF HANDSFREE KIT TO RESET ASSOCIATED PHONES, YOU MUST ONLY TO PRESS THE
SEQUENCE OF VOLUMES: VOLUME - FOLLOWED BY VOLUME +
(FIVE TIMES VOL- / VOL + / VOL- / VOL + / VOL- / VOL +/ VOL- / VOL +/ VOL- / VOL+ )
+ X 5
+ X 5
HOW TO CLEAR PHONES MEMORY
+
X 5
X 5
+
X 5
+
WARRANTY CONDITIONS
THIS PRODUCT HAS A TWO-YEAR GUARANTEE FOR ANY KIND OF PRODUCTION DEFECT.
THE FISCAL SALES DOCUMENT IS NECESSARY FOR THE VALIDITY OF THE GUARANTEE.
