PB TEEN Shelf 2FT User guide

Shelf 2FT
Mounting Instruction
PARTS INCLUDED:
A. (1) Shelf
B. (2) Brackets
HARDWARE:
C. (4) Bolts
D. (4) Mounting Screws
E. (4) Drywall Anchors
Mounting Template
Tools Required: Phillips Screwdriver, Level, Pencil, Stud-Finder
WARNING! Do not mount this item above cribs, beds, or changing tables.
Maximum total weight capacity for this product is 30 pounds (13.6 kg).
ASSEMBLY INSTRUCTIONS:
Place the Shelf (A) face down on flat, protected surface so that
the four threaded holes face up as shown. Position each side
Bracket (B) to the shelf by aligning the holes on the bracket and
the shelf. Secure bracket to the shelf using provided Bolts (C)
and tighten with a Phillips screwdriver.
After assembled, check to make sure that the brackets and the
shelf is even on the back. If they are not, slightly loosen the bolts
and put the assembly against a flat wall and retighten the blots.
MOUNTING INSTRUCTIONS:
We have included a paper mounting template for you to easier locate the insertion points of the mounting hardware
on the wall. Do not discard the paper template while you opening the carton.
1. Position the provided paper template on wall at a desired location of the Peg Rack. Use a level to ensure that
the template is level and then secure it to the wall using tape or tacks. Use a sharp pencil to mark on the wall
by piercing the template at the four insertion points (the black dots shown on the template, like below). Remove
the template from the wall. The mounting hardware will be installed at these marks.
Note: The provided mounting hardware is meant for
drywall and stud construction only. For other wall
types, please consult your local hardware store for
assistance in selecting the appropriate hardware.

2. The provided anchors cannot penetrate wood studs. Therefore we have to find out if either mark of Step #1
happens to align with a wall stud (use a stud finder to determine this). If either does, do not use an anchor at
that mark (let’s call it stud mark) –you will only install a mounting screw there. Refer to Step #4 & Step #6
about the screw installations.
3. For marks that do not align with a wall stud, first install an anchor at each mark. To install the anchor, use a
Phillips screwdriver to engage an anchor and then position the anchor tip against the wall at the mark. Rotate
the anchor clockwise as you firmly push it into the wall. The anchor will drive itself into the wall when you rotate
it clockwise, while applying an even pressure. Continue rotating until the anchor’s head becomes even with the
wall surface. Do not over-tighten. Repeat for the other anchors at non-stud marks.
4. At the two UPPER insertion points on the wall, use the screwdriver to secure a provided screw into either the
installed anchor or directly the wall (stud mark). Rotate each screw clockwise until the screw head resides
about 3/8 inch from the wall. DO NOT secure any screw into any LOWER installed anchor or stud mark... yet.
5. With the help of another person, lift the item against the wall and engage the two keyholes on the back of the
item with protruding screw heads. Make sure each keyhole engages with its screw in place so that the item is
properly supported by the screws. Meanwhile the two straight holes on the front of the item should also align
with the two LOWER insertion locations.
6. Now use the remaining two screws to further secure the item on the wall through the straight holes located at
the left & right metal bars. Inset the screw through the hole and into either an install anchor or stud mark. Use
the screwdriver to rotate the screws until tight.
CARE INSTRUCTIONS:
-Wipe with a soft, dry or slightly damp cloth.
-To protect the finish, do not apply household cleaners or abrasives.
Thank you for your purchase!
www.pbteen.com
Step.6
Step.3
Step.5
Step.4
