PB TEEN Stuff-Your-Stuff Suspension Shelf User manual

1 / 3
www.pbteen.com
Stuff-Your-Stuff Suspension Shelf (Full and Queen)
Pre-Assembly:
Please read all instructions before beginning assembly.
Save all packing materials until assembly is complete to avoid accidentally discarding smaller parts or hardware.
Parts Included:
Hardware Enclosed:
C –Screw (M4x1 ¼”)
10 Pcs
D - Wire Rod –4 Pcs
E - Flat Washer (ø12xø1.5)
–8 Pcs
F - Pan-Head Nut –8 Pcs
G –Toggle Anchor –6
Pcs
H –Toggle Screw –6 Pcs
I –Hanging Bar –2 Pcs
Tools Required:
Phillips Head Screwdriver (not included)
Do not use the power drill cause it may cause cracking
Assembly Instructions:
1. Attach the Bottom Panel (A) to Back Panel (B) by
aligning the exposed wood dowels on Bottom Panel
(A) with pre-drilled holes on front side of Back
Panel (B). (Back side of this Back Panel (B) has an
affixed product-mounting bracket). (Fig.1)
A –Bottom Panel –2 Pcs
B –Back Panel –2 Pcs
B
A
Exposed
wood dowel
Fig.1

2 / 3
www.pbteen.com
2. Insert the screws (C) into the pre-drilled holes on the
Back Panel (B). Use Philips Head Screwdriver and
turn clockwise, but do not tighten the Screws (C).
(Fig.2)
3. Insert the Wire Rods (D) into the pre-drilled holes at
the sides of the Bottom Panel (A) and Back Panel.
Note: one threaded end of the Wire Rod is longer
than the other end. Insert this long threaded end into
the pre-drilled hole on Back Panel (B). (Back Panel
(B) is thicker than Bottom Panel (A) ). (Fig.3)
4. Secure the two ends of each Wire Rod (D) with a
Flat Washer (E) and a Pan-Head Nut (F) from
behind and under of the shelf by using a Philips
Head Screwdriver.
Continue tightening all the Screws (C). (Fig.4)
Note :
Repeat Steps 1 to 4 to assemble another piece
using the same procedure.
Care Instructions:
Do not exceed the weight capacity of the shelf. Maximum weight capacity of the shelf is 50 lbs.
Hardware may loosen over time. Periodically check to make sure all connections are tight. Re-tighten if necessary.
Dust often with a soft, dry cloth.
To clean, slightly moisten cloth with water. (a damp cloth holds dust and prevent scratching ; dry thoroughly).
Fig. 3
Do not tighten
the Screws (C)
Insert this long
threaded end to the
Back Panel (B)
B
A
D
E
F
E
F
D
F
E
B
Fig.4
Tighten the Screws
(C) at this step.
Fig.2
B
C

3 / 3
www.pbteen.com
Sample Mount Hardware Installation:
Note: Toggle anchors and toggle screws are meant for dry wall only.
1. Determine the desired location on the wall for the product. Place the Wall Mount Bracket (I) on the wall. Using the
bubble level confirm that the brackets is level. Use a pencil to mark (3) wall mount bracket hole positions at left,
center and right on the wall. This is where the toggle anchor hardware will be inserted.
Do not attach Wall Mount Bracket at this stage.
2. Use a Philips Head Screwdriver to install the Toggle Anchors
(G). Do not use a drill to install the toggle anchors and do not
force or “pound” the anchor into the wall. The Toggle anchor is
designed to cleanly cut and bore itself into the wall like a drill
bit.
3. Slowly turn the Toggle Anchors (G) clockwise while applying
even pressure until the flange just touches the wall. If the
anchor position is close to a stud (1/2” or less), keep turning
clockwise until one of the arrows on the flange is pointing to
the 12 o’clock position.
4. Insert the Toggle Screws (H) into the Toggle Anchors (G) and
turn clockwise. Here, you will feel a slight resistance. This is
the point where the toggle anchor screw is engaging the
pivoting portion of the anchor. Continue turning the screw
clockwise until the screw head touches the flange. Tighten the
toggle anchor screw until it becomes difficult to turn. At this
point the internal pivot will have engaged the backside of the
dry wall.
Remove the toggle Anchor Screw (H), turning counter-
clockwise.
5. Align the Hanging Bar (I) on the wall over the Toggle Anchors
(G), and re-insert Toggle Anchor Screws (H) with a Philips
Head Screwdriver until tight.
Hanging the Product:
1. On the back of your product is an affixed product-mounting bracket.
2. Slowly attach the wooden bracket over the Hanging Bar (I) until it is fully placed on the Hanging Bar (I).
See below picture.
3. Your product is ready for use.
WALL
G
G
H
I
WALL
Wall
Shelf
