I. PRODUCT FEATURES AND SPECIFICATIONS
PORTABLE MID-RISED MODEL MR06
●Automatic safety lock: 3 position safety locks, mechanical safety locks release, No
need of air source.
●High speed: From 0-1090mm (43”) in just 21 seconds
●Portable design: It is easy to move the unit with the power unit stand
●Adjustable rubber pad included
Fig.1
MODEL MR06 SPECIFICATIONS
Model Lifting
Capacity Raised Height Lifting Time Overall Length Platform Width Swing Width Lowered Height Gross Weight Motor
MR06
2.8T
6,000 lbs
1090mm
43”
21S 1885mm 74 1/4
1000mm
39 3/8”
1604mm
63 1/8”
125mm
5”
394Kg
840 lbs
3.0HP

2
II. INSTALLATION REQUIREMENT
A. TOOLS REQUIRED
Screw Set
English Spanner (12″)
Wrench sets：(13＃、15＃、17＃、19＃)
B. POWER SUPPLY
The electrical source must be 2.2kw minimum. The source cable size must be
2.5mm² and in good condition of contacting with floor.
Fig. 2
Pliers
Grease gun
Hook spanner (40~42mm)

3
III. INSTALLATION STEPS
A. Check the parts before assembly, make sure all the parts are completed.
1. Packaged lift, Parts box, Power Unit and Power Unit Stand.
Move the parts aside, open the outer packing and check the parts according to the
shipment parts list (See Fig. 3).
2. Open the parts box, check the parts according to the part list (See Fig. 4).
Fig. 3
Fig. 4
41

4
3. Check the parts of the parts bag according to the parts bag list (See Fig. 5).
B. Install hydraulic power unit and needle valve (See Fig. 6)
Fig.5
Fig. 6

5
C. Install oil hose (See Fig. 7)
Fig. 7
37A
28
29
40
40
43
37B
42
39
27

6
D. Install supporting arm
1. Prepare the parts of supporting arms(See Fig. 8)
2. Install supporting arms and pads (See Fig. 9)
Fig. 8
Fig. 9

7
E. Install electric system
Connect the power source on the data plate of Motor
Note: 1. For the safety of operators, the power wiring must contact the floor well.
2. Pay attention to the direction of rotations when using three phase motors.
PEAK Single phase motor (See Fig. 10)
1. Connecting the two power supply lines (fire wire Land zero wire N) to terminals of AC
contactor marked L1, L2 respectively.
2. Connecting the two motor wires to terminals of AC contactor marked T1, T2.
3. Connecting L2 to A2 of AC contactor.
4. Two wires of control button connected with terminals of AC contactor marked A1, L1.
Fig. 10
Single phase

8
SPX Single phase motor (See Fig. 11)
1．Power supply line (active wire L) connected with wire 4
＃
of control button.
2．Wire 3
＃
of control button connected with wire 6# of motor.
3．Power supply line (neutral wire N) connected with wire 5# of motor.
Fig. 11
N
G
3＃
4＃
6#
5#
Earth wire
L

9
PEAK three phase motor
1. Circuit diagram (See Fig. 12)
2. Connection Step (See Fig. 13)
a. The source wires (L1, L2, L3) are connected with terminals of AC contactor marked
L1, L2, L3 respectively.
b. Terminals of AC contactor marked L1 are connected with terminals 4# of control
button. TerminalsA1 of AC contactor are connected with terminals 3# of control
button.
Fig.12
Fig. 13
L1
L2
L3
A1
3#
4#
Three phase

10
IV. EXPLODED VIEW Model MR06
Fig. 14

11
CYLINDER
SPX power unit 220V,50Hz
Fig.15
Fig.16

12
PEAK MANUAL POWER UNIT
SPX Power unit 220V 50Hz single phase(Fig.18)
220V/50HZ/1 phase
Fig.17
380V/50HZ/3 phase
Fig.18
Oil outlet
Release valve
Handle for release
valve
Check valve
Relief
valve
Auxiliary
hole
Auxiliary hole
Oil return port Protective ring
Capacitor

13
PEAK Power unit 220V 50Hz single phase (See.Fig19)
PEAK power unit 380V 50Hz Three phase
Fig.19
Relief valve
Throttle valve
Release valve
Oil outlet
Oil return port
Check valve
Oil return port
Capacitor Protective ring
Handle for release
valve
Relief
valve
Throttle
valve
图二十
Oil outlet
Oil returen port
Release valve
Protective ring
Handle for release
valve
Check valve

14
V. OPERATION INSTRUCTIONS
1. Install the oil hose between oil cylinder and power unit, connect with the power
supply wire well. The machine can be ready to use.
2. When lifting vehicle, be sure the center of gravity of vehicle must be in the middle
of lift, select the suitable adapters and move the arms to find the support point.
Make sure the safety lock must be in engaged when lifting (See Fig. 18).
3. Lower the lift: Press the button “UP”, until the safety lock is in released position
(See Fig.19), lower the lift by pushing lowering handle.
Safety lock Safety release
Fig. 21 Fig.22
5. Move the lift with the power unit stand (See Fig. 23)
Fig. 23

15
VI. MAINTENANCE SCHEDULE
Monthly:
1. Lubricate all moving parts with lubricant (See Fig.22).
2. Check all connectors, bolts and pins to insure proper mounting.
3. Make a visual inspection of all hydraulic hoses/lines for possible wear or leakage.
Every six months:
1. Make a visual inspection of all moving parts for possible wear, interference or
damage.
2. Check all fastener and re-torque.
Fig. 24

16
VII. TROUBLE SHOOTING
TROUBLE CAUSE REMEDY
Motor does not
run
1. Button does not work
2. Wiring connections are not in good
condition
3. Motor burned out
4. Safety Switch is damaged
5. AC contactor burned out
1. Replace button
2. Repair all wiring connections
3. Repair or replace motor
4. Replace the Safety Switch
5. Replace AC Contactor
Motor runs but
the lift is not
raised
1. Motor runs in reverse rotation
2. Gear Pump out of operation
3. Release Valve in damage
4. Relief Valve or Check Valve in damage
5. Low oil level
6. Overload lifting or low pressure
1.Reverse two power wire
2. Repair or replace
3. Repair or replace
4. Repair or replace
5. Fill tank
6.Check
load or adjust the
pressure
Lift does not
stay up
1. Release Valve out of work
2. Relief Valve or Check Valve leakage
3. Cylinder or Fittings leaks
Repair or replace
Lift raises
slowly
1. Oil line is jammed
2. Motor running on low voltage
3. Oil mixed with air
4. Gear Pump leaks
5. Overload lifting
1. Clean the oil line
2. Check Electrical System
3. Fill tank
4. Repair or replace
5. Check load
Lift cannot lower
1. Safety device are in activated
2. Release Valve in damage
3. Oil system is jammed
1. Release the safeties
2. Repair or replace
3. Clean the oil system

17
VIII. PARTS LIST FOR MODEL MR06
Item Part# Description QTY. Note
(See Fig. 14, Fig.6-7)
1 640001 Platform 1
2 640002A Stackable Adapter Bracket 4
3 209052B Stackable Adapter (2.5”) 4
3A 209051B Stackable Adapter (1.5”) 4
4 201046A Rubber Pad Assy. 4
4A 420138 Socket bolt 4
4B 209134 Rubber pad 4
4C 680030C Rubber Pad Frame 4
5 209009 Cup Head Bolt 16
6 680004 Rubber Pad 4
7 640003 Supporting pad 4
8 640023A Limit pin 4
9 640004 Supporting arm 4
10 640005 Washer 10
11 640109 Washer 4
11A 620022 Self locking Nut 8
12 640007 Cylinder 2
13 206032 Snap Ring 12
14 640057 Pin For Cylinder Connecting 2
14A 640012 Pin 2
15 640006A Pin for Cylinder 2
16 640017B Outer Scissor 1
17 640009 Inner Scissor Pin 2
18 640010 Safety Bar Set 2
19 640011 Safety Pin 2
20 203004A Bronze Bush 8
21 420023A Washer 2
22 420132A Bronze Bush 4
23 640022 Roller 2
24 630107 Split Pin 2
25 640016B Inner Scissor 1
26 610003A Slider 2
27 61K107 Straight Fitting 1
28 640114 Oil Hose 1

18
Item Part# Description QTY. Note
29 420097 Straight Fitting 2
30 640020 Manual Power Unit 1
31 209003 Hex Bolt 4
32 209005 Self locking Nut 4
33 640021 Power Unit Stand 1
34 206006 Washer 2
35 201005 Split Pin 2
36 640023 Roller 2
37A 201020 900Fitting 1
37B 209119 compensation valve 1
38 209060 Straight Fitting For Power Unit 1
39 209062 T Fitting 1
40 630110 Oil Hose 1
41 640500A Parts Box 1
42 420244 Straight fitting 1
43 420245 Straight fitting 1
PARTS FOR HYDRAULIC CYLINDER (See Fig. 15)
12-1 640030A Bore Weldment 2
12-2 640031A Piston Rod 2
12-3 201034 Bleeding Plug 2
12-4 201033 Head Cap 2
12-5 209078 Dust Ring 2
12-6 201032 O - Ring 2
12-7 201035 O - Ring 2
12-8 201028 Piston 2
12-9 206069 O-Ring 2
12-10 201031 O-Ring 2
12-11 201030 Y-Ring 2
12-12 201029 Support Ring 2
12-13 206071 Nut 2
12-14 620064 Greasing Fitting 4
