Pecron E1000 PRO User manual

Please read the user manual thoroughly before using
[email protected]
USER MANUAL
E1000
E1000 PRO

E1000 PRO
[email protected]
FUNCTION INTRODUCTION
① ② DC 12V~18V Charging Port ③
AC 100V~120V Switch
④ ⑤ Wireless Charger
⑦
LCD Display
DC12V Auxiliary Output
⑧
⑥DC 12V/USB/ Wireless Switch
DC 32V~95V Charging Port
⑨DC12V(5525)Output
USB-A/USB-C Ports
⑩
AC 100V~120V Output
①
②
③
④
⑥
⑦
⑧
⑨
⑤
⑩

[email protected]
INPUT SPECS
DC Charging(32V~95V)
Max 400W
5521*1
DC Charging(12V~18V)
Max 100W
GX16MF*1
SPECIFICATIONS
Lithium-ion(NCM)
1000CycleLife＞80%
Dimension
L11.7*W7.8*H8.5 in
L298*W199*H215
mm
Capacity Battery Type Net Weight
Around 20lb
Around 9.1kg
1000Wh
(25.2V39.6Ah)
Protections
Over-Voltage,
Overheat,
Overload,
Short-Circuit,
Self-Recovery
Temperature
0℃~45℃/32°F~113°F
(Charging)
-20℃~45℃/-4°F~113°F
(Discharging)
Charging Time
Minimum
2H to 100%
AC: 3.5H to 100%
E1000PRO
OUTPUT SPECS
AC Out*3
Pure sine wave 100V~120V
Rated 1200W
Smart-Boostable to 1500W
（supporting 2000W
resistive types of loads）
USB-A*2
(5V,9V,12V,
Max 18W)*1
(5V,9V,12V,20V,
Max 100W)*1
USB-C*2 Cigar Port*1
Max 15W
DC 5525 Output*2
DC 5525 Output*2
(5V,9V,12V,
Max 18W)*2
DC 12V 10A DC 12V 5A

E1000 PRO
[email protected]
HOW TO USE THE E1000 PRO
press and hold to turn on / off DC / USB / Wireless Charger
press and hold to turn on / off AC (
Please turn off the AC
function if there is no AC load on the unit)
LCD SMART DISPLAY
AC Overload Alarm Icon
E1000 PRO is rated 1200W, smart-boostable to 1500W
(Accept up to 2000W resistive loads).
When overload occurs, the AC Overload Alarm Icon will
flash and the unit will stop working.
Temperature Alarm Icon
E1000 PRO can power your devices at temperatures
ranging from -20~45℃.
If your working temperature is more than 45℃, the
temperature alarm will flash,the unit may stop working.
Charge Indicator
Discharge Indicator
Net Input/Output Wattage
AC Output Wattage(W)/Voltage(V)
AC Overload Alarm
PF Value/Remaining Charging/
Discharging Time(Hrs)
Time Indicator
DC Out
AC Output Wattage(%)
AC Out
Battery Soc(%)
Voltage(V)
Temperature Alarm

[email protected]
PACKING LIST
RECHARGE TIME
Around 3.5Hours
Electric Generator
Around 12Hours
Car Charger
Around 3.5Hours
MC4 Solar Charging Cable
pecron 200W
SOLAR CHARGE TIME
The solar charging time depends on weather conditions. E1000 PRO has a built-in MPPT charge
controller that supports 32~95V, 15A PV charging up to 400W.
200W(×1)
6~7 Hours
Recommended
400W(×2)
3~4 Hours
Recommended
Anderson Solar
Charging Cable*1
Pecron
E1000 PRO *1
AC Charger*1
MC4 Solar Charging
Cable
(LSMC4-5GX16)*1
Car Charging
Cable
*1
Wall Charger
E1000 PRO

[email protected]
USING SOLAR PANELS TO CHARGE THE E1000 PRO
1. DC5521 Charging Port: PV/DC 12V~18V, 100W maximum; VOC(open circuit voltage) of solar panel must be than 25V;
2. GX16MF-5 Charging Port: PV(operating voltage) range 32V~95V, 400W maximum; VOC(open circuit voltage) of solar
panel/array must be than 95V, otherwise, it will damage the unit! Do not wire more than two 36V(AKA 24V) solar
panels in series. (36V stands for Vmp, the operating voltage, of the solar panel)
3. If you have any questions, Please feel free to contact us：[email protected]
E1000 PRO
DC5521 Charging Port:
PV12V~18V-100W Maximum Input
GX16MF-5 Charging Port:
PV32~95V-400W Maximum Input

[email protected]
Using the pecron 100W /18V*1（100W）to charge the E1000 PRO
pecron 100W
18V
pecron 100W*1 ※ 18V is the operating voltage of the solar panels
USING SOLAR PANELS TO CHARGE THE E1000 PRO
36V 36V
MC4 Solar Charging Cable*1pecron 200W*1
Using the pecron 200W /36V*1（200W）to charge the E1000 PRO
※ 36V is the operating voltage of the solar panels
36V
36V
72V
Using the pecron 200W /36V*2（400W）to charge the E1000 PRO
MC4 Solar Charging Cable*1pecron 200W*2
※ 36V is the operating voltage of the solar panels

Q1： What kind of battery is used in E1000 PRO? How long it can last?
A： E1000 PRO utilizes high quality UL certified automotive battery cell, it can retain 80% efficiency at 1000 complete
charge cycles.
Q2： What devices can E1000 PRO power?
A： E1000 PRO can power any appliance within 1200W, it can be automatically boosted to 1500W(accept up to 2000W
resistive loads; and 12V DC load at maximum of 10A.
Q3： Can the E1000 PRO be used as UPS?
A： The UPS function is not supported.
Q4： How to calculate the E1000 PRO running time?
A： Running Time=Total Capacity(1002Wh) * 0.85 (Depth of Discharge)/Loading Power(Watts)
Q5： Can I use the E1000 PRO indoors and charge the E1000 PRO indoors?
A： Yes, the E1000 PRO is safe to use indoors.
Q6： Does E1000 Pro have built-in MPPT charge controller?
A： Yes, there are two independent built-in MPPT charge controllers; “5521”port supports 12~18V(Max 100W) PV input,
and “GX16MF”port supports 32~95V(Max 400W) PV input.
Q7： What kind of maintenance does E1000 PRO require?
A： Charging E1000 PRO in time when the battery running low; And please charge it at least once for every six months
even if it is not being used.
Q8： How to store the E1000 PRO?
A： Do not store, charge or use E1000 PRO near heat sources, or in an area exposed to flammable or corrosive gas;
Do not immerse in water. Keep away from liquids and store it in a cool and dry place.
FAQS
[email protected]

[email protected]
1、 Do not place the device near heat source, such as a fire or a heating furnace.
2、 Do not immerse in any liquid, or expose the unit to rain or wet conditions.
3、 Do not use the battery in a strong static electricity or electromagnetic environment.
4、 Do not disassemble or puncture the product with sharp objects in any way.
5、 Short circuits can be caused by: vermin or pests chewing through wires; water or other fluids coming into contact with
electrical wiring.
6、 Do not use accessories or parts other than those provided by Pecron. Please visit our website www.pecron.com or
reach our support team for a complete list of accessories and parts.
7、 When using this product, please strictly follow the ambient temperature for use in the user manual. If the temperature
is too high, the battery can potentially result in self-combustion and will burst into flames, which can cause widespread
damage. If the temperature is too low, the performance of the battery will be seriously degraded, and it may even fail
to meet the normal use requirements.
Please read the user manual thoroughly before using this product, and keep this manual in a safe place for future reference.
Failure to follow the instructions for proper set up, use, and care for the device can increase the risk of serious personal
injury, death, or property damage. Once you use this device, you are deemed to have understood, recognized and accepted
all terms and contents of this document. The user shall be responsible for his own actions and all consequences arising from
failure to use the device in accordance with the“User Manual”, or as authorized in Pecron's current product literature.
In compliance with laws and regulations, Pecron reserves all rights for final explanation, and to change these terms and
conditions at any time without prior notice. In the event that any revisions are made, the revised terms and conditions shall
be posted on our website immediately, please visit our website to inform yourself of any changes.
DISCLAIMER
WARNING

[email protected]
8、 Do not stack heavy objects on this product.
9、 Do not block the air vents during use, or leave the device in a non-ventilated or dusty space.
10、Please avoid impacts, fall off, and violent vibration. Please turn off the device immediately and stop using it in the event
of major exterior impact. Please fasten the unit firmly during transportation to avoid vibration and impact.
11、In the event of immersing the device into the water accidently, please place the unit in a safe open area and keep away
from the unit until it is completely dry. The dried unit should not be reused and should be disposed of properly
according to the local regulation. If the device catches fire, use the fire extinguishing equipment in the following
recommended order: water or mist, sand, fire blanket, dry chemical, carbon dioxide fire extinguisher.
12、Please wipe it with a dry cloth to clean the surface of the device.
13、Please place this device with care to prevent the product from being damaged due to fall off. If the product is damaged
due to fall off, please turn off the unit immediately and place it in an open area, keep away from combustibles and
crowds, and dispose of in accordance with local laws and regulations.
14、Please store this device in a place out of reach of children and pets.
DISPOSAL
1、When conditions permit, please be sure to completely discharge the battery of this product, and then put the product
in the designated battery recycling box. This product contains batteries. Batteries are dangerous chemicals and are
strictly prohibited from being disposed of in ordinary trash. For details, please follow local laws and regulations on
battery recycling and disposal.
2、If the battery cannot be completely discharged due to the failure of the product itself, please do not dispose of the
battery directly in the battery recycling box, and contact a professional battery recycling company for further disposal.
3、The battery will not be able to start after being over-discharged, please dispose of it according to the principle of
disposal.

[email protected]
EXCLUSIONS
Pecron’s warranty does not apply to：
Misused, abused, modified,damaged by accident, or used for anything other than normal consumer
use as authorized in Pecron’s current product literature.
CUSTOMER SUPPORT：[email protected]
WEBSITE：www.pecron.com
PECRON.LLC
