Pecron E3000 User manual

Please read the user manual thoroughly before using
E3000 USER MANUAL
[email protected]

[email protected]
FUNCTION INTRODUCTION
①
②
③
④
⑤
⑥
⑦
⑧
⑨
⑩
DC 12V~18V Charging Port
②
DC 32V~95V Charging Port
③
DC 12V/USB/ Wireless Switch
⑤
AC 100V~120V Switch
⑥
DC12V10A Auxiliary Outlet⑦
AC 100V~120V Output
④ DC12V（5525）Output
⑧
①LCD Display ⑨USB-A/USB-C Ports
⑩Wireless Charger

Around 56.2lb
Around 25.5Kg
Max 15W
[email protected]
GX16MF*2 5521*1
SPECIFICATIONS
OUTPUT SPECS
INPUT SPECS
Lithium-ion(NCM)
1000CycleLife＞80%
L16.1*W10*H11.6 in
L409*W256*H297
mm
USB-A*4
5V-2A*3
(5V,9V,12V,
Max 18W)*1
(5V,9V,12V,
Max 18W)*1
(5V,9V,12V,20V,
Max 100W)*1
DC 12V-3A DC 12V-10A
Capacity Battery Type
3108Wh
(25.9V120Ah)
Charging Time Protections
5~6H
(Standard)
2.5~3H
(Fast Charging)
Over-Voltage,
Overheat,
Overload,
Short-Circuit,
Self-Recovery
Temperature
0℃~45℃/32℉~113℉
（Char ging)
-20℃~45℃/-4℉~113℉
（Discharging)
Dimension Net Weight
AC OUT*6
Pure sine wave
100V~120V
Rated 2000W
USB-C*2 DC 5525 Output*2 Cigar Port*1 Wireless Charger*1
DC Charging(32V~95V)
Max1200W(600W*2)
DC Charging(12V~18V)
Max 100W

[email protected]
HOW TO USE THE E3000
LCD SMART DISPLAY
AC Overload Alarm Icon
E3000 can power most devices with power consumption
less than 2000 watts.
If your device is more than 2000W, The AC overload alarm
will flash, The power supply will stop working.
Temperature Alarm Icon
E3000 can power your devices at temperatures ranging
from -20~45℃.
If your working temperature is more than 45℃, the
temperature alarm will flash,the unit may stop working.
DC Out
press and hold to turn on / off DC /USB / Wireless Charger
press and hold to turn on / off AC(
Please turn off the AC
function if there is no AC load on the unit)
DC
AC
DC
AC
Over load
℃
Temperature Alarm
Battery Soc(%)
Voltage(V)
AC Overload Alarm
Charge Indicator
Discharge Indicator
Net Input/Output Wattage
AC Input Wattage(W)/Voltage(V)
AC Out
PF Value/Remaining Charging/
Discharging Time(Hrs)
Time Indicator

[email protected]
MC4 Solar Charging Cable
pecron 200W
PACKING LIST
RECHARGE TIME
SOLAR CHARGE TIME
Around 5~6 Hours
Around 2.5~3Hours(2 adapters)
※ Includes one AC charger,extra one can be purchased on our website if needed.
Around 5~6 Hours
Around 2.5~3Hours(2 adapters) Around 31Hours
200W(×1) 400W(×2) 600W(×3) 1200W(×6)
23~24 Hours
The solar charging time depends on weather conditions.
E3000 has a built-in MPPT charge controller
that supports 32~95V, 15A PV charging up to 1200W.
11~12 Hours 7~8 Hours 3~4 Hours
Electric Generator Car Charger
Recommended
Recommended Recommended Recommended
800W(×4)
5~6 Hours
Recommended
AC Charger*1
MC4 Solar Charging
Cable
(LSMC4-5GX16)*2
Car Charging Cable*1
Pecron E300 0*1
Wall Charger

[email protected]
USING SOLAR PANELS TO CHARGE THE E3000
1. 1x DC5521 Charging Port: PV/DC 12V~18V, 100W maximum; VOC(open circuit voltage) of solar panel must be than 25V;
2. 2x GX16MF-5 Charging Port: PV(operating voltage) range 32V~95V, 600W maximum; VOC(open circuit voltage) of
solar panel/array must be than 95V, otherwise, it will damage the unit! Do not wire more than two 36V(AKA 24V)
solar panels in series, or more than four 18V(AKA 12V) solar panels in series.
(18V/36V stands for Vmp, the operating voltage, of the solar panel)
3. If you have any questions, Please feel free to contact us：[email protected]
1x DC5521 Charging Port:
PV12V~18V-100W Maximum Input
2x GX16MF-5 Charging Port:
PV32~95V-600W Maximum Input

[email protected]
Using the pecron 100W /18V*1（100W）to charge the E3000
USING SOLAR PANELS TO CHARGE THE E3000
pecron 100W
18V
pecron 100W*1 ※ 18V is the operating voltage of the solar panels
Using the pecron 200W /36V*1（200W）to charge the E3000
36V 36V
MC4 Solar Charging Cable*1
※ 36V is the operating voltage of the solar panels
pecron 200W*1

[email protected]
USING SOLAR PANELS TO CHARGE THE E3000
Using the pecron 200W /36V*2（400W）to charge the E3000
MC4 Solar Charging Cable*1
※ 36V is the operating voltage of the solar panels
pecron 200W*2
36V
36V
72V
Using the pecron 200W /36V*2（400W）to charge the E3000
MC4 Solar Charging Cable*2
※ 36V is the operating voltage of the solar panels
pecron 200W*2
36V
36V 36V
36V

[email protected]
USING SOLAR PANELS TO CHARGE THE E3000
DO NOT wire three solar panels in series！
Using the pecron 200W /36V*3（600W）to charge the E3000
MC4 Solar Charging Cable*2
※ 36V is the operating voltage of the solar panels
pecron 200W*3
36V 36V
72V
36V
36V
※ PV(GX16MF-5) Port Only work within 32V~95V Open Circuit voltage,exceeding 95V
will damage the machine.
36V
36V
36V
108V

[email protected]
USING SOLAR PANELS TO CHARGE THE E3000
Using the pecron 200W /36V*4（800W）to charge the E3000
MC4 Solar Charging Cable*2
※ 36V is the operating voltage of the solar panels
pecron 200W*4
72V
72V
36V
36V
36V
36V
DO NOT wire four solar panels in series！
※ PV(GX16MF-5) Port Only work within 32V~95V Open Circuit voltage,exceeding 95V
will damage the machine.
36V
36V
144V
36V
36V

USING SOLAR PANELS TO CHARGE THE E3000
[email protected]
36V
36V
36V
36V
36V
Using the pecron 200W /36V*6（1200W）to charge the E3000
MC4 Solar Charging Cable*2
Y Branch MC4 Charging Cable(+)*2
Y Branch MC4 Charging Cable(-)*2
pecron 200W*6
※ 36V is the operating voltage of the solar panels
36V
36V
36V

FAQS
[email protected]
Q1： What kind of battery is used in E3000? How long it can last?
A： E3000 utilizes high quality UL certified automotive battery cell, it can retain 80% efficiency after 1000 complete
charge cycles.
Q2： What devices can E3000 power?
A： E3000 can power most devices with power consumption less than 2000 watts.
Q3： Can the E3000 be used as UPS?
A： The UPS function is not supported.
Q4： Can the E3000 be charged while discharging?
A： Yes, E3000 can run devices while it is being charged. The battery will eventually run out if the discharging is
greater than the charging during the pass through charging.
Q5： How to calculate the E3000 running time?
A： Running Time=Total Capacity(3108Wh) * 0.85 (Depth of Discharge)/Loading Power(Watts)
Q6： Can I use the E3000 indoors and charge the E3000 indoors?
A： Yes, the E3000 is safe to use indoors.
Q7： Does E3000 have built-in MPPT controller?
A： Yes, there are two independent 600W(PV 32V~95V) MPPT charge controllers inside, and one step up 100W
(PV 18V) MPPT charge controller, The Voc ( Open Circuit Voltage) of the solar panels should not exceed 95V.
Q8： What kind of maintenance does E3000 require?
A： Charging E3000 in time when the battery running low; And please charge it at least once for every six months
even if it is not being used.
Q9： How to store the E3000?
A： Do not store, charge or use E3000 near heat sources, or in an area exposed to flammable or corrosive gas;
Do not immerse in water. Keep away from liquids and store it in a cool and dry place.

[email protected]
1、 Do not place the device near heat source, such as a fire or a heating furnace.
2、 Do not immerse in any liquid, or expose the unit to rain or wet conditions.
3、 Do not use the battery in a strong static electricity or electromagnetic environment.
4、 Do not disassemble or puncture the product with sharp objects in any way.
5、 Short circuits can be caused by: vermin or pests chewing through wires; water or other fluids coming into contact with
electrical wiring.
6、 Do not use accessories or parts other than those provided by Pecron. Please visit our website www.pecron.com or
reach our support team for a complete list of accessories and parts.
7、 When using this product, please strictly follow the ambient temperature for use in the user manual. If the temperature
is too high, the battery can potentially result in self-combustion and will burst into flames, which can cause widespread
damage. If the temperature is too low, the performance of the battery will be seriously degraded, and it may even fail
to meet the normal use requirements.
8、 Do not stack heavy objects on this product.
Please read the user manual thoroughly before using this product, and keep this manual in a safe place for future reference.
Failure to follow the instructions for proper set up, use, and care for the device can increase the risk of serious personal
injury, death, or property damage. Once you use this device, you are deemed to have understood, recognized and accepted
all terms and contents of this document. The user shall be responsible for his own actions and all consequences arising from
failure to use the device in accordance with the “User Manual”, or as authorized in Pecron's current product literature.
In compliance with laws and regulations, Pecron reserves all rights for final explanation, and to change these terms and
conditions at any time without prior notice. In the event that any revisions are made, the revised terms and conditions shall
be posted on our website immediately, please visit our website to inform yourself of any changes.
DISCLAIMER
WARNING

[email protected]
9、 Do not block the air vents during use, or leave the device in a non-ventilated or dusty space.
10、Please avoid impacts, fall off, and violent vibration. Please turn off the device immediately and stop using it in the event
of major exterior impact. Please fasten the unit firmly during transportation to avoid vibration and impact.
11、In the event of immersing the device into the water accidently, please place the unit in a safe open area and keep away
from the unit until it is completely dry. The dried unit should not be reused and should be disposed of properly
according to the local regulation. If the device catches fire, use the fire extinguishing equipment in the following
recommended order: water or mist, sand, fire blanket, dry chemical, carbon dioxide fire extinguisher.
12、Please wipe it with a dry cloth to clean the surface of the device.
13、Please place this device with care to prevent the product from being damaged due to fall off. If the product is damaged
due to fall off, please turn off the unit immediately and place it in an open area, keep away from combustibles and
crowds, and dispose of in accordance with local laws and regulations.
14、Please store this device in a place out of reach of children and pets.
DISPOSAL
1、When conditions permit, please be sure to completely discharge the battery of this product, and then put the product
in the designated battery recycling box. This product contains batteries. Batteries are dangerous chemicals and are
strictly prohibited from being disposed of in ordinary trash. For details, please follow local laws and regulations on
battery recycling and disposal.
2、If the battery cannot be completely discharged due to the failure of the product itself, please do not dispose of the
battery directly in the battery recycling box, and contact a professional battery recycling company for further disposal.
3、The battery will not be able to start after being over-discharged, please dispose of it according to the principle of
disposal.

[email protected]
Pecron’s warranty does not apply to：
Misused, abused, modified,damaged by accident, or used for anything other than normal
consumer use as authorized in Pecron’s current product literature.
CUSTOMER SUPPORT：[email protected]
WEBSITE：www.pecron.com
PECRON.LLC
EXCLUSIONS
