Pecron Q2000S User manual

User manual for Q2000S /Q3000S
PORTABLE POWER STATION

Content
1.Product introduction
2.Functions
3.Notice for function
4.Warranty service
PORTABLE POWER STATION

1.Product Introduction
Thanks for choosing PECRON Q series portable power station. Q
series features with an easy-maneuver robust design, large battery
capacity and high rated power. This back-up power source can
provide you with easy access to power in the fields of mobile working,
outdoor recreation, off-grid living, emergency rescuing and etc.
Main functions for Q2000S/Q3000S:
Please read the manual carefully before using the unit, and keep the purchase
receipt as a proof of purchase for any warranty claim.
Q2000S/Q3000S HIGHLIGHTS
110V/60Hz pure sine wave output
Three-way to recharge
12V10A DC output
QC3.0- dual USB output
Intelligent LCD display
PORTABLE POWER STATION

Specifications
Model
Q2000S
Q3000S
AC output voltage
AC 110V60Hz
Output waveform
AC pure sine wave
Rated power
2000W
Peak power
4000W
Battery capacity
1885.52Wh(25.9V72.8Ah)
3024Wh(25.2V120Ah)
Battery type
Lithium-ion battery
Charging voltage
and current
DC29.4V9A
DC29.4~40V20A(Solar charge）
Charging time
8~9H
11~12H
DC output
DC12V10A QC3.0(5V2A 9~12V1.5A)
Temp
0℃~45℃(Charge),－20℃~45℃(Discharge)
Protection
Over-voltage, over temperature
overload, short-circuit
Product color
Black +yellow
Dimension(cm)
L40*W24.5*H27.2
Weight 52.9lbs(24kg) 62.8lbs(28.5kg)
PORTABLE POWER STATION

2.Functions
Please read the main functions carefully before using the power unit to avoid
unnecessary damage.
When you leave the unit unused for a long period of time, make sure to charge
it every 6 months.
If the power station has been kept idle for a long time, please charge it to full
even if the battery level reads 100%.
Accessories list
NO. Q2000S/Q3000S accessories Quantity
1 Charging adapter 1
2 Solar charging cable 1
3 User manual and warranty card 1
4 Accessories Bag 1
PORTABLE POWER STATION

Q2000S/Q3000S Panel
5 6 7
12 3 4
PORTABLE POWER STATION

NO.Functions of each part
1 DC cigar outlet :12V output with constant voltage; max current is 10A.
2 QC3.0*2 : supply power to DC equipment (DC 5V2A
9V~12V1.5A)
3Smart display : showing the battery level, percentage, loading power and
remaining using hours.
4DC/Power switch : Press this button to activate the DC function. At the
same time, the display will show the battery level, remaining hous, voltage
etc.
5 DC charging ports (1, 2 is positive, 3, 4 is negative):charging voltage
range of this port is DC 29.4V~40V20A(solar charge)
6 AC outputs : Supply 110V/60Hz power to run your AC appliances
7 AC switch: Press this button to activate the AC function
PORTABLE POWER STATION

3.Notice for usage
Working environment
Power Charging:
Please use Pecron original power adapter to charge, and do not leave the unit unattended
while using. It is recommended to charge the power station without load to prevent
excessive heating.
When the display shows 100% charged, the charger will still delivery a small voltage to
the power station through trickle charge until the indicator turns green.
AC Load:
Q2000S/Q3000S portable power station support any devices with working power under its
rated power. However, some appliances require extra power to start up; In general, the starting
power for inductive load equipments(e.g. motor, compressor, drill, fluorescent lamps) is 3~8
times higher than its rated power. The BMS will activate the over-load protection and shut
down all outputs if the total output exceeds its working power.
Use and store the unit only in a cool and dry environment
Temperature 0℃~45℃ for charging
-20℃~45℃ for discharging
Keep the air vents at least 20cm away from any objects to
prevent improper air flow
Safety Do not store, charge or use the unit in an area exposed to
flammable or corrosive gas
Ventilation
Dry
PORTABLE POWER STATION
Operating Steps:

(1) Turn on AC output.
(2) Check the working power of your device and ensure it’s within the 2000W
rated power.
(3) Plug into the AC socket and turn on your device.
(4) Turn off the AC output after using.
(5) Please charge your Pecron on time when the battery is running low.
Note: Please make sure to turn off the AC function to save power when there is
no AC loading source. Keeping the AC function on all the time will drain the
battery quickly.
4.Warranty service
All Pecron products come with a 12-month warranty. The warranty activate
automatically since the date of receiving your Pecron. Pecron warrants that our product
to be free from defects in workmanship and material under normal consumer use
during the applicable warranty period .We will not assume, nor authorize any person to
assume for us, any other liability in connection with the sale of Pecron products.
Pecron will repair or replace (at our discretion) any Pecron product that fails to operate
during the applicable warranty period due to defect in workmanship or material. If a
valid claim is made during the applicable period, Pecron, at its option, will either(1)
replace the product, or (2) exchange the product with a product that is of equal value.
A replacement product assumes the remaining warranty of the original product.
Customer is responsible for the return shipping costs.
Pecron warranty does not apply to following situations even it’s within warranty
period:
1.Alter or disassemble the unit.
2.Wear/tear on the out surface.
3.Misused or abused for anything other than normal consumer use as authorized in
Pecron's current product literature.
4.Breakdown or damage caused by natural hazard beyond control (earthquake, fire,
tsunami and etc.)
5.Maintenance does not cover the packaging and accessories
PORTABLE POWER STATION

Certification
Item:
Inspector:
Date of production:
Warranty Card
Item Product name Purchase date
Factory No. Client Contact
Address Invoice No.
Dealer Address
