Pecron S1500 User manual

ShenZhen Pecron Technology CO.,LED
Outdoor Portable Power Station Specification
Model:S1500
Thanks for choosing pecron outdoor portable power station S1500
Please read the manual carefully before you use!
Shenzhen Pecron Technology Co.,Ltd
Http://www.pecron.com

Content
1. Introduction:...................................................................................................- 1 -
2. Panel Function Description:..........................................................................- 2 -
3. Product Specification:....................................................................................- 6 -
4. Environmental Conditions:..............................................................................- 7 -
5. Electrical Specifications:..................................................................................- 8 -
5.1-5.4 Specifications ....................................................................................- 8 -
5.5-5.7 Protection Instructions..........................................................................- 9 -
6. Operating Instructions And Precautions:.................................................- 10 -
6.1 How To Use AC : .....................................................................................-10 -
6.2 How To Operate:....................................................................................- 11 -
6.3 How To Charge:.....................................................................................- 12 -
6.4 How To Use DC 12V and USB................................................................- 13 -
7. Product Function Test:................................................................................- 13 -
7.1 Test Conditions:.....................................................................................- 13 -
7.2 Basic Function Test Display.....................................................................- 15 -
8. Misuse And Countermeasures:......................................................................- 18-
9. Package:...........................................................................................................- 19-

Shenzhen Pecron Technology Co.,Ltd
POWER IT POSSIBLE
Shenzhen Pecron Technology Co.,Ltd http://www.pecron.com Tel:0755-28601668
- 1 -
1. Introduction:
Pecron S1500 is a functional outdoor portable power station,it has safe
Lithium-ion battery and inverter conversion technology,with light
weight,high capacity,high power function,to provide portable power
solutions,its main function is as below:
♦Pure sine wave output
♦DC output 12V10A、USB*4(QC3.0)
♦DC output 12V10A、USB*4(QC3.0)LCD smart display screen
♦Support solar charging,car charging(need to add an external car
charger adapter)
S1500 can be used in series smart products, such as mobile phones,
satellite telephone, digital camera,mobile driver,digital camera, tablet,car
start, outdoor illumination, water pump,post and telecommunications,
medical device,and it also can use in these area: financial, first aid, dig,
exploration, military, science, media, tourism, disaster relief, medical
assistance and areas with widespread power shortages.
Please read the user manual carefully before you use,and please save it
with the purchase certificate for future reference.

Shenzhen Pecron Technology Co.,Ltd
POWER IT POSSIBLE
Shenzhen Pecron Technology Co.,Ltd http://www.pecron.com Tel:0755-28601668
- 2 -
2. Panel Function Description:
①Power Switch:Lightly press the power switch to initialize the dynamic
percentage display,the full screen will light up and resume normal after 1 second.
At the same time,the brightness of the LCD will be 100%.At this time,the power
station is on,lightly press the power switch again,the brightness of LCD will change
to 50%(Lightly press the power switch to adjust the LCD brightness after it is
on),and then press and hold the switch for 1 second to shut down and enter sleep
mode.

Shenzhen Pecron Technology Co.,Ltd
POWER IT POSSIBLE
Shenzhen Pecron Technology Co.,Ltd http://www.pecron.com Tel:0755-28601668
- 3 -
②DC Switch:After the power station on,press and hold the DC switch for 1
second,the USB and 12V output will be on,at the same time,the LCD screen shows
the battery percentage,DC discharge time(H)、DC discharge power, DC OUT
symbol(shown as picture 1,Page11). After DC output on, press the DC switch and
hold 1 second, the USB and 12V output shut down;After powering on,lightly press
DC switch,switch the real-time battery percentage /Battery real-time voltage mode.
Picture 1
③AC Switch:After powering on,press the AC switch and hold 1 second,the AC
output will be on,at the same time the LCD screen shows battery capacity
percentage / battery voltage、AC discharge time(h)、AC discharge power,AC
output power percentage、“AC OUT”symbol(shown as picture 2,Page11).After
AC output is on,press the AC switch and hold 1 second,the AC output will shut
down;After AC output on,lightly press the AC switch to AC discharge power + AC
discharge time / AC discharge voltage + PF value mode(shown as picture 2/3)

Shenzhen Pecron Technology Co.,Ltd
POWER IT POSSIBLE
Shenzhen Pecron Technology Co.,Ltd http://www.pecron.com Tel:0755-28601668
- 4 -
Picture 2
Picture 3

Shenzhen Pecron Technology Co.,Ltd
POWER IT POSSIBLE
Shenzhen Pecron Technology Co.,Ltd http://www.pecron.com Tel:0755-28601668
- 5 -
④LCD smart display screen
⑤USB Output port: When DC switch is on,it can supply USB device.
⑥Cooling fan outlet
⑦DC output 16MF two core aviation connector(1 is positive,2 is negative):
When DC switch turn on,it can supply power to DC appliance(12V 10A)
⑧DC input 16MF4 core aviation connector(1、2 is positive,3、4 is negative):
When the power station need to charge,you can use the power adapter to connect to
the 16MF 4 core aviation connector.(29.4V9A)
⑨AC output socket*2:When AC turn on,you can use the appliance to connect to
the AC socket .
⑩Cooling air inlet

Shenzhen Pecron Technology Co.,Ltd
POWER IT POSSIBLE
Shenzhen Pecron Technology Co.,Ltd http://www.pecron.com Tel:0755-28601668
- 6 -
3. Product Specification:
NO.
Introduction
S1500
1
Rate Power
1500W
2
Peak Power
3000W
3
AC Output
220V/50Hz
(Version)
AC110V60Hz
(Version)
AC100V50Hz
(Version)
4
Output
Waveform
Pure sine wave
5
DC Output
DC 12V10A USB*4(QC3.0)
5
Battery Type
18650-20P7S( 3.6V2.9Ah)
6
Battery Capacity
1461.6Wh(25.2V58Ah)
7
Battery Type
Lithium-ion
9
Charging Time
7~ 8H
10
Charging Voltage
And Current
DC29.4V9A Solar panel 36V20A( MAX )
11
Protection
Function
Over-voltage, low-voltage, over-temperature, overload, AC
short circuit protection
12
Working
Temperature
0℃~45℃(Charge)
-20℃~60℃(Discharge)
13
Product
Dimension
L352*W187*H260( mm )
14
Shell Material
UL94-V0 PC+ABS
16
Net Weight
11.6kg

Shenzhen Pecron Technology Co.,Ltd
POWER IT POSSIBLE
Shenzhen Pecron Technology Co.,Ltd http://www.pecron.com Tel:0755-28601668
- 7 -
4. Environmental Conditions:
NO.
Test Project
Specification
Unit
Remark
1
Working
Temperature
0 ~ 45
℃
2
Storage
Temperature
-20 ~ 60
℃
3
Humidity
45% ~ 85%
RH
4
Cooling type
Air-cooled
Cooling≥45℃
5
Altitude
3000
m
6
Mean time
between failures
≥5000
H

Shenzhen Pecron Technology Co.,Ltd
POWER IT POSSIBLE
Shenzhen Pecron Technology Co.,Ltd http://www.pecron.com Tel:0755-28601668
- 8 -
5. Electrical Specifications:
5.1-5.4 Specifications
NO .
Test Project
Specification
Unit
Remark
5.1
AC Charging
5.1.1
Rated Voltage
100 / 240
VAC
5.1.2
Rated
Frequency
50/60
Hz
5.1.3
Input Voltage
29.4
VD
C
5.1.4
Input Current
≤10
A
5.2
Solar Charging
5.2.1
Load Voltage
29.4-40V
VD
C
Open
Circuit
Voltage<
44V
5.2.2
Current
≤20
A
5 .3
AC Output
5.3.1
Rated Voltage
220±5%
(Version)
110±5%
(Version)
100±5%
(Version
)
VAC
5.3.2
Rated
Frequency
50±1%
60±1%
50±1%
Hz
5.3.3
Rated Power
1500
W
5.3.4
Harmonic
distortion
<3%
5.3.5
Conversion
efficiency
≥85%
5.4
DC Output
5.4.1
USB Voltage
5±5%
VD
C
5.4.2
USB Current
2.0±10%
A
5.4.3
Aviation
Connector
Output Voltage
12±5%
VD
C
5.4.4
Aviation
Connector
Output Current
10±10%
A

Shenzhen Pecron Technology Co.,Ltd
POWER IT POSSIBLE
Shenzhen Pecron Technology Co.,Ltd http://www.pecron.com Tel:0755-28601668
- 9 -
5.5-5.7 Protection Instructions
NO .
Test Project
Specification
Unit
Remark
5.5
Inverter
5.5.1
Over Temperature
Inverter
cooling≥65℃
℃
Lock,AC No
output,Until the
temperature drops
5.5.2
Over Load
>1500
W
Locked, no output,
until disconnected
and restart
5.5.3
AC Output Short
Circuit
—
W
Locked, no output,
until disconnected
Remark
When 5.5.2 ,5.5.3 in the protection state, the AC current switch needs to
be turned off. When it is turned on again, the AC output will be turned on.
5.6
Controller
5.6.1
USB Over Current
3
A
Output shut down
5.6.2
DC12V Output Over
Current Protection
15
A
Output shut down
5.6.3
Solar charging
protection
29.2-29.7
V
Stop charging after
achieve voltage
5.7
Battery Pack
5.7.1
Single-cell overcharge
voltage protection
4.2 V
V
Disconnect input,
keep output
5.7.2
Single-cell
over-discharge voltage
protection
2.8V
V
Shut down output
5.7.3
Battery pack
over-temperature
protection
≥65
℃
Shut down input
and output
5.7.4
Short circuit protection
Yes
Shut down output

Shenzhen Pecron Technology Co.,Ltd
POWER IT POSSIBLE
Shenzhen Pecron Technology Co.,Ltd http://www.pecron.com Tel:0755-28601668
- 10 -
5.7.5
Battery pack over
current protection
120-180
A
Shut down output
6. Operating Instructions And Precautions:
To make sure safety transportation,when you receive the power station,the
power station is under low capacity status,please charge the power station to full
capacity before you use.
If you want fast charge,please use our standard original power adapter to charge
it,or use 36V 200~300W solar panel to charge it.
To make sure safety,please use our standard charger,when PECRON-S1500 is
full charge,please disconnect the charger.
6.1 How To Use AC
Please note the following below before using:
(1)Please make sure the input voltage and frequency is same as S1500
(2)Please make sure the appliance rated power is lower than 1500W, it is better
that don’t over 80% rated power.
* If you violate these,the charger may damage or out of work.
* If your appliance power higher than 1500W, please choose other higher power
portable power station.
Remark:Because when some appliances turn on,its consumption power is higher
than the rated power,such as sensitive load device start up current normally is 3-8
times than its rated power,Energy-saving lamps start up power is dozens of times
than its rated power,if their start up power is higher than the emergency power
station’s peak power,it will trigger the over load protection,and shut down the power
station.The S1500 is with over load,short circuit,over temperature protection.
(3)When the following happens,S1500 will stop output to protect the appliance:
①When the appliance load power is higher than the power station rated power.

Shenzhen Pecron Technology Co.,Ltd
POWER IT POSSIBLE
Shenzhen Pecron Technology Co.,Ltd http://www.pecron.com Tel:0755-28601668
- 11 -
②AC output or appliance circuit
③The internal temperature of power station is too high
④The internal battery voltage is too low
6.2 How To Operation:
Step 1:Lightly press “ON/OFF”,after the power is on,press “AC ON/OFF” and
hold for 1 second,at this time,the AC output is on.
Step 2:Check whether the load input voltage and frequency correspond.
Step 3:Check the load power and make sure it does not exceed the amount of this
power supply.
Step 4:Plug the device into this AC outlet and turn on the load switch
Step 5:After using the power station,please lightly press the ON/OFF to shut down.
Step 6:If the power of the power supply is exhausted or insufficient at this time,
please charge the power supply in time for the next use!

Shenzhen Pecron Technology Co.,Ltd
POWER IT POSSIBLE
Shenzhen Pecron Technology Co.,Ltd http://www.pecron.com Tel:0755-28601668
- 12 -
6.3 How To Charge:
You can use the following methods to charge the power station:
(1)Use our standard power adapter to charge the power station:Please connect
the power cord with the adapter,and connect to the power station input port,then
plug to the grid,start to charge.
+ =
Adapter
(2)Use solar panel to charge:Use the solar cable to connect to the solar
panel,and the other side connect to the input port,start to charge(Solar panel max
voltage can’t over 40V,min voltage not lower than 29.4V).
( 3 ) Use car adapter to charge:when you use car charging,after you start up the
car,and then just insert the cigar connector to the car cigar port,the other side
connect to the power station input port.When the car is not on start up status,please
don’t use car charge.
Notes:
①Our S1500 standard power adapter only use in our S1500, please don’t use in other
device and keep away from rain.
②When you use car charge and solar charge,please pay attention to the positive and
negative.

Shenzhen Pecron Technology Co.,Ltd
POWER IT POSSIBLE
Shenzhen Pecron Technology Co.,Ltd http://www.pecron.com Tel:0755-28601668
- 13 -
③When the portable power is left unused for a long time, the battery will run out.
Please make sure to charge it every six months.
6.4 How To Use DC 12V and USB:
=>DC output 16MF two core aviation connector,press DC switch for 1
second,DC 12V output turn on,its rated current is 10A,press DC switch for 1
second,the DC output will turn off.
=> USB output,press DC switch for 1 second,USB
output turn on,press DC switch for 1 second,USB output turn off.
7. Product Function Test:
7.1 Test Conditions:
No.
Test Project
Test Conditions
Check Item
1
High-altitud
e test
1. Pressure≤=11.6Kpa,T =20±5℃
2. No package,no electricity
1.Appearance
2.Power
performance
2
Temperature
test
1. Temperature between 40±2 and 75±2℃
2. Repeat the test 10 times
3. Switching time is 30 minutes
1.Appearance
2.Power
performance

Shenzhen Pecron Technology Co.,Ltd
POWER IT POSSIBLE
Shenzhen Pecron Technology Co.,Ltd http://www.pecron.com Tel:0755-28601668
- 14 -
3
Vibration
test
Amplitude:1.52mm,
Scanning frequency range:5Hz ~ 10Hz,Scan
speed:About 10 ㎡/ S3,
Scanning frequency range:0Hz〜200Hz,Scan
speed:About 3㎡/ S3,
Scanning frequency range:200Hz ~ 500Hz,Scan
speed:About 1 ㎡/ S3,
The duration of each vibration is 20 minutes. It
vibrates from all directions of the X, Y and Z axes.
The appearance of the power supply is free of any
signs of damage. The product can pass each
function test, and the product identification text is
clear, complete, and clear. There is no shaking or
squeaking noise; the screws are fastened firmly and
there are no sliding teeth.
1. Appearanc
e
2.Power
performance

Shenzhen Pecron Technology Co.,Ltd
POWER IT POSSIBLE
Shenzhen Pecron Technology Co.,Ltd http://www.pecron.com Tel:0755-28601668
- 15 -
7.2 Basic Function Test
7.2.1 Discharge test under load
7.2.2 Charge test
7.2.3 12V DC output test 7.2.4 USB output test

Shenzhen Pecron Technology Co.,Ltd
POWER IT POSSIBLE
Shenzhen Pecron Technology Co.,Ltd http://www.pecron.com Tel:0755-28601668
- 16 -
8. MisuseAnd Countermeasures
Error
Root
Solution
Press any switch,no LCD
display or output
Interior battery protection
Charge up
Power station turn
on,press AC switch,no
output
Over temperature
Disconnect the load and
wait until it cooling down
Over load
Check the loading power
and decrease it
Load voltage
Charge up
USB no output
DC switch turn off
Press DC switch for 1
second
12V or USB consume
energy quickly
AC switch is on; standby
current is too large
Turn off AC switch during
DC output
Not full charged by solar
panel charger
1.The solar panel is not
suitable
2.Sunshine is not enough
Choose another solar
panel that is much more
suitable. And ensure that
the charging voltage is not
lower than 29.4V.

Shenzhen Pecron Technology Co.,Ltd
POWER IT POSSIBLE
Shenzhen Pecron Technology Co.,Ltd http://www.pecron.com Tel:0755-28601668
- 17 -
9. Package Content
NO .
Package Content
Quantity
1
S1500 Power Station
1
2
Power Adapter
1
3
Power Cord
1
4
DC Output Cable 1+4(4 in 1 cable)
1
5
Solar Cable + accessory bag
1
6
Car charger(optional)
1
7
User Manual And Warranty Card
1
Other manuals for S1500
1
Table of contents
Other Pecron Portable Generator manuals

Pecron
Pecron E3000 User manual

Pecron
Pecron S200 User manual

Pecron
Pecron E600 LFP User manual

Pecron
Pecron S1500 User manual

Pecron
Pecron S500 User manual

Pecron
Pecron EB3000-24V User manual

Pecron
Pecron P600 User manual

Pecron
Pecron P500 User manual

Pecron
Pecron E1000 PRO User manual

Pecron
Pecron H600 User manual
