Pecron S1500 User manual

Please read the user manual thoroughly before using
[email protected]
S1500 USER MANUAL
DC12V10A-OUT DC29.4V15A-IN

[email protected]
FUNCTION INTRODUCTION
④
⑤
⑥
LCD Display
USB-A Ports
Air Vent
⑦
⑧
⑨
DC 12V-10A Output
DC 29.4V15A Input
AC 110V Output
⑩
⑪
Air Vent
Ground receptacle
①
②
③
Power Switch
DC 12V/USB Switch
AC 110V Switch
①
②
③
④
⑤
⑨
⑩
⑪
DC12V10A-OUT DC29.4V15A-IN
⑥
⑦⑧

[email protected]
SPECIFICATIONS
OUTPUT SPECS
INPUT SPECS
Lithium-ion(NCM)
1000CycleLife＞80%
Dimension
L13.9*W7.4*H10.2 in
L352*W187*H260
mm
Capacity Battery Type Net Weight
Around 27lb
Around 12.5kg
1461.6Wh
(25.2V58Ah)
Protections
Over-Voltage,
Overheat,
Overload,
Short-Circuit,
Self-Recovery
Temperature
0℃~45℃/32°F~113°F
(Charging)
-20℃~45℃/-4°F~113°F
(Discharging)
AC Out*3
Pure sine wave
110V
Rated 1500W
USB-A*4
5V,9V,12V,
Max 18W *1
12V-10A
16MF Aviation DC
Charging Time
3~4 H
AC Charger
AC Charging
29.4V
Max 15A
Solar Charging
36V-20A 29.4V-5A
Car Charging
12.5kg

[email protected]
HOW TO USE THE S1500
press and hold to turn on / off the device
press and hold to turn on / off DC / USB
press and hold to turn on / off AC (
Please turn off the AC function if there is no AC load on the unit)
LCD SMART DISPLAY
AC Overload Alarm Icon
S1500 can power most devices with power consumption
less than 1500 watts.
If your device is more than 1500W, The AC overload
alarm will flash, The power supply will stop working.
Temperature Alarm Icon
S1500 can power your devices at temperatures ranging
from -20~45℃.
If your working temperature is more than 45℃, the
temperature alarm will flash,the unit may stop working.
Charge Indicator
Discharge Indicator
Net Input/Output Wattage
AC Output Wattage(W)/Voltage(V)
AC Overload Alarm
PF Value/Remaining Charging/
Discharging Time(Hrs)
Time Indicator
DC Out
AC Output Wattage(%)
AC Out
Battery Soc(%)
Voltage(V)
Temperature Alarm

[email protected]
PACKING LIST
RECHARGE TIME
Around 3~4Hours
Electric Generator
Around 3~4Hours
pecron 200W
SOLAR CHARGE TIME
The solar charging time depends on weather conditions. The included external MPPT charge controller supports
32-95V PV input that allows you to charge the S1500 30% faster via solar panels.
200W(×1)
9~10 Hours
Recommended
400W(×2)
4~5 Hours
Recommended
600W(×3)
3~3.5 Hours
Recommended
4-In-1
DC Output Adapter*1
Pecron
S1500 *1
AC Charger*1
MPPT Charger 9029*1 Car Charger (DC1229)*1
MPPT Charger 9029*1
Wall Charger

[email protected]
USING SOLAR PANELS TO CHARGE THE S1500
1. DC29.4V15A-IN: PV/DC 29.4-40V, 20A maximum; VOC(open circuit voltage) of solar panel must be less than 45V;
2. MPPT charger: INPUT DC 32V~95V 500W maximum; OUTPUT DC 29.4V15A
3. If you have any questions, Please feel free to contact us：[email protected]
DC12V10A-OUT DC29.4V15A-IN
DC29.4V15A-IN
PV 29.4-40V, 20A Maximum Input
DC29.4V15A-IN

[email protected]
USING SOLAR PANELS TO CHARGE THE S1500
pecron 200W*1
Using the pecron 200W /36V*1（200W）to charge the S1500
※ 36V is the operating voltage of the solar panels
Using the pecron 200W /36V*2（400W）to charge the S1500
pecron 200W*2
※ 36V is the operating voltage of the solar panels
DC-29.4V15A-IN
DC-29.4V15A-IN
MPPT Charger 9029*1
MPPT Charger 9029*1
36V
36V

36V
36V
36V
[email protected]
USING SOLAR PANELS TO CHARGE THE S1500
DO NOT wire three solar panels in series！
※The MPPT charge controller accepts input range from 32V~95V(Voc), connecting
solar panels over 95V will damage the controller
Using the pecron 200W /36V*3（600W）to charge the S1500
Y Branch MC4 Charging Cable(+)*1 Y Branch MC4 Charging Cable(-)*1
pecron 200W*3
※ 36V is the operating voltage of the solar panels
DC-29.4V15A-IN
MPPT Charger 9029*1
DC-29.4V15A-IN
（NOTE：This parallel charging cable sold separately）
36V
36V
36V

Q1： What kind of battery is used in S1500? How long it can last?
A： S1500 utilizes high quality UL certified automotive battery cell, it can retain 80% efficiency at 1000 complete
charge cycles.
Q2： What devices can S1500 power?
A： The AC output ports can power appliances which use less than 1500 watts of electricity. However, inductive types of
loads such as freezer, fridge, compressor, motor require a much higher power to start (approx. 3-7 times lager than
its rated power). The DC output ports can supply a maximum DC power of 120W(12V@10A).
Q3： Can the S1500 be used as UPS?
A： The UPS function is not supported.
Q4： How to calculate the S1500 running time?
A： Running Time=Total Capacity(1461.6Wh) * 0.85 (Depth of Discharge)/Loading Power(Watts)
Q5： Can I use the S1500 indoors and charge the S1500 indoors?
A： Yes, the S1500 is safe to use indoors.
Q6： Does S1500 have built-in charge controller?
A： Yes, there is a built-in PWM charge controllers, which supports 29.4-40V, 20A maximum PV input;
Q7： What kind of maintenance does S1500 require?
A： Charging S1500 in time when the battery running low; And please charge it at least once for every six months
even if it is not being used.
Q8： How to store the S1500?
A： Do not store, charge or use S1500 near heat sources, or in an area exposed to flammable or corrosive gas;
Do not immerse in water. Keep away from liquids and store it in a cool and dry place.
FAQS
Please read the user manual thoroughly before using this product, and keep this manual in a safe place for future reference.
Failure to follow the instructions for proper set up, use, and care for the device can increase the risk of serious personal
injury, death, or property damage. Once you use this device, you are deemed to have understood, recognized and accepted
all terms and contents of this document. The user shall be responsible for his own actions and all consequences arising from
failure to use the device in accordance with the “User Manual”, or as authorized in Pecron's current product literature.
[email protected]
DISCLAIMER

[email protected]
1、 Do not place the device near heat source, such as a fire or a heating furnace.
2、 Do not immerse in any liquid, or expose the unit to rain or wet conditions.
3、 Do not use the battery in a strong static electricity or electromagnetic environment.
4、 Do not disassemble or puncture the product with sharp objects in any way.
5、 Short circuits can be caused by: vermin or pests chewing through wires; water or other fluids coming into contact with
electrical wiring.
6、 Do not use accessories or parts other than those provided by Pecron. Please visit our website www.pecron.com or
reach our support team for a complete list of accessories and parts.
7、 When using this product, please strictly follow the ambient temperature for use in the user manual. If the temperature
is too high, the battery can potentially result in self-combustion and will burst into flames, which can cause widespread
damage. If the temperature is too low, the performance of the battery will be seriously degraded, and it may even fail
to meet the normal use requirements.
8、 Do not stack heavy objects on this product.
9、 Do not block the air vents during use, or leave the device in a non-ventilated or dusty space.
10、Please avoid impacts, fall off, and violent vibration. Please turn off the device immediately and stop using it in the event
of major exterior impact. Please fasten the unit firmly during transportation to avoid vibration and impact.
11、In the event of immersing the device into the water accidently, please place the unit in a safe open area and keep away
from the unit until it is completely dry. The dried unit should not be reused and should be disposed of properly
according to the local regulation. If the device catches fire, use the fire extinguishing equipment in the following
recommended order: water or mist, sand, fire blanket, dry chemical, carbon dioxide fire extinguisher.
12、Please wipe it with a dry cloth to clean the surface of the device.
13、Please place this device with care to prevent the product from being damaged due to fall off. If the product is damaged
due to fall off, please turn off the unit immediately and place it in an open area, keep away from combustibles and
crowds, and dispose of in accordance with local laws and regulations.
14、Please store this device in a place out of reach of children and pets.
WARNING
In compliance with laws and regulations, Pecron reserves all rights for final explanation, and to change these terms and
conditions at any time without prior notice. In the event that any revisions are made, the revised terms and conditions shall
be posted on our website immediately, please visit our website to inform yourself of any changes.

[email protected]
CUSTOMER SUPPORT：[email protected]
DISPOSAL
1、When conditions permit, please be sure to completely discharge the battery of this product, and then put the product
in the designated battery recycling box. This product contains batteries. Batteries are dangerous chemicals and are
strictly prohibited from being disposed of in ordinary trash. For details, please follow local laws and regulations on
battery recycling and disposal.
2、If the battery cannot be completely discharged due to the failure of the product itself, please do not dispose of the
battery directly in the battery recycling box, and contact a professional battery recycling company for further disposal.
3、The battery will not be able to start after being over-discharged, please dispose of it according to the principle of
disposal.
Pecron’s warranty does not apply to：
Misused, abused, modified,damaged by accident, or used for anything other than normal consumer
use as authorized in Pecron’s current product literature.
EXCLUSIONS
