Pecron S500 User manual

User manualPlease read the manual carefully before you use!Please keep the manual carefully so that you can check it for usage in the future. And please read the manual carefully to avoid unnecessary damage of the power.PORTABLE POWER STATION S500

Please read the following information before you use the power unit.To ensure the safety of use and avoid damage to the power pack, please first read the Safety Precautions (pages 1-3) and the Handling Precautions (page 3-5). Please also read this manual carefully to ensure proper use of the power.Please refer to this manual while using the power unit to familiar with the use of the device.When you reading this manual, please try to charge the device and familiarize yourself with the operating procedures of the power supply. This will give you a better understanding of our power unit Please be sure to keep the manual so that you can refer it again when you need it.Please read the instructions carefully before use.Our company does not assume any responsibility for any damage to your equipment caused by incorrect use of the power supply.

User ManualThank you for purchasing and using our products. In order to ensure the safe and correct use of this product, please read the user manual carefully before operating. ▇ This printed manual is a basic instruction manual. ▇ This manual only applies to portable power station of S500.▇ Due to product improvement and upgrading, the contents of product specifications and manuals may be changed without notice. ▇ The images and screen shots used in this manual may differ from the actual product.▇ Copyright - it is strictly prohibited to copy the contents of this manual without permission.

Editing routine in the manual(Page **): Reference page for more information: Warnings about problems with the power supply: Additional information: Tips or advice for better use of the power pack: Suggestions for troubleshooting

Content
Safety Precautions1Handling Precautions (Reserve and Use of Equipment Correctly)3List of the product6Product introduction7Product specifications8Introduction of the parts and functions9Operation instructions and precautions12How to charge the battery13How to use DC output18Misuse and countermeasures19Warranty and after-sale service20Certificate of qualification22Statement for poisonous and harmful substance of the power unit23Copyright24How to use AC output15.....................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................

，1Safety PrecautionsTo protect yourself and others from harm and to protect your equipment from damage, please read all the following information carefully before using your equipment.Warnings:1.Do not put the battery in the fire or heat the power and do not store the power in high temperature environment.2.Do not put the power supply into the water. Keep it in a cool and dry place during storage.3.Do not use the power supply in flammable or explosive environments such as gasoline, gas, chemical preparations,or mines, as this may endanger your safety.• Operate according to regulations, instructions and signs in potentially explosive environments. • Do not store or carry flammable liquids, gases, or explosive materials in boxes that is containing power supplies and power accessories.4.Do not use the power supply in a corrosive environment, otherwise the power supply may be damaged. 5.Do not apply paint or stickers to the power supply. Paints and stickers can clog equipment parts and prevent proper use. If you are allergic to paint or metal parts of your equipment, it may cause itching, eczema, or skin swelling. When this happens, please stop using and see a doctor.

26.Make sure that the heat dissipation is at least 5cm around the power supply.7.Do not disassemble, modify or repair the power supply. Any changes or modifications made to the equipment will not be warranted by the manufacturer. For repairs, please contact the dealer where you purchased the product.8.Do not use a charger that is not approved by the manufacturer to charge the power supply.9.Do not use the device in thunderstorms. This maybe cause the malfunction of the device and maybe increase the risk of electric shock.10.Handle and dispose of power and its charging adapter carefully.• Use only chargers that are specifically designed for the device and approved by our company. Unmatched chargers may cause danger or damage the device.• Do not throw battery into fire. When disposing of waste power, please comply with local and national regulations.• Do not place the battery or device inside or on top of a heating device (such as a microwave oven, oven, or radiator). Battery overheating may explode.• Do not squeeze or puncture the power supply and battery. Do not subject the battery to external high voltage, which may cause internal short circuit and overheating.11.Protect the power supply and charger from damage.• Avoid exposing the power supply to extremely cold or hot temperatures.

3• Extreme temperatures can damage the device, reduce its charging capacity, and shorten the life of the power supply.• Do not use a damaged charger.Handling Precautions (Custody and Use of Equipment Correctly)Keep the power supply dry• Moisture and liquids can damage equipment components or circuits。• Do not switch on the device when it is wet. If the device is turned on, turn it off immediately (if the device does not turn off, please maintain the status quo). • If the liquid enters the power source, it will damage the internal parts of the device, and the manufacturer will not guarantee this.Do not use or store equipment in dusty or dusty areasDust can cause equipment malfunction, fire or electric shock.Equipment can only be stored on a flat surfaceIf the device falls, it will be damagedDo not store the device in hot or cold places. Use the equipment within the range between -20°C and 60°C• If the device is placed in a closed vehicle, the device may

4be in a dangerous state because the internal temperature of the vehicle can reach as high as 80°C during the summer.• Do not expose the power supply to direct sunlight for long periods of time, such as on the dashboard of a car.• When charging the power supply, the operating temperature should be guaranteed between 0 °C and 45 °CDo not store equipment near or inside water heaters, microwave ovens, hot cooking equipment or high pressure vessels• Equipment may be overheated and this may cause a fire.Do not slide or crash the device• This may damage the device's screen. If you bend or deform it, it may damage the device or the part may malfunction.When cleaning equipment• Wipe the device or charger with a towel or eraser• Do not use chemicals or cleaners How to ensure maximum life for the battery and charger • If the multi-functional emergency power pack is idle for a long time, the power of the battery may be run out. Therefore, please make sure to charge the power supply every 6 months.• After long-term storage, when using the power again, please fully charge it first. (the power display will show,

5100% for the battery capacity, but the actual battery power will be less than 100% due to self-consumption of the battery, and the long-term loss of the control panel ) • When the charger is not in use, please disconnect the power.• Battery can only be used for specific purposes.• To make the battery life longer, please don't run off the power of the battery to 0% when using it, and it's better to recharge it when the battery is 10% remaining.Please use original accessories of our company to ensure the best performance.• Our company will not be responsible for any damage to the product or any accidents (such as fire) caused by using accessories that are not original from the company. (such as battery leakage or explosion)• Please note that any failure of this product caused by the use of accessories that are not original is not covered by the warranty of this product, but the user can pay for repairs.• Our company will not take any responsibility for the malfunction or accident caused by using an incompatible charger or product.If there is any malfunction, problem or damage to this product, please contact the dealer where you purchased the product.

6Packing list QuantityS500 power packCharging adapter Manual and warranty cardCharging cableCar charging cable1111112345NO.Charging adapter Charging cableCar charging cableProduct list Please check if the following standard items are included in the power after you buy our product. If there is a standard item missed, please contact the dealer. (Optional accessories should be explained with the manufacturer or distributor before purchase if necessary.)

Product IntroductionS500 is a multiple functional off-line portable power station which is designed with the safe lithium-ion battery and inverter technology. It’s very easy to carry and convenient offering power to electrical appliances with advantages of light weight, large capacity , high power and multiple functions; It is applied to a variety of intelligent products,such as mobile phone ,satellite phone, digital camera,mobile hard disk, tablet computer, LED lamp, laptop computer, car boot ,outdoor lighting. And it can also be used in the following fields like outdoor activities, media, tourism, and somewhere lacking of advanced technology.The following examples illustrate the power and standby time of some common appliancesSupply power to other appliances by :Smart Phone (8-10Wh) : charging for more than 53 timesTablet(16-25Wh) : charging for more than 27 timesLaptop(50Wh) : charging for more than 9 timesCar refrigerator(30-60W) : 7-14 hours7

Product parametersRated output powerPeak powerOutput voltageBattery type
Battery capacity
Life circleCharging timeCharging voltageand currentProtectionTempLED lightingSize (mm)Weight (kg)Model Over-voltage, low-voltage, over temperature, overload and AC short circuit protectionAC pure-sine wave 230V50Hz or AC110V60Hz 9~12.6V8A(MAX15A) USB 5V2ALithium-ion battery529.2Wh(10.8V49Ah)7~8HDC 13~30V 7A (MAX) solar panel with 18V1W*3L206*W149*H266S500 500W 1000W 70%@1000cycle0℃ - 45℃(Charge) ,-20℃-60℃(Discharge)4.58

Introduction of the parts and its functions
Front Panel
928615347

No.Description1DC cigar outlet : supply power to appliances with DC12V and the output voltage is 9~12.6V with rated current of 8A,Max output current is 15A. 2345DC charging input : support wide voltage charging from 13V to 30V with max current of 7A. Also support car charing, solar charging. The port is with DC5521 jack with max power of 90W.USB ports*2 : supply power with 5V and max current of 2A.
Smart display : showing the battery capacity,percentage,power and time of charging and discharging
USB Output/Power switch : Press this button to view the remaining power of the power unit. At the same time, the display will turn on, as same as the USB output.If need to turn off it, please press it again.
106DC 5525 jack*2 : supply power to appliances with DC port by 9~12.6V8A(MAX 15A).7 *3LED lights8Switch for LED light : The led light will be on after pressing the switch.

Back Panel 11910No.9Description
AC outputs : supply 230V or 110V output after pressing the AC switch.
AC output switch : AC output will work after pressing it .10

Operation instructions and precautions▇ Charge the power unit before using itTo ensure safe transportation of the S500 power supply, when you just get the power unit. it is not fully charged or it is in a low battery state, so please charge the power unit before using it.▇ Use the original charger provided by the manufacturerIn order to ensure the safety of charging, please use the original charger provided by the manufacturer, or use solar panels with 18V 100~250W Warning : Please pay attention the power unit when it's charging.Please disconnect the charger and stop charging when the S500 is fully charged.12▇ Hint for low batteryWhen battery is only 10% left, the outline of the battery frame will flash. You should charge the power pack at thistime;

How to charge the power unitThe rated power of S500 is 500W and its battery capacity is 529.2Wh(10.8V49Ah). We can charge the battery in the following ways at present：1. Charge the power unit with the original adapter from our company. During charging, we need to insert the end of the power cord into the adapter terminal and connect the 230V/110 AC mains. The DC output of the other end of the adapter is connected to the power charging interface. 13Electric supply

2.Charge the battery with original car charging cable. When you use the car charger, after starting the car engine, you only need to insert the cigarette lighter plug into the car cigarette lighter socket, and then connect the other end of the DC output port with our power unit. Then car charging is working(Power supply must be equipped with wide voltage charging module)Do not use the car charger when the car is not in the starting state.3.Charge the battery with solar panel. In this case, it is only necessary to connect one end of the connection cable to the solar panel and the other end to the power charging interface. Then solar charging is working.(maximum voltage of solar panels not more than 30V, minimum voltage not less than 13V)14Car cigar port
