Pepperl+Fuchs LUC-M10 User manual

BA 237O/98/en/05.05
52027986
185564 05/05 00 Ultrasonic level sensor
LUC-M** with HART and 4 mA ... 20 mA
Operating instructions
LUC-M10
LUC-M20
LUC-M30
HART
HART
R
R
FIELD COMMUNICATION PROTOCOL
C
LUC-M40

2
Date of Issue 07/18/05 185564
Subject to reasonable modifications due to technical advances. Copyright Pepperl+Fuchs, Printed in Germany
Pepperl+Fuchs Group •Tel.:Germany [phone] • USA [phone] • Singapore [phone] • Internet http://www.pepperl-fuchs.com
Short instructions LUC-M**
Short instructions
Contents of the operating instructions
This operating instructions describes the installation and commissioning of the
LUC-M** ultrasonic level transmitter. It contains all the functions required for a nor-
mal measuring operation. Also, the LUC-M** provides additional functions for opti-
mising the measuring point and for converting the measured value. These functions
are not included in this operating instructions.
You can find an overview of all the device functions in the appendix.
You can find a detailed description of all the device functions in the operating
instructions BA 240O/98/en "LUC-M**– Description of instrument functions".
E
+
-
+
E
+
-
F
L
D
E
E
E
-
... ...
KA 183O/98/a2/04.05
52027994
185587 04/05 00
BD
... ...
100%
0%
100 (HART)
2457 (PA,FF)
333 (HART)
33333 (PA,FF)
... ...
... ...
LUC-M** - Quick setup
- dome
ceiling
- horizontal
cyl.
- bypass
...
- unknown
- liquid
- > 4 mm
- < 4 mm
- standard
- calm
surface
agitator
- add.
...
input E
(see sketch) input F
(see sketch) - ok
- too small
- too big
- unknown
- manual
(see sketch)
000
measured value
group
selection
00
basic setup
01
saf
ety settings
0C
system
parameter
0E
envelope curve
04
linearisation
05
e
xtended calibr.
06
output (HART, FF)
profibus param.(PA)
0A
diagnostics
0A0
present
error
002
tank shape 004
process
cond.
005
empty
calibr.
006
full
calibr.
008
dist./
meas. value
051
check
distance
003
medium
property
052 053
008
dist./
meas. value
0E1
plot settings
0E2
recording
curve
0A1
previous
error
0A4
unlock
parameter
03
temperature
09
display
092
language
BD: blocking distance
0A3
reset
0C0
tag no.
059
blocking
distance
BD is
displayed
(see sketch)
Contrast: + or +
52027994
range of
mapping start
mapping
confirm
or specify
range
suggestion
displayed
D and L are

Subject to reasonable modifications due to technical advances. Copyright Pepperl+Fuchs, Printed in Germany
Pepperl+Fuchs Group •Tel.:Germany [phone] • USA [phone] • Singapore [phone] • Internet http://www.pepperl-fuchs.com
3
Date of Issue 07/18/05 185564
Table of contents
LUC-M**
Short instructions. . . . . . . . . . . . . . . . . . . . . 2
1 Safety instructions . . . . . . . . . . . . . . . . 4
1.1 Designated use . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
1.2 Installation, commissioning, operation . . . . . . . . . . 4
1.3 Hazardous area. . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
1.4 Notes on safety conventions and symbols . . . . . . . 5
2 Identification . . . . . . . . . . . . . . . . . . . . . 6
2.1 Nameplate. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
2.2 Product structure LUC-M10. . . . . . . . . . . . . . . . . . . 7
2.3 Product structure LUC-M20. . . . . . . . . . . . . . . . . . . 7
2.4 Product structure LUC-M30. . . . . . . . . . . . . . . . . . . 8
2.5 Product structure LUC-M40. . . . . . . . . . . . . . . . . . . 8
2.6 Scope of delivery. . . . . . . . . . . . . . . . . . . . . . . . . . . 9
2.7 Certificates and approvals. . . . . . . . . . . . . . . . . . . . 9
2.8 Registered trademarks . . . . . . . . . . . . . . . . . . . . . . 9
3 Installation . . . . . . . . . . . . . . . . . . . . . . 10
3.1 Dimensions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
3.2 Installation variants . . . . . . . . . . . . . . . . . . . . . . . . 11
3.3 Installation conditions . . . . . . . . . . . . . . . . . . . . . . 12
3.4 Measuring range . . . . . . . . . . . . . . . . . . . . . . . . . . 15
3.5 Installation hint for LUC-M10/20 . . . . . . . . . . . . . . 16
3.6 Turn housing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
3.7 Installation check. . . . . . . . . . . . . . . . . . . . . . . . . . 17
4 Wiring . . . . . . . . . . . . . . . . . . . . . . . . . . 18
4.1 Electrical connection . . . . . . . . . . . . . . . . . . . . . . . 18
4.2 Terminal assignment. . . . . . . . . . . . . . . . . . . . . . . 19
4.3 Supply voltage. . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
4.4 Potential matching. . . . . . . . . . . . . . . . . . . . . . . . . 21
4.5 Checking the connection. . . . . . . . . . . . . . . . . . . . 21
5 Operation . . . . . . . . . . . . . . . . . . . . . . . 22
5.1 Display and operating elements . . . . . . . . . . . . . . 22
5.2 Function codes . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
5.3 Operating options . . . . . . . . . . . . . . . . . . . . . . . . . 24
5.4 Operation using the on-site display VU331. . . . . . 25
5.5 Operation using PACTwareTM . . . . . . . . . . . . . . . . . 26
5.6 Operation using a HART handheld terminal . . . . . 26
5.7 Lock/unlock configuration . . . . . . . . . . . . . . . . . . . 26
5.8 Resetting the customer parameters . . . . . . . . . . . 27
5.9 Resetting an interference echo suppression
(tank map) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
6 Commissioning . . . . . . . . . . . . . . . . . . 29
6.1 Power up instrument. . . . . . . . . . . . . . . . . . . . . . . . 29
6.2 Basic calibration . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
6.3 Envelope curve. . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
7 Troubleshooting . . . . . . . . . . . . . . . . . 37
7.1 System error messages . . . . . . . . . . . . . . . . . . . . . 37
7.2 Application errors . . . . . . . . . . . . . . . . . . . . . . . . . . 39
8 Maintenance and repairs. . . . . . . . . . . 40
8.1 Exterior cleaning. . . . . . . . . . . . . . . . . . . . . . . . . . . 40
8.2 Repairs. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40
8.3 Repairs to Ex-approved devices. . . . . . . . . . . . . . . 40
8.4 Replacement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40
8.5 Spare parts (housing type F12) . . . . . . . . . . . . . . . 41
8.6 Spare parts (housing type T12) . . . . . . . . . . . . . . . 43
8.7 Return. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45
8.8 Disposal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45
8.9 Contact addresses of Pepperl+Fuchs . . . . . . . . . . 45
9 Accessories . . . . . . . . . . . . . . . . . . . . . 46
9.1 Weather protection cover . . . . . . . . . . . . . . . . . . . . 46
9.2 Installation bracket for LUC-M10/LUC-M20 . . . . . . 46
9.3 Mounting bracket for LUC-M30/LUC-M40 . . . . . . . 46
9.4 Cantilever . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47
9.5 Mounting frame for cantilever. . . . . . . . . . . . . . . . . 48
9.6 Wall bracket for cantilever . . . . . . . . . . . . . . . . . . . 48
9.7 Adapter flange for LUC-M10/LUC-M20 . . . . . . . . . 49
9.8 Universal slip-on flange for LUC-M30. . . . . . . . . . . 50
9.9 Remote display and operation . . . . . . . . . . . . . . . . 50
10 Technical data . . . . . . . . . . . . . . . . . . . 51
10.1 Input . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51
10.2 Output. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51
10.3 Auxiliary energy . . . . . . . . . . . . . . . . . . . . . . . . . . . 51
10.4 Performance characteristics. . . . . . . . . . . . . . . . . . 52
10.5 Ambient conditions. . . . . . . . . . . . . . . . . . . . . . . . . 53
10.6 Process conditions. . . . . . . . . . . . . . . . . . . . . . . . . 53
11 Appendix . . . . . . . . . . . . . . . . . . . . . . . 54
11.1 Operating menu . . . . . . . . . . . . . . . . . . . . . . . . . . . 54
11.2 Measuring principle . . . . . . . . . . . . . . . . . . . . . . . . 56
Index. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 57
Declaration of contamination. . . . . . . . . . . 58

4
Date of Issue 07/18/05 185564
Subject to reasonable modifications due to technical advances. Copyright Pepperl+Fuchs, Printed in Germany
Pepperl+Fuchs Group •Tel.:Germany [phone] • USA [phone] • Singapore [phone] • Internet http://www.pepperl-fuchs.com
Safety instructions LUC-M**
1 Safety instructions
1.1 Designated use
The LUC-M** is a compact measuring device for continuous, non-contact level
measurement. Depending on the sensor, the measuring range is up to 15 m in
fluids and up to 7 m in bulk solids. By using the linearisation function, the LUC-M**
can also be used for flow measurements in open channels and measuring weirs.
1.2 Installation, commissioning, operation
The LUC-M** is fail-safe and is constructed to the state-of-the-art. It meets the
appropriate standards and EC directives. However, if you use it improperly or other
than for its designated use, it may pose application-specific hazards, e. g. product
overflow due to incorrect installation or configuration. Installation, electrical
connection, start-up, operation and maintenance of the measuring device must
therefore be carried out exclusively by trained specialists authorised by the system
operator. Technical personnel must have read and understood these operating
instructions and must adhere to them. You may only undertake modifications or
repair work to the device when it is expressly permitted by the operating
instructions.
1.3 Hazardous area
Measuring systems for use in hazardous environments are accompanied by
separate "Ex documentation", which is an integral part of this Operating Manual.
Strict compliance with the installation instructions and ratings as stated in this
supplementary documentation is mandatory.
• Ensure that all personnel are suitably qualified.
• Observe the specifications in the certificate as well as national and local
regulations.

5
Subject to reasonable modifications due to technical advances. Copyright Pepperl+Fuchs, Printed in Germany
Pepperl+Fuchs Group •Tel.:Germany [phone] • USA [phone] • Singapore [phone] • Internet http://www.pepperl-fuchs.com
Date of Issue 07/18/05 185564
Safety instructions
LUC-M**
1.4 Notes on safety conventions and symbols
In order to highlight safety-relevant or alternative operating procedures in the
manual, the following conventions have been used, each indicated by a
corresponding symbol in the margin.
Symbol Meaning
#Warning!
A warning highlights actions or procedures which, if not performed correctly,
will lead to personal injury, a safety hazard or destruction of the instrument.
"Caution!
Caution highlights actions or procedures which, if not performed correctly,
may lead to personal injury or incorrect functioning of the instrument.
!Note!
A note highlights actions or procedures which, if not performed correctly,
may indirectly affect operation or may lead to an instrument response which
is not planned.
0Device certified for use in explosion hazardous area
If the device has this symbol embossed on its name plate it can be installed
in an explosion hazardous area.
-
Explosion hazardous area
Symbol used in drawings to indicate explosion hazardous areas.
- Devices located in and wiring entering areas with the designation
"explosion hazardous areas" must conform with the stated type of
protection.
.
Safe area (non-explosion hazardous area)
Symbol used in drawings to indicate, if necessary, non-explosion hazardous
areas.
- Devices located in safe areas still require a certificate if their outputs run
into explosion hazardous areas.
%Direct voltage
A terminal to which or from which a direct current or voltage may be applied
or supplied.
&Alternating voltage
A terminal to which or from which an alternating (sine-wave) current or
voltage may be applied or supplied.
)Grounded terminal
A grounded terminal, which as far as the operator is concerned, is already
grounded by means of an earth grounding system.
*Protective grounding (earth) terminal
A terminal which must be connected to earth ground prior to making any
other connection to the equipment.
+Equipotential connection (earth bonding)
A connection made to the plant grounding system which may be of type
e. g. neutral star or equipotential line according to national or company
practice.
Temperature resistance of the connection cables
States, that the connection calbes must be resistant to a temperature of at
least 85 °C (358 K).
t > 85˚C

6
Date of Issue 07/18/05 185564
Subject to reasonable modifications due to technical advances. Copyright Pepperl+Fuchs, Printed in Germany
Pepperl+Fuchs Group •Tel.:Germany [phone] • USA [phone] • Singapore [phone] • Internet http://www.pepperl-fuchs.com
Safety instructions LUC-M**
2 Identification
2.1 Nameplate
Informations at the LUC-M** nameplate (example)
Made in Germany
Dat./Insp.:
Order Code:
IP68 / NEMA 6P
Ser.-No.:
4-wire
t >85°C
TA > 70°C :
D01301-A
if modification
see sep. label
X = Patents
LUC-M**
90 ... 253 V AC 1VA
10,5 ... 32 V DC 1W
14 ... 36 V DC 0,8W
Profibus PA
Foundation Fieldbus
LN= PN=
4 ... 20 mA HART 2-wire
order code
(see order information)
communication
variant and
supply voltage
serial number
reference to additional
safe-relevant documentation
designation according to directive 94/9/EG
and designation of the type of protection

7
Subject to reasonable modifications due to technical advances. Copyright Pepperl+Fuchs, Printed in Germany
Pepperl+Fuchs Group •Tel.:Germany [phone] • USA [phone] • Singapore [phone] • Internet http://www.pepperl-fuchs.com
Date of Issue 07/18/05 185564
Safety instructions
LUC-M**
2.2 Product structure LUC-M10
2.3 Product structure LUC-M20
LUC–M10– – –
Certificate
NA version for non-explosion hazardous areas
EX ¬II 1/2 G EEx ia IIC T6
ES ¬II 1/2 D, aluminium cover
E2 ¬II 1/3 D
SX ¬II 1/2 G EEx d (ia) IIC T6
S2 ¬II 3G EEx nA II T6
F1 FM IS, Cl. I/II/III, Div.1 Group A-G, N.I .Cl. I, Div.2
F2 FM XP, Cl. I/II/III, Div. 1, Group A-G
CG CSA, General Purpose
C1 CSA IS, Cl. I/II/III, Div. 1, Group A-D, G + coal dust, N.I.
C2 CSA XP, Cl. I/II/III, Div. 1, Group A-D, G + coal dust, N.I.
Display
A* prepared for remote display, order display as accessory LUC-Z40
Bwithout display
Dwith display VU331 inclusive on-site operation, envelope curve display
Electrical output
AH 4-wire, 90 V AC ... 250 V AC, 4 mA ... 20 mA, HART
DH 4-wire, 10.5 V DC ... 32 V DC, 4 mA ... 20 mA, HART
FF 2-wire, Foundation Fieldbus
PA 2-wire, PROFIBUS PA
IH 2-wire, 4 mA ... 20 mA, HART
Cable entry
2cable gland M20 x 1.5
3thread G½
4thread ½ NPT
5connector M12, PROFIBUS PA
6connector 7/8", Foundation Fieldbus
Housing
A1 aluminium housing F12, IP68, thread M20 x 1.5
A2 aluminium housing T12, IP68, coated, with separate terminal compartment
A4 aluminium housing T12, IP68, coated, with separate terminal compartment, overvoltage protection
Prozess connection
G5 thread G1½B, ISO 228, PVDF
N5 thread 1½ NPT, ANSI, PVDF * in preparation
LUC–M20– – –
Certificate
NA version for non-explosion hazardous areas
EX ¬II 1/2 G EEx ia IIC T6
ES ¬II 1/2 D, aluminium cover
E2 ¬II 1/3 D
SX ¬II 1/2 G EEx d (ia) IIC T6
S2 ¬II 3G EEx nA II T6
F1 FM IS, Cl. I/II/III, Div.1 Group A-G, N.I .Cl. I, Div.2
F2 FM XP, Cl. I/II/III, Div. 1, Group A-G
CG CSA, General Purpose
C1 CSA IS, Cl. I/II/III, Div. 1, Group A-D, G + coal dust, N.I.
C2 CSA XP, Cl. I/II/III, Div. 1, Group A-D, G + coal dust, N.I.
Display
A* prepared for remote display, order display as accessory LUC-Z40
Bwithout display
Dwith display VU331 inclusive on-site operation, envelope curve display
Electrical output
AH 4-wire, 90 V AC ... 250 V AC, 4 mA ... 20 mA, HART
DH 4-wire, 10.5 V DC ... 32 V DC, 4 mA ... 20 mA, HART
FF 2-wire, Foundation Fieldbus
PA 2-wire, PROFIBUS PA
IH 2-wire, 4 mA ... 20 mA, HART
Cable entry
2cable gland M20 x 1,5
3thread G½
4thread ½ NPT
5connector M12, PROFIBUS PA
6connector 7/8", Foundation Fieldbus
Housing
A1 aluminium housing F12, IP68, thread M20 x 1.5
A2 aluminium housing T12, IP68, coated, with separate terminal compartment
A4 aluminium housing T12, IP68, coated, with separate terminal compartment, overvoltage protection
Prozess connection
G6 thread G2B, ISO 228, PVDF
N6 thread 2 NPT, ANSI, PVDF * in preparation

8
Date of Issue 07/18/05 185564
Subject to reasonable modifications due to technical advances. Copyright Pepperl+Fuchs, Printed in Germany
Pepperl+Fuchs Group •Tel.:Germany [phone] • USA [phone] • Singapore [phone] • Internet http://www.pepperl-fuchs.com
Safety instructions LUC-M**
2.4 Product structure LUC-M30
2.5 Product structure LUC-M40
LUC–M30– – –
Certificate
NA version for non-explosion hazardous areas
ES ¬II 1/2 D, aluminium cover
E2 ¬II 1/3 D
FM FM DIP, Cl. II, Div.1 Group E-G, N.I .Cl. I, Div.2
CG CSA, General Purpose
CS CSA DIP, Cl. II, Div. 1, Group E-G, N.I .Cl. I, Div.2
Display
A* prepared for remote display, order display as accessory LUC-Z40
Bwithout display
Dwith display VU331 inclusive on-site operation, envelope curve display
Electrical output
AH 4-wire, 90 V AC ... 250 V AC, 4 mA ... 20 mA, HART
DH 4-wire, 10.5 V DC ... 32 V DC, 4 mA ... 20 mA, HART
FF 2-wire, Foundation Fieldbus
PA 2-wire, PROFIBUS PA
Cable entry
2cable gland M20 x 1,5
3thread G½
4thread ½ NPT
5connector M12, PROFIBUS PA
6connector 7/8", Foundation Fieldbus
Housing
A1 aluminium housing F12, IP68, thread M20 x 1.5
Prozess connection
FA universal flange DN100/ANSI 4"/JIS16K100, PP
FS universal flange DN100/ANSI 4"/JIS16K100, 316Ti
FK without slip-on flange, without mounting bracket, customer mounting equipment
FM with mounting bracket LUC-Z17 * in preparation
LUC–M40– – –
Certificate
NA version for non-explosion hazardous areas
EX ¬II 1/2 G EEx ia IIC T6
SX ¬II 1/2 G EEx d (ia) IIC T6
S2 ¬II 3G EEx nA II T6
F1 FM IS, Cl. I/II/III, Div.1 Group A-G, N.I .Cl. I, Div.2
F2 FM XP, Cl. I/II/III, Div. 1, Group A-G
CG CSA, General Purpose
C1 CSA IS, Cl. I/II/III, Div. 1, Group A-D, G + coal dust, N.I.
C2 CSA XP, Cl. I/II/III, Div. 1, Group A-D, G + coal dust, N.I.
Additional option
Abasic version
Sealing sensor/flange
2Viton
3EPDM
Display
A* prepared for remote display, order display as accessory LUC-Z40
Bwithout display
Dwith display VU331 inclusive on-site operation, envelope curve display
Electrical output
AH 4-wire, 90 V AC ... 250 V AC, 4 mA ... 20 mA, HART
DH 4-wire, 10.5 V DC ... 32 V DC, 4 mA ... 20 mA, HART
FF 2-wire, Foundation Fieldbus
PA 2-wire, PROFIBUS PA
IH 2-wire, 4 mA ... 20 mA, HART
Cable entry
2cable gland M20 x 1.5
3thread G½
4thread ½ NPT
5connector M12, PROFIBUS PA
6connector 7/8", Foundation Fieldbus
Housing
A1 aluminium housing F12, IP68, thread M20 x 1.5
A2 aluminium housing T12, IP68, coated, with separate terminal compartment
A4 aluminium housing T12, IP68, coated, with separate terminal compartment, overvoltage protection
Process connection; max. 3 bar abs/44 psia, hole circle PN16/150 lbs/10K
Puniversal flange DN80/ANSI 3"/JIS10K80, PP
Quniversal flange DN80/ANSI 3"/JIS10K80, PVDF
Suniversal flange DN80/ANSI 3"/JIS10K80, 316L
Tuniversal flange DN100/ANSI 4"/JIS16K100, PP
Uuniversal flange DN100/ANSI 4"/JIS16K100, PVDF
Vuniversal flange DN100/ANSI 4"/JIS16K100, 316L
Mmounting bracket LUC-Z17 * in preparation

9
Subject to reasonable modifications due to technical advances. Copyright Pepperl+Fuchs, Printed in Germany
Pepperl+Fuchs Group •Tel.:Germany [phone] • USA [phone] • Singapore [phone] • Internet http://www.pepperl-fuchs.com
Date of Issue 07/18/05 185564
Safety instructions
LUC-M**
2.6 Scope of delivery
2.6.1 Instrument and accessories
• Instrument according to the version ordered
• for LUC-M10/20 in the versions LUC-M10-G5**** and LUC-M20-G6****:
counter nut (PA)
• for LUC-M10/20: sealing ring (EPDM)
• or gland M20 x 1.5:
– 1 cable gland for 2-wire instruments
– 2 cable glands for 4-wire instruments
The cable glands are mounted on delivery.
2.6.2 Supplied documentation
Short instructions (KA 183O, in the instrument)
intended as a memory jogger for users who are familiar with the operating concept
of Pepperl+Fuchs time-of-flight instruments.
Operating instructions (BA 237O, this booklet)
This describes the installation and commissioning of the LUC-M**. The operating
menu includes all the functions which are required for standard measurement tasks.
Any additional functions are not included.
Description of instrument functions (BA 240O)
contains a detailed description of all the functions of the LUC-M**.
Safety instructions
Additional safety instructions (SI, ZE, ZD) are supplied with certified device
versions. Refer to the nameplate for the names of the safety instructions that apply
to your device variant.
2.7 Certificates and approvals
CE mark, declaration of conformity
The instrument is designed to meet state-of-the-art safety requirements, has been
tested and left the factory in a condition in which it is safe to operate. The instrument
complies with the applicable standards and regulations in accordance with
EN 61010 "Protection Measures for Electrical Equipment for Measurement, Control,
Regulation and Laboratory Procedures". The instrument described in this manual
thus complies with the statutory requirements of the EC directives. Pepperl+Fuchs
confirms the successful testing of the instrument by affixing to it the CE mark.
2.8 Registered trademarks
HART®
Registered trademark of HART Communication Foundation, Austin, USA

10
Date of Issue 07/18/05 185564
Subject to reasonable modifications due to technical advances. Copyright Pepperl+Fuchs, Printed in Germany
Pepperl+Fuchs Group •Tel.:Germany [phone] • USA [phone] • Singapore [phone] • Internet http://www.pepperl-fuchs.com
Installation LUC-M**
3 Installation
3.1 Dimensions
65 78
Ø129
78
85
85
65
Ø129
162
150
68 94
~148
~83
22
LUC-M10 LUC-M20
Ø39 Ø50
~148
~87
22
85
2 x M8
65 78
Ø129
~86
150
~248
32
Ø158
Ø230
~ 88
Ø70
F12/
T12
75
30
119
M8
F12
105
75
G2
2 NPT
G1½
1½ NPT
ANSI 4"/DN100
Ø89
ca.
Gehäuse F12 GehäuseT12
LUC-M40 mit Universalflansch
SW60
SW60
LUC-M30 mit Montagebügel
LUC-M40 mit Montagebügel
Flansch:
DN80/ANSI 3"/JIS10K80
DN100/ANSI 4"/JIS16K100
passen zu PN16
nach DIN/EN 1092 Teil 1
LUC-M30 mit Universalüberwurfflansch
Es kann auch ein getrennter Flansch verwendet werden.
86

11
Subject to reasonable modifications due to technical advances. Copyright Pepperl+Fuchs, Printed in Germany
Pepperl+Fuchs Group •Tel.:Germany [phone] • USA [phone] • Singapore [phone] • Internet http://www.pepperl-fuchs.com
Date of Issue 07/18/05 185564
Installation
LUC-M**
3.2 Installation variants
3.2.1 Installation variants LUC-M10, LUC-M20
For mounting bracket or adapter flange see section "Accessories"
3.2.2 Installation variants LUC-M30
Installation with welding sleeveInstallation with counter nut
Installation with mounting bracket
counter nut (PC)
is supplied to
G1½ and
G2 devices
adapter flange
sensor nozzle
sealing ring
(EPDM)
supplied
Installation with adapter flange
sealing ring
(EPDM)
supplied
.
-
Installation with
mounting bracket
Installation with
universal slip-on flange (option)
slip-on flange
sensor
nozzle e. g.
zone 20 zone 20

12
Date of Issue 07/18/05 185564
Subject to reasonable modifications due to technical advances. Copyright Pepperl+Fuchs, Printed in Germany
Pepperl+Fuchs Group •Tel.:Germany [phone] • USA [phone] • Singapore [phone] • Internet http://www.pepperl-fuchs.com
Installation LUC-M**
3.2.3 Installation variants LUC-M40
3.3 Installation conditions
3.3.1 Installation conditions for level measurements
• Do not install the sensor in the middle of the tank (3). We recommend leaving a
distance between the sensor and the tank wall (1) measuring 1/6 of the tank
diameter.
• Use a protective cover, in order to protect the device from direct sun or rain (2).
• Avoid measurements through the filling curtain (4).
• Make sure that equipment (5) such as limit switches, temperature sensors, etc.
arenotlocatedwithintheemittingangleα.Inparticular,symmetricalequipment
(6) such as heating coils, baffles etc. can influence measurement.
• Align the sensor so that it is vertical to the product surface (7).
• Never install two ultrasonic measuring devices in a tank, as the two signals may
affect each other.
• To estimate the transmitted echo beam and its detection range, use the 3 dB
emitting angle α:
Sensor αLr
LUC-M10 11° 5 m 0.48 m
LUC-M20 11° 8 m 0.77 m
LUC-M30 6° 15 m 0.79 m
LUC-M40 11° 10 m 0.96 m
Installation with
mounting bracket
Installation with universal flange
flange:
DN80/ANSI 3"/JIS10K80
DN100/ANSI 4"/JIS16K100
1
234
5
6
1/6D
7
D
r
αL

13
Subject to reasonable modifications due to technical advances. Copyright Pepperl+Fuchs, Printed in Germany
Pepperl+Fuchs Group •Tel.:Germany [phone] • USA [phone] • Singapore [phone] • Internet http://www.pepperl-fuchs.com
Date of Issue 07/18/05 185564
Installation
LUC-M**
3.3.2 Installation in narrow shafts
3.3.3 Installation conditions for flow measurements
• Install the LUC-M** at the inflow side, as close above the maximum water level
Hmax as possible, plus the blocking distance BD.
• Position the LUC-M** in the middle of the channel or weir.
• Align the sensor membrane parallel to the water surface.
• Keep to the installation distance of the channel or weir.
• You can enter the "flow to level" linearisation curve ("Q/h curve") using via the
on-site display.
Example: Khafagi-Venturi flume
In narrow shafts with strong interference
echoes, we recommend using an
ultrasound guide pipe (e. g. PE or PVC
wastewater pipe) with a minimum
diameter of 100 mm.
Make sure that the pipe is not soiled by
accumulated dirt. If necessary, clean the
pipe at regular intervals.
ENDRESS+HAUSER
ProsonicM ENDRESS+HAUSER
ProsonicM
venting
hole
1 x b0
b0
BD
Hmax
Khafagi - Venturi - flume direction of flow
inflow outflow
empty calibr.

14
Date of Issue 07/18/05 185564
Subject to reasonable modifications due to technical advances. Copyright Pepperl+Fuchs, Printed in Germany
Pepperl+Fuchs Group •Tel.:Germany [phone] • USA [phone] • Singapore [phone] • Internet http://www.pepperl-fuchs.com
Installation LUC-M**
Example: Triangular weir
max
max
max
max
min. 3 H
H
min. 2 H
α
min. 2 H
BD
(= full calibr.)
empty calibr.

15
Subject to reasonable modifications due to technical advances. Copyright Pepperl+Fuchs, Printed in Germany
Pepperl+Fuchs Group •Tel.:Germany [phone] • USA [phone] • Singapore [phone] • Internet http://www.pepperl-fuchs.com
Date of Issue 07/18/05 185564
Installation
LUC-M**
3.4 Measuring range
3.4.1 Blocking distance, nozzle mounting
Install the LUC-M** at a height so that the blocking distance BD is not undershot,
even at maximum fill level. Use a pipe nozzle if you cannot maintain the blocking
distance in any other way. The interior of the nozzle must be smooth and may not
contain any edges or welded joints. In particular, there should be no burr on the
inside of the tank side nozzle end. Note the specified limits for nozzle diameter and
length. To minimise disturbing factors, we recommend an angled socket edge
(ideally 45°).
BD: blocking distance; SD: safety distance; E: empty calibration; F: full calibration
(span); D: nozzle diameter; L: nozzle length
"Caution!
If the blocking distance is undershot, it may cause device malfunction.
!Note!
In order to prevent the level from entering the blocking distance, you can specify a
safety distance (SD). If the level is within this safety distance, the LUC-M** outputs
a warning or alarm message.
Sensor BD Max. range
liquids Max. range bulk materials nozzle diameter max. nozzle length
LUC-M10 0.25 m 5 m 2 m 50 mm approx. 80 mm
80 mm approx. 240 mm
100 mm approx. 300 mm
LUC-M20 0.35 m 8 m 3.5 m 80 mm approx. 240 mm
100 mm approx. 300 mm
LUC-M30 0.6 m 15 m 7 m min. 100 mm approx. 300 mm
LUC-M40 0.4 m 10 m 5 m 80 mm approx. 250 mm
100 mm approx. 300 mm
F
E
BD
SD
LD
LUC-M10/20
L
D
LUC-M30
L
D
LUC-M40

16
Date of Issue 07/18/05 185564
Subject to reasonable modifications due to technical advances. Copyright Pepperl+Fuchs, Printed in Germany
Pepperl+Fuchs Group •Tel.:Germany [phone] • USA [phone] • Singapore [phone] • Internet http://www.pepperl-fuchs.com
Installation LUC-M**
3.4.2 Safety distance
If the level rises to the safety distance SD, the device switches to warning or alarm
status.
The size of SD can be set freely in the "Safety distance" (015) function. The
"in safety distance" (016) function defines how the device reacts if the level enters
the safety distance.
There are three options:
•Warning: The device outputs an error message but continues measurement.
•Alarm: The device outputs an error message. The output signal assumes the
valuedefinedinthe"Outputon alarm" (011)function(MAX,MIN,user-specific
value or holds the last value). As soon as the level drops below the safety
distance, the device recommences measurement.
•Self holding: The device reacts in the same way as foran alarm. However, the
alarm condition continues after the level drops below the safety distance. The
device only recommences measurement when you cancel the alarm using the
"Ackn. alarm" (017) function.
3.4.3 Range
The sensor range is dependent on the measuring conditions. Refer to Technical
Information TI 365O/98/en for an estimation. The maximum range is shown in the
above diagram (valid for good conditions).
3.5 Installation hint for LUC-M10/20
Sensor Maximum range
LUC-M10 5 m
LUC-M20 8 m
LUC-M30 15 m
LUC-M40 10 m
Screw the LUC-M** at the screw-in
piece using an AF60 spanner.
Maximum torque: 20 Nm. Caution!
Use only the
screw-in peace
to screw in the
LUC-M**
max. torque
20 Nm
F12 or T12 housing
AF 60
60

17
Subject to reasonable modifications due to technical advances. Copyright Pepperl+Fuchs, Printed in Germany
Pepperl+Fuchs Group •Tel.:Germany [phone] • USA [phone] • Singapore [phone] • Internet http://www.pepperl-fuchs.com
Date of Issue 07/18/05 185564
Installation
LUC-M**
3.6 Turn housing
After mounting, the housing can be turned 350° in order to simplify access to the
display and the terminal compartment. Proceed as follows to turn the housing to the
required position:
• undo the fixing screws (1)
• turn the housing (2) in the required direction
• tighten up the fixing screws (1). Maximum torque 0.5 Nm
3.7 Installation check
After installing the device, carry out the following checks:
• Is the device damaged (visual inspection)?
• Does the device correspond to the measuring point specifications for process
temperature, process pressure, ambient temperature, measuring range etc.
• If available: Are the measuring point number and labelling correct (visual
inspection)?
• Is the measuring device sufficiently protected against precipitation and direct
sunlight?
• Are the cable glands tightened correctly?
• After aligning the housing, check the process seal at the nozzle or flange.
F12 housing T12 housing
Allen key
4 mm/ 0.1"
max. torque 0.5 Nm
2
1
2
1

18
Date of Issue 07/18/05 185564
Subject to reasonable modifications due to technical advances. Copyright Pepperl+Fuchs, Printed in Germany
Pepperl+Fuchs Group •Tel.:Germany [phone] • USA [phone] • Singapore [phone] • Internet http://www.pepperl-fuchs.com
Installation LUC-M**
4Wiring
4.1 Electrical connection
"Caution!
Before connection please note the following:
• The power supply must be identical to the data on the nameplate.
• Switch off power supply before connecting up the instrument.
• Connectequipotentialbondingtotransmittergroundterminalbeforeconnecting
up the instrument (s. section "Potential matching")
#Warning!
When you use the measuring system in hazardous areas, make sure to comply with
national standards and the specifications in the safety instructions (SI’s). Make sure
you use the specified cable gland.
4.1.1 Wiring in the housing F12
1. Unscrew housing cover (1).
2. Remove display (2) if fitted.
3. Removecoverplate(3)fromterminal
compartment.
4. Pull out terminal module (4) slightly
using pulling loop.
5. Insert cable (5) through gland (6).
6. Connect cable screen to the
grounding terminal (7) within the
terminal compartment.
7. Make connection according to
terminal assignment (see below).
8. Re-insert terminal module (4).
9. Tighten cable gland (6).
10. Tighten screws on cover plate (3).
11. Insert display (2) if fitted.
12. Screw on housing cover (1).
13. Switch on power supply.
1234
ENDRESS+HAUSER
3
5
4
1
2
6
7

19
Subject to reasonable modifications due to technical advances. Copyright Pepperl+Fuchs, Printed in Germany
Pepperl+Fuchs Group •Tel.:Germany [phone] • USA [phone] • Singapore [phone] • Internet http://www.pepperl-fuchs.com
Date of Issue 07/18/05 185564
Installation
LUC-M**
4.1.2 Wiring in the housing T12
4.2 Terminal assignment
1. Unscrew the cover (1) of the
separate connection room.
2. Insert cable (2) through gland (3).
3. Connect cable screen to the
grounding terminal (4) within the
connection room.
4. Make connection according to the
terminal assignment (see below).
5. Tighten cable gland (3).
6. Screw on housing cover (1).
7. Switch on power supply
HART, 2-wire version HART, 4-wire version, active
3
2
1234
4
1
(> 250 Ω)
3
I+ I-
12
L+
L-
4 mA ... 20 mA
PAL
4
Communication
resistor
HART
modem
alternative
Auxiliary
voltage
Test socket
(output current)
5
I+ I-
12
N/L-
L1/L+
AC / DC
4 mA ... 20 mA
PAL
DC
6
(> 250 Ω)
HART
modem
alternative
Auxiliary
voltage
Communication
resistor
Display unit,
Recorder, PCS

20
Date of Issue 07/18/05 185564
Subject to reasonable modifications due to technical advances. Copyright Pepperl+Fuchs, Printed in Germany
Pepperl+Fuchs Group •Tel.:Germany [phone] • USA [phone] • Singapore [phone] • Internet http://www.pepperl-fuchs.com
Installation LUC-M**
4.3 Supply voltage
4.3.1 HART, 2-wire
The following values are the voltages across the terminals directly at the instrument:
1) start-up current 11 mA
4.3.2 HART, 4-wire
"Caution!
When using the public powers supply, install an easy accessible power switch in the
proximity of the instrument. Mark the power switch as a disconnector for the
instrument (IEC/EN 61010).
Version Current
consumption Terminal voltage minimum Terminal voltage maximum
2-wire HART
standard 4 mA 14 V 36 V
20 mA 8 V 36 V
EEx ia 4 mA 14 V 30 V
20 mA 8 V 30 V
EEx d 4 mA 14 V 30 V
20 mA 11 V 30 V
Fixed current,
adjustable, e. g.
for solar power
operation
(measured value
via HART)
standard 11 mA 10 V 36 V
EEx ia 11 mA 10 V 30 V
Fixed current for
HART multidrop
mode
standard 4 mA114 V 36 V
EEx ia 4 mA114 V 30 V
Version Voltage Max. load
DC 10.5 V ... 32 V 600 Ω
AC 50/60 Hz 90 V ... 253 V 600 Ω
