Pepperl+Fuchs VDM54 Series User manual

MANUAL
FACTORY AUTOMATION
DISTANCE SENSOR
VDM54

Date of issue 09/30/2009 Part No. 210258
With regard to the supply of products, the current issue of the following document is applicable:
The General Terms of Delivery for Products and Services of the Electrical Industry, published by the Central
Association of the Electrical Industry (Zentralverband Elektrotechnik und Elektroindustrie (ZVEI) e.V.)
in its most recent version as well as the supplementary clause: "Expanded reservation of proprietorship"

Distance sensor VDM54
Ausgabedatum 09/30/2009 Part No. 210258
3
1 Introduction ...............................................................................4
1.1 Warranty ........................................................................................... 4
2 Declaration of Conformity ........................................................ 5
3 Safety ......................................................................................... 6
3.1 Symbols used ................................................................................... 6
3.2 General safety instructions ............................................................... 7
4 Product description .................................................................. 8
4.1 Models .............................................................................................. 9
4.2 Scope of supply .............................................................................. 10
4.3 Accessories .................................................................................... 10
5 Installation ...............................................................................11
5.1 Storage and transportation ............................................................. 11
5.2 Unpacking ...................................................................................... 11
5.3 Installation ...................................................................................... 11
6 Commissioning ....................................................................... 12
6.1 Device connections ........................................................................ 12
6.2 Alignment ....................................................................................... 12
7 Software ................................................................................... 13
7.1 Software installation ....................................................................... 13
7.2 Programming with VDMConfig ....................................................... 13
8 Maintenance and repair .......................................................... 17
9 Appendix ..................................................................................18
9.1 Notes ............................................................................................. 18

Distance sensor VDM54
Introduction
Issue date 09/30/2009 Part No. 210258
4
1 Introduction
Congratulations
You have chosen a device from Pepperl+Fuchs. Pepperl+Fuchs develops, manufac-
tures, and markets electronic sensors and interface components for the factory automa-
tion market on a global scale.
Contact
If you have any questions about the device, accessories, or function, please contact:
Pepperl+Fuchs GmbH
Lilienthalstraße 200
D-68307 Mannheim
Telephone: [phone]
Fax: [phone]
e-mail: [email protected]
1.1 Warranty
Pepperl+Fuchs manufactures its products according to recognized industrial standards.
Pepperl+Fuchs guarantees its products to be free of defects in material and workman-
ship provided the products are used under the normal operating conditions specified by
the manufacturer. The warranty applies only to the original owner and is not transferable.
All accompanying exclusions of liability, restrictions, and other conditions of this section
apply to this warranty.
Exclusion of liability
The warranty shall not apply to products that:
• have been repaired, modified, or tampered with unless explicitly performed or ap-
proved by Pepperl+Fuchs,
• have not been maintained in accordance with the operating and handling instructions
provided by Pepperl+Fuchs,
• have been exposed to unusual physical or electrical loads, immersed in liquids, or
have been exposed to any one of the following:
• breakdown
•crushing
• improper use
• abuse
• low current
• unsuitable power supply
• reverse polarity
• negligence or accident
• have been used for any purpose other than what is described in the operating and han-
dling instructions.
Preventive maintenance is the responsibility of the customer and is not covered by this
warranty.

Distance sensor VDM54
Declaration of Conformity
Issue date 09/30/2009 Part No. 210258
5
General
With the exception of the warranties noted above, Pepperl+Fuchs offers no warranties
for products supplied in any form whatsoever, whether explicit or implicit, including, but
not limited to implicit warranties for defects and guarantees of suitability for a special pur-
pose and non-infringement of third-party rights. The explicit warranties noted above shall
satisfy all obligations and liabilities of Pepperl+Fuchs for damages, including, but not lim-
ited to concrete damages, indirect damages, or consequential damages in connection
with the use or design of the product. The seller's liability to the buyer and other persons
(regardless of the origin of liability, whether it be based on contract, warranty, impermis-
sible handling, misuse, and/or other origin) in connection with the use of a product shall
under no circumstances exceed the original purchase price of the product. Pep-
perl+Fuchs shall in no event be liable for consequential damages, concrete and indirect
damages, secondary damages or penalties, lost profits or sales, or loss of data, even if
Pepperl+Fuchs had been informed of this possibility in writing.
2 Declaration of Conformity
Pepperl+Fuchs GmbH hereby declares under sole responsibility that the
Distance sensor VDM54
and all models of this product to which this declaration refers, complies with the following
standards and other regulatory documents
EN 60947-5-2
Product standard: Electromagnetic Compatibility (EMC for control technology, industry)
Pepperl+Fuchs GmbH in D-68301 Mannheim has a certified quality assurance program
in accordance with ISO 9001.
A corresponding declaration of conformity can be requested from the
manufacturer.
ISO9001

Distance sensor VDM54
Safety
Issue date 09/30/2009 Part No. 210258
6
3Safety
3.1 Symbols used
Safety related symbols
Information symbols
Danger!
This symbol identifies an immediate and present danger.
Failure to heed this warning may result in serious or even fatal injury.
Warning!
This symbol warns the user of a possible malfunction or danger.
Failure to heed this warning may result in personal injury or extensive
property damage.
Caution!
This symbol warns the user of a possible malfunction.
If the instruction given in this warning is not heeded, the device and any
plant or systems connected to it may develop a fault or fail completely.
Note!
This symbol draws your attention to important information.
Instruction
This symbol indicates a required action.

Distance sensor VDM54
Safety
Issue date 09/30/2009 Part No. 210258
7
3.2 General safety instructions
The following basic instructions must be observed at all times:
• The device must not be placed into service until the manual has been read and under-
stood
• The power supply for generating the supply voltage must be insulated by a
double insulation and a safety transformer according to DIN VDE 0551 (complies with
IEC 742).
• The device must not be used outside the specifications without taking suitable protec-
tive measures
• No unauthorized tampering with the device is permitted
• Do not point the device directly towards the sun or take measurements in direct sun-
light
• Do not remove the warning/machine labels
The radiation emitted from a class 1 laser is harmless. This type of laser instrument can
be operated by anyone.
The company operating the device is responsible for planning, assembly, commission-
ing, operation, and maintenance.
Installation and commissioning of all devices must only be performed by personnel spe-
cially trained for that purpose.
The protection of the operating personnel and the overall system is not ensured if the as-
sembly is not used according to its intended purpose.
Observe the laws and/or directives applicable to the use or planned application. The de-
vicesareonlyapprovedforproperuseinaccordancewiththeirintendedpurpose.Failure
to comply with these provisions will invalidate all warranties and absolve the manufactur-
er of all liability.
Use only recommended original accessories.
If malfunctions cannot be eliminated, take the device out of service and secure it from
accidental use. Secure the device against inadvertent operation. For repairs to the de-
vice, send the device to Pepperl+Fuchs. Only Pepperl+Fuchs can make repairs to the
device. Interventions in and modifications to the device are not permissible, render the
warranty null and void, and exclude the manufacturer from any liability.
Dispose of the device according to all applicable laws and regulations.
For example, you can take the sensor to the designated collection center for electronic
scrap.
In applications with shelf stacking equipment and moving carriages,
care must always be taken to observe the applicable safety regulations.
Failure to observe this warning can result in fatal injury!

Distance sensor VDM54
Product description
Issue date 09/30/2009 Part No. 210258
8
4 Product description
VDM54
The VDM54 is the reliable solution for measuring the distance between vehicles on rail
mounted tracks. Braking distances and distances between vehicles differ according to
the type of goods being carried, the length of the vehicle, and the speed of the vehicle.
This requires adjustable switching distances. Constantly changing objects around vehi-
cles and the presence of other sensors do not impair the VDM54's ability to accurately
measure distances. In order to maintain the reliability of the distance measuring function
and ensure accurate switching points, regardless of the surroundings and conditions of
the vehicles themselves, a reflector is fitted to the rear of every vehicle in the installation.
The VDM54 is fitted to the front of each vehicle and always points at the reflector on the
vehicledirectlyahead.Whenthevehiclereaches the currently selectedbrakingdistance,
the switching output is activated and the vehicle slows down. When the vehicle reaches
theselectedstoppingdistance, it comes to a complete standstill. Once the vehicle in front
begins to move, the signals are enabled and the vehicle travels forward. When using ve-
hicles of variable length, e.g. due to overhanging loads, the distances maintained in the
installation can be varied. This VDM54 function enables optimum use of congested ar-
eas.
Measurement principle
The VDM54 works on the principle of optical time of flight measurement. Distance mea-
surement uses the physical principle that light always spreads at a constant speed of
c=299,792 kilometers per second. In other words, light travels a distance of 1 m in 3.335
ns (0.000,000,003,35 s). With pulsed time of flight measurement, a very short light im-
pulse is emitted, reflected, and registered by the receiver; the measured time is stopped
at that very same moment. The emitted impulse triggers a clock which is stopped by the
received impulse. The time elapsed (time of flight) is always proportional to the optical
path length.
Use of this physical principle makes VDM54 ideal for optical anti-collision distance mea-
surement.
t
reflection echo receivedimpulse send out
time-of-flight

Distance sensor VDM54
Product description
Issue date 09/30/2009 Part No. 210258
9
4.1 Models
4.1.1 VDM54-6000-R/20/105
• Detection range: 0 – 6 m
• Aperture angle: horizontal ± 7.5 degrees; vertical ± 3.5 degrees
• 2 PNP NC outputs Q1, Q2
• 1 range selection input
The four signal points (close / far for both Q1 and Q2) are programmed via a ConfigBox.
The ConfigBox has a serial RS-232 interface and connects to the VDM54 with a pro-
gramming cable.
Distancevaluesforswitchpointscanbe programmed usingparametersoftware currently
available free of charge.
Advantages: It is very simple to install in existing installations. Sensor settings are easy
to reproduce and can be recorded. Sensors can be easily preset outside the installation
(short commissioning time).
4.1.2 VDM54-6000-R/20/88/105 and VDM54-6000-R-3999
• Detection range: 0 – 6 m
• Aperture angle: horizontal ± 7.5 degrees; vertical ± 3.5 degrees
• Serial interface RS-485
The VDM54-6000-R/20/88/105 only communicates with the vehicle control system via
the RS-485 interface. The control system software must have implemented the protocol
for the VDM54-6000-R/20/88/105.
Advantages: Parameter settings are carried out via the control system. Should it be nec-
essary to replace one VDM54 with another, no sensor adjustments are necessary.
4.1.3 LED indicators and control buttons
Figure 4.1: Dimensional drawing VDM54-6000-R/20/105
Power On LED (green)
Q1 LED (red)
Q2 LED (red)
LED proximity / distance (green)
132
145
115
ø 6.5 (4x)
72
55
4
1880
42

Distance sensor VDM54
Product description
Issue date 09/30/2009 Part No. 210258
10
Figure 4.2: Dimensional drawing VDM54-6000-R/20/88/105 and VDM54-6000-R-3999
4.2 Scope of supply
The following is included with delivery:
•VDM54
4.3 Accessories
The following products are available as accessories:
No. Part number Diagram Description
1 REFLEKTOR H100-2R Reflector, square
100 mm x 100 mm
2 VDM54-CONFIGBOX Programming accessory for
VDM54
132
145
115
ø 6.5 (4x)
72
55
4
1880
85

Distance sensor VDM54
Installation
Issue date 09/30/2009 Part No. 210258
11
5Installation
5.1 Storage and transportation
When packing the device for storage or transportation, use materials that will protect the
device from jarring, impacts and humidity. The original packaging provides the best pro-
tection. Take into account the permitted ambient conditions as well.
5.2 Unpacking
Check that the contents are not damaged. In case of damage, inform the postal service
or delivery agent and notify the supplier.
Check the scope of delivery against your order and the delivery documents.
Keep the original packaging in case the device must be stored or shipped at a later date.
If you have any questions, please contact Pepperl+Fuchs.
5.3 Installation
5.3.1 Installation/Mounting example
The illustration shows how the frame protects the VDM54 and reflector from damage
when the vehicles are pushed together for servicing.
If the device has been subjected to extreme temperature fluctuations
during transportation, it must be allowed to acclimatize for approxi-
mately one hour before being installed and put into operation. Always
prevent condensation from forming in or on the unit as this could result
in internal components being damaged.
Do not point the sensor directly at the sun. Always protect the sensor
against direct and lengthy exposure to sunlight. Prevent the formation
of condensation by not exposing the sensor to large fluctuations in tem-
perature. Keep the sensor away from aggressive chemicals. Make sure
that the glass and the reflector on the device are kept clean. Always use
soft cloths and, if necessary, a commercial glass cleaner.

Distance sensor VDM54
Commissioning
Issue date 09/30/2009 Part No. 210258
12
6 Commissioning
After the device is turned on, the VDM54 is ready for operation after completing an ini-
tialization phase of approx. 10 seconds.
To achieve maximum accuracy, allow the device to warm up for 10 minutes.
The sensor has been tested and calibrated before leaving the factory. It can be placed in
operation immediately.
6.1 Device connections
Electrical connection and pin out of the VDM54-6000-R/20/105
Electrical connection and pin out of the VDM54-6000-R/20/88/105 and VDM54-6000-R-
3999
6.2 Alignment
Aim the VDM54 directly at the reflector(s).
Q1
Q2
IN
2/WH
1/BN
3/BU
4/BK
0 V
+UB
5/GY
1
24
3
5
RS 485 A (-)
RS 485 B (+)
n. c.
2/WH
1/BN
3/BU
4/BK
0 V
+UB
5/GY
1
24
3
5

Distance sensor VDM54
Software
Issue date 09/30/2009 Part No. 210258
13
7 Software
7.1 Software installation
Switch points can be programmed from a PC. VDMConfig parameter software must be
successfully installed on the appropriate device and a Pepperl+Fuchs ConfigBox is re-
quired. The ConfigBox is connected to the PC via RS-232 interface.
When the setup.exe file is started, the following window appears:
Follow the instructions on the screen until installation of VDMConfig is complete. Once
VDMConfig has been successfully installed, the program can be started e.g. via the Win-
dows Start button.
7.2 Programming with VDMConfig
In order to program settings on the VDM54 ensure that:
1. the VDM54 is connected to the power supply,
2. the VDM54 is connected to a free COM interface on the PC via the VDMConfig Box.
3. VDMConfig is installed on the PC.
When is started, the VDMConfig start window appears:
Click here to
start the
installation

Distance sensor VDM54
Software
Issue date 09/30/2009 Part No. 210258
14
In the start window, please select VDM54 to open the main window.
The main window essentially consists of the menu bar, button bar, and display field.
Menu bar
•File:
Files can be opened and saved. Quit closes the program.
Menu Bar
Button Panel
Display Panel

Distance sensor VDM54
Software
Issue date 09/30/2009 Part No. 210258
15
•Sensor:
Theconnectedsensortypeisselectedhere.Automatic or manual search are available
as options. For a manual search, the following parameters must be entered for the
VDM54:
•Sensor data:
Read current setting from sensor; send setting from VDMConfig to VDM54. Sensor on-
line mode can be started. In online mode, the sensor periodically transfers measured
data, which then appears in the display. If the option "continuously" is not activated,
only one measured value is sent.
•Help:
This displays the VDMConfig version along with error messages in the event of trans-
mission errors.
•Language:
Choice of language; options: German / English
The use of VDMConfig is based on standard Microsoft Windows functions and is there-
fore mainly intuitive. Alterations in appearance are possible at any time in the course of
an update or as the result of other Windows adjustments.
Button bar
Open
Data File
Save Settings
Search for
connected
sensors Read the
current sensor
settings
Send
VDMConfig
settings to the
sensor
Start
of the online mode
Exit VDMConfig

Distance sensor VDM54
Software
Issue date 09/30/2009 Part No. 210258
16
Procedure for programming VDMConfig with data input
(to access graphic parameter input directly, press OK to exit)
1. Select sensor type and enter parameters directly.
2. Transfer parameters to sensor
Procedure for programming VDMConfig with settings from another sensor
1. Connect sensor with required setting using serial connection
2. Run an automatic sensor search
3. Read out setting from sensor
4. Disconnect sensor that has been read and connect sensor to be programmed in its
place.
5. Transfer parameters to sensor
(Steps 4 and 5 can be repeated as many times as required without reconnecting sensor
to be read)

Distance sensor VDM54
Maintenance and repair
Issue date 09/30/2009 Part No. 210258
17
8 Maintenance and repair
Maintenance
Observe the applicable regulations for servicing.
The sensor requires little or no maintenance.
Check the sensor system at regular intervals, in particular, check for damage to the hous-
ing.
To ensure that the sensor functions correctly, occasionally check the sensor for soiling.
Regularly clean the sensor by wiping across it with a soft dry or moist cloth.
The housing is made of plastic. For this reason, avoid contact with acetone and deter-
gents containing solvents.
Repair
If malfunctions cannot be eliminated, take the device out of service and secure it from
accidental use. For repairs to the device, send the device to Pepperl+Fuchs. Only Pep-
perl+Fuchs can make repairs to the device. Interventions in and modifications to the de-
vicearenotpermissible,render the warranty null and void,andexcludethemanufacturer
from any liability.

Distance sensor VDM54
Appendix
Issue date 09/30/2009 Part No. 210258
18
9Appendix
9.1 Notes

Date of issue 09/30/2009 Part No. 210258
With regard to the supply of products, the current issue of the following document is applicable:
The General Terms of Delivery for Products and Services of the Electrical Industry, published by the Central
Association of the Electrical Industry (Zentralverband Elektrotechnik und Elektroindustrie (ZVEI) e.V.)
in its most recent version as well as the supplementary clause: "Expanded reservation of proprietorship"

Subject to modifications
Copyright PEPPERL+FUCHS • Printed in Germany
www.pepperl-fuchs.com
Worldwide Headquarters
Pepperl+Fuchs GmbH
68307 Mannheim · Germany
Tel. [phone]
E-mail: [email protected]
USA Headquarters
Pepperl+Fuchs Inc.
Twinsburg, Ohio 44087 · USA
Tel. [phone]
E-mail: [email protected]
Asia Pacific Headquarters
Pepperl+Fuchs Pte Ltd.
Company Registration No. 199003130E
Singapore 139942
Tel. [phone]
E-mail: [email protected]
FACTORY AUTOMATION –
SENSING YOUR NEEDS
DOCT-1525A 210258
10/2009
