Pepperl+Fuchs UC F77 Series User manual

UC***-F77 Series
Configuring Ultrasonic Sensors
with IO-Link Interface
FACTORY AUTO ATION
ANUAL

With regard to the supply of products, the current issue of the following document is ap-
plicable: The General Terms of Delivery for Products and Services of the lectrical Indus-
try, published by the Central Association of the lectrical Industry (Zentralverband
lektrotechnik und lektroindustrie (ZV I) e.V.) in its most recent version as well as the
supplementary clause: " xpanded reservation of proprietorship"
UC***-F77 series

UC***-F77 series
3
1 Introduction................................................................................. 7
1.1 Content of this Document ................................................................... 7
1.2 Target Group, Personnel...................................................................... 7
1.3 Symbols Used ...................................................................................... 7
1.4 Intended Use ........................................................................................ 8
1.5 General Safety Notes ........................................................................... 8
1.6 Declaration of Conformity ................................................................... 9
2 Product Description ................................................................. 10
2.1 Use and Application........................................................................... 10
2.2 Displays and Local Controls ............................................................. 12
2.3 Accessories ........................................................................................ 13
2.3.1 Accessories for Mounting and Connection....................................... 13
2.3.2 Configuration Aids ........................................................................... 14
3 Installation................................................................................. 15
3.1 Safety Information.............................................................................. 15
3.2 Preparation ......................................................................................... 15
3.3 ounting ............................................................................................. 15
3.4 Connection ......................................................................................... 16
4 Commissioning without IO-Link.............................................. 17
5 Sensor Programming via the Programming Button.............. 18
5.1 Programming Switch Points/Limits.................................................. 18
5.2 Programming Sensor Operating odes
(Sensor with Switching Output) ....................................................... 19
5.3 Programming the Sensor Operating odes
(Sensor with Analog Output) ............................................................ 20
6 Commissioning with IO-Link Using PACTware and DT ...... 22

4
UC***-F77 series
7 Configuration and Analysis with DT via IO-Link................. 25
7.1 Overview..............................................................................................25
7.2 Sensor Information enu Option......................................................26
7.3 Output Configuration enu Item ......................................................26
7.4 Sensor Configuration enu Option..................................................27
7.5 Analysis & Echo Suppression enu Option....................................29
7.6 Observation enu Option..................................................................37
7.7 Service enu Option..........................................................................42
7.8 Information enu Option...................................................................43
8 Description of Sensor Parameters.......................................... 44
8.1 Sensor Information.............................................................................44
8.2 Output – Switching Output ................................................................44
8.2.1 Output Mode .................................................................................... 44
8.2.2 Output Logic.....................................................................................47
8.2.3 Output Type......................................................................................47
8.2.4 Switch Point 1...................................................................................47
8.2.5 Switch Point 2...................................................................................48
8.2.6 Retroreflective Mode Offset..............................................................48
8.2.7 Switching Hysteresis ........................................................................49
8.2.8 Switch-On Delay .............................................................................. 49
8.2.9 Switch-Off Delay ..............................................................................50
8.3 Output Configuration – Analog Output ............................................50
8.3.1 Output Mode .................................................................................... 50
8.3.2 Output Type......................................................................................50
8.3.3 Near Limit.........................................................................................51
8.3.4 Far Limit ...........................................................................................51
8.3.5 Lower Output Value ..........................................................................51
8.3.6 Upper Output Value..........................................................................52

UC***-F77 series
5
8.4 Sensor Configuration – Evaluation .................................................. 52
8.4.1 Sound Beam Width.......................................................................... 52
8.4.2 cho valuation ............................................................................... 53
8.4.3 valuation Method ........................................................................... 54
8.4.4 Averages & Skip Count .................................................................... 55
8.4.5 Weighting of Former Measurement.................................................. 55
8.4.6 Allowed Deviation to the Former Measurement................................ 56
8.4.7 Skip Time......................................................................................... 56
8.4.8 Temperature Compensation............................................................. 57
8.4.9 Operating Temperature .................................................................... 58
8.4.10 Foreground Suppression ................................................................. 58
8.4.11 Background Suppression................................................................. 58
8.4.12 Sensor Cycle Time........................................................................... 59
8.4.13 Ultrasonic Pulse Length ................................................................... 59
8.5 Sensor Configuration – Synchronization......................................... 60
8.6 Sensor Configuration – Echo Loss and Error Handling................. 61
8.6.1 No cho........................................................................................... 61
8.6.2 Output Behavior if an rror Occurs .................................................. 61
8.6.3 rror Replacement Value – Current/Voltage..................................... 62
8.7 Sensor Configuration – Local Controls ........................................... 62
8.7.1 Local Controls.................................................................................. 62
8.7.2 Local Controls Status ....................................................................... 63
8.8 Service ................................................................................................ 63
8.8.1 Locator Indication ............................................................................ 63
8.8.2 "Reset to Factory Defaults" Button ................................................... 63
9 Synchronizing ultiple Sensors ............................................. 64
10 aintenance and Repair .......................................................... 66
10.1 aintenance Work ............................................................................. 66
10.2 Cleaning .............................................................................................. 66
10.3 Resetting to the Factory Default ....................................................... 66
11 Troubleshooting........................................................................ 67
11.1 What to Do in Case of an Error ......................................................... 67

6
UC***-F77 series
12 Appendix ................................................................................... 68
12.1 IO-Link Device Parameters ................................................................68

UC***-F77 series
Introduction
2017-06
7
1 Introduction
1.1 Content of this Document
This document contains information required to use the product in the relevant phases of the
product life cycle. This may include information on the following:
■ Product identification
■ Delivery, transport, and storage
■ Mounting and installation
■ Commissioning and operation
■ Maintenance and repair
■ Troubleshooting
■ Dismounting
■ Disposal
The documentation comprises the following parts:
■ This document
■ Datasheet
In addition, the documentation may comprise the following parts, if applicable:
■ U-type examination certificate
■ U declaration of conformity
■ Attestation of conformity
■ Certificates
■ Control drawings
■ Instruction manual
■ Other documents
1.2 Target Group, Personnel
Responsibility for planning, assembly, commissioning, operation, maintenance, and
dismounting lies with the plant operator.
Only appropriately trained and qualified personnel may carry out mounting, installation,
commissioning, operation, maintenance, and dismounting of the product. The personnel must
have read and understood the instruction manual and the further documentation.
Prior to using the product make yourself familiar with it. Read the document carefully.
1.3 Symbols Used
This document contains symbols for the identification of warning messages and of informative
messages.
Warning essages
You will find warning messages, whenever dangers may arise from your actions. It is mandatory
that you observe these warning messages for your personal safety and in order to avoid
property damage.
Note!
Visit www.pepperl-fuchs.com to access further documentation for full information about the
product.

2017-06
8
UC***-F77 series
Introduction
Depending on the risk level, the warning messages are displayed in descending order as
follows:
Informative Symbols
Action
This symbol indicates a paragraph with instructions. You are prompted to perform an action or
a sequence of actions.
1.4 Intended Use
The UC***-F77 series ultrasonic sensors use ultrasonic pulses to detect objects. The sensor
emits ultrasound which is reflected by the object and received again by the sensor. The
measured sound propagation time is used to determine the distance to the object (pulse-echo
principle). Objects in the following forms can be detected: solid, granular, powder, or liquid. The
color and surface structure of the objects are irrelevant. Gases cannot be detected.
Always operate the device as described in these instructions to ensure that the device and
connected systems function correctly. The protection of operating personnel and plant is
guaranteed only if the device is operated in accordance with its intended use.
Responsibility for compliance with locally-valid safety regulations is borne by the operator.
Only use recommended original accessories.
1.5 General Safety Notes
Responsibility for planning, assembly, commissioning, operation, maintenance, and
dismounting lies with the plant operator.
Installation and commissioning of all devices may only be performed by trained and qualified
personnel.
The device is only approved for appropriate and intended use. Ignoring these instructions will
void any warranty and absolve the manufacturer from any liability.
Danger!
This symbol indicates an imminent danger.
Non-observance will result in personal injury or death.
Warning!
This symbol indicates a possible fault or danger.
Non-observance may cause personal injury or serious property damage.
Caution!
This symbol indicates a possible fault.
Non-observance could interrupt the device and any connected systems and plants, or result in
their complete failure.
Note!
This symbol brings important information to your attention.
Note!
UC***-F77 series ultrasonic sensors are not safety components within the meaning of the C
Machinery Directive 2006/42/ C. They must not be used for the purposes of avoiding risk to
individuals or parts of the body.

UC***-F77 series
Introduction
2017-06
9
If serious faults occur, stop using the device. Secure the device against inadvertent operation.
In the event of repairs, return the device to your local Pepperl+Fuchs representative or sales
office.
1.6 Declaration of conformity
This product was developed and manufactured under observance of the applicable uropean
standards and guidelines.
The product manufacturer, Pepperl+Fuchs GmbH, D-68307 Mannheim, has a certified quality
assurance system that conforms to ISO 9001.
Note!
Disposal
lectronic waste is hazardous waste. When disposing of the equipment, observe the current
statutory requirements in the respective country of use, as well as local regulations.
Note!
A Declaration of Conformity can be requested from the manufacturer.
ISO9001

2017-06
10
UC***-F77 series
Product Description
2 Product Description
2.1 Use and Application
The UC***-F77 series ultrasonic sensors use ultrasonic pulses to detect objects. The sensor
emits ultrasound which is reflected by the object and received again by the sensor. The
measured sound propagation time is used to determine the distance to the object (pulse-echo
principle). Objects in the following forms can be detected: solid, granular, powder, or liquid. The
color and surface structure of the objects are irrelevant. Gases cannot be detected.
Figure 2.1 xample of application: film monitoring on a packaging machine
Typically, ultrasonic sensors are used in a wide range of applications including:
■ Sag control on packaging and metal processing machines
■ To measure diameter of roll material (e.g., film, paper, metal sheet)
■ To detect fill levels in tanks and silos
■ To avoid collisions with self-propelled or controlled machines
■ Height control of booms for sprayers
■ To detect containers on refuse collection vehicles
■ To detect objects or to measure fill levels on conveyor belts
■ To detect pallets on forklift trucks
■ To monitor range on barrier systems
■ To detect PCBs when feeding them to SMD placement machines

UC***-F77 series
Product Description
2017-06
11
The F77 compact housing design can be programmed and so adapted to various applications.
You can program limits, output mode, output type, and sound beam width via the programming
button on the sensor or the convenient IO-Link interface. Programming via the IO-Link also
provides the option of setting many other parameters such as filter options, echo suppression,
synchronization settings,...
The IO-Link versions with switching output enable IO-Link communication in accordance with
the IO-Link standard. The F77 versions with analog output can be configured via their IO-Link
interface but are not designed for long-term IO-Link operation.
The advantages of the UC***-F77 series ultrasonic sensors are:
■ Compact housing design
■ Advanced setting options via programming button on the device
■ IO-Link 1.1 interface for service and process data, and for parameterization
■ xcellent immunity to background noise such as compressed air
■ Can be self-synchronized to avoid mutual interference of several adjacently mounted
ultrasonic sensors
■ Programmable echo suppression
■ Also available as sidelooker version with M18 mounting option and higher detection range
What is IO-Link?
IO-Link is a new dimension in the communication of and with sensors. The possibility of making
the intelligence that is already integrated in each and every sensor fully available to users
opens up new possibilities for automation. Using IO-Link brings specific advantages to all
areas of application in the field of factory automation; in service (fault elimination, maintenance,
and device replacement), during commissioning (cloning, identification, configuration, and
localization) or in operation (job changes, continuous parameter monitoring, and online
diagnostics). Reducing the variety of interfaces offers users significant savings potential. This
variety of interfaces often results from having analog sensor inputs and the complex installation
required in this case.
Device description file (IODD)
The sensor parameters are different for each device. These parameters are described in a
standardized format in the device description IODD (IO Device Description). The IODD can be
imported into various engineering tools from different system providers, providing they support
IODD. The sensor can be configured or diagnosed using the appropriate tool.
You can also transform the IODD via the "IODD DTM Configurator" to configure via a tabular
user interface. We recommend "PACTware" software as the user interface in which you can
load the transformed IODD. It is also possible to use equivalent software.
You can find the device description file (IODD) which is necessary for connecting to an IO-Link
system online at www.pepperl-fuchs.com on the product page for the relevant UC***-F77-... .
DT (Device Type anager)
If a sensor is not used long-term in an IO-Link environment, but nevertheless needs to be
configured, this can be done easily via a PC with installed FDT framework application (e.g.,
PACTware) and with the DTM (Device Type Manager, a kind of "device driver") available for the
sensor. Unlike configuration via the IODD, this method provides extended functions and
ensures improved graphic visualization and convenient operation. Functions such as UC***-
F77 series "echo suppression" can only be configured via the relevant DTM.

2017-06
12
UC***-F77 series
Product Description
2.2 Displays and Local Controls
Figure 2.2
1. Sonically-active area
2. Yellow L D
3. Green/red L D (Duo L D)
4. Programming button
LED display for sensors with switching output
Green L D Yellow L D Red L D
In normal operation
rror-free operation On Switching state Off
Fault (e.g., compressed air) Off Retains previous state (factory
default setting, can be
changed via IO-Link)
On
Standby (high level for > 1 s at
synchronization input)
Flashing Retains previous state Off
When programming the switch points
Object detected Off Flashing slowly Off
No object detected Off Flashing quickly Off
Unreliable object detection Off Off Flashing
Confirmation of successful
programming
Flashes 3x Off Off
Warning in the event of invalid
programming
Off Off Flashes 3x
When programming operating modes
Programming output mode Flashing Off Off
Programming output logic Off Flashing Off
Programming sound beam width Off Off Flashing
Table 2.1
1
2 3 4

UC***-F77 series
Product Description
2017-06
13
LED display for sensors with analog output
2.3 Accessories
Various accessories are available.
2.3.1 Accessories for Mounting and Connection
Several components are available for mounting and connecting UC***-F77 series sensors. You
will find details online at www.pepperl-fuchs.com on the product page for the relevant sensor
or on the relevant datasheet.
The following types of accessories are available for order:
■ OMH ML7* mounting aids
■ Connection cable and cordset
Green L D Yellow L D Red L D
In normal operation
rror-free operation On Output state Off
Fault (e.g., compressed air) Off Retains previous state (factory
default setting, can be
changed via IO-Link)
On
Standby (high level for > 1 s at
synchronization input)
Flashing Retains previous state Off
When programming the limits
Object detected Off Flashing slowly Off
No object detected Off Flashing quickly Off
Unreliable object detection Off Off Flashing
Confirmation of successful
programming
Flashes 3x Off Off
Warning in the event of invalid
programming
Off Off Flashes 3x
When programming operating modes
Programming output mode Flashing Off Off
Programming the output type Off Flashing Off
Programming sound beam width Off Off Flashing
Table 2.2
Note!
For mounting, connection, and commissioning, the following product information is available
online at www.pepperl-fuchs.com on the product page for the relevant sensor: datasheet,
commissioning manual, manual. The relevant DTM also contains comprehensive context-
related help descriptions.

2017-06
14
UC***-F77 series
Product Description
2.3.2 Configuration Aids
The following configuration aids are available:
Designation Description
PACTware FDT frame application for operating IODDs and DTMs
Pepperl + Fuchs PACTware
Connection Wizard
Wizard for simple project and connection set-up of the ultrasonic
sensor in PACTware.
Visit www.pepperl-fuchs.com and the product page for the
relevant UC***-F77 series sensor.
IODD for UC***-F77* IODD (IO Device Description) – device description for operating
the sensor, integration in the system environment
Visit www.pepperl-fuchs.com and the product page for the
relevant UC***-F77 series sensor.
DTM for UC***-F77* DTM (Device Type Manager) – device description and graphic
user interface for operating the sensor, integration into the system
environment
Visit www.pepperl-fuchs.com and the product page for the
relevant UC***-F77 series sensor.
IODD Interpreter DTM Software for integrating IODDs in an FDT frame application (e.g.,
PACTware)
IO-Link-Master02 USB "USB-IO-Link-Master02" adapter box for direct control of an IO-
Link sensor via a PC, M12 connection for sensor
V31-GM-1M-PVC-V1-G Connection cable, M8 to M12 , for connecting a UC***-F77 series
sensor to the IO-Link-Master02 USB
IO-Link-Master-USB DTM Device Type Manager – software for operating the IO-Link-
Master02 USB via FDT
Table 2.3

UC***-F77 series
Installation
2017-06
15
3 Installation
3.1 Safety Information
3.2 Preparation
Unpacking the unit
1. Check that all package contents are present and undamaged.
If anything is damaged, inform the shipper and contact the supplier.
2. Check that all items are present and correct based on your order and the shipping
documents.
If you have any questions, please contact Pepperl+Fuchs.
3. Keep the original packing material in case you need to store or ship the unit at a later time.
3.3 Mounting
Mounting UC***-F77 sensors
Use M3 cylinder head screws to secure the sensor and tighten to a maximum torque of 0.2 Nm.
Figure 3.1
Caution!
Risk of short circuit
Carrying out work while the system is energized may result in damage to the device.
■ Always disconnect the supply voltage before carrying out work on the device.
■ Only connect the device to the supply voltage once all work has been completed.
Note!
Mounting instructions for UC400-F77... sensors
To ensure a reliable function of UC400-F77... sensors at operating temperatures below 0 °C,
you need to mount the enclosed plastic mounting base between the sensor housing and
mounting rack.

2017-06
16
UC***-F77 series
Installation
Mounting UC***-F77S sensors
F77S sensors can be secured using either M3 cylinder head screws or an M18 nut.
Tighten the M3 cylinder head screws with a maximum torque of 0.2 Nm. Tighten the M18 nut
with a maximum torque of 1 Nm.
Figure 3.2
3.4 Connection
Applying supply voltage for a sensor with connector plug
To supply voltage to the sensor, proceed as follows:
1. Insert the prepared connection cable into the connector plug provided for this purpose on the
underside of the housing.
2. Screw the cap nut onto the connector plug as far as it will go. This ensures that the power
cable cannot be inadvertently pulled out.
3. Now connect the supply voltage to the cable provided for this purpose and switch it on.
The sensor is now ready for operation.
Applying supply voltage for a sensor with connection cable
To supply voltage to the sensor, proceed as follows:
1. Connect the sensor connection cable to your control environment.
2. Switch on the supply voltage for the sensor.
The sensor is now ready for operation.
Control via IO-Link
To prepare the sensor for control via IO-Link, proceed as follows:
Connect the sensor to an IO-Link master. For a sensor with connector plug, screw the cap nut
onto the connector plug as far as it will go. Use a 4-wire or 5-wire sensor cable for the
connection.
The sensor is now prepared for IO-Link communication.
Note!
If the synchronization option is not used, the synchronization input must be connected to
ground (0 V).

UC***-F77 series
Commissioning without IO-Link
2017-06
17
4 Commissioning without IO-Link
Switch on the supply voltage. The operating indicator on the sensor lights up green.
The sensor will now function using the preset parameters.
Note!
It is only possible to change configuration by programming with the programming button or by
configuring via IO-Link!

2017-06
18
UC***-F77 series
Sensor Programming via the Programming Button
5 Sensor Programming via the Programming Button
Basic information about programming
In terms of factory settings, the sensor can only be programmed during the first 5 minutes after
switching on. This time is extended during the actual programming process. The option of
programming the sensor is revoked if no programming activities take place for 5 minutes. After
this, programming is no longer possible until the sensor is switched off and on again.
When configuring sensors via the IO-Link, you can use the DTM to adjust the programming
button’s locking logic. This is done in the "Sensor configuration" menu option, "Local controls"
tab.
When actively communicating via the IO-Link interface of the sensor, it is not possible to use
the programming button to program.
The programming activities can be canceled at any time without changing the sensor settings.
To do so, press and hold the programming button for 10 seconds.
Programming via the programming button can take place in the stand-alone mode of a sensor
or also in the synchronized sensor group of several sensors (only for automatic common mode
and multiplex mode). When programming in the synchronized sensor group, there may be a
delay to starting the programming routine, depending on when the sensor in question is next in
line. For the duration of the programming process, the other sensors in the sensor group go into
standby mode (green L D is flashing). Then synchronization mode continues to operate as
normal.
5.1 Programming Switch Points/Limits
Programming Switch Point 1/Near Limit (SP1)
If the object is detected correctly during the programming process, the yellow L D flashes
slowly. If no object is detected, the yellow L D flashes at a higher frequency. A flashing red L D
during or when completing the programming process indicates unreliable object detection. In
this case, correct the alignment of the object during the programming process until the yellow
L D flashes. Only then will the settings be transferred to the sensor memory.
1. Position the object at the site of the required switch point/the required near limit.
2. Press and hold the T programming button for 2 seconds (yellow L D flashes)
3. Briefly press the T programming button (green L D flashes 3 times as confirmation). The
sensor returns to normal operation.
Programming Switch Point 2/Far Limit (SP2)
1. Position the object at the site of the required switch point/required far limit.
2. Press and hold the T programming button for 2 seconds (yellow L D flashes)
3. Press and hold the T programming button for 2 seconds (green L D flashes 3 times as
confirmation). The sensor returns to normal operation.
Note!
Depending on the type of sensor, you can program the switch points for sensors with switching
output and the limits for sensors with analog output. The programming procedures are the
same in both cases and are therefore described in conjunction below.

UC***-F77 series
Sensor Programming via the Programming Button
2017-06
19
5.2 Programming Sensor Operating Modes (Sensor with Switching Output)
The sensor features a 3-stage process for programming the sensor operating modes. In this
programming routine you can program as follows:
■ A) Output mode
■ B) Output logic
■ C) Sound beam width
These stages of the process are programmed in succession. To switch from one programming
step to the next, press and hold the programming button for 2 seconds.
The following graphic illustrates the programming routine:
Figure 5.1
Activating the programming routine
To activate the programming routine, press the programming button for 5 seconds until the
green L D begins to flash.
Programming output mode
The green L D is now flashing. The number of flashing pulses shows the currently
programmed output mode:
1x: switch point mode
2x: window mode
3x: hysteresis mode
4x: retroreflective mode
1. Briefly press the programming button to navigate through the output modes in succession.
Select the required output mode.
2. Press the programming button for 2 seconds to switch to the next programming step, to
adjust the output logic.
Programming output logic
The yellow L D is now flashing. The number of flashing pulses shows the currently
programmed output logic:
1x: normally-open
2x: normally-closed
1. Briefly press the programming button to navigate through the output logic in succession. Use
this method to choose the output logic.
2. Press the programming button for 2 seconds to switch to the next programming step, the
programming of the sound beam width.
Programming sound beam width
The red L D is now flashing. The number of flashing pulses shows the currently programmed
sound beam width:
1x: small
2x: medium
3x: wide
T
5s
1x
2x
3x
4x
T
T
2s
1x
2x
T
T
2s
1x
2x
3x
T
2s
T
Output mode
LED green
Output logic
LED yellow
Beam width
LED red
Normal
operation
short short short

2017-06
20
UC***-F77 series
Sensor Programming via the Programming Button
1. Briefly press the programming button to navigate through the sound beam widths in succes-
sion. Use this method to choose the required sound beam width.
2. Press and hold the push button for 2 seconds to save all performed settings and to return to
normal operation.
5.3 Programming the Sensor Operating Modes (Sensor with Analog Output)
The sensor features a 3-stage process for programming the sensor operating modes. In this
programming routine you can program as follows:
■ A) Output mode
■ B) Output type
■ C) Sound beam width
These stages of the process are programmed in succession. To switch from one programming
step to the next, press and hold the programming button for 2 seconds.
The following graphic illustrates the programming routine:
Figure 5.2
Activating the programming routine
To activate the programming routine, press the programming button for 5 seconds until the
green L D begins to flash.
Programming output mode
The green L D is now flashing. The number of flashing pulses shows the currently
programmed output mode:
1x: rising ramp
2x: falling ramp
3x: IO-Link mode (select this mode if you want to communicate with the sensor via IO-Link)
1. Briefly press the programming button to navigate through the output modes in succession.
This allows you to select the required output mode.
2. Press the programming button for 2 seconds to change to the next programming step, the
selection of the output type.
Programming output logic
The yellow L D is now flashing. The number of flashing pulses displays the currently
programmed output type:
1x: current output
2x: voltage output
T
5s
1x
2x
3x
T
T
2s
T
2s
1x
2x
T
T
2s
1x
2x
3x
T
2s
T
Output mode
LED green
Output type
LED yellow
Beam width
LED red
Normal
operation
short short short
“Communication
ready”
Current
Voltage
I/O-Link
Note!
To exit the IO-Link parameter mode in normal operation (analog signal at the output), briefly
disconnect the sensor from the power supply.
