Introduction
2019-02
5
1 Introduction
Congratulations
You have chosen a device manufactured by Pepperl+Fuchs. Pepperl+Fuchs develops,
produces and distributes electronic sensors and interface modules for the market of
automation technology on a worldwide scale.
Sy bols used
The following symbols are used in this manual:
Handling instructions
You will find handling instructions beside this symbol
Contact
If you have any questions about the device, its functions, or accessories, please contact us at:
Pepperl+Fuchs GmbH
Lilienthalstraße 200
68307 Mannheim, Germany
Telephone: [phone]
Fax: [phone]
mail: [e-mail]
Note!
This symbol draws your attention to important information.

2019-02
6
PMI360DV-F130-IU2 0-V15
Declaration of Conformity
2 Declaration of Conformity
This product was developed and manufactured under observance of the applicable uropean
standards and guidelines.
The product manufacturer, Pepperl+Fuchs GmbH, D-68307 Mannheim, has a certified quality
assurance system that conforms to ISO 9001.
Note!
A Declaration of Conformity can be requested from the manufacturer.
ISO9001

PMI360DV-F130-IU2 0-V15
Safety
2019-02
7
3 Safety
3.1 Symbols Used
Safety-Relevant Sy bols
Infor ative Sy bols
Action
This symbol indicates a paragraph with instructions. You are prompted to perform an action or
a sequence of actions.
3.2 Intended Use
The inductive angle positioning system PMI360DV-F130... was designed for position detection
on valve actuators or valves. In addition to these main applications, the inductive angle
positioning system PMI360DV-F130... is also suitable for the precision, non-contact detection
of all movement sequences in applications where machine or system components rotate or
swivel around an axis with a maximum diameter of 41.5 mm.
3.3 General Safety Instructions
Responsibility for planning, assembly, commissioning, operation, maintenance, and
dismounting lies with the plant operator.
Installation and commissioning of all devices may only be performed by trained and qualified
personnel.
User modification and or repair are dangerous and will void the warranty and exclude the
manufacturer from any liability. If serious faults occur, stop using the device. Secure the device
against inadvertent operation. In the event of repairs, return the device to your local
Pepperl+Fuchs representative or sales office.
Danger!
This symbol indicates an imminent danger.
Non-observance will result in personal injury or death.
Warning!
This symbol indicates a possible fault or danger.
Non-observance may cause personal injury or serious property damage.
Caution!
This symbol indicates a possible fault.
Non-observance could interrupt the device and any connected systems and plants, or result in
their complete failure.
Note!
This symbol brings important information to your attention.
Note!
Disposal
lectronic waste is hazardous waste. When disposing of the equipment, observe the current
statutory requirements in the respective country of use, as well as local regulations.

2019-02
8
PMI360DV-F130-IU2 0-V15
Product Description
4 Product Description
4.1 Use and Application
The inductive angular positioning system PMI360DV-F130-IU2 0-V15 is a measuring system
designed for the noncontact detection of the angular position of valve actuators and valves. In
addition, the flexible, user-friendly parameterization functions offered by the system make it
suitable for the universal detection and feedback of rotation around a fixed rotation point in all
areas of machine and plant construction.
The PMI360DV-F130-IU2 0-V15 has an analog output for the analog indication of angular
positions. For high resistance loads (>3.3 kΩ), the angular position is output as a voltage value
0 ... 10 VDC and for low resistance loads (<400 Ω), as a current value 4 ... 20 mA. In addition,
the PMI360DV-F130-IU2 0-V15 has two switching outputs that can be programmed
independently of one another and that are used to mark two important positions (e.g., start and
stop position).
The actuator BT-F130-A (see chapter 4.3) is usually attached to the rotary system component
to detect the position. This actuator rotates in the central hole on the PMI360DV-F130-IU2 0-
V15 and contains the metal insert required for detecting the position. The component is
optimally adapted to the mechanical requirements of valves and valve actuators.

PMI360DV-F130-IU2 0-V15
Product Description
2019-02
9
4.2 Displays and Controls
4 L Ds and 3 programming buttons are located on top of the PMI360DV-F130-IU2 0-V15.
The central, front "Power/ rror" L D is a 2-color L D that lights up or flashes green (normal
operation) or red (fault) depending on the operating state of the device. The L Ds "S1", "S2"
and "I/U" are yellow and indicate the status of the device during programming and normal
operation.
The programming buttons are used to configure the angular positioning system. The central I/U
button is used to configure the start and end points of the analog output and the outer "S1" and
"S2" buttons are used to configure the start and end of the detection zone of the two switching
outputs on the sensor.
The "S1", "S2" and "I/U" L Ds correspond to the "S1", "S2" and "I/U" programming buttons.
4.3 Accessories
Various accessories are available.
4.3.1 Connection Cables
You can use the following single-ended female cordsets to establish the electrical connection:
Note!
In principle, the actuator BT-F130-A is not required. A damping element made from
construction steel such as S235JR+AR (previously St37-2) must then be mounted on the rotary
system component. This damping element must fulfill all requirements relating to the material,
dimensions, and distances to the inductive angular positioning system PMI360DV-F130... See
chapter 5.2
A LED indicators
B Progra ing buttons
B
A

2019-02
10
PMI360DV-F130-IU2 0-V15
Product Description
M12 x 1 single-ended fe ale cordsets, 5-pin
Other lengths on request. If the cordset is to be used in environments with significant potential
for electromagnetic interference, please use shielded single-ended female cordsets from our
extensive range of accessories.
4.3.2 Actuator
The BT-F130-A actuator is designed for mounting directly on the drive shaft or a servodrive.
Illustration Material Length Model number
M12 x 1, straight, 5-pin PVC 2 m
5 m
10 m
V15-G-2M-PVC
V15-G-5M-PVC
V15-G-10M-PVC
PUR 2 m
5 m
10 m
V15-G-2M-PUR
V15-G-5M-PUR
V15-G-10M-PUR
M12 x 1, angled, 5-pin PVC 2 m
5 m
10 m
V15-W-2M-PVC
V15-W-5M-PVC
V15-W-10M-PVC
PUR 2 m
5 m
10 m
V15-W-2M-PUR
V15-W-5M-PUR
V15-W-10M-PUR
