Pepperl+Fuchs F2D0-TI-Ex8.FF Series User manual

Temperature Multi-Input
Device
F2D0-TI-Ex8.FF.*, 
RD0-TI-Ex8.FF.*
6.2.0 (DEV_REV 02)
PROCESS AUTOMATION
MANUAL

With regard to the supply of products, the current issue of the following document is ap-
plicable: The General Terms of Delivery for Products and Services of the Electrical Indus-
try, published by the Central Association of the Electrical Industry (Zentralverband
Elektrotechnik und Elektroindustrie (ZVEI) e.V.) in its most recent version as well as the
supplementary clause: "Expanded reservation of proprietorship"
Temperature Multi-Input Device

Temperature Multi-Input Device
3
1 Introduction................................................................................. 5
1.1 Content of this Document ................................................................... 5
1.2 Target Group, Personnel...................................................................... 5
1.3 Symbols Used ...................................................................................... 5
2 Product Specifications............................................................... 7
2.1 Overview and Application ................................................................... 7
2.2 Hazardous Area Installation and Use................................................. 7
2.3 Component Identity ............................................................................. 9
3 Installation and Commissioning ............................................. 11
3.1 Mounting and Dismounting............................................................... 11
3.1.1 Using the Separation Wall................................................................ 13
3.2 Hardware Installation......................................................................... 14
3.2.1 TM-I Cable and Connection Information .......................................... 14
3.2.2 F2 Housing Degree of Protection..................................................... 15
3.2.3 Grounding and Shielding ................................................................ 18
3.2.4 Electrical Connection....................................................................... 19
3.2.5 Fieldbus and Shield Connection ...................................................... 20
3.2.6 Dip Switch Settings.......................................................................... 20
3.3 Firmware Download ........................................................................... 20
4 TM-I Configuration.................................................................... 21
4.1 Introduction ........................................................................................ 21
4.2 Function Block Interaction and Channel Mapping ......................... 21
4.3 Identification, Device ID, PD Tag....................................................... 23
4.4 Parameterization Prerequisites and Procedure .............................. 23
4.5 Sensor Block Configuration.............................................................. 24
4.6 Concentrator Block Configuration ................................................... 26
4.7 AI and MAI Block Configuration ....................................................... 27
5 Operation................................................................................... 28

4
Temperature Multi-Input Device
5.1 Primary Value Status ..........................................................................28
5.2 Body Temperature Status ..................................................................28
5.3 Device-Integrated Diagnostics..........................................................28
5.4 Alarms .................................................................................................28
6 Troubleshooting........................................................................ 29
6.1 LED Indications ..................................................................................29
6.2 Resource Block...................................................................................30
6.3 Sensor Block.......................................................................................31
6.4 Concentrator Block ............................................................................32
6.5 AI Function Block ...............................................................................33
6.6 MAI Function Block Errors ................................................................33
6.7 Diagnostic Summary..........................................................................34
6.8 Recommended Action for Field Diagnostics 
according to NE 107...........................................................................35
7 Function Block Descriptions ................................................... 36
7.1 Resource Block (RB)..........................................................................36
7.2 Analog Input Function Block (AI)......................................................39
7.3 Multiple Analog Input Function Block (MAI)....................................41
7.4 TI_SENS Sensor Blocks (TIS) ...........................................................42
7.5 Concentrator Block (TIC)...................................................................46

Temperature Multi-Input Device
Introduction
2017-05
5
1Introduction
1.1 Content of this Document
This document contains information that you need in order to use your product throughout the
applicable stages of the product life cycle. These can include the following:
■Product identification
■Delivery, transport, and storage
■Mounting and installation
■Commissioning and operation
■Maintenance and repair
■Troubleshooting
■Dismounting
■Disposal
The documentation consists of the following parts:
■Present document
■Instruction manual
■Datasheet
Additionally, the following parts may belong to the documentation, if applicable:
■EU-type examination certificate
■EU declaration of conformity
■Attestation of conformity
■Certificates
■Control drawings
■Additional documents
1.2 Target Group, Personnel
Responsibility for planning, assembly, commissioning, operation, maintenance, and
dismounting lies with the plant operator.
Only appropriately trained and qualified personnel may carry out mounting, installation,
commissioning, operation, maintenance, and dismounting of the product. The personnel must
have read and understood the instruction manual and the further documentation.
Prior to using the product make yourself familiar with it. Read the document carefully.
1.3 Symbols Used
This document contains symbols for the identification of warning messages and of informative
messages.
Note!
This document does not substitute the instruction manual.
Note!
For full information on the product, refer to the instruction manual and further documentation on
the Internet at www.pepperl-fuchs.com.

2017-05
6
Temperature Multi-Input Device
Introduction
Warning Messages
You will find warning messages, whenever dangers may arise from your actions. It is mandatory
that you observe these warning messages for your personal safety and in order to avoid
property damage.
Depending on the risk level, the warning messages are displayed in descending order as
follows:
Informative Symbols
Action
This symbol indicates a paragraph with instructions. You are prompted to perform an action or
a sequence of actions.
Danger!
This symbol indicates an imminent danger.
Non-observance will result in personal injury or death.
Warning!
This symbol indicates a possible fault or danger.
Non-observance may cause personal injury or serious property damage.
Caution!
This symbol indicates a possible fault.
Non-observance could interrupt the device and any connected systems and plants, or result in
their complete failure.
Note!
This symbol brings important information to your attention.

Temperature Multi-Input Device
Product Specifications
2017-05
7
2 Product Specifications
2.1 Overview and Application
The 8-channel temperature multi-input device measures temperature with resistance
thermometers (RTD) or thermocouples (TC) via FOUNDATION Fieldbus. Each channel can be
configured independently.
The device is designed for use in intrinsically safe fieldbus systems according to FISCO or
Entity.
Use the device only within the specified ambient temperature range.
The device is only approved for appropriate and intended use. Ignoring these instructions will
void any warranty and absolve the manufacturer from any liability.
This manual describes the following temperature multi-input devices:
■F2D0-TI-Ex8.*.*:* in a fieldbus housing for panel mounting
■RD0-TI-Ex8.*.* for mounting on a 35 mm DIN rail in accordance with EN 50022
2.2 Hazardous Area Installation and Use
The device may be operated in Zone 1.
For applications in Zone 1, the type of protection must be Ex i.
The device may be installed in Zone 2.
For Zone 2 applications, the type of protection must be Ex nA or Ex i.
Independent of the type of protection of the fieldbus, the sensor inputs remain intrinsically safe.
Zone 2
Type of Protection "Ex i"
Danger!
Explosion hazard from live wiring of non-intrinsically safe circuits
If you connect or disconnect energized non-intrinsically safe circuits in a potentially explosive
atmosphere, sparks can ignite the surrounding atmosphere.
Only connect or disconnect energized non-intrinsically safe circuits in the absence of a
potentially explosive atmosphere.
Danger!
Explosion hazard from wrong separation distances
Non-observance of the separation distances between circuits can result in added currents or
voltages. This can result in a current/voltage flashover generating sparks. The sparks can ignite
the surrounding potentially explosive atmosphere.
Ensure you observe the compliance of the separation distances according to
IEC/EN 60079–14.

2017-05
8
Temperature Multi-Input Device
Product Specifications
Figure 2.1 Installation options for the temperature multi-input device in the hazardous area
Observe the EC-type-examination certificate or the statement of conformity. Pay particular
attention to any "special conditions" that may be indicated.
Danger!
Explosion hazard from wrong calculation of verification of intrinsic safety
If you do not consider the maximum permissible peak values of all components when
connecting intrinsically safe devices with intrinsically safe circuits of associated apparatus, this
can lead to added currents or voltages. This, in return, can result in a current/voltage flashover
generating sparks. The sparks can ignite the surrounding potentially explosive atmosphere.
Ensure you observe IEC/EN 60079-14 and IEC/EN 60079-25 for the verification of intrinsic
safety.
Danger!
Explosion hazard from inadequate or missing separation appliance
If you fail to apply the required separation appliance, e. g. a separation wall, between an
intrinsically safe and a non–intrinsically safe circuit, this can result in a current/voltage flashover
generating sparks. The sparks can ignite the surrounding potentially explosive atmosphere.
Ensure you apply the required separation appliance in order to meet the requirements
according to IEC/EN 60079–11.
Hazardous Area Installation Options
Zone 2
Zone 0
Zone 1
Non-Explosion
Hazardous
Area
Ex i/
Ex nA
Ex i
PI
*D0-TI-Ex8.*
PI
*D0-TI-Ex8.*
FB

Temperature Multi-Input Device
Product Specifications
2017-05
9
2.3 Component Identity
The following section shows the dimensions, the inside connections, and the options of the
device.
1. Notch for fixing the temperature multi-input device housing with M6 screw.
2. Grounding point for connecting the temperature multi-Input device to earth with M4 screw.
3. Cable gland for the fieldbus IN cable. For outside dimensions, see datasheet.
4. 8 cables glands for inputs, wrench size AF 20. For outside dimensions, see datasheet.
X: Height depending on cable gland, see datasheet.
All dimensions in millimeters (mm).
F2D0-TI-Ex8.* Housing and Dimensions
1
2
3
4
CH1 ... CH8 Bus
(57)
114
240
84
258
228
(57)
114
240
84
258
228
9.5
x
CH1
CH2 CH4 CH6
CH3 CH5 CH7 Bus
CH8
+HL - +- S

2017-05
10
Temperature Multi-Input Device
Product Specifications
1. Service interface (covered)
2. Status LEDs for channel fault indication
3. Status LED for communication
4. Status LED for power
5. Dip switches for configuration:
6. Separation wall: Used if the temperature multi-input device is supplied by a non-intrinsical-
ly safe fieldbus.
7. DIN mounting rail
8. Mounting on DIN rail
All dimensions in millimeters (mm).
RD0-TI-Ex8.* Components and Dimensions
1 2 3 4 5 6
7
8
CH1 ... CH8 Bus
100
217
60
CH1
CH2 CH4 CH6
CH3 CH5 CH7
Bus
+HL - +- S
CH8

Temperature Multi-Input Device
Installation and Commissioning
2017-05
11
3 Installation and Commissioning
In the following section you find information on how to install and commission the multi-
input/output (MIO) device in your fieldbus topology.
3.1 Mounting and Dismounting
Mounting/Dismounting F2D0-TI-Ex8.*
F2D0-TI-Ex8.* is designed for panel (wall) mounting.
■Select mounting material that is suitable for the sub-surface (the wall).
■Ensure that the mounting material guarantees secure fastening.
■To attach the device: use 2 fixing screws with a diameter of 6 mm.
■To dismount the device: Undo the fixing screws and take the device off the wall.
Mounting/Dismounting RD0-TI-Ex8.*
RD0-TI-Ex8.* is designed for mounting on a 35 mm DIN rail in accordance with EN 50022.
Danger!
Danger to life from using damaged or repaired devices.
Using a defective or repaired device can compromise its function and its electrical safety.
■Do not use a damaged or polluted device.
■The device must not be repaired, changed or manipulated.
■If there is a defect, always replace the device with an original device from Pepperl+Fuchs.
Danger!
Explosion hazard from damaged electronic components
Premature wear of electronic components in a device that was previously used in a general
electrical installation can cause sparks that can ignite the surrounding potentially explosive
atmosphere.
Never install devices that have already been operated in general electrical installations in
electrical installations used in combination with hazardous areas!

2017-05
12
Temperature Multi-Input Device
Installation and Commissioning
Ensure that the device is firmly fixed on the DIN rail.
To dismount the device: Take off the device in reverse order.
RD0-TI-Ex8.* Installations
Depending on the application, the RD0-TI-Ex8.* must be mounted in a suitable environment.
If mounted in Zone 2 for an Ex nA application, the environment must ensure the following
degree of protection:
■IP54 in accordance with IEC 60529 for hazardous area Zone 2

Temperature Multi-Input Device
Installation and Commissioning
2017-05
13
3.1.1 Using the Separation Wall
The device is delivered with a removable separation wall. The separation wall separates the
fieldbus terminals from the terminals of the sensor inputs. This way it ensures the clearance
requirements of IEC/EN 60079-11 between intrinsically safe and non-intrinsically safe signals.
Danger!
Explosion hazard from inadequate or missing separation appliance
If you fail to apply the required separation appliance, e. g. a separation wall, between an
intrinsically safe and a non–intrinsically safe circuit, this can result in a current/voltage flashover
generating sparks. The sparks can ignite the surrounding potentially explosive atmosphere.
Ensure you apply the required separation appliance in order to meet the requirements
according to IEC/EN 60079–11.

2017-05
14
Temperature Multi-Input Device
Installation and Commissioning
3.2 Hardware Installation
3.2.1 TM-I Cable and Connection Information
Connection Details
You can connect sensors to one of the following 2 pre–engineered terminal options :
■Spring terminals
■Screw terminals
Adhere to the following information when connecting cables to terminals:
■Insulation stripping length of wires: 10 mm
■Core cross-section: 0.2 mm²... 2.5 mm²or AWG 24 ... 14
■If you use stranded conductors: Protect the conductor ends by crimping wire end ferrules
on them.
■Screw terminals tightening torque: 0.5 ... 0.6 Nm
■Insulation voltage between the fieldbus line and the shield for intrinsically safe segments:
500 V
■Do not strain the cables and connection lines. Provide an adequate strain relief.
■Connect unused cables and connection lines to terminals or securely tie them down and
isolate them.
Parameterization interface: Service interface. see image on page 10. 
Only trained specialists authorized by Pepperl+Fuchs may carry out parameterization tasks via
the Service interface.
Danger!
Explosion hazard from insufficient insulation
Insufficient dielectric strength of insulators between intrinsically safe circuits may lead to
interferences and to charge transfers that cause sparks. These sparks can ignite a potentially
explosive atmosphere.
Ensure that the dielectric strength of the insulation between intrinsically safe circuits is at least
500 V according to IEC/EN 60079–14.
Danger!
Explosion hazard or danger to life from inadequate installation of cables and connection lines
If you do not install cables and connection lines according to the instructions given in the
instruction manual, this can generate sparks that can ignite the surrounding potentially
explosive atmosphere. Furthermore, insufficient installation practice can result in electric
shock.
Ensure you carry out any cable gland installations in accordance with the instructions given in
the instruction manual.

Temperature Multi-Input Device
Installation and Commissioning
2017-05
15
3.2.2 F2 Housing Degree of Protection
The following section contains information concerning the installation and sealing of the cable
glands and the housing cover.
Installing Cable Glands
When installing cable glands, observe the following:
■Only insert permanently laid cables and wires into the cable glands.
• Ensure that the cables laid do not execute any strain on the cable glands.
• For permissible cable diameters, refer to the respective datasheet.
■Use an appropriate strain relief clamp, e.g., a suitable cable clamp.
■Seal unused cable glands with a suitable plug or replace them with appropriate screw
plugs. Observe the required degree of protection IP66.
• For a choice of stop plugs and screw plugs, refer to the respective datasheets.
• Note that the ambient temperature range can be restricted by the stopping plug.
■Protect plastic cable glands against mechanical hazard.
The following table with tightening torques offers an approximate guideline:
F2D0-TI-Ex8.* Tightening Torques for Cap Nuts and Counterparts
Danger!
Explosion hazard or danger to life from inadequate installation of cable glands
If you do not install cable glands according to the instructions given in the instruction manual,
this can generate sparks that can ignite the surrounding potentially explosive atmosphere.
Furthermore, insufficient installation practice can result in electric shock.
Ensure you carry out any cable gland installations in accordance with the instructions given in
the instruction manual.
Note!
Careful when tightening cap nuts!
■The cap nuts must be securely tightened. Tightening the cap nuts too much or not enough
both can affect the degree of protection.
■The tightening torques of cap nuts vary, depending on the cable type used. For exact
details refer to the documentation of your cable manufacturer.
Ty p e Size Cap nut Counterpart
F2D0-TI-
Ex8.*.*:*.CG
M16 2.5 Nm 3.75 Nm
M20 2.5 Nm 3.75 Nm
F2D0-TI-
Ex8.*.*:*.CGB
M16 6 Nm 6 Nm
M20 10 Nm 10 Nm
F2D0-TI-
Ex8.*.*:*.CGS
M16 6 Nm 6 Nm
M20 10 Nm 10 Nm

2017-05
16
Temperature Multi-Input Device
Installation and Commissioning
Connectorizing Cables Using F*D0-TI-Ex8.*.CG Cable Glands
1. Strip the insulation of the cable up to about 120 mm.
2. Loosen the cap nut and the seals from the temperature multi-input device. Depending on
the application, slip Seal 1 & Seal 2 or only the obligatory Seal 2 over the cable as shown:
1. Seal 1, used in the following instance: Type: M20 x 1.5, Terminal area: 5 ... 8 mm
2. Seal 2, obligatory
3. Move the required seal(s) over the cable until after the last seal about 5 mm insulation
protrude before the stripped wire begins:
4. Insert the cable with the seals into the cable gland of the temperature multi-input device and
tighten the cap nut.
The tightening torques of cap nuts vary depending on the cable type used. Ensure that you
use the cap nuts according to the table "F2D0-TI-Ex8.* Tightening Torques for Cap Nuts and
Counterparts" above. 
21

Temperature Multi-Input Device
Installation and Commissioning
2017-05
17
Connectorizing Cables Using F*D0-TI-Ex8.*.CGB and F*D0-TI-Ex8.*.CGS
Cable Glands
1. Strip the insulation of the cable up to about 120 mm.
2. Loosen the cap nut from the temperature multi-input device.
3. Remove the inner plastic piece and slip it onto the cable: move it far enough over the cable,
so it completely surrounds the cable insulation. 
Ensure that no cable insulation protrudes behind the inner plastic piece.
1. Inner plastic piece
2. O-ring
3. Invert the cable shield over the inside plastic piece and shorten it to a length of 3 ... 4 mm
behind the O-ring.
12

2017-05
18
Temperature Multi-Input Device
Installation and Commissioning
1. O-ring
2. Inverted cable shield
3. Insert the cable wires with the inner plastic piece into the counterpart of the cable gland.
4. Tighten the cap nut and the counterpart. 
The tightening torques of cap nuts vary depending on the cable type used. Ensure that you
use the cap nuts according to the table "F2D0-TI-Ex8.* Tightening Torques for Cap Nuts and
Counterparts" above.
Fixing the Housing Cover
Before closing the housing cover: Visually inspect the housing for any visible signs of damage
on the cover seal. If damaged, replace the seal with an original seal wear part.
Tightening torque for the screws of the housing cover: 2.5 Nm
3.2.3 Grounding and Shielding
12
3-4 mm
Note!
Electromagnetic Compatibility and Grounding
If the shield of the fieldbus data transfer line is grounded for electromagnetic compatibility
reasons, the following guideline must always be observed:
■FOUNDATION Fieldbus Application Guide "31.35 bit/s Intrinsically Safe Systems"
Note!
Ensure Equipotential Bonding of F2* Metal Housings
Ensure that the metal housing is connected properly to the equipotential bonding.

Temperature Multi-Input Device
Installation and Commissioning
2017-05
19
Equipotential Bonding of Devices in F2* Metal Housings
For electronic components in F2* metal housings in Zone 1 hazardous areas, suitable
equipotential bonding in accordance with IEC/EN 60079 is required. Therefore, the device is
designed as follows:
■The shield (terminal S) of the intrinsically safe segment is internally connected to the
F2* metal housing.
■The housing has a grounding point with a grounding screw. The grounding connection
must be secured against loosening and corrosion, e. g., by using tinned cable plates.
Shielding the R* Electronic Component in Intrinsically Safe Segments
The shield (terminal S) of the intrinsically safe segment is internally connected to the DIN
mounting rail.
3.2.4 Electrical Connection
Sensor Types Connecting to Temperature Multi-Input Devices
Figure 3.1 RTD, 2-wire technology
Figure 3.2 RTD, 3-wire technology
Figure 3.3 RTD, 4-wire technology
Figure 3.4 Millivolt
Note!
Ensure Shielding of the R* Electronic Component
Ensure that the DIN mounting rail is connected to the cabinet and the cabinet itself is
connected to the equipotential bonding.
+-
+-
L
+-
L
H
HL
mV

2017-05
20
Temperature Multi-Input Device
Installation and Commissioning
Figure 3.5 Thermocouple
3.2.5 Fieldbus and Shield Connection
The TM-I device provides a connection for the fieldbus cable.
The device itself can operate in both polarities.
Not all FOUNDATION Fieldbus devices support polarity independent operation, therefore we
recommend you always wire all field devices consistently.
3.2.6 Dip Switch Settings
The device has 8 DIP switches, with DIP switch 1 and 2 in use. The DIP switches can be
activated during operation.
■Switch 1, Simulation ON/OFF
■Switch 2, Hardware write protection ON/OFF
Dip switch 1 "Simulation ON": 
The control system sets the sensor input that is transferred from the transducer block to the
function block, independent of the hardware input of an input channel. 
For safety reasons, it is recommended to set the switch to OFF for normal operation.
Dip switch 2 "Hardware write protection ON": 
Parameterization of the device via the bus is disabled.
3.3 Firmware Download
The temperature input supports firmware download according to FF-883 device download,
class 2. In order to enable the firmware download, set the resource block out of service (OoS).
During the firmware download, the temperature input does not operate its IO function and goes
through a reset, while activating the new firmware version.
Refer to your system software documentation for information on how to perform the firmware
download. If available, new firmware files can be downloaded from www.pepperl-fuchs.com.
HL
