Perlesmith PSLTK2 User manual

V3.0
Instruction Manual

02
01 03
x4 x4
60 kg
132 lbs
x4
B
x8
C1
A1 A2
x8
C2
x4
D1
x4
D2
x4
E2
x4
E3
x4
E1
M6x15mm M6x30mm M8x15mm M8x45mm M8x65mm

IMPORTANT SAFETY INFORMATION
WEIGHT CAPACITY
TOOLS NEEDED
HARDWARE INCLUDED
TV SCREWS / WASHERS
•Check package contents against Supplied Parts and Hardware Lists to assure that all components were received
undamaged. Do not use damaged or defective parts.lf you require replacement parts, contact customer service at
[email protected]
•Not all parts and hardware included will be used.
•Carefully read all instructions before attempting installation.If you do not understand the instructions or have any concerns
or questions, please contact customer service at [email protected]
•This product may contain moving parts. Use with caution.
•Do not use this product for any purpose or in any configuration not explicitly specified in this instruction. We hereby
disclaim any liability for injury or damage arising from incorrect assembly, incorrect mounting, or incorrect use of this
product.
•DO NOT INSTALL INTO DRYWALL ALONE.
•Please check www.perlesmith.com for more products and company information.
M7x55
1
4mm
Wood Drill
10mm
Concrete Drill
Wall Anchor
These anchors are for
concrete or brick walls
ONLY. DO NOT use them
in drywall or wood studs.

2
100 mm ≈4 in
200 mm ≈7 7/8 in
300 mm ≈11 3/4 in
400 mm ≈15 3/4 in
600 mm ≈23 5/8 in
Max 600mm（23 5/8 in）
400mm (15 3/4 in)Max
Hand thread screws into the threaded inserts on the back of
your TV to determine which screw diameter (M6, M8) to use.
Step 1
Check the VESA Pattern of Your TV
Step 2
Check TV Screws
The small and medium assembly option is for smaller TVs where the full
assembly may stick out on either side. The mount is shipped in the medium
assembly option.

3
Larger TVs may
not tilt the full
without including
the spacers.
B
D1
C1/C2
B
D2
C1/C2
E3
C1/C2
E2
E1
Medium 16”Studs
VESA:100x100-400x400mm
Large
angle
Step 3
Attach the TV Brackets to the TV
Step 4
Assemble Wall Plate(optional)
M6x15mm
M6x30mm M8x15mm
M8x45mm M8x65mm
24”Studs
VESA:100x100-600x400mm
02
02

4
Mark Holes
Use Wall Anchors
Drill Holes
Secure Mount
10mm Drill bit
Mark HolesDrill Holes
4mm Drill Bit
Step 5
Attach Wall Plate to Wall
WARNING:
● Avoid potential personal injury or property damage! DO NOT
over-tighten the lag bolts [A1]. Tighten the lag bolts [A1] only
until they are pulled firmly against the wall plate [01 or 01/03].
● Ensure the wall plate is securely fastened to the wall before
continuing on to the next step.
● Anything covering the wall must not exceed 5/8 in. (16 mm)
● Nominal wood stud size: common 2 x 4 in. (51 x 102 mm)
minimum 1½ x 3½ in. (38 x 89 mm)
● Stud center must be verified
ø4mm
55mm
Wall
Anchor
A2
● Avoid potential personal injury or property damage! DO NOT over-tighten
the lag bolts [A1]. Tighten the lag bolts [A1] only until they are pulled firmly
against the wall plate [01 or 01/03]
.
● Ensure the wall plate is securely fastened to the wall before continuing
on to the next step.
● Mount the wall plate
[01 or 01/03] directly onto the concrete surface
● Anything covering the wall must not exceed 5/8 in. (16 mm)
● Minimum solid concrete thickness: 203 mm (8 in.)
● Minimum concrete block size: 203 x 203 x 406 mm (8 x 8 x 16 in.)
60mm
ø10mm
X
Install the wall plate [01 or 01/03]
using lag bolts [A1].
A2
A1
01
01
A1

02
02
Top of TV
Bottom of TV
S
S
5
Step 6
Adjust the Tilt Tension Screws [S] to Adjust Tilt Angles of TV
8mm Wrench
Loosen the four tilt tension screws [S] on both brackets, adjust the hook of the
bracket to the desired angle, then tighten tilt tension screws with a wrench (not
included) and a screwdriver (not included) to fix the tilting angle of the TV.
Loosen
Tighten
S
Step 7 Hang TV to the Wall Plate [01 or 01/03]
HEAVY! You may need assistance with this step.

6
Locking
Step 8
Secure TV
Pull down and hold both cords [R], press the bottom of the TV into the wall plate
assembly [01 or 01/03] until the latches lock the TV in place.
Press
R
Unlocking
Disconnect all cables, pull down and hold both cords [R] while gently pulling the bottom of
the TV away from the wall.
CAUTION: Avoid potential personal injury or property damage! To prevent breaking the
locking latch: always pull and hold the cords [R] down while pulling the TV away from the
wall.
Then lift the TV up and off of wall plate assembly [01 or 01/03]. Place the TV on cardbard or
other protective surface to avoid damage.
NOTE: To rehang the TV, follow the procedures in Step 7 and 8.
Removing the TV
HEAVY! You may need
assistance with this step.
R
